Blaupunkt BP 10.0A User manual

Operating and Installation Instructions
DIGITAL VIDEO RECORDER
BP 10.0A/AG FHD 2-CHANNEL

Please insert the micro SD card in the right direction
to avoid damage to the card or the device. If device
shows error message, please format the micro SD
card from device menu.
Please reset device or change micro SD card if
similar error continues.
Note : All les will be deleted when formatting
micro SD card. Please backup the important les
before formatting takes place. When reset function
is selected, the settings will return to default setting.
Blaupunkt does not warrant the performance of
device if with use of other Micro SD card other than
Blaupunkt Micro SD card.
New Micro SD card must be formatted for rst use.
Ensure bracket is installed correctly & rmly on
windscreen to avoid damage to device and for
better recording angle.
Please do not use product under wet
environment as device is not waterproofed/water
resistant.
Please do not record or take pictures facing
sunlight.
To obtain clear image, please clean
windscreen and device lens regularly. Avoid
using device in dusty environment.
Handle device with care and avoid direct
impact on the device. Avoid using device in
high electromagnetic environment.
Operating temperature of the device is -10°C ~
60°C, storage temperature is -30°C ~ 80°C.
Continuous exposure to sunlight, especially when
locked in cabin where temperature exceeds 80°C
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
may result to device malfunction, colour change,
housing and image distortion.
In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages, to property or life, improper storage,
whatsoever arising out of or connected with the use
or misuse of our products.
USA & CANADA : Products not intended for sales in
the United States and Canada. If purchased in the
U.S or Canada, this product is purchased as-is. No
warranty, expressed or implied is provided in the
U.S. and Canada.
This device is NOT intended to be used for illegal
purpose, surveillance and shall not be used in any
form as evidence for claim purposes.
Some countries prohibit drivers from mounting
anything on the windshield, or restrict mounting to
specic areas of the windshield. It is the owner’s
responsibility to mount the device in compliance
with local laws.
Error may occur depending on the surrounding
environment and the voltage of the car.
Blaupunkt is not liable/ responsible for
non-recorded event, missing les, etc.
If the power discharge protection is set ‘ON’, motion
detection will work as park recording mode. If the
car battery voltage is lesser than the setting value of
cut-o voltage, device will stop recording even at
park recording mode.
CAUTIONS
1

STRUCTURE
1
1. Bracket slot
2. Operation indicator light
3. Lens
4. Wireless connection
indicator light
5. GPS connection indicator light
6. Recording indicator light
7. Power cable input
8. Mute/unmute (Press once),
SD format (Press & hold)
9. MicroSD card slot
10. Rear DVR cable input
11. GPS cable input
12. Rear cable
13. Rear lens
4 5 6
3
7
8
10
11
12
13
9
2
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Compact & screenless driving video recorder
Resolution : Front 2MP FHD 1920x1080 30fps, Rear 1MP HD 1280x720 25fps
Wide viewing angle : Front – 120°, Rear – 110°
Preview, download, playback Videos & Setting Conguration via Smartphone Wireless Control App
Instant le sharing to social networks (Selected Apps only)
Format-free technology
Low car battery voltage cut-o
Automatic park recording with smart motion (24-hour park monitoring)
G-sensor, loop recording
Built-in microphone & speaker
Language : English
Storage : Support up to 128GB MicroSD, class 10 & above
Power supply : DC 12V ~ 24V
Temperature : 10° ~ +60° (Operating), -30° ~ +80° (Storage)
Weight : Front 64g, Rear 120g (with cable)
Includes : Micro SD Card & Reader, Cable Holder, 3M Bracket, Hardwire Cable, Manual
(Global Positioning Tracker Module for BP10.0AG model Only)
2

