Blodgett MT2136 E Series Application guide

MT2136 E & G SERIES
CONVEYOR OVEN
REPLACEMENT PARTS LIST
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items specified are not available.
ERR RS: Descriptive and/or typographic errors are subject to correction.
EFFECTIVE SEPTEMBER 6, 2001
www.blodgett.com
THE BLODGETT CORPORATION
50 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: [phone]) 331-5842 Fax: [phone]
www.blodgett.com

MT2136 E & G
September 6, 2001
þASAP Distributor Required Stocking Parts
tDoors Are Not Returnable
TEMPERATURE CO TROLS
SOLID STATE CONTROLS (MANUAL) FOR OVENS
MANUFACTURED BEFORE MID SEPT., 1993
2 DIGITAL DISPLAYS
Ref. Pa t
No. No. Desc iption
þM3146 Time Display, Digital
þM3149 Controller, Digital Temperature
þM3439 Relay, Digital Temp. Controller (UE Control)
þM31 0 Control Board, Temperature Hi-Lo Limit
þM31 1 Thermocouple, Dual Lead
þM8 24 Filter, Capacitor
ELECTRICAL COMPO E TS
Ref. Pa t
No. No. Desc iption
M2 71 Element Assy., 208V, 3 PH, 1 KW (Qty 1)
M2697 Element Assy., 208V, 1 PH, 1 KW (Qty 1)
M2 72 Element Assy., 240V, 3 PH, 1 KW (Qty 1)
M2698 Element Assy., 240V, 1 PH, 1 KW (Qty 1)
M6891 Element, Individual, 208V (Qty 6)
M6892 Element, Individual, 220V (Qty 6)
M6893 Element, Individual, 240V (Qty 6)
þM1821 Fuse, 4 AMP, 300V, SC-4 (Qty 2)
þM01 8 Fuse Holder for SC-10 & SC-4 Fuses (Qty 2)
þM01 6 Fuse, 10 AMP, 2 0V, FMN-10 Blowers ZA
M0702 Fuse Block for FMN-10 Fuse Blowers ZA
þM3389 Fuse, 4 AMP, Ceramic, MDA-4
Computerized Ovens
(Need screw driver to remove)
þM3390 Fuse Holder, 20 AMP for MDA-4 Fuse
Computerized Ovens
þM24 3 Snap Disc, L140-20F, 3 Pole SPDT
(Blower Compartment)
þM1362 Snap Disc, L140-20F, 2 Pole SPST
(Control Compartment)
þM063 Snap Disc, F110-20F, 2 Pole SPST
(Control Compartment-ZA version only)
þM2734 Snap Disc, L16 -30F, 2 Pole SPST
(Control Comparment-ZA version only)
M0 93 Terminal Block, 2 Pole (Neutrals) w/ Push On
Terminals
M3714 Terminal Block, 3 Pole (Power) MT2136E
w/Allen Head Screws
281 Terminal Block, 90 AMP, 3 Pole
R0164 Terminal Block, Power
R0166 Terminal Block, Ground
R1 80 End Stop, for Terminal Block
þM0708 Contactor, Mechanical, 16 AMP, 3 Pole,120V
Coil (Blowers)
M2483 Contactor, Mercury, 60 AMP, 3 Pole, 120V Coil
(Heat) 3PH
M2720 Contactor, Mercury, 100 AMP, 2 Pole, 120V
Coil (Heat) 1PH
M7170 Transformer, 208/460V to 120V
þM2469 Fan, Axial 110 CFM 4-1/2" (Qty 3) or
(AB Qty 4)
M0 71 Guard & Hardware, Fan (Qty 3) or (AB Qty 4)
M0 72 Cord Set, Axial Fan (Qty 3) or (AB Qty 4)
þM01 2 Selector Switch, Heat & Conveyor
þM01 3 Selector Switch, Blower
þM01 1 Knob, Selector Switch
(Heat/Conveyor/Blower)
M1694 Cord Set & Plug Assy., 10 Foot
M0772 Receptacle, Twist Lock
4168 Lug, Grounding
IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge
2

CO TROL PA EL OPTIO COMPUTER CO TROLS SB DOMESTIC
FOR MT2136
TEMPERATURE CO TROLS
COMPUTER SOLID STATE CONTROLS FOR OVENS MANUFACTURED AFTER MID SEPT., 1993
PROG
ENTER TIME ACT TEMP SET TEMP CLEAR
FAN HEAT
123
456
78910
POWER
ON
OFF
SEPTEMBER 6, 2001 3 MT2136 E & G
PART #M6474
SB=SINGLE BELT
TB=TWIN BELT
M6474
Computer Control Kit,
Complete
(Does not include cover)
8
M3175
Decal Onl , SB OR
22
Ref. Pa t
No. No. Desc iption
8þM6474 Computer Control Kit, Closed Loop SB
FW 2 Computer Control Kit, Closed Loop SB,
Recon.
