Motif Sketch™ 1
1.Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Optional Accessories 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2.Meet The Motif Sketch™ 5
Features 5
DMX Quick Reference 5
The
Motif Sketch™ Pin-up Picture 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch Of Motif Sketch™’s 7
Data/DMX Cables 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
4.Operating Adjustments 10
The Remote Control 10
Setting the DMX Address 10
Static Colors 10
DMX Mode 10
Blackout 11
Built-in Programs 11
Auto Mode 11
Manual Color Adjustments 11
Restore Factory Settings 11
5. Appendix 12
A Quick DMX Lesson 12
Troubleshooting 12
Keeping Your Motif Sketch™ As Good As New 13
Returns (Gasp!) 13
Shipping Issues 13
Tech Specs 14

Page 3
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
1 . GETTING STARTED
What’s In The Box?
• 1 x Motif Sketch™ LED Fixture
• 1 x Mounting Bracket w/Bolts & Washers
• 1 x IP Rated AC Power Cord with Cable Cap
• 1 x Set of IP Rated DMX In/Out Cables
• This Lovely User Manual
Optional Accessories (sold separately)
The following accessories are available for this xture. But being the lone wolves that they are, they need
to be purchased separately! Contact your favorite Blizzard Lighting dealer for pricing.
• Motif Sketch Remote: IR Remote Control
• CABLE_MotifData3M: 3M IP-Rated DMX Extension
• CABLE_MotifDMXSET: 1M IP-Rated DMX IN/OUT Set
• CABLE_MotifPower3M: 3M IP-Rated Power Extension
Getting It Out Of The Box
Congratulations on purchasing one of the brightest, cutest little outdoor rated xtures anywhere! Now
that you’ve got your Motif Sketch™ (or hopefully, Sketch’s!), you should carefully unpack the box and
check the contents to ensure that all parts are present and in good condition. If anything looks as if it has
been damaged in transit, notify the shipper immediately and keep the packing material for inspection.
Again, please save the carton and all packing materials. If a xture must be returned to the factory, it is
important that the xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly off a switched circuit and cannot be run off a rheostat (variable
resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0% to
100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the xture you
receive is suitable for your local power supply. See the label on the xture or refer to the xture’s
specications chart for more information. A xture’s listed current rating is its average current draw under
normal conditions. Check the xture or device carefully to make sure that if a voltage selection switch
exists that it is set to the correct line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line voltage applied.
Damage to your xture may result if the line voltage applied does not match the voltage
indicated on the voltage selector switch. All xtures must be connected to circuits with a
suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, just give us a call or send an email. We’ll be happy to help, honest.
Blizzard Lighting
N16 W23390 Stoneridge Dr. Ste E
Waukesha, WI 53188 USA
www.blizzardlighting.com
414-395-8365
Email: [email protected]
Disclaimer: The information and specications contained in this document are subject to change without
notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may
appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or
to create a new document to correct any errors or omissions at any time. You can download the latest
version of this document from www.blizzardlighting.com.
Author: Date: Last Edited: Date:
J. Thomas 12/17/2012 J. Thomas 3/21/2013

Page 4
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
SAFETY INSTRUCTIONS
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
cal or rear panel of the xture.
• This product is intended for indoor use only.
• To prevent risk of re or shock, do not expose xture to rain or moisture.
• Make sure there are no ammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
• ALWAYS secure xture using a safety chain. NEVER carry the xture by its
cord. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
your unit may require service, please contact Blizzard Lighting at sup-
[email protected].

Page 5
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
2. MEET THE MOTIF SKETCH™
MAIN FEATURES
• Exceptional color mixing from 7x 3-watt TRI-color LEDs
• Advanced heat sink design for zero fan noise
• Secure mounting bracket
• Multiple built-in color presets and auto programs
• User adjustable program speed & fade times
• 0-100% variable electronic dimmer
• Variable electronic strobe
• Durable cast aluminum housing
• Tempered glass lens and watertight internal gaskets
• Built like a rock (It hits the gym regularly)
CONTROL FEATURES
• USITT DMX-512 (3-channels)
• 3-pin Input/Output
• Easy to use IR remote control (sold separately)
ADDITIONAL FEATURES
• Compact and lightweight (it kept its new year’s resolution!)
• Efcient convection cooling for zero fan noise
DMX Quick Reference (3-Channel Mode)
Channel What is does...
1 Red Intensity (0 <--> 100%)
2 Green Intensity (0 <--> 100%)
3 Blue Intensity (0 <--> 100%)

