Boneco H320 User manual

H320
MANUAL
Read and save these instructions
Lisez et enregistrez ces instructions
Lea y guarde estas instrucciones

EN Always observe all safety notes (included separately in delivery).
FR Veuillez respecter impérativement l’ensemble des consignes de sécurité
(fournies séparéme nt dans le contenu de la livraison).
ES Tenga en cuenta siempre todas las indicaciones de seguridad (se suministran aparte junto
con el producto).

EN Instructions for use 5
FR Mode d’emploi 27
ES Instrucciones de uso 49

5
en
INSTRUCTIONS FOR USE

6
en TABLE OF CONTENTS
The various operating modes 17
Hybrid mode (“Hybrid”) 17
“Hybrid” LED operating mode 17
Humidification only (“Humidifier”) 17
“Humidifier” LED operating mode 17
AH320 pollen filter only (“Purifier”) 17
“Purifier” LED operating mode 17
The various comfort modes 18
Comfort modes 18
AUTO mode 18
SLEEP mode 18
BABY mode 18
Using fragrances 19
Basics 19
Adding fragrances 19
Notes on cleaning 20
About cleaning 20
Recommended cleaning intervals 20
Cleaning in the dishwasher 21
Parts not permitted 21
Water base and drum 21
Items included 8
Healthy air is a basic need 8
Availability of accessories 8
Overview and part names 9
Technical data 10
Starting up 11
Manual handling 12
About manual handling 12
AUTO mode 12
Adapted AUTO mode 12
Switching on and off 12
Manual control 13
The benefits of the BONECO app 14
About the BONECO app 14
Scope of services 14
Download 15
BONECO app for iOS 15
BONECO app for Android 15
Pairing with the BONECO appliance 16
Getting ready 16
Pairing 16

7
en
Cleaning the pre-filter 22
About the pre-filter 22
Cleaning the pre-filter 22
Cleaning the AW200 evaporator mat 23
About the AW200 evaporator mat 23
Cleaning in the washing machine 23
Cleaning by hand 23
Replacing the accessories 24
Replacing the AH320 pollen filter 24
Malfunctions and troubleshooting 25
Factory default settings 26
About the factory default settings 26
Resetting the appliance 26

8
en ITEMS INCLUDED
BONECO H320
ITEMS INCLUDED
Quick Manual Power supplySafety instructions
HEALTHY AIR IS A BASIC NEED
There is little to which we react with greater sensi-
tivity than poor air. And yet many people do not pay
enough attention to air quality, which has conse-
quences for health and quality of life. This makes us
all the more pleased that you have chosen a BONECO
appliance to ensure that the basic need for healthy
room air is satisfied for you and the people around
you.
AVAILABILITY OF ACCESSORIES
You can obtain replacements for worn-out accesso-
ries as well as additional accessories from:
• At your BONECO specialist dealer,
• At shop.boneco.us or
• Directly via the “BONECO healthy air” app.

9
en
OVERVIEW AND PART NAMES
1
2
3
4
5
7 8 96
1Cover/air inlet
2Pre-filter
3AH320 pollen filter
4Hygrostat opening
5On/O, knob
6Air outlet
7Fragrance container
8Water base*
9Float gage*
10 Drum*
11 AW200 evaporator mat**
1110
* Washable in the dishwasher up to
122°F (50°C)
** Washable in the washing machine
up to 104°F (40°C)

10
en TECHNICAL DATA
TECHNICAL DATA*
Type designation BONECO H320
Power supply voltage 100 –120 V ~ 60 Hz
Power consumption Standby 0.5 W
Level 1 3.3 W
Level 6 9.7 W
Humidity output up to 2.2 gal/day (350 g/h)**
Particle CADR ≤30 CFM (50 m3/h)
For rooms up to 540 square feet (50 m2/ 125 m3)
Water capacity max. 1.6 gallons (6.0 liters)
Dimensions L × W× H 16.9× 11 ×18.3 in. (430× 280×465 mm)
Weight (empty) 14 lbs (6.4 kg)
Operating noise level Level 1 28 db(A)
Level 6 51 db(A)
* Subject to change
** At 120 V ~ 60Hz, Level 6 (humidification only)

11
en
STARTING UP
654
3
2
1
Open the water inlet. Fill with cold tap water up to the marking.
Close the water inlet.
Place the BONECO appliance on a flat surface.
Plug the power supply into a power outlet. Briefly press the knob to switch on the appliance.

