Boneco U700 User manual

U700
MANUAL

Instructions for use 4
Instructions d’utilisation 20
Instrucciones de uso 36

4
en
INSTRUCTIONS FOR USE
BONECO U700

5
en
TABLE OF CONTENTS
Overview and part names 6
Technical specifications 7
Introduction 8
Valuable information about humidity 8
Items included 8
The right location 9
The right location 9
Preparation of the demineralization cartridge 10
Demineralization cartridge preparation 10
Replacing the demineralization cartridge 10
Preparing the Hydro Cell 10
Starting up and switching off 11
Indicators on the display 12
Keypad 13
Humidity and humidifier 14
Save settings 14
Auto mode 14
Controlling humidity 14
Regulate the output 14
Comfort functions and mood light 15
Switching the heater on and off 15
Switching off the mood light 15
Fragrance tray 15
Timer functions 16
Setting the OFF timer 16
Setting the ON timer 16
Cleaning and maintenance 17
Care instructions 17
Descaling 18
Cleaning function 18
Procedure 18
Descaling the appliance 18
Removing limescale residue 18
Replacing the Hydro Cell 19
How it works 19
Preparation 19
Replacements 19

6
en OVERVIEW AND PART NAMES
1Water tank handle
2Humidifier opening
3Water tank
4Opening for demineralization cartridge
5Membrane
6Touch display
7Hydro Cell
8Demineralization cartridge
9Water tank cap
10 Cleaning brush
11 Fragrance tray
12 BONECO U700
1
2
6
4
5
9
8
7
10
11
12
3

7
en
TECHNICAL SPECIFICATIONS
* During operation with pre-heating
Technical specifications
Mains voltage 120 V / 60 Hz
Power consumption 45 W / 180 W*
Humidity output 600 g/h* (4.0 gal/24h*)
For rooms up to 92 m² (1000 square feet)
Water capacity 9.0 liter (2.4 gallons)
Dimension 325×190×360 mm (12.79×7.48×14.17 inch)
Weight (empty) 4.6 kg (10.14 lbs)
Operation noise level <25 dB(A)

8
en
ITEMS INCLUDED
BONECO U700 “EZCal” descaling powder
A7531 demineralization
cartridge
Congratulations on your purchase of the BONECO U700.
This high-performance ultrasonic humidifier keeps the
humidity at a comfortable level at all times.
The BONECO U700 is designed for convenient, fully au-
tomated operation. However, you can adjust all of its fea-
tures according to your preferences and requirements.
This manual shows you how you can create your own
comfortable climate.
VALUABLE INFORMATION ABOUT HUMIDITY
The right humidity is very important for our health. Dry
room air in the winter leads to skin that cracks and itches.
It makes your eyes and throat feel dry while significantly
affecting physical comfort. Not only does this affect
adults, it is especially true for infants, small children and
even pets. Dry mucous membranes in the winter also
make us more prone to colds and other infections.
The BONECO U700 makes these problems a distant
memory. Its intelligent automatic controls always keep
the humidity at the ideal level, even in large rooms with
an area of up to 92 square meters (1000 square feet).
You will not want to give up your newly gained com-
fort.
INTRODUCTION
Hydro Cell

9
en
THE RIGHT LOCATION
The BONECO U700 releases more than half a liter of water
into the air per hour. This makes it important to set up the
appliance in the right location.
Do not place the BONECO U700 directly on the floor,
since the moisture from the mist can damage floor
surfaces such as parquet or delicate carpeting.
• Make sure that the appliance stands about 30 centime-
ters (one foot) away from the closest wall.
• Do not direct the mist toward the wall, plants, furniture
or other objects in order to prevent water condensation
from damaging them. Maintain a distance of at least
50cm (20 inches).
THE RIGHT LOCATION