M10049 Decal & Control Membrane SB
(for M6474/FW 2 )
22 M317 Lexan Decal only, SB
M9692 DAC Board, SB (for M6474)
21 M10197 Remote Mounting Support Kit, for Computer
(sgl, dbl, & tpl ovens) Replaces M3314
M0984 Pick-Up, PV2
M 63 Computer Control Kit, Open Loop TB
M10034 Decal & Control Membrane TB (for M 63 )
M4400 Lexan Decal only, TB
M7427 Probe, Temperature RTD, 00 OHMS
þM1003 Silicone Compound (for cables)
M3347 Cable, Computer Control, 2 Pin, 10 Foot
þM3348 Cable, Computer Control, 9 Pin, 10 Foot
þM9262 Jack Screw (for harness mounts)
M3490 Cable, Computer Control, 2 Pin, 0 Foot
M3491 Cable, Computer Control, 9 Pin, 0 Foot
Ref. Pa t
No. No. Desc iption
M 661 Bracket Assy., Cable Clamp
22672 Relay, Control (Ice Cube) (Qty 4)
þ36066 Thermostat, High Limit (Manual Reset)
þM01 2 Contact, Emergency Stop Switch
þM3296 Activator, Emergency Stop Switch
(Mushroom Shape)
M3297 Nameplate, Emergency Stop
M3136 Breaker, 7 AMP Circuit (Qty 2)
þM2772 Breaker, 4 AMP Circuit (Qty 2)
þM33 2 Transformer, 120V to 24V (Qty 1)
þM3349 Harness, w/socket, Inter-Connecting DC
Drive, 3 Wire, 9 Pin (Qty 1)
þM7237 Harness, w/socket, Relay Board, 2 Pin
(Qty 1)
þM998 Relay Harness & Jack Screw Kit, 2 pin
M10049
Decal & Control Membrane, SB

GAS BUR ER COMPO E TS
Ref. Pa t
No. No. Desc iption
þ20287 Valve, Sgl Solenoid 110/120V
M0282 Valve, Manual Gas
þM0767 Blower Motor, Combustion w/ Control Box
þM2383 Blower Motor, Combustion
þM2381 Transformer, 120V to 24V
þM238 Relay, Time Delay
þM6397 Pilot Burner & Ignitor Assy, Nat
M6398 Pilot Burner & Ignitor Assy, LP
M0248 Tube, Pilot Aluminum 1/4"
M10076 Burner Assy, Complete Nat
M10078 Burner Assy, Complete LP
þM041 Flame Sensor
M0697 Orifice, Pilot Nat
M2690 Orifice, Pilot LP
M3203 Orifice, Main Burner, Nat (MTD 29)
M1491 Orifice, Main Burner, LP (MTD 4 )
M2140 Flame Tube Assy
þM10 4 Spark Box, 24V
M0 9 Air Pressure Switch (All gas ovens)
þM 49 Dual Solenoid/Pres Reg Nat 24V
