Bosch Performance Line User manual

Sales:
Hermann Hartje KG
Tel. 04251 - 811-500
[email protected]
www.hartje.de
USER MANUAL
AS ORIGINAL USER MANUAL
DIN EN 15194 / DIN EN 82079-1
E-BIKE (PEDELEC/EPAC)

3
E-bike components
The BOSCH drive systems “Active Line” and “Performance Line”
consist of the components shown here. The two drive systems
differ only with respect to the technical setup of the components
and with respect to the operation in case of the “Nyon” and
“Purion” option.
All other functions and safety devices are identical. Familiarise
yourself with operation, the functions as well as the care and
maintenance notes.
Control computer
Nyon
or
Active Line or
Performance Line
Control unit
Rechargeable battery with indicator
Standard charger
Speed sensor
or
Drive
Purion
WALK
WALK
ALK
W
W
W
W
W
WA
A
A
L
K
K
K
K
K
W
W
W
W
W
W
W
W
WWWW
WW
W
WW
W
WW
W
W
W
WW
W
WW
W
A
A
WW
W
WAWA
WA
W
W
WW
WW
W
A
WAWA
AAAA
AA
A
AA
A
A
AA
A
A
A
A
L
LLLL
L
L
AA
A
AA
A
L
LL
LL
L
K
KKKK
K
K
KK
K
K
KK
K
K
K
K
K
K
K
K
KK
K
KK
K
Compact charger

4
E-bike components 3
Table of contents 4
In an emergency 6
General protective measures 6
In the event of excessive heat 6
In the event of deformation, odour, liquid 6
If the rechargeable battery catches fire 6
Safety 7
General notes and information 7
Be absolutely sure to read the warning notes 7
Labelling of warning notes 7
Charger 10
Residual risks 11
Fundamental information 11
Symbols and terms 11
Symbols on the products 11
Symbols in this manual 12
Written labels 13
Units 13
Notes 13
E-bike 13
Differences between a bicycle and e-bike 13
Functionality 14
Range 14
Cycling with an empty rechargeable battery 14
Drive overheat protection 15
Rechargeable battery 15
Charging times 16
Storing the rechargeable battery 16
Transporting or shipping the rechargeable battery 16
Protective equipment 17
Use 17
Information regarding road traffic 17
Areas of application of the rechargeable battery and charger 18
Insurance 18
Lighting 18
Admissible total weight 18
Exclusion of wearable parts 18
Disclaimer 18
Transport 19
Disposal 19
Before each ride 20
Your first ride 20
Inspection instructions 21
Start-up 21
Preparations 21
Rechargeable battery 21
Charger 21
Removing the rechargeable battery 21
Table of contents

5
Operation 23
Rechargeable battery 23
Inserting the rechargeable battery 23
Charging indicator 23
Checking the charge level of the rechargeable battery 24
Charging the rechargeable battery 24
Control computer 27
Switching on and off 27
Insertion and removal 27
Removal lock 28
Power supply 28
Charging the control computer 29
Changing the batteries 30
Activating the e-bike 31
Deactivating the e-bike 32
Indicators of the control computer 32
Basic settings 35
Purion basic settings 36
Indicators of the Purion control computer 36
Switching Purion control computer on and off 36
Setting the level of assistance 37
Lighting 38
Charging external devices via USB 38
System query with USB 39
Walk assistance 39
Nyon option 40
Start-up 41
Operating notes 43
Control computer 44
Care 51
Checking the speed sensor 52
Error messages 54
Rechargeable battery 56
Charger 56
Technical data 57
Notes 59
Declaration of conformity 61
Legal notice 62
Table of contents