Page 6
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Figure 1: The Motif Sketch™ Pin-Up Picture
Figure 2: The Remote Control (sold separately)
AC Power In
DMX In
DMX Out
R/G/B Dimming Buttons
Blackout
Auto Run
Select Program Flash
Speed
DMX Mode
Sound Active Slave Mode
Set Address
Buttons (0-9)
+/- Buttons
TRI-Color RGB LEDs
AC Power Out

Page 7
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
With a philips head screwdriver, unscrew the fuse holder from its hous-
ing. Remove the damaged fuse from its holder and replace with exact
same type fuse. Insert the fuse holder back in its place and reconnect
power.
Connecting A Bunch of Motif Sketch™ Fixtures
You will need a serial data link to run light shows using a DMX-512
controller or to run shows on two or more xtures set to sync in mas-
ter/slave operating mode. The combined number of channels required
by all the xtures on a serial data link determines the number of x-
tures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line.
Also, connecting more than 32 xtures on one serial data link without
the use of a DMX optically-isolated splitter may result in deterioration
of the digital DMX signal.
The maximum recommended cable-run distance is 500 meters (1640
ft). The maximum recommended number of xtures on a serial data
link is 32 xtures.
Data/DMX Cabling
To link xtures together you’ll need data cables. You should use data-
grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
For instance, Belden© 9841 meets the specications for EIA RS-485
applications. Standard microphone cables will “probably” be OK, but
note that they cannot transmit DMX data as reliably over long distanc-
es. In any event, the cable should have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms

Page 8
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR
connector on the other end. (Duh!)
CAUTION: Do not allow contact between the common and the x-
ture’s chassis ground. Grounding the common can cause a ground
loop, and your xture may perform erratically. Test cables with an
ohm meter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
They are widely available over the internet and from specialty retailers If you’d like to build your own, the
chart below details a proper cable conversion:
Conductor 3-Pin Female
(Output)
5-Pin Male
(Input)
Ground/Shield Pin 1 Pin 1
DMX Data (-) Pin 2 Pin 2
DMX Data (+) Pin 3 Pin 3
Not Used. No Connection. No Connection.
Not Used. No Connection. No Connection.
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the
DMX cable to the female connector (output)
on the controller.
Step 2: Connect the female connector of the
DMX cable to the rst xture’s male connec-
tor (input). Note: It doesn’t matter which
xture address is the rst one connected.
We recommend connecting the xtures in
terms of their proximity to the controller,
rather than connecting the lowest xture
number rst, and so on.
Step 3: Connect other xtures in the chain
from output to input as above. Place a DMX
terminator on the output of the nal xture
to ensure best communication.

Page 9
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3 pin connector side of the
DMX cable to the output (female) 3 pin connector of
the rst xture.
2. Connect the end of the cable coming from the
rst xture which will have a (female) 3 pin connec-
tor to the input connector of the next xture con-
sisting of a (male) 3 pin connector. Then, proceed
to connect from the output as stated above to the
input of the following xture and so on.
A quick note: Often,
the setup for Master-
Slave and Standalone
operation requires that
the rst xture in the
chain be initialized for
this purpose via either
settings in the control
panel or DIP-switches.
Secondarily, the xtures
that follow may also re-
quire a slave setting.
Check the “Operating Adjustments” section in this manual for com-
plete instructions for this type of setup and conguration.
Mounting and Rigging
This xture may be mounted in any SAFE position provided there is
enough room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the
xture using a suitable “C” or “O” type clamp. The clamp should be
rated to hold at least 10x the xture’s weight to ensure structural sta-
bility. Do not mount to surfaces with unknown strength, and ensure
properly “rated” rigging is used when mounting xutres overhead.
Adjust the angle of the xture by loosening both knobs and tilting the
xture. After nding the desired position, retighten both knobs.
• When selecting installation location, take into consideration lamp
replacement access (if applicable) and routine maintenance.
• Safety cables MUST ALWAYS be used.