þ22190 Dual Solenoid/Pres Reg LP 24V
M3434 Conversion Kit, Nat to LP (MTD 4 )
M343 Conversion Kit, LP to Nat (MTD 29)
18612 Spring, Solenoid Valve, Nat to LP
23007 Spring, Solenoid Valve, LP to Nat
M0279 Union, 1/2 Inch Black
1949 Nipple, Pipe 1/2 x 1-3/16 Close
M0 90 Nipple, Pipe 1/2 x 2-1/2
M0317 Elbow, 1/2 Inch Street 90°
97 Ell, Black 90°
17874 Ell, Black 1/2 x 3/4
CO VECTIO COMPO E TS
Ref. Pa t
No. No. Desc iption
þM2871 Motor & Blower Assy., 60 HZ, CW (Qty 1)
þM2870 Motor & Blower Assy., 60 HZ, CCW (Qty 1)
9 M2100 Nozzle Assy (Aluminum) (Qty )
M 288 Nozzle Assy, AB Version (S/S) (Qty )
M 302 Nozzle Assy, AB Version (Aluminum) (Qty )
M2741 Plate Assy, Air (LH & RH)
11 M7490 Air Plate, LH (R-L)
12 M7493 Air Plate, RH (R-L)
M7492 Block Off, used with M7490 & M7493
M312 Upgrade Kit, Cooling Fan (Domestic)
M7 03 Plate Assy, Air LH (L-R) Bottom
M7 02 Plate Assy, Air RH (L-R) Bottom Fazoli's Only
M7 01 Plate Assy, Air LH (L-R) Bottom Fazoli's Only
M7 07 Plate Assy, Air RH (R-L) Bottom Fazoli's Only
M7 0 Plate Assy, Air RH (L-R) Top & Middle
Fazoli's Only
M7 08 Plate Assy, Air LH (R-L) Top & Middle
Fazoli's Only
M10 28 Plate Assy, Air LH (L-R) Papa Johns Only
M964 Plate Assy, Air RH (L-R) Papa Johns Only
M7217 Plate Assy, Air LH (R-L) Papa Johns Only
M10 29 Plate Assy, Air RH (R-L) Papa Johns Only
M10447 Block Off, used with M10 28 & M10 29
NOTE: No Block Offs are used with M9445 & M7217
SEPTEMBER 6, 2001 4 MT2136 E & G
CO VEYOR COMPO E TS
SB=SINGLE BELT TB=TWIN BELT
Ref. Pa t
No. No. Desc iption
þFW 02 Speed Control Board, Bodine Recond.
NOTE: M2379 is o lo ger available
þM10099 Conveyor Motor & Control Kit, Brushless
(for Computerized Ovens) *See Note
þM10246 Conveyor Motor & Control Kit, Brushless
(for Non-Computerized Ovens) *See Note
þM10081 Conveyor Control, Brushless *See Note
þM10082 Conveyor Motor, Brushless *See Note
NOTE: You must i stall the Brushless Kit BEFORE
you purchase the ew brushless motor or
co trol separately.