6
In an emergency
In an emergency
You can find notes on handling the rechargeable battery in this
user manual. Despite compliance with all safety measures, the
rechargeable battery poses a risk, e.g. if it catches fire (see chapter
“Residual risks”).
• In an emergency, act in such a way that you do not at any time
endanger yourself or other persons.
• In an emergency, follow the instructions on this page.
• Immediately read these instructions so that you can
concentrate and respond in a calculated manner in the event
of an emergency.
General protective measures
If you identify defects or damages to the rechargeable battery:
1. Do not use the rechargeable battery.
2. Wear protective gloves when you touch the rechargeable
battery.
3. Do not inhale any gases or vapours that are emitted.
4. Avoid contact between your skin and any liquid that is
leaked.
In the event of excessive heat
If you notice that excessive heat is being generated by the
rechargeable battery:
1. Have the rechargeable battery checked by your specialist
dealer immediately.
2. For short-term temporary storage, select an outdoor location
and, if possible, place the rechargeable battery in a fire-proof
container or on the soil.
3. If you store the rechargeable battery outdoors, clearly secure
the area with ample space around the storage location.
In the event of deformation, odour, liquid
If you identify any deformation, odour or liquid leaked on the
rechargeable battery:
1. If possible, do the following if there is no danger: Place the
rechargeable battery in a fire and acid-proof container, e.g.
made of rock or clay.
2. If you are able to transport the rechargeable battery without
any danger: Have your specialist dealer dispose of the
rechargeable battery immediately.
3. Select a fire-proof location outdoors for short-term temporary
storage, e.g. on the soil.
4. If you store the rechargeable battery outdoors, clearly secure
the area with ample space around the storage location.
If the rechargeable battery catches fire
1. Call the fire brigade immediately.
2. If possible, do the following if there is no danger: Use plenty
of water and sand to cool the fire.

7
Safety
Safety
General notes and information
Be absolutely sure to read the warning notes
Read all warnings and notes in this user manual with
care before you operate the e-bike for the first time. This
user manual is a supplementary manual and integral
part of the e-bike user manual. Keep all user manuals so
that they are handy and available at all times. Include the user
manual when passing the e-bike on to third parties.
Labelling of warning notes
The purpose of the warning notes is to draw your attention to
potential hazards. Your complete attention is required for the
warning notes; the statements must be understood completely.
Failure to follow a warning note may result in injury to yourself or
other persons. The warning notes alone cannot prevent dangers.
Follow all warning notes to avoid a risk when using the e-bike.
There are safety notes in the following categories:
WARNING
The signal word “Warning” designates a hazard with
moderate degree of risk which may lead to death or
severe injury if not avoided.
CAUTION
The signal word “Caution” designates a hazard with
low degree of risk which may lead to minor or moderate
injury if not followed.
NOTICE
The signal word “Notice” warns against potential
damage to property.

8
Safety
WARNING
Risks for children and persons with impaired
physical, sensory or mental capacities or lack
of experience and knowledge, e.g. children
or persons with impaired mental and physical
capacities.
The e-bike, rechargeable battery and the charger may
only be used by persons, who are able to act without
restriction with respect to their mental and physical
abilities. There is a high risk of injury for persons with
restricted mental and physical capacities.
• Only allow the e-bike, rechargeable battery and the
charger to be used by persons briefed on safe and
proper use and who understand the risks arising in
connection with it.
• Do not let children, young persons and persons without
a vehicle operator’s license play with the e-bike.
WARNING
Risk of accident and injury!
There is an increased risk of accident and injury if the
bicycle is used in an improper manner or with disregard
for regulations.
• Do not repair the e-bike yourself.
• Have repairs performed by your specialist dealer.
CAUTION
Risk of damage!
High or low temperatures could restrict the functioning
of the e-bike or damage it.
• Take note of the temperature limits.
• Do not park the e-bike near heat sources.

