Bobrick CompacDryer B-710 User manual

Compac_DTG r8-13 Page 1 of 6
CompacDryerTM
Guide
Effective 10/09
www.bobrick.com
U.S. Headquarters: BOBRICK WASHROOM EQUIPMENT, INC.
11611 Hart Street, North Hollywood, California 91605-5882, Tel: [phone], FAX: [phone]
Email: [e-mail]
Canada Headquarters: BOBRICK WASHROOM EQUIPMENT COMPANY.
45 Rolark Drive, Scarborough, Ontario M1R 3B1, Eastern: 877.423.6555, FAX: [phone], Western: 877.423.6444,
FAX: [phone], Email: [e-mail]
International Sales: BOBRICK WASHROOM EQUIPMENT, INC.
11611 Hart Street, North Hollywood, CA 91605-5882, +1.818.764.1000, FAX: [phone]
Email: [e-mail]
Australia: Bobrick Washroom Equipment Pty Ltd., 1.800.353158, FAX: [phone]
Email: [e-mail]
Germany: 0800.79.00.456, FAX: [phone] Email: [e-mail]
United Kingdom: Bobrick Washroom Equipment Ltd., +44.0.20.8366 1771, FAX: [phone].
Email: [e-mail]
All Bobrick dryers require cleaning every 6 months to ensure
that they function effectively. Please note that failing to clean
the dryer may result in malfunction and can void the warranty.
(Refer to page 3 of the Dryer Troubleshooting and Information Guide for Routine Maintenance Instructions)

Compac_DTG r8-13 Page 2 of 6
CompacDryerTM
Contents Page
1. Information and Troubleshooting 3
2. Limited Warranty 4
3. Series A Cover Installation Instructions 5
4. Schematic Diagrams 6

Compac_DTG r8-13 Page 3 of 6
Warning
Risk of electric
shock
Disconnect power
supply before
removing cover
Information and Troubleshooting
for the B-710 CompacDryerTM
For complete set of Installation Instructions refer to form No. 710-69
http://www.bobrick.com/Bobrick/Install_Instructions.aspx
Information about the Dryer:
• Model B-710 CompacDryerTM is not designed for vandal-prone installations. For vandal-
prone installations use Bobrick AirCraft®dryers with cast-iron, vitreous enamel finished
covers.
• Only the cover and the electronic controller are available for replacement.
Product Types:
B-710 Series A B-710 Series B
Electrical Characteristics.
115V , 15A, 1725W , 60 HZ, cULus listed.
220-240V, 7A, 1500-1700W, 50/60Hz, VDE approved, CE marked.
Removal of Cover.
Remove three screws, one from each side
and one from the bottom of the dryer. Pull
bottom of the cover away from the mounting base.
If a fault occurs with the dryer:
1. Check that the electrical supply is OK.
2. Check that the circuit breaker is switched on.
3. Check that sensor is clean and not obstructed.
Replacement Parts
710-250 Series B cover 115V
710E-150 Series A cover 220-240V
710-360 Controller 115V
710-361 Controller 220-240V

Compac_DTG r8-13 Page 4 of 6
Limited Warranty
The Bobrick B-710 CompacDryerTM are warranted to the original owner of the installed unit
for one year from date of original installation against defects in factory workmanship or
material under normal use and service*.
This warranty is limited to repair or exchange of defective parts at the option of Bobrick.
This warranty does not cover accidental damage, improper handling or
installation, or repairs made by unauthorized persons, and specifically
excludes claims for indirect, accidental or consequential damages to
property. The implied warranties of merchantability and fitness for a
particular purpose are limited to the same duration of the above
warranty.
Some states do not allow the exclusion of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. Some states do not allow limitations on
how long an implied warranty lasts, so the above limitation may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
* Normal service constitutes performing the following preventive maintenance
procedures at six-month intervals:
Clean any lint, dust or grease from air-intake grille and air-outlet grille.
Labor costs for preventive maintenance shall be at owner's expense.
For repair or exchange of defective part, send the part together with installation date and
serial number to Bobrick.

Compac_DTG r8-13 Page 5 of 6
Warning
Risk of electric
shock
Disconnect power
supply before
removing cover
Replacement Instructions for
B-710 CompacDryerTM Cover
To Remove Existing Cover
1. Remove the (3) Phillips-head
screws from the cover, (1) from
each side and (1) from the bottom
face of the dryer. See Fig. 1.
2. Pull the bottom of the cover
outward and slightly downward,
then rotate upward to disengage
the (2) tabs from the slots at the
base. See Fig. 2.
To Install New Cover
1. Slide cover onto base plate making
sure that the bottom outlet
aperture engages in the sides of
the outlet grille.
2. Push the top of the cover forward
until the (2) tabs snap into the
slots in the base. See Fig. 3.
3. Check that the cover is a close fit
to the base, then replace the (3)
screws.
4. Reconnect electrical supply and
test with normal hand drying
procedure, allowing 10 seconds for
the sensor to stabilize.
Fig 1
Fig 3
Fig 2

Compac_DTG r8-13 Page 6 of 6
Schematic Diagram
115V Dryer
Schematic Diagram
220-240V Dryer