M6192 Bracket, Motor Support (for M10082)
þM314 Potentiometer, Bodine, 10K
þM9787 Fuse, Armature, 2 0 MA, 2 0V (Qty 1)
(Replaces M2316, DOMESTIC ONLY)
þM22 4 Fuse, Line, Bodine Board, AMP, 2 0V
(Qty 1)
M 770 Conversion Kit, Micro-Drive
M7202 Conversion Kit, Open Loop to Closed Loop
(Computerized)
M0984 Pick-Up, PV-2 (For M6474 or M8677)
M3147 Pick-Up, PV-10 (For M3146)
M0200 Lock, Speed Control Potentiometer
M0201 Dial, Speed Control Potentiometer
21169 Knob, Speed Control Potentiometer
M2 00 Brush Set, Bodine
M2738 Chain, Drive, 16"
M0391 Chain, Drive, 1.92 ft. (FAZOLI'S ONLY)
þM0112 Masterlink, Drive Chain
18 þM2740 Belt, Wire S/S 21" SB (Per Foot) (Total 11 FT)
18 M6336 Belt, Wire S/S 10" TB (Per Foot) (Total 21 FT)
18 þM 289 Belt, Wire S/S 12" (Total 11 FT)
þM 260 Belt, Wire S/S 8" (Total 11 FT)
M2388 Tensioner Assy, Belt
(Spring, Sleeve & Shaft Assy)
2 M2011 Conveyor Assy, Drive Side SB
M2012 Conveyor Assy, Idle Side SB
M2207 Conveyor Assy, Drive Side TB
M2208 Conveyor Assy, Idle Side TB
þM0109 Sprocket, Motor Drive, 12 Tooth SB/TB
þM0108 Sprocket, Conveyor Belt, 11 Tooth SB/TB
(Bore Diameter 3/4" ) (Qty 1)
þM0110 Sprocket, Conveyor Drive, 1 Tooth SB/TB
(Bore Diameter 3/4")
M186 Sprocket, Conveyor Drive, 1 Tooth TB
(Bore Diameter 1/2")
M3441 Sprocket, 19 Tooth
M0122 Bearing, Rulon for Conveyor Drive
M9216 Speed Up Kit, 22 Tooth, Fazoli's

SEPTEMBER 6, 2001 5 MT2136 E & G
EXCLUSIVE TO VERSIO AB
(SERIAL NUMBER MODEL IDENTIFICATION
CODE OF BK = MT2136G, OR FB = MT2136E)
Ref. Pa t
No. No. Desc iption
M7274 Body Top w/ Hardware
M6220 Body Back
21390 Legs, 17-1/4" w/ Casters (Dbl Oven)
21391 Legs, 23-1/4" w/ Casters (Sgl Oven)
M7887 Pin, Stacking (Set of 4)
M9484 Stacking Kit, AB/AB Integral Controls
M948 Stacking Kit, AB/AB Remote Controls
22067 Triple Plate w/ Casters
Note: MT2136 AB ve sion is only available with legs
(Pa t #'s 21390 & 21391). The e is no stand option.
10 M20 9 Drip Pan
7 M 071 Crumb Pan, Idle (Remote & Integral)
(Bottom Section)
3 M 33 Crumb Pan, Drive w/ Remote
(Bottom Section)
M6996 Crumb Pan, Idle (Remote & Integral)
(Top & Middle Section - Vented)
M699 Crumb Pan, Drive w/ Remote
(Top & Middle Section - Vented)
3 M 068 Crumb Pan, Drive w/ Integral
(All Sections)
M7002 Extension Assy, Product 6"
6 M6997 Extension Assy, Product 12"
9 M 302 Nozzle Assy (Aluminized) (Qty ) Extruded
M 288 Nozzle Assy (S/S) (Qty ) Extruded
M2741 Plate Assy, Air (LH & RH)
11 M7490 Air Plate, LH
12 M7493 Air Plate, RH
11 M4674 Air Plate, LH (S/S)
12 M467 Air Plate, RH (S/S)
M4163 Plate Assy, Block Off
M4673 Plate Assy, Block Off (S/S)
.
EXCLUSIVE TO VERSIO AB
(SERIAL NUMBER MODEL IDENTIFICATION
CODE OF BK = MT2136G, OR FB = MT2136E)
Ref. Pa t
No. No. Desc iption
8 M6474 Computer, Closed Loop
M9932 Kit, Integral to Remote
Computer Conversion
2 M 070 Conveyor Assy, Drive Side SB
M 066 Conveyor Assy, Idle Side SB
M 069 Conveyor Assy, Drive Side TB
M 067 Conveyor Assy, Idle Side TB
4 M2002 Conveyor Support, S/S (Qty 2, Bars)
þM6044 Snap Disc, L110-20F, 3 Pole
M7000 False Front w/o Door
17 M7001 False Front w/ Door
M9110 Access Panel, Combustion Compartment
22 M6213 Access Panel, louvered, Control Box
M603 Latch, Combustion Compartment Access
Panel AND Sandwich Door
13 M4 80 Access Panel, Entire Front
(Has opening for Sandwich Door)
13 M6389 Access Panel, Entire Front, Solid
(Has no opening for Sandwich Door)
M9217 Access Panel Conversion Kit
(To add a Glass Sandwich Door)
M6970 Access Panel Conversion Kit
(To add a Solid Sandwich Door)
16 M10181 Sandwich Door Assy, 17"x ", Solid w/handle
Replaces M4 87
16 M10243 Sandwich Door Assy, 17"x ", Glass w/
handle Replaces M9237
NOTE: For ALL ove s, if you eed a ew sa dwich
door order part M10181, Solid Door Assy, or
part M10243, Glass Door Assy.