Page 10
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Setting the DMX Address
1.) To set the starting DMX address, push the
<S> button. You’ll see the LEDs ash 3 times in a
sequence of colors that indicate the currently set
DMX address. For example, if the DMX address is
currently 001, the ashes would be white (zero)/
white (zero)/ red(one). (See static color table)
2.) Enter a 3-digit DMX address: 001-512.
3.) Now you’ll see the LEDs ash 3 times per digit
you enter, and notably, they will ash the assigned
static color that corresponds to that digit. For
example, setting the xture to the DMX address of
010, the ashes would be white (zero)/ red (one)/
white (zero). (See static color table)
Static Colors
To use xture in static color mode, press either the
<R>, <G>, or <B> buttons, and then one of the numeric buttons (0-9). The color
table below shows the static color for each number.
Static color table
Button 0 Button 1 Button 2 Button 3 Button 4
White Red Orange Light Yellow Green
Button 5 Button 6 Button 7 Button 8 Button 9
Cyan Blue Purple Pink Yellow
DMX Mode
The Motif Sketch™ will automatically recognizes a DMX signal when connected to a
controller, and will function in 3-channel RGB color mixing mode. If the DMX signal is
lost, the xture will revert to its previously set mode.
You can use the remote control while in DMX mode to switch to any other mode.
Then to return to DMX mode, press the <D> button.
3-channel DMX mode
Channel Channel Value What it does...
1 000 <-> 255 Red Intensity (0 <--> 100%)
2 000 <-> 255 Green Intensity (0 <--> 100%)
3 000 <-> 255 Blue Intensity (0 <--> 100%)
4. OPERATING ADJUSTMENTS
The Remote Control
All the goodies and different modes possible with the Motif Sketch™ are accessed by
using the IR remote control (sold separately).

Page 11
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Blackout
The blackout button on the remote control <B> will turn off the LEDs, regard-
less of what mode you are currently running. Push the blackout <B> button
again to return to its previous mode.
Built-in Programs
To run one of the six built-in programs, press the <SPR> button. You will see
the LEDs ash yellow, prompting you to then select a program number from
buttons <2-7> on the numeric keys. You can also access static color mode
from here by pressing button <1>. (see the static color table, page 10)
Built-in programs
Button 2 Button 3 Button 4
7-Color Fade 3-Color Fade Fantasy Color Fade
Button 5 Button 6 Button 7
7-Color Snap 3-Color Snap Various Color Snap
Now you can adjust the program speed and ash (strobe) by pushing their
corresponding buttons: <SP> button for speed, and the <FL> button for
ash. Then use the <+/-> buttons to adjust the rate. The <+> button will
increase the speed, and <-> button will decrease the speed.
Auto Mode
In auto mode, the xture will run the built-in programs 2-7 in sequence. Press
the <AR> button to start auto mode. Speed and ash setting will be inherited
from your settings in program mode.
Manual Color Adjustment
This allows you to adjust the color balance of the xture. These settings are
global, they will effect all modes.
To adjust the 16 intensity levels of red, green, or blue (0% - 100%), press
either the <R>, <G>, or <B> buttons on the remote control. Then use the
<+/-> buttons to adjust the intensity. The <+> button will increase the
intensity, and <-> button will decrease the intensity.
Slave Mode
To set the xture to run in slave mode, push the <SL> button. The xture is
now in slave mode. Tip: If you want the xture to be black without DMX, set
the xture to slave mode.
Restore Factory Settings
To restore the Motif Sketch™ back to its factory installed settings, rst press
the blackout button <BL> to turn off the LEDs. Then, press the numeric keys
<9>, <8>, and <7> in that order.