10
en PREPARATION OF THE DEMINERALIZATION CARTRIDGE
DEMINERALIZATION CARTRIDGE PREPARATION
The BONECO U700 is supplied with a A7531 deminer-
alization cartridge. The granules it contains has to soak
for 24 hours before being used in operation in order to be
most effective.
1. Unscrew the cartridge out of the appliance.
2. Place the cartridge with the cover into a typical house-
hold container filled with cold tap water and let it sit for
24 hours. The cartridge must be fully immersed in the
water.
3. Screw the cartridge back into the BONECO U700.
4. Continue with the instructions on page 11.
REPLACING THE DEMINERALIZATION CARTRIDGE
The cartridge has to be replaced every 2 to 3 months.
In cases of very hard water, it may have to be replaced
sooner. White dust around the appliance is a sure indica-
tion that the cartridge has run its course. You can obtain
replacements from your BONECO specialist dealer or our
online store at www.boneco.us
1. Soak the new cartridge for 24 hours as outlined on the
left.
2. Remove the cover from the old cartridge and dispose
of it with your regular household waste.
3. Screw the cover onto the new, freshly soaked cartridge.
4. Screw the cartridge back into the BONECO U700.
PREPARING THE HYDRO CELL
1. Remove the protective foil from the Hydro Cell.
2. Rinse the new Hydro Cell for 30 seconds under cold tap
water.
3. Put the new Hydro Cell into the water tank of the
BONECO U700.

11
en
STARTING UP AND SWITCHING OFF
5
3
1
4
2
6
Tap to switch on the BONECO U700.
Fill the tank with cold tap water.
Direct the mist into the open room.
Plug the power cord into a power outlet.
Briefly tap once to switch off the blue mood light. Tap again to switch off the BONECO U700
entirely.

12
en INDICATORS ON THE DISPLAY
Overview of all indicators on the display
Symbol Meaning
Current or desired humidity 14
Fully automated operation 14
Heater turned on 15
Timer active 16
Value shows the current humidity 14
Value shows the desired humidity 14
Symbol Required action
Refill the water 17
Change the water in the appliance 17
Cleaning required 18

13
en
KEYPAD
Keypad on the appliance
Symbol Function
Switch heater on/off 15
Access the timer function 16
Change the humidity 14
Automatic mode 14
Regulate the output 14
Switch the appliance on and off / start cleaning 18

14
en
SAVE SETTINGS
The BONECO U700 saves the last-used settings when it
is switched off. However, if the appliance is disconnected
from the power supply for a few seconds, it will start in
the operating mode.
AUTO MODE
In mode the humidification is controlled automati-
cally and the humidity is set to 50%. As soon as the hu-
midity or the humidifier is manually adjusted, however,
the appliance leaves mode.
To return to mode, tap the symbol once.
The heater can be switched on or off without the appli-
ance leaving mode. mode also remains ac-
tive when setting the timer.
CONTROLLING HUMIDITY
The humidity can be set between 30% and 70%. In the
“Co” setting (for “Continuous”), the humidifier runs re-
gardless of the measured humidity. This means it does
not switch off until the tank is empty or the appliance is
switched off.
1. Tap the symbol. The current humidity indicator
starts flashing.
2. While the indicator is flashing, tap the symbol again,
until the desired humidity is set.
The value is applied after a few seconds. The indicator
stops flashing.
REGULATE THE OUTPUT
1. Tap the symbol multiple times, until the desired
level appears on the display.
The symbol on the display shows which of the three levels
(low/medium/high) has been selected:
HUMIDITY AND HUMIDIFIER

15
en
SWITCHING THE HEATER ON AND OFF
The BONECO U700 is equipped with a heater that can be
turned on and off. It warms the outgoing mist up to ap-
proximately 104 °F (40 °C), so that the room temperature
stays at a comfortable level.
It takes a few minutes until the heater reaches its full
output.
1. Tap the symbol once to switch the heater on or off.
SWITCHING OFF THE MOOD LIGHT
The BONECO U700 is switched off in a two-step process
(see page 11).
1. Briefly tap the button once to switch off the blue
mood light. The appliance will remain running.
2. Tap the button again to switch the BONECO U700
into standby mode. Now the air will no longer be hu-
midified and the display will turn off.
In dark environments (such as a bedroom at night),
the display's brightness is automatically reduced. This
means just turning off the mood light is enough to ensure
a good night's sleep undisturbed.
FRAGRANCE TRAY
Commercially available scented aromatic substances for
humidifiers can be added to the fragrance tray on the
back of the BONECO U700.
1. Briefly press the fragrance tray to unlock the drawer.
Never add the aromatic substance directly into the
water tank or water base; doing so will damage the
BONECO U700 and void the warranty!
COMFORT FUNCTIONS AND MOOD LIGHT

