Boneco U350 User manual

READ AND SAVE THESE INSTRUCTIONS
U350
MANUAL

Instructions for use 3
Mode d’emploi 18
Instrucciones de uso 33

3
en
INSTRUCTIONS FOR USE
BONECO U350

4
en TABLE OF CONTENTS
Technical data 5
Introduction 6
Valuable information about humidity 6
Items included 6
Overview and part names 7
Indicators on the display 8
Keypad 9
Preparation of the A250 AQUA PRO 10
A250 AQUA PRO preparation 10
On water hardness 10
Determining water hardness 10
Starting up and switching off 11
The right location 12
The right location 12
Humidity and ultrasonic 13
Save settings 13
“AUTO” comfort mode 13
Controlling humidity 13
Regulating performance 13
Comfort functions 14
Switching the heater on and off 14
Fragrance container 14
Timer functions 15
Setting the OFF timer 15
Setting the ON timer 15
Cleaning and maintenance 16
Care instructions 16
Descaling 17
Descaling the appliance 17
Cleaning the membrane 17
Clearing the cleaning message 17

5
en
* During operation with pre-heating
Mains voltage 120 V / 60 Hz
Power consumption 30 W / 115 W*
Humidity output 3.170 gal/day (500 g/h*)
For rooms up to 650 sq ft / 5,300 cubic ft (60 m2/ 150 m3)
Water capacity 1.32 gallons (5.0 liters)
Dimensions L×W×H 12.1×6.5×12.7 in. (308×165×325mm)
Weight (empty) 6 lb (2.74 kg)
Operation noise level <45dB(A)
TECHNICAL DATA

6
en
ITEMS INCLUDED
BONECO U350 “EZCal” descaling powder
Water hardness test strips
Congratulations on your purchase of the BONECO U350.
This high-performance ultrasonic humidifier keeps the
humidity at a comfortable level at all times.
The BONECO U350 is designed for convenient, fully au-
tomated operation. However, you can adjust all of its fea-
tures according to your preferences and requirements.
This manual shows you how you can create your own
comfortable climate.
VALUABLE INFORMATION ABOUT HUMIDITY
The right humidity is very important for our health. Dry
room air in winter leads to skin that cracks and itches. It
makes your eyes and throat feel dry while significantly af-
fecting physical comfort. Not only does this affect adults,
it is especially true for infants, small children and even
pets. Dry mucous membranes in winter also make us
more prone to colds and other infections.
The BONECO U350 makes these problems a distant me-
mory. Its intelligent automatic controls always keep the
humidity at the ideal level, even in large rooms with an
area of up to 60 square meters (650 square feet).
You will not want to give up your newly
gained comfort.
INTRODUCTION
A250 AQUA PRO

1
2
6
5
7
8
3
4
1Cover
2Nozzle
3Flue
4Touch display
5Cleaning brush
6A250 AQUA PRO
7Fragrance container
8Power supply
7
en
OVERVIEW AND PART NAMES

8
en
Overview of all indicators on the display
Symbol Meaning
Current or desired humidity 13
Fully automated operation 13
Heater turned on 14
Timer active 15
Value shows the current humidity 13
Value shows the desired humidity 13
Symbol Required action
Refill the water 16
Change the water in the appliance 16
Cleaning required 17
INDICATORS ON THE DISPLAY

9
en
Keypad on the appliance
Button Function
Switching unit on and off 17
Regulating output 13
“AUTO” comfort mode 13
Switch heater on/off 14
Access the timer function 15
Change the humidity 13
KEYPAD