Page 12
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
5. APPENDIX
A Quick Lesson On DMX
DMX covers (and is an abbreviation for) Digital MultipleXed signals. It is the most common
communications standard used by lighting and related stage equipment.
DMX provides up to 512 control “channels” per data link. Each of these channels was
originally intended to control lamp dimmer levels. You can think of it as 512 faders on a
lighting console, connected to 512 light bulbs. Each slider’s position is sent over the data
link as an 8-bit number having a value between 0 and 255. The value 0 corresponds to the
light bulb being completely off while 255 corresponds to the light bulb being fully on.
DMX data is transmitted at 250,000 bits per second using the RS-485 transmission
standard over two wires. As with microphone cables, a grounded cable shield is used to
prevent interference with other signals.
There are ve pins on a DMX connector: a wire for ground (cable shield), two wires for
“Primary” communication which goes from a DMX source to a DMX receiver, and two
wires for a “Secondary” communication which goes from a DMX receiver back to a DMX
source. Generally, the “Secondary” channel is not used so data ows only from sources
to receivers. Hence, most of us are most familiar with DMX-512 as being employer over
typical 3-pin “mic cables,” although this does not conform to the dened standard.
DMX is connected using a daisy-chain conguration where the source connects to the input
of the rst device, the output of the rst device connects to the input of the next device,
and so on. The standard allows for up to 32 devices on a single DMX link.
Each receiving device typically has a means for setting the “starting channel number” that
it will respond to. For example, if two 6-channel xtures are used, the rst xture might
be set to start at channel 1 so it would respond to DMX channels 1 through 6, and the next
xture would be set to start at channel 7 so it would respond to channels 7 through 12.
Troubleshooting
Symptom Solution
Fixture Auto-
Shut Off
Check the fan in the xture. If it is stopped or moving slower than
normal, the unit may have shut itself off due to high heat. This is to
protect the xture from overheating. Clear the fan of obstructions,
or return the unit for service.
Beam is Dim Check optical system and clean excess dust/grime. Also ensure that
the 220V/110V switch is in the correct position, if applicable.
No Light Output Check to ensure xture is operating under correct mode, IE sound
active/auto/DMX/Etc., if applicable. Contact service for more infor-
mation.
Chase Speed Too
Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check fuse, AC cord and circuit for malfunction.
No Response to
Audio
Verify that the xture is in “Sound Active” mode.
Adjust Audio Sensitivity, If Applicable.
Fixture Not
Responding /
Responding Er-
ratically
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset xture(s).

Page 13
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Keeping Your Motif Sketch™ As Good As New
The xture you’ve received is a rugged, tough piece of pro lighting equip-
ment, and as long as you take care of it, it will take care of you. That said, like
anything, you’ll need to take care of it if you want it to operate as designed.
You should absolutely keep the xture clean, especially if you are using it in an
environment with a lot of dust, fog, haze, wild animals, wild teenagers or spilled
drinks.
Cleaning the optics routinely with a suitable glass cleaner will greatly improve
the quality of light output. Keeping the fans free of dust and debris will keep
the xture running cool and prevent damage from overheating.
In transit, keep the xtures in cases. You wouldn’t throw a prized guitar,
drumset, or other piece of expensive gear into a gear trailer without a case,
and similarly, you shouldn’t even think about doing it with your shiny new light
xtures.
Common sense and taking care of your xtures will be the single biggest thing
you can do to keep them running at peak performance and let you worry about
designing a great light show, putting on a great concert, or maximizing your cli-
ent’s satisfaction and “wow factor.” That’s what it’s all about, after all!
Returns - Gasp!
We’ve taken a lot of precautions to make sure you never even have to worry
about sending a defective unit back, or sending a unit in for service. But, like
any complex piece of equipment designed and built by humans, once in a while,
something doesn’t go as planned. If you nd yourself with a xture that isn’t
behaving like a good little xture should, you’ll need to obtain a Return Authori-
zation (RA).
Don’t worry, this is easy. Just send an email to [email protected],
and we’ll issue you an RA. Then, you’ll need to send the unit to us using a
trackable, pre-paid freight method. We suggest using USPS Priority or UPS.
Make sure you carefully pack the xture for transit, and whenever possible, use
the original box & packing for shipping.
When returning your xture for service, be sure to include the following:
1.) Your contact information (Name, Address, Phone Number, Email address).
2.) The RA# issued to you
3.) A brief description of the problem/symptoms.
We will, at our discretion, repair or replace the xture. Please remember that
any shipping damage which occurs in transit to us is the customer’s responsibil-
ity, so pack it well!
Shipping Issues
Damage incurred in shipping is the responsibility of the shipper, and
must be reported to the carrier immediately upon receipt of the items.
Claims must be made within seven (7) days of receipt.

Page 14
Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 6.29 inches (16 cm)
Width 2.78 inches (7.5 cm)
Height 3.54 inches (9 cm)
Weight 2.87 lbs (1.3 kg)
Power
Operating Voltage 100-260VAC, 50-60 Hertz
Fuse 2A 250V
Power Consumption 21W, .26A
Power Factor .48
Light Source
LED 7x 3-watt TRI-color LEDs, 100,000 hours.
Optical
Beam Angle 25 degrees
Luminous Intensity Lux/meter Red Green Blue All
1m 1,480 1,840 1,900 4,940
2m 410 520 530 1,300
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 3-channel
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover
malfunction caused by damage to LED’s.

6.29 in
160 mm
5.1 in
125.6 mm
2.78 in
70.5 mm