12
en MANUAL HANDLING
ABOUT MANUAL HANDLING
Manual handling works conveniently by the knob
on the front side. The BONECO app oers additional
extensive options for control and automation of the
BONECO appliance.
AUTO MODE
If you have never operated the BONECO appliance
with the BONECO app and switch it on for the first
time, it starts up in AUTO mode. The appliance is pre-
set to a target relative humidity of 50 percent.
The performance level is automatically adapted to
the current humidity: The drier the air, the higher
the performance level.
If the preset target humidity is exceeded by 2 per-
cent, the appliance switches to standby mode,
which is indicated by the pulsing LED:
If the humidity drops below the set level, the
BONECO appliance resumes operation.
ADAPTED AUTO MODE
If you have already operated the BONECO appliance
with the BONECO app and set a dierent humidity,
that value is automatically taken over when the ap-
pliance is switched on.
SWITCHING ON AND OFF
1. Briefly press the knob once to switch on the
BONECO appliance.
The appliance is always in AUTO mode when it is
switched on. You can identify active AUTO mode by
the small LED that lights up above the knob.
2. To switch o the BONECO appliance while it is in
AUTO mode, briefly press the output regulator
once.

13
en
The selected performance level is indicated by the
number of LEDs that light up above the knob.
3. Briefly press the knob once to exit manual mode
and to reactivate AUTO mode.
4. Briefly press the knob once more to switch o the
BONECO appliance.
If you exit AUTO mode, the BONECO appliance
will continue at the selected performance
level until the water base is empty, regardless of
what the current level of humidity is.
MANUAL CONTROL
1. Briefly press the knob once to switch on the
BONECO appliance.
The appliance is always in AUTO mode when it is
switched on.
2. Adjust the output to your needs by setting the
knob to the desired level from 1 to 6. This action
exits AUTO mode (AUTO LED is o).

14
en THE BENEFITS OF THE BONECO APP
ABOUT THE BONECO APP
The “BONECO healthy air” app is used for enhanced
control of the BONECO appliance and lets you take
full advantage of its potential. The app includes
functions such as a timer, a humidity preset and the
option to switch between various programs. In ad-
dition, it provides reminders for the cleaning inter-
vals, filter changes and other recurring tasks.
SCOPE OF SERVICES
Programs Predefined settings for frequent situations
“Baby” mode The appliance uses fan level 1 through 4 and increases the humidity
to 60%
“Sleep” mode The appliance uses fan level 1 only and increases the target humidity
to 45%
ON timer The appliance switches on after a set time
OFF timer The appliance switches o after a set time
Programs Predefined settings for frequent situations
Hygrostat Defining the desired humidity
Dimmer Setting the brightness of the status LED
Weather Displays the current weather and outside temperature
Filter change information Indicates when an AH320 pollen filter is used up
Accessories and consumables Provides support in replacement orders and further information

15
en
DOWNLOAD
BONECO APP FOR IOS
Search the App Store for “BONECO healthy air” or
scan the QR code below. Reading the QR code under
iOS 10 or earlier requires installing a corresponding
app. Under iOS 11 and later, the QR code is read au-
tomatically whenever you direct the camera at it.
BONECO APP FOR ANDROID
Search the Google Play Store for “BONECO healthy
air” or scan the QR code below. Reading the QR code
requires installing a corresponding app on your de-
vice.

16
en PAIRING WITH THE BONECO APPLIANCE
GETTING READY
Make sure that Bluetooth is activated on your smart-
phone. During pairing, make sure that the smart-
phone is in the same room as the BONECO appliance.
Once paired successfully, you can control the
BONECO appliance with your smartphone from the
same room or even from an adjacent room. How-
ever, the maximum distance between smartphone
and BONECO appliance depends on the specific
structural conditions.
PAIRING
1. Make sure that Bluetooth is activated on your
smartphone.
2. Start the BONECO app.
3. Follow the instructions in the app.