16
en
The timer function lets you determine how long the
BONECO U700 should run before it switches off auto-
matically (OFF timer).
Alternatively, you can specify a time for when the ap-
pliance should switch on automatically (ON timer). Use
this function, for example, to activate the BONECO U700
before you return home, so that you have the ideal humid-
ity level waiting for you.
SETTING THE OFF TIMER
1. Switch on the BONECO U700.
2. Select the desired settings.
3. Tap the symbol several times until the desired run
time is displayed.
Now the BONECO U700 will run for the specified time and
then switch off.
4. To deactivate the OFF timer early, switch the BONECO
U700 off and back on as needed.
SETTING THE ON TIMER
1. Switch off the BONECO U700.
2. Tap the symbol several times until the desired
standby time is displayed.
The BONECO U700 switches on after the defined time
and operates with the selected settings.
3. To deactivate the ON timer early, switch the BONECO
U700 off and back on as needed.
TIMER FUNCTIONS

17
en
CARE INSTRUCTIONS
With time and use, the performance of the Hydro Cell
decreases and scale builds up inside the BONECO U700.
Stagnant water can also impair cleanliness and lead to
unpleasant odors. This means regular maintenance and
cleaning is necessary to ensure clean and unimpaired
operation.
Recommended cleaning and maintenance intervals vary
depending on air and water quality, and length of opera-
tion.
Use a soft, damp cloth to clean the exterior.
Always unplug the unit from the power outlet before
cleaning.
CLEANING AND MAINTENANCE
Interval Task
Daily Check the water level; add water if necessary
After 3 days without operation Empty and clean the BONECO U700
Every 2 weeks Clean the water base and the water tank
Every 2 months Replace the Hydro Cell

18
en
CLEANING FUNCTION
The BONECO U700 is equipped with a descaling function.
All you need is a packet of “BONECO EZCal”. One of these
packets is included with the appliance. You can obtain
more EZCal bags from your BONECO specialist dealer or
our online store at www.boneco.us.
The BONECO U700 uses this symbol to indicate that des-
caling is needed:
PROCEDURE
During descaling, the water is heated by the heater for 5
minutes and then pauses for 25 minutes each time. This
process repeats until the cleaning time has elapsed. The
cleaning time can be set between 1 and 4 hours. As a rule:
The longer the cleaning process, the better the results.
DESCALING THE APPLIANCE
1. Switch off the BONECO U700.
2. Empty the water base and the water tank.
3. Remove the HydroCell and the demineralization
cartridge from the water-tank.
4. Mix 1 packet of EZCal with 1 liter (a quarter gallon) of
water and pour the mixture into the water tank.
5. Place the water tank back onto the base of the unit.
6. Press the symbol for 3 seconds. Descaling starts.
7. Tap the symbol repeatedly to set the desired clean-
ing time. The cleaning time increases by one-hour
increments (max. 4 hours).
The symbol for the cleaning mode flashes on the display.
The BONECO U700 switches off automatically once the
cleaning time has elapsed.
8. Empty the water base and fill the water tank with tap
water.
The cleaning symbol goes out. The BONECO U700 is
ready for use again.
REMOVING LIMESCALE RESIDUE
Stubborn limescale residue on the membrane can be re-
moved using the yellow brush stored inside the BONECO
U700.
Never clean the membrane using sharp objects or
aggressive cleaning agents; doing so can damage
the BONECO U700 and voids the warranty!
DESCALING

19
en
REPLACING THE HYDRO CELL
HOW IT WORKS
The BONECO Hydro Cell activates as soon as it comes
into contact with water. Its activated carbon technology
filters helps reduce heavy metals, impurities, chemicals
and remove pesticides from tap water. It also reduces
odor emissions.
It is recommended to replace the Hydro Cell every two
months of use to keep your unit fresh.
The used Hydro Cell can be thrown out with your house-
hold waste.
PREPARATION
1. Remove the protective foil from the Hydro Cell.
2. Rinse the new Hydro Cell for 30 seconds under cold tap
water.
3. Put the new Hydro Cell into the water tank of the U700.
REPLACEMENTS
One Hydro Cell is included with the U700. You can obtain
replacements from your BONECO specialist dealer or our
online store at www.boneco.us.

20
fr
INSTRUCTIONS D’UTILISATION
BONECO U700
