Blaupunkt 7 607 548 500 User manual

www.blaupunkt.com
Zubehör / Accessories
Bluetooth-/USB-Interface 7 607 545 500
mit / with PTT
mit / with OLED-Display (optional) 7 607 548 500
PTT
optional
BTUSBIFPTT_545_500_DE_1208.indd 1BTUSBIFPTT_545_500_DE_1208.indd 1 19.12.2008 9:28:52 Uhr19.12.2008 9:28:52 Uhr

2
1
2
C3
C2
C1 C2 C3
BLAUPUNKT
Microphone
Mikrofon
PTT (Push To Talk) - Key
PTT-Taste
USB Socket (Memory stick not included)
USB-Anschluss (ohne USB-Datenträger)
Connection / Anschluss
BTUSBIFPTT_545_500_DE_1208.indd 2BTUSBIFPTT_545_500_DE_1208.indd 2 19.12.2008 9:28:59 Uhr19.12.2008 9:28:59 Uhr

3
1
2
Microphone
Mikrofon
PTT (Push To Talk) - Key
PTT-Taste
USB Socket (Memory stick not included)
USB-Anschluss (ohne USB-Datenträger)
C3
C2
C1 C2 C3
BLAUPUNKT
OLED (not included)
Connection / Anschluss
BTUSBIFPTT_545_500_DE_1208.indd 3BTUSBIFPTT_545_500_DE_1208.indd 3 19.12.2008 9:29:00 Uhr19.12.2008 9:29:00 Uhr

4
Bluetooth 1.2 (compatible with 1.x)
Supported Bluetooth profiles
Unterstützte Bluetooth-Profile HFP, SPP, GAP, SDAP. AADP (A2DP), AVRCP
Certifications
Standards e1, CE, FCC, Bluetooth
USB Version 2.0 (full speed), (compatible with 1.x)
Mass Storage Device Class
MP3-USB-Bitrate max. 320 kb/s, max. 48 kHz sample rate
MP3 Meta Data ID3 v1, v2 (ISO8859-1 and ASCII), max.32char Title,
Album, Artist
WAV Playback uncompressed WAV, 8, 11.25, 12, 16, 22.5, 24, 32,
44.1, 48 kHz
WAV Meta Data Filename, Directoryname
Playlist M3U format supported, Latin-1 char set,
see e.g. http://en.wikipedia.org/wiki/M3U
Data Structure max. 64000 files and directories, up to 16 directory levels
Temperature range
Temperaturbereich
- 40° C ... 85° C
USB voltage / current strength
USB-Spannung / -Stromstärke 5V / 0,5 A (1,0 A short term / kurzzeitig)
Power Supply
Spannungsversorgung +12 ... 28 V
Dimensions (inch)
Abmessungen (mm)
1.1 x 3.2 x 4.8 (without cables)
28 x 81 x 121 (ohne Kabel)
Weight
Gewicht 300 g
For all Blaupunkt Aftermarket radios as from 2002 supporting CDC.
Für alle Blaupunkt-Autoradios ab 2002, die CD Changer Control unterstützen.
Technical Data / Technische Daten
BTUSBIFPTT_545_500_DE_1208.indd 4BTUSBIFPTT_545_500_DE_1208.indd 4 19.12.2008 9:29:00 Uhr19.12.2008 9:29:00 Uhr

24
Connection ............................................................... 2
Technical Data........................................................... 4
Safety notes ............................................................ 25
Declaration of conformity ........................................25
Switch-on................................................................ 25
Switch-off ............................................................... 25
Displays and controls............................................... 26
Registering (pairing) your cell phone
with the interface ....................................................26
Connecting two BT devices with
the interface at the same time .................................. 27
Overview of functions.............................................. 28
Telephone: incoming call.......................................... 30
Telephone: outgoing call ..........................................30
Phone list control (PTT) ........................................... 30
Audio streaming via BT ............................................ 31
MP3 or WAV playback via USB.................................. 31
Browsing (OLED) ..................................................... 32
Settings menu (OLED only)....................................... 32
Which settings are active?........................................32
Settings .................................................................. 34
Software update...................................................... 40
Reading out technical data ....................................... 40
Changing the configuration (PTT)............................. 41
FCC-Statements ...................................................... 43