19 M10128 Handle Kit, 16 1/2" For M10181 & M10243
For ovens after 12/0 /00, or converted units
with 16 1/2" handle
M2188 Handle Assy, black plastic, for Sandwich
Door, 2" Handle For ovens before 12/0 /00
1 M4 81 Plate, Pivot RH Slotted
14 M4 82 Plate, Pivot LH Slotted
M2733 Screw, Front Access Panel
23 M 0 9 1/4 Turn Bolt
M 060 Snap-in Receptacle
M 061 Retainer, Push-On
M9780 1/4 Turn Door Bolt Kit
(Includes 1 each of M 0 9, M 060, M 061)
M9768 Gasket Assy., Front Access Panel
(Replaces M2 99 & M3420)
20 M2801 Hinge Pin & Plate Assy.
16470 Nameplate, Blodgett 10"

MT2136 AB VERSIO
19
SEPTEMBER 6, 2001 6 MT2136 E & G
M2801
Hinge Pin &
Plate Ass
20
M5068
Crumb
Pan
3
8M6474
Computer
Control
Kit
21 M10197
Remote Mounting
Support Kit
M10181
Sandwich Door, Sld,
w/handle
16
M2188
(Black plastic
handle) 2"
OR M10128
(Towel Rack style)
16"
M4580
M6389
Access Panel
Ass 13
M2075
Tunnel Extension,
Cover & Clip Ass
1
M5289
M2740
Belts,
Conve or
18
M2059
Drip Pan
10
M4581
Plate,
pivot,
slotted
RH
15
M7001
False
Front,
w/door
17
M4582
Plate, pivot,
slotted LH
14
M7490-Alum.
M4674-S/S
Air Plates
11
M2002
Conve or
Support
4
M5070
Conve or
Ass ,
Drive Side
2
M2075
Tunnel Extension,
Cover & Clip Ass
1
M5066
Conve or Ass ,
Idle Side
5
M5071
Crumb
Pan
7
M6997
Product
Extension
6
M7493-Alum
M4675-S/S
Air Plates
12
M5302
Nozzle
Ass ,
Alum
9
M7273-ZA Version
M7274-AB Version
Bod Top
21
M6213
Access Panel
Ass , Complete
louvered
22
M5059
Pin,
1/4 Turn
23
16470, Nameplate
24
M5059
Pin,
1/4 Turn
23
not replaceable

SEPTEMBER 6, 2001 7 MT2136 E & G
EXTERIOR COMPO E TS
Ref. Pa t
No. No. Desc iption
M208 Decal, Control Panel, SB, Red
M2087 Decal, Control Panel, TB, Red
7 M4306 Crumb Pan, Idle (Remote & Integral)
3 M4372 Crumb Pan, Drive w/ Remote
M430 Crumb Pan, Drive w/ Integral
M4309 Stop, Product
6 M7002 Extension Assy., Product 6"
M6997 Extension Assy., Product 12"
M20 9 Drip Pan (Aluminized)
M 008 Drip Pan (S/S)
M24 0 Access Panel, Combustion Compartment
(Manual)
M3376 Access Panel, Combustion Compartment
(Computer Controls)
M3 3 Access Panel, Control Box (Integral)
13 M6389 Access Panel, Entire Front, Solid
(Has no opening for Sandwich Door)
13 M4 80 Access Panel, Entire Front
(Has opening for Sandwich Door)
M6970 Access Panel Conversion Kit
(To add a Solid Sandwich Door)
M9217 Access Panel Conversion Kit
(To add a Glass Sandwich Door)
M10181 Sandwich Door Assy, 17"x ", Solid w/handle
Replaces M4 87
M10243 Sandwich Door Assy, 17"x ",Glass w/handle
Replaces M9237
NOTE: For ALL ove s, if you eed a ew sa dwich
door order part M10181, Door Assy,
Sa dwich Solid w/ha dle or part M10243,
Door Assy, Sa dwich Glass w/ha dle.