FUNCTION
System Setup
System setup is accessible only via smartphone application.
Wi-Fi
Change Password Default : 12345678
DVR
Video Quality FHD+HD
HD+HD
Bitrate Maximum
High
Average
Impact Sensitivity 1~10
Volume 1~5
Voice Record ON/OFF
White Balance Auto
Daylight/Sunny
Cloudy
Domestic Lighting
Fluorescent
Contrast 0 ~ 6
Exposure -3 ~ +3
Date Time DD/MM/YYYY, HH:MM
Impact Alert ON/OFF
Cut-o Voltage 11.5V(23.5V)
11.7V(23.7V)
11.9V(24.1V)
12.1V(24.1V)
12.3V(24.3V)
Park Mode Impact Sensitivity 1~10
Park Mode Recording Time 6hr/12hr/ 24hr/ 36hr/ 48hr/ OFF
GMT -11 ~ +12
Voice Guide ON/OFF
LED ON/OFF
Format SD Card Delete all memory data
Adjust Memory Ratio A-Type
B-Type
C-Type
Reset Reset device to default setting
3

FUNCTION
Mobile Application
Search “Blaupunkt DVR BP10.0A”on Google Play and App Store to download.
Mobile App device OS version requirement : Android 4.4 (KitKat) or higher, iOS 10.0.2 or higher.
Pair DVR and Smartphone
The range of distance between the DVR (with Wireless Control dongle) and smartphone is approximately
10 meters (33ft) in an open eld environment.
After successful pairing, enter into mobile app to start.
a. Go to smartphone setting to search for available Wi-Fi
b. Select BP10.0A Wi-Fi “BP10.0_.......” to connect
c. Enter default password 12345678 for rst time connection
Google Play Store App Store
1. Full screen
2. Mute/unmute
3. Switch between front & rear DVR
4. Live view
5. Download File
6. Car DVR (Video File)
7. Settings
8. Reect (Rear DVR only)
8. Snapshot (Photo)
1
2 9
83
4
4
5
7
6

1. Go to CAR DVR
2. Click to download le
3. Press & hold the downloaded le for sharing option
4. Select the preferred sharing option
(Applicable for selected social networks only)
Instant File Sharing to Social Network
FUNCTION
3
4
5
1
2

Settings
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
Go to Setting to change setup
Change Password (Default Password : 12345678)
Video Resolution
Impact Sensitivity (G-sensor)
Volume
Voice Record
White Balance
Contrast
Exposure
Date/Time
Impact Alert
Cut-o Voltage (Low car battery cut-o setting)
Park Mode Impact Sensitivity (G-sensor)
Park Mode Recording Time (Set power supply duration)
GMT (Standard time setting)
Voice Guide
Format SD Card (Delete all memory data)
Adjust Memory Ratio (All data will be deleted when
ratio setting is adjusted, backup data before
changing the setting)
Reset (Reset setting to default setting)
2
3
4
5
6
7
1
FUNCTION
8
9
10
11
12
13
14
15
16
17
18
19
6

FUNCTION
Blaupunkt DVR BP10.0A PC Viewer - Visit www.blaupunkt.com/ase to download PC Viewer
File Search Extract le to play
front/rear video
le in normal
video player
Note :
Older les will be overwritten when memory card is full and requires new storage space. Files will be
overwritten according to le arrangement DRIVE/EVENT/PARK/PHOTO. Backup recordings regularly to prevent
import les from being overwritten.
Map
7

INSTALLATION
SAFETY
•
•
•
•
Power Cable Hardwiring
•
•
•
•
Assign a mounting location that will not obstruct driver in any circumstances or cause injuries to drivers and
passengers in case of emergency brake or accident.
Ensure all wires are connected properly, and that the device is functioning well before installation.
Any unauthorized installation and modication may cause malfunction to the device and void warranty of
product. Always use the parts that are included with the device only.
Please contact Blaupunkt dealer or vehicle’s manufacturer if information provided here does not t your
specic requirement.
Use the hardwire power cable.
BATT (+) : Connect the wire cable to permanent power fuse box. (Ex.: Hazard light, dome light, tail light etc)
ACC (+) : Connect the wire cable to the fuse that receive power through ignition. (Ex.: Cig lighter, audio system)
GND : Connect the cable to the vehicle chassis or vehicle bolts.
BATT (+)
ACC (+)
GND
CABLE
8

ACCESSORIES
8
Front DVR Rear DVR & Cable Hardwire Cable 3M Bracket
Micro SD Card
* Subject to change
Card Reader Cable Clip Global Positioning Tracker
Module (BP10.0AG only)

Designed and engineered by Blaupunkt
V2
BP10.0A 2301170082201
BP10.0AG 2301170092201
