BLOTZ B10-MW-001 User manual

B10-MW-001
10mm 3x2 Residential
Designed and made in the UK.
This is a model kit and is not intended for
ersons under 14 years old.
This kit consists of:
B10-MW-100: Foyer (2 sheets)
B10-MW-150: Middle (1 sheet)
B10-MW-200: Roof (1 sheet)
Blotz
90 Fullers Avenue
Cricklade
SN6 6EU
[email protected]
www.blotz.co.uk

10mm 3x2 Residential Foyer
B10-MW-100
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Foyer (B10-MW-100)
Start by removing the sections shown above (left)
from the sprue. There are enough parts to create
both doorway sections.
Glue them together as shown in the image on the
right.
Glue each doorway to the back of the long sides using
the lugs/holes provided.
At the same time glue a triangular bracer to the
back of the long sides at each end. Leave these to
dry.
Glue the shorter end walls into place to give a hollow
rectangle. Once this is dry glue the decorative
columns and balconies into position.

10mm 3x2 Residential Middle
B10-MW-150
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Mid-Section (B10-MW-150)
Remove the four walls and four triangular corner
bracers from the sprue. Glue the triangles to
non-etched side of the two long walls as shown
in the example above. Leave to dry.
Once the bracers are dry apply a little glue to the side
lugs and glue the shorter walls in place as shown
above. You should now have a hollow square
structure. Leave it to dry.
Now remove the four rectangles from the sprue.
Each of these has a line etched across it. Apply
glue to one side of the line only and attach it (as
shown) to the centre bottom edge of each wall.
Finally glue the balconies into position.