10
en
DEMINERALIZATION CARTRIDGE PREPARATION
1. Remove the packaging of the BONECO A250 AQUA PRO.
2. Rinse the A250 AQUA PRO for 2 minutes under cold
running water.
3. Screw the A250 AQUA PRO to the BONECO U350.
ON WATER HARDNESS
The BONECO U350 is supplied with an A250 AQUA PRO.
The granulate contained in it filters the lime out of the tap
water so that it is not released into the room air. Hard tap
water accelerates saturation of the granulate so that the
A250 AQUA PRO must be replaced earlier.
DETERMINING WATER HARDNESS
1. Dip the enclosed test strip into a glass of cold tap water
for 1 second.
2. Read the water hardness after one minute.
3. Refer to the table to determine the duration of effect of
the A250 AQUA PRO:
Dispose of the saturated A250 AQUA PRO with your re-
gular household waste.
The A250 AQUA PRO should not be used longer than spe-
cified. White dust around the appliance is a sure indica-
tion that the A250 AQUA PRO has run its course. You can
obtain replacements from your BONECO specialist dealer
or our online store at www.shop.boneco.us.
= 6 months
= 6 months
= 5 months
= 4 months
= 3 months
= 2 months
PREPARATION OF THE A250 AQUA PRO

11
en
5
3
1
4
2
6
Tap to switch on the BONECO U350.
Fill the tank with cold tap water.
Direct the mist into the open room.
Plug the power cord into a power outlet.
Select the desired output level using the button. Tap again to switch off the BONECO U350
entirely.
STARTING UP AND SWITCHING OFF

12
en
THE RIGHT LOCATION
The BONECO U350 releases more than half a liter of wa-
ter into the air per hour. This makes it important to set up
the appliance in the right location.
Do not place the BONECO U350 directly on the floor,
since the moisture from the mist can damage floor
surfaces such as parquet or delicate carpeting.
• Make sure that the unit stands about 1 ft (30 cm) away
from the closest wall.
• The unit should be placed in an elevated position,
e.g. on a table, chest of drawers, etc.
• Do not direct the mist toward the wall, plants, furniture
or other objects in order to prevent water condensation
from damaging them. Maintain a distance of at least
20 inches (50 cm).
THE RIGHT LOCATION

13
en
SAVE SETTINGS
The BONECO U350 saves the last-used settings when it
is switched off. However, if the appliance is disconnected
from the power supply for a few seconds, it will start in
the operating mode.
“AUTO” COMFORT MODE
In mode the humidification is controlled automa-
tically and the humidity is set to 50%. As soon as the
humidity or the ultrasonic is manually adjusted, however,
the appliance leaves mode.
To return to mode, tap the symbol once.
The heater can be switched on or off without the ap-
pliance leaving mode. mode also remains
active when setting the timer.
CONTROLLING HUMIDITY
The humidity can be set between 30% and 70%. In the
“Co” setting (for “Continuous”), the ultrasonic runs re-
gardless of the measured humidity. This means it does
not switch off until the tank is empty or the appliance is
switched off.
1. Tap the symbol. The current humidity indicator
starts flashing.
2. While the indicator is flashing, tap the symbol again
until the desired humidity is set.
The value is applied after a few seconds. The indicator
stops flashing.
REGULATING PERFORMANCE
1. Tap the symbol multiple times until the desired le-
vel appears on the display.
The symbol on the display indicates which of the three
levels (low/medium/high) has been selected:
HUMIDITY AND ULTRASONIC

14
en
SWITCHING THE HEATER ON AND OFF
The BONECO U350 is equipped with a heater that can be
turned on and off. It warms the outgoing mist up to ap-
proximately 95 °F (35 °C), so that the room temperature
stays at a comfortable level.
It takes a few minutes until the heater reaches its full
output.
1. Tap the symbol once to switch on or off the heater.
FRAGRANCE CONTAINER
Commercially available scented aromatic substances for
humidifiers can be added to the fragrance container on
the back of the BONECO U350.
Never add the aromatic substance directly into the
water tank or water base; doing so will damage the
BONECO U350 and void the warranty!
1. Press down on the fragrance container to unlock the
drawer.
2. Sprinkle the cotton wadding in the drawer with the
fragrance of your choice.
COMFORT FUNCTIONS

