Operating and Installation Instructions
ALL-VIEW-MONITORING CAMERA
AVMC 1.0

Safety Notes
This vehicle security system has been manufactured
according to established safety guidelines. However,
dangers may still occur if the safety notes in this manual
is not observed. This manual is intended to familiarize
the user with the reverse camera important functions.
Read this carefully, prior to using the product. Keep this
manual in an easily accessible location. In addition, do
observe the instructions of the devices used in conjunc-
tion with this all-view monitoring camera.
Attentions
•
•
•
•
•
•
•
•
•
•
This manual may be updated from time to time without
any notice
CAUTIONS
Disclaimer
In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages to property or life and whatsoever arising out
of or connected with the use or misuse of our products.
USA & CANADA: This product is not intended for sale in
the United States and Canada. If purchased in the U.S. or
Canada, this product is purchased on as-is basis. No
warranty, whether expressed or implied is provided in
the U.S. or Canada.
1
Assign a mounting location that will not obstruct
driver in any circumstances. Or cause injuries to
drives and passengers in case of emergency brake
or accidents.
Ensure all wires are connected properly, and that
the unit is functioning well before tting the unit
into the mount.
Any unauthorized installation, disassembly or
modication may cause malfunction to the unit and
void warranty of the unit.
Always use only the parts that are included with
the units only.
Do not damage vehicle components when drilling
holes for the mount.
Vehicle may dier from the description provided
here. Consult an authorized Blaupunkt dealer or ve-
hicle’s manufacturer if the information provided here
does not t your specic installation requirement.
This unit is applicable for front, rear and side camera
use. Consult an authorized Blaupunkt dealer during
installation.
Unit does not record video.
Avoid automatic car wash or high-pressure water
to prevent water and pressure from damaging the
camera or causing it to fall o.
Do not install this unit near heater outlet.

SPECIFICATION
2
Features
Chip Model
Camera Specications
Eective Pixels
Image Resolution
Maximum Frame Rate
Dynamic Range
Sync System
Signal Noise Ratio
Video Signal
Exposure Control
White Balance
Illumination Min.
Operating Voltage
Power Input Range
Operating Temperature
Accessories
IMX8307(Camera)+NVP2431(Processing)
1/3 inch (6mm)
1297x977=L27MP
1000 TVL
720p HD 60fps
Support Standard Dynamic Range
Internal
≥48dB
1.0Vp-p at 75ohm
Automatic
Automatic
0.001 Lux/F2.0
3.5V~5.5V
3.5V~5.5V
-20~75°C
Front & Rear Camera
4x Extension Cord
(Yellow - 6.5m)/ (Red - 3.9m)/
(Blue - 4.0m)/ (Black - 4.0m)
Hole Saw Rear Camera
Bracket
3M Tape 4x Grommet
Side Camera (Left/ Right)
1x Wire Hardness (0.2m)
4x Tapping Screws
4x Machine Screws

a) Front Camera c) Side Camerab) Rear Camera
3
WIRING DIAGRAM
INSTALLATION LOCATION
HDMI 4G-
4G+
GPS
WIFI
BLACK
Connec
t
YELLOW
RED
BLUE
BLACK
YELLOW
RED
BLUE
FRONT
REAR
LEFT
RIGHT
FRONT
CAMERA
REAR
CAMERA
LEFT
CAMERA
RIGHT
CAMERA

4
NOTE :
• Chessboard Cloth is use for All-View Monitoring Camera
Correction Calibration.
• It is excluded in the packaging.
CORRECTION CALIBRATION

5
TROUBLESHOOTING
Problem
Display monitor / car radio does not show surround
view.
Surround view does not show even after restarting
the display monitor/ car radio.
Surround view does not show even though power
supplies of the reverse light or the rear car plate light
is properly connected.
Solution
Restart the display monitor / car radio.
Examine if the power supplies is properly connected.
Examine if the power supply cables is damaged. Repair/
replace if the cables are damaged.
If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt
authorized dealer if problem persist.

Designed and engineered by Blaupunkt Competence Centre 1 321 21 001 20 01