9
Safety
CAUTION
Danger to health and the environment!
Lithium could be leaked if the rechargeable battery is
damaged. Lithium causes severe burns to the skin.
• Do not touch the damaged rechargeable batteries with
bare hands.
CAUTION
Risk of damage!
Improperly charging the rechargeable battery can
damage the rechargeable battery and the drive.
• Do not charge the rechargeable battery if you suspect
that it is damaged.
• Before charging the rechargeable battery for the first
time, be absolutely sure to read the chapter “Charging
the rechargeable battery”.
• Only use the original charger to charge the rechargeable
battery and only under supervision.
• While charging the rechargeable battery, always place it
on non-flammable materials (e.g. stone, glass, ceramics).
• If you are not absolutely sure how to handle lithium
ion rechargeable batteries, have a qualified specialist
explain how to do so.
WARNING
Risk of fire and explosion!
Rechargeable batteries that have caught fire are very
difficult to extinguish; the cells affected must burn down
in a controlled manner. Responding properly may
prevent severe damages.
• Read the chapter “In an emergency” so that you are
properly prepared.
WARNING
Risk of fire and explosion!
Internal damages to the rechargeable battery may cause
the rechargeable battery to overheat, emit gases or
leak liquids even a significant amount of time after the
damage occurred.
• Have your specialist dealer inspect the rechargeable
battery after falls or severe impacts.
• Do not open, dismantle, drill through or deform the
rechargeable battery.

10
Safety
CAUTION
Risk of damage!
Incorrect use of the rechargeable battery could cause
damage to the rechargeable battery, the drive or
surrounding objects, e.g. due to overheating.
• Only use the rechargeable battery included in the
product contents for the original drive.
• Only use original rechargeable batteries approved for
use with the original drive.
• Keep the rechargeable battery away from fire and other
heat sources; protect it against exposure to intense
sunlight.
• Protect the rechargeable battery against moisture.
Never clean or spray the rechargeable battery with liquids.
Do not use the rechargeable battery if you notice any
unusual warmth, odour or discolouration and/or if the
rechargeable battery exhibits obvious damages.
Charger
WARNING
Risk to life!
Incorrect handling of electrical current and corresponding
components poses a risk to life due to electric shock.
• Check the charger, mains cord and mains plug for
damage before each use.
• If you identify or suspect damages, do not use the
charger.
• Only use the charger indoors.
• Only connect the charger to a properly installed power
supply “220 to 240 V ~ (50 Hz)”.
• Set up the charger so that it is not able to become
moist or wet, e.g. due to splashing water.
• Never clean or spray the charger with liquids.
• While charging the charger, always place it on
non-flammable materials (e.g. stone, glass, ceramics).
Do not open, dismantle, drill through or deform the
charger.

11
Fundamental information
• Only have the charger repaired by qualified professionals
with original spare parts.
• Only use the charger to charge the original rechargeable
battery or equivalent replacement rechargeable batteries.
• Always pull the mains plug out of the socket after use.
• Read the additional safety notes on the housing of the
charger.
Residual risks
Using the e-bike is associated with the following unforeseeable
residual risks despite compliance with all safety notes:
Risk of injury
-Gases, vapours and liquids could leak out of the rechargeable
battery due to internal, invisible damages and in the event of
fire. Injuries to external and internal organs are possible, e.g.
in the event of contact with skin or inhalation of the gases (see
chapter “In an emergency”).
Fire hazard
Internal, invisible damages can cause the rechargeable battery to
catch fire and ignite objects in the surrounding area (see chapter
“In an emergency”).
Risk of damage
-If the rechargeable battery catches fire, hydrofluoric acid leaks
out with the smoke gas. Hydrofluoric acid is highly corrosive
and causes permanent damage to surfaces (see chapter
“In an emergency”).
Fundamental information
Symbols and terms
Symbols on the products
The following symbols are located on the packaging, the
rechargeable battery or the charger:
Label for electrical devices that you must not dispose
of with household waste. You are obligated by law
to dispose of correspondingly labelled products at
suitable recycling points for environmentally-friendly
recycling.
Label for rechargeable batteries and batteries that you
must not dispose of with household or other garbage.
You are obligated by law to dispose of correspond-
ingly labelled products at suitable recycling points for
environmentally-friendly recycling.