15
en
The timer function lets you determine how long the
BONECO U350 should run before it switches off automa-
tically (OFF timer).
Alternatively, you can specify a time for when the appli-
ance should switch on automatically (ON timer). For ex-
ample, you can use this function to activate the BONECO
U350 before you return home, so that when you get back
you have the perfect home climate waiting for you.
SETTING THE OFF TIMER
1. Switch on the BONECO U350.
2. Select the desired settings.
3. Tap the symbol multiple times until the desired run
time is displayed.
Now the BONECO U350 will run for the specified time and
then switch off.
4. To deactivate the OFF timer early, switch the BONECO
U350 off and back on as needed.
SETTING THE ON TIMER
1. Switch off the BONECO U350.
2. Tap the symbol multiple times until the desired
standby time is displayed.
The BONECO U350 switches on after the defined time and
operates with the selected settings.
3. To deactivate the ON timer early, switch the BONECO
U350 off and back on as needed.
TIMER FUNCTIONS

16
en
CARE INSTRUCTIONS
With time and use, the performance of the A250 AQUA PRO
decreases and scale builds up on the inner parts of the
BONECO U350. Stagnant water can also impair cleanli-
ness and lead to unpleasant odors. This means regular
maintenance and cleaning is necessary to ensure clean
and unimpaired operation.
Recommended cleaning and maintenance intervals vary
depending on air and water quality, and operating time.
Use a soft, damp cloth to clean the exterior.
Always unplug the unit from the power outlet before
cleaning.
Interval Task
Daily Check the water level; add water if necessary
After 1 week without operation Empty and clean the BONECO U350
Every 2 weeks Clean the water base and water tank
Every 2-6 months Replacing the A250 AQUA PRO
CLEANING AND MAINTENANCE

17
en
DESCALING THE APPLIANCE
1. Switch off the BONECO U350.
2. Empty the water base and the water tank.
3. Take out the A250 AQUA PRO.
4. Mix 1 bag of EZCal with 32 oz. (0.5 liters) of water
and pour the mixture into the water tank, one half to
the left and right each.
5. Wait 30 minutes to allow the solution to take effect.
6. Rinse the water tank with tap water. Remove remai-
ning lime residue, if any, using a scrub brush.
CLEANING THE MEMBRANE
Stubborn limescale residue on the membrane can be re-
moved using the yellow cleaning brush stored inside the
BONECO U350.
Never clean the membrane using sharp objects or
aggressive cleaning agents; doing so can damage
the BONECO U350 and voids the warranty!
CLEARING THE CLEANING MESSAGE
After completion of cleaning, delete the message by
pressing the button and holding it for 2 seconds.
DESCALING

18
fr
MODE D’EMPLOI
BONECO U350

19
fr
Caractéristiques techniques 21
Introduction 22
Bon à savoir au sujet de l’humidité de l’air 22
Contenu de la livraison 22
Vue d’ensemble et désignation des pièces 23
Affichage à l’écran 24
Clavier 25
Préparation de l’A250 AQUA PRO 26
Préparatifs concernant l’A250 AQUA PRO 26
Informations concernant la dureté de l’eau 26
Mesure de la dureté de l’eau 26
Mise en service et arrêt de l’appareil 27
Le bon endroit 28
Le bon endroit 28
Humidité de l’air et nébuliseur 29
Enregistrement des réglages 29
Mode «AUTO» 29
Ajustement de l’humidité de l’air 29
Ajustement de la puissance 29
Fonctions de confort 30
Mise en marche et arrêt du chauffage 30
Récipient pour substances odorantes 30
Fonctions Minuteur 31
Réglage de la minuterie d’arrêt 31
Réglage de la minuterie de mise en marche 31
Nettoyage et entretien 32
Consignes d’entretien 32
Détartrage 33
Détartrage de l’appareil 33
Nettoyage de la membrane 33
Suppression du message concernant le nettoyage 33

20
fr
* en cas de fonctionnement avec préchauffage
Tension de réseau 120 V / 60 Hz
Consommation électrique 30 W / 115 W*
Performance d’humidification 3.170 gal/day (500 g/h*)
Pour des locaux d’une superficie max. de 650 sq ft / 5,300 cubic ft (60 m2/ 150 m3)
Capacité 1.32 gallons (5.0 L.)
Dimensions L×l×H 12.1×6.5×12.7 in. (308×165×325mm)
Poids à vide 6 lb (2.74 kg)
Niveau sonore <45dB(A)
CARACTÉRISTIQUES TECHNIQUES