M10128 Handle Kit, 16 1/2" For M10181 & M10243
For ovens after 12/0 /00 or converted units
with 16 1/2" handle
M2188 Handle Assy, black plastic, for Sandwich
Door 2" Handle For ovens before 12/0 /00
NOTE: To co vert from 2" to 16 1/2" Ha dle, you
must purchase complete Sa dwich Door
Assy M10181 or M10243.
M603 Latch, Sandwich Door
M4 81 Plate, Pivot RH Slotted
M4 82 Plate, Pivot LH Slotted
M2 14 Bolt, Front Access Panel
(Allen Head Decoration)
M2 1 Allen Key for M2 14
M9768 Gasket Assy, Front Access Panel
(Replaces M2 99 & M3420)
M2801 Hinge Pin & Plate Assy.
16470 Nameplate, Blodgett 10"
21826 Installation Hose, 36"
21242 Installation Hose, 48"
EXTERIOR COMPO E TS-CO T'D.
Ref. Pa t
No. No. Desc iption
21 M7273 Body Top w/ Hardware
M2678 Body Back
M2 32 Triple Stacking Base w/ Casters
M9106 Pin, Stacking (Set of 4)
M2439 Stand, 24" w/Caster Assy.
M9481 Stacking Kit, ZA/ZA Manual Controls
M9482 Stacking Kit, ZA/ZA Integral Controls
M9483 Stacking Kit, AA/AA Remote Controls
M9486 Stacking Kit, AB/ZA or AA Integral Controls
M9487 Stacking Kit, AB/ZA or AA Remote
Controls
M6846 Chimney Kit, Sgl
M6847 Chimney Kit, Dbl
M6848 Chimney Kit, Tpl
M3998 Heat Shield Kit
1 M207 Tunnel Extension Cover & Clip Assy.
M9932 Kit, Integral to Remote Mount, Computer
Conversion

SEPTEMBER 6, 2001 8 MT2136 E & G
EXCLUSIVE TO EXPORT 50 HZ
(ZA VERSIO ) - Cont'd
Ref. Pa t
No. No. Desc iption
16037 Indicator Light, 2 0V, Red, Round CE &
Australia
M10064 Wiring Harness, Elec. Ovens ONLY CE
M10039 Wiring Harness, Gas Ovens ONLY CE
M31 Controller, Digital Temp. CE
M7880 Computer Control Kit, Closed Loop SB CE
M8 24 Filter Capacitor (Manual Controls Only)
M31 4 Time Display, Digital 0 HZ
M10 44 Reset Switch Kit, Pushbutton CE
Replaces M2497 & M2498
M0 9 Air Pressure Switch
M9978 Conversion Kit, Air Pressure Differential
Switch (Replaces M3330 & M2819) CE
M9422 Air Pressure Differential Switch, switch only
CE
M970 Polyurethane Tubing (Per Foot, Total 3 FT)
used w/pressure switch CE
M224 Solenoid Valve, Sgl (Manual Controls ONLY)
M9182 Combination Gas Valve CE & Export
(Replaces M6117) After 10/8/97
M6000 Combination Gas Valve Nat 0HZ
Before 10/8/97
M6001 Combination Gas Valve LP 0HZ
Before 10/8/97
17874 Ell, Black 1/2" x 3/4" CE
4 88 Nipple, Pipe 3/4" x 1-3/8" (Qty 2) CE
R3378 Tee, 1/2" x 1/2" x 1/2" CE
R 347 Nipple, 1/2" x 3" CE
M8690 Bushing, Hex 1/2' x 1/8" CE
