BLOTZ B10-MW-113 User manual

10mm Monorail Station
(Double Platform)
B10-MW-113
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Start by removing the support pillar pieces from
the sprue. The image shown above is for a single
support pillar.
Glue the pieces together as shown above with the
slots being opposite each other. Repeat for the other
three pillars.
Glue the lugs at the bases of two pillars into the
base. Repeat for the other pair of pillars and their
base. Allow glue to dry. Note the slots on the top
of the supports run along the length of the base
(see above)
Now take the two platform pieces and the seven
stanchions from the sprue.
Each of the roof supports is formed from four pieces
(shown above). Glue them together as shown with the
slots opposite each other. Allow to dry.

Turn the platform pieces upside down and glue
the stanchions in place as shown. Allow to dry.
The roof is formed from the three large pieces
and four beams (see above).
Turn the main roof piece over and glue the beams into
place using the holes/lugs provided.
Once you’re happy that the glue has set
sufficiently turn the roof over and glue the side
pieces into place as shown. Leave to dry fully.
The lifts are formed from the pieces shown above.
Glue the pieces
together as shown
with the square
holes in the side
pieces nearest to
the back piece (i.e
the one with the
slot).
Slot the platform section on top of the support pillars.
Push the lifts into position aligning the ends of the
central stanchions into the slots on the lifts.
Add the four roof supports (note the direction of
the slots on the top of the support) into the holes
provided.
The railings are added to the edges of the platform
and will slot into the holes provided.

Finally sit the roof on top with the roof beams
resting in the slots on top of the roof supports.
A view down the length of the platform.
