Borglocks BL3030ECP User manual

BL3030ECP & BL3080ECP
Series Instruction Manual
Helpline: [phone]www.borglocks.com
Model
Part No. Descripon BL3030 ECP BL3080 ECP
1Lock Assembly
2Code Card
3Fixing Bolts Washers
4Fixing Bolts
5Fixing Bolt Sleeves
6Latch Bolt Sleeve
7Hex Wrench
8Push Label
9Pull Label
Code C####
PUSH PULL
Part No. Retrot 140mm Centre Adaptor Plate
10 Adaptor Plate
11 Adaptor Plate Fixing Screws
Parts Lists
1
2 43
5 6 7
8 9
10 11
Retrot 140mm Centre Adaptor Plate (S331)

Please check that all the parts are working correctly. Enter the factory preset code as on the code card (Part No.2 ),
rotate the knob way from the edge of the locking mechanism, ensuring that the knob rotates freely and retracts the
latchbolt each time.
For the BL3080 model, check the push/pull fully retracts the latchbolt when pushed/pulled.
The keypad knob and push/pull pad should return easily under its spring pressure.
Preparation & Handing
Latch Bolt Length Adjustment
Please note the minimum latch bolt length is 65mm and the maximum is 90mm. If the (S331) 140mm centre
adaptor plate is tted the minimum latch bolt length would be 60mm with a maximum adjustment of 85mm.
1. Hold the tip of the latch bolt ensuring that it does not move and insert the hex key (Part No.7) into the hole in the
end of the latch bolt.
2. In the centre of the latch bolt hole is a sprung loaded plunger, press the plunger with the hex key and hold. The
latch bolt can then be rotated anti-clockwise to lengthen and clockwise to reduce.
3. When the latch bolt is at the required length the pressure can be released on the plunger. Ensure the bevelled
part of the latch is facing to the left of right and the latch bolt will lock into position and no longer rotate.
Latch Bolt Direction
1. Hold the tip of the latch bolt ensuring that it does not move and insert the hex key (Part No.7) into the hole in the
end of the latch bolt.
2. In the centre of the latch bolt hole is a sprung loaded plunger, press the plunger with the hex key and rotate the
latch bolt to the required direction for the handing of gate. Ensure the bevelled part of the latch is facing to the left of
right and the latch bolt will lock into position and no longer rotate.
HOLD
&
ROTATE
INSERT
&
HOLD
2

1
3
3
4
4
5
5
6
1
10 11
11
34
5
3
45
6
Installation
New Fit Installation Diagram
Retro-t Installation Diagram - W/ S331 Adaptor Plate
3

Code Change Instructions
4
x
The code can be changed with the unit tted on/off the gate. The unit is non sequential, therefore if the code is set to
1234, the keypad will open if entered 4321, 3214 etc..There are over 500 different code combinations available.
The code should be changed with the door in the open position.
To change the code you will need to know what the keypad code is currently set to.
1. Using the hex key (Part No.7) remove the shroud around the top of the keypad to reveal the *button underneath.
2. Enter existing code
3. Press and hold the *button and press the ‘C’ button - this will clear the old code.
4. Still holding down the *button, press the digits that are to be in the new code. Once the new code has been
entered, press all the digits in the code once again to ensure that all the digits in the code are set.
5. Release the *button.
6. Press ‘C’ button or rotate the knob to set the new code.
7. The new code is now set and ready for use. Check that the code is working 5 times and that it is withdrawing the
latchbolt before closing the gate and retting the shroud around the top of the keypad.
Please note: If a new code has been set and it does not work, the ‘C’ button has not been pressed when
clearing the old code and before inputting the new code; therefore the code will be a combination of the new
and old code i.e. if the old code was 1234 and the new code is 6789 the code actually set if 1234-6789. Input
both the old and new code and follow the code change from step 3. If the code has been changed and the
keypad knob is free turning, the new code has not been set. Follow the code change from step 3.