1949 Nipple, 1/2" x Close CE
M3407 Spring, NAT to LP Conversion
M97 3 Gas Conversion Kit, Nat to But/LP CE
M9767 Gas Conversion Kit, But/LP to Nat CE
M8690 Orifice, bushing (for M9182) CE
M8782 Cover, Athena Control CE
M8744 17 1/4" Leg/Caster Kit CE
M874 23 1/4" Leg/Caster Kit CE
9 M2100 Nozzle Assy (Aluminum) (Qty )
EXCLUSIVE TO EXPORT 60 HZ
(AB VERSIO )
Ref. Pa t
No. No. Desc iption
M6122 Transformer 220/110V
EXCLUSIVE TO EXPORT 50 HZ
(AB VERSIO )
Ref. Pa t
No. No. Desc iption
M01 8 Fuseholder NON-CE
20162 Fuse NON-CE
EXCLUSIVE TO EXPORT 50 HZ
(ZA VERSIO )
Ref. Pa t
No. No. Desc iption
M10071 Burner Assy, Complete Nat CE
M10073 Burner Assy. Complete LP CE
M10076 Burner Assy, Complete Nat Gen Exp
M10078 Burner Assy, Complete LP Gen Exp
NOTE: For general export ovens, use domestic
burners.
M10067 Pilot Burner & Ignitor Assy, Nat CE
M10066 Pilot Burner & Ignitor Assy, LP CE
M3168 Spark Box, 240V (Landis & Gyr) CE
M2 49 Strip, Terminal (used w/spark box) CE
(Plugs on M3168)
M6449 Noise Filter (G&E)
M6448 Noise Filter (E Only)
M8784 Suppression Harness CE
M2384 Transformer, 240V (Burner Assy.)
M329 Thermostat, High Limit, (Man Reset)
M2386 Motor, Combustion Blower
M2873 Motor & Blower Assy., 0 HZ, CW
M2872 Motor & Blower Assy., 0 HZ, CCW
M3128 Motor, Conveyor Drive, 180VDC
M2 73 Element Assy., 220/380V, 3 PH, 1 KW
M2699 Element Assy., 220/380V, 1 PH, 1 KW
M2 74 Element Assy., 240/41 V, 3 PH, 1 KW
M2698 Element Assy., 240/41 V, 1 PH, 1 KW
þM6892 Element, Individual, 220/380V
M6893 Element, Individual, 240/41 V
þ23034 Axial Fan, 230V (Qty 3)
M3126 Upgrade Kit, Cooling Fan (Export)
M2247 Contactor, Mechanical, 16 AMP, 3 Pole, 2 0V
(Motor) 0 HZ
R1 30 Contactor, Mercury, 60 AMP, 3 Pole (Heat)
M2 91 Contactor, Mercury, 100 AMP, 1 Pole (Heat)
M7170 Transformer, 208/460-120V, 300VA
(Step Down)
M329 Thermostat, High Limit, (Man Reset) CE
902 0 Relay, 240V 3PDT CE
1677 Relay, 240V SPST, 30 AMP CE
M7282 Relay Board (All Computerized Ovens) CE
M6024 Transformer (for M7282) CE
M8704 Fuse, 2 0V 12 MA (For M7282) (Qty 1)
(Replaces M86 2) CE
M3166 Fuse, 4 Amp., Ceramic 2 0V CE
M3167 Fuse Holder CE
M2630 Fuse, Bodine Speed Control, AMP, 2 0V
(Qty 1) CE
M2316 Fuse, Armature, 200MA, 2 0V (Qty 1) CE
þR0164 Terminal Block, Power CE
R1 80 End Stop, Terminal Block (Qty 1)
used w/R0164
R0166 Terminal Block, Ground CE
M3172 Timer, Fixed, 2 Second CE
M3173 Timer, Fixed, 10 Second CE