17
en
THE VARIOUS OPERATING MODES
HYBRID MODE (“HYBRID”)
The BONECO appliance combines two functions.
• The AH320 pollen filter cleanses breathing air by
removing pollen, household dust and fine par-
ticles.
• The AW200 evaporator mat humidifies the room
air.
You achieve the best results when the BONECO ap-
pliance is humidifying and purifying the air at the
same time. Nevertheless it is possible to use just
one of the two functions.
“HYBRID” LED OPERATING MODE
HUMIDIFICATION ONLY (“HUMIDIFIER”)
We recommend using the BONECO appliance with
inserted AH320 pollen filter even in the winter be-
cause, aside from pollen, it also filters household
dust out of the air. In order to operate the appliance
without the AH320 pollen filter, simply remove the
filter from its holder and use the BONECO app to
switch to “Humidifier” mode.
If you remove the AH320 pollen filter, the maximum
humidifier output rises from about 1.27 gal/day
(200 g/h) to about 2.22 gal/day (350 g/h).
“HUMIDIFIER” LED OPERATING MODE
AH320 POLLEN FILTER ONLY (“PURIFIER”)
In summer, humidity is usually sucient, but pollen
gives people with allergies a dicult time. If you
only want to use the purifying eect of the AH320
pollen filter, switch the BONECO appliance to “Puri-
fier” operating mode using the BONECO app and re-
move the water and the drum from the appliance.
“PURIFIER” LED OPERATING MODE

18
en
COMFORT MODES
There are three dierent comfort modes available
in each of the three “Hybrid”, “Air purification” and
“Air humidification” operating modes: AUTO, SLEEP
and BABY.
AUTO MODE
In AUTO mode, the BONECO appliance uses all of the
fan levels between 1 and 5. The preset humidity is
50%.
SLEEP MODE
In SLEEP mode, the BONECO appliance can even be
used in a bedroom at night. The appliance automat-
ically operates at the lowest fan level of 1 to keep
the operating noise level to a minimum. The preset
humidity is 45%.
BABY MODE
The BABY mode uses fan levels 1 through 4 and in-
creases the humidity to 60%. This value is ideal for
use in a nursery or baby's room since higher humid-
ity is recommended for babies and small children.
The fan also operates quietly enough that it will not
trigger a baby monitor.
THE VARIOUS COMFORT MODES

19
en
USING FRAGRANCES
BASICS
Commercially available fragrances and essential
oils can be inserted into the fragrance container on
the rear side.
Never mix any additives into the water base
itself, since doing so can decrease the per-
formance of the BONECO appliance and even cause
damage. Such damage is not covered by the war-
ranty.
The fragrance container can be cleaned in the
dishwasher. However, the temperature may
not exceed 122°F (50°C).
ADDING FRAGRANCES
1. Press down on the fragrance container to take
out the drawer.
2. Sprinkle the felt insert in the drawer with the fra-
grance of your choice.

20
en NOTES ON CLEANING
ABOUT CLEANING
Regular maintenance and cleaning are necessary
for trouble-free and hygienic operation.
Recommended cleaning and maintenance intervals
vary depending on air quality, water quality and
operating time.
A soft cloth, dish detergent and a scrub brush are
recommended for cleaning by hand.
Always unplug the BONECO appliance from
the power outlet before you begin cleaning.
Failure to do so can result in electric shock and fatal
injury!
If you clean the drum and the water base
in the dishwasher, a temperature of 122 °F
(50°C) may not be exceeded, as temperatures high-
er than this can cause the plastic parts to deform.
RECOMMENDED CLEANING INTERVALS
Interval Action
After the third day without operation Empty water base and fill with fresh water
Every 2 weeks Clean water base, drum and AW200 evaporator mat
Clean the pre-filter
Annually Replacing the AH320 pollen filter
Clean the fan and the inner area of the appliance