12
Fundamental information
Label for environmentally-harmful hazardous substances.
Exercise special caution when handling products
labelled as such. Observe disposal guidelines!
Label for waste materials intended for recycling.
Sort the packaging before you dispose of it. Dispose
of cardboard and carton as waste paper and foils via
the recyclable material collection service.
Symbol confirming conformity with guidelines for
products corresponding to the requirements of the
European General Product Safety Directive.
Labelling for products that may only be used indoors.
The 230 V ~/50 Hz mains connection corresponds to
protection class II.
Symbol for direct current (DC).
Symbols in this manual
1. Steps to be performed in a particular order begin
with a number.
•Steps to be performed in no particular order begin
with a dot.
–Lists begin with a so-called dash.
NOTICE: Supplementary notes regarding steps to be
performed or use.
Terms
Terms with “nominal”: Nominal output, nominal capacitance etc.
are values stipulated according to the design. The actual values
may differ from the nominal values depending on operating con-
ditions.
E-bike (Pedelec/EPAC): An e-bike is a bike powered by an elec-
trical auxiliary motor. E-bikes of this kind are also referred to as
pedelecs (pedal electric cycle) or EPAC (electric power assisted
cycles). The term “e-bike” will be used hereinafter.
Capacitance: The amount of electrical charge in the unit “Ah” if the
rechargeable battery has been completely charged (see chapter
“Fundamental information > Symbols and terms > Units”).
Charging cycle: Refers to fully charging a completely depleted
rechargeable battery.

13
Notes
Memory effect: Refers to the loss in the capacitance of recharge-
able batteries if they are not completely charged (does not apply
to lithium ion rechargeable batteries).
Pedal drive: Assembly consisting of pedal, crank arm and chain
wheel.
Temperature limits: Minimum and maximum temperature at
which the corresponding component may be used. At the same
time, both the temperature limits for the component as well as for
the ambient temperature may be specified.
Pedalling frequency: Number of revolutions of the pedal drive in
one minute expressed in the unit “1/min”.
Written labels
-Image captions and references in the text are rendered in italics .
Units
Unit Meaning Unit for
1/min per minute Revolutions
AAmperes Electric current (=W/V)
Ah Ampere hour Electric charge (=Wh/V)
gGram Weight (=kg/1000)
Hz Hertz Frequency (Hz=oscillation/s)
kg Kilogramme Weight (=g×1000)
Nm Newton meter Torque
VVolt Electric voltage (=W/A)
WWatt Electric power (A/V)
Wh Watt hour Electric capacitance (=V×Ah)
Notes
E-bike
Differences between a bicycle and e-bike
The additional components of the electric drive constitute the
major differences between a conventional bike and an e-bike.
-The e-bike's weight is considerably greater and its weight is
distributed differently than with conventional bikes. This results
in different handling.
-The drive has a significant effect on braking characteristics.
-E-bikes require greater braking forces. This may result in greater
wear than with conventional bicycles.
-The electrical assistance will increase your average speed.
• You should therefore cycle attentively. Keep in mind that
other road users must get used to the increased speed of
the e-bike.
-The bike's handling and braking as well as handling of the
rechargeable battery and charger require an appropriate level
of knowledge.
• Familiarise yourself with the characteristics of your e-bike
even if you already have some experience with electric
assisted bicycles (see chapter “Notes > Use > Before your
first ride”).

14
Notes
Functionality
The drive only provides you with riding assistance when you
pedal. The intensity of assistance is automatically adjusted
depending on the selected riding mode, the pressure applied
when pedalling, the load and the speed. The drive assists you
up to a speed of 25 km/h.
Range
The drive is an assistive motor. The range is affected by your
pedalling intensity.
• Set the assistance as low as possible.
The lower the pedalling frequency of the pedal drive the higher
the energy requirement for the drive.
• Use the gear shift as you would without assistance.
• For inclines, head wind or a heavy load, use the lower gears
of the gear shift.
The drive requires a large amount of energy when starting.
• Always start in a low gear and apply as much pressure to the
pedal as possible.
• Before travelling uphill, switch to a lower gear in time.
• Ride with foresight in order to prevent unnecessary stops.
Energy consumption increases under heavy loads.
• Do not transport any unnecessary loads.
Lack of care and maintenance may reduce the range.
• Handle the e-bike with care and observe all notes regarding
the rechargeable battery in this user manual.
• Check the tyre pressure regularly.
• Comply with the maintenance intervals.
Temperatures below +10 °C may negatively affect the perfor-
mance of the rechargeable battery during operation. When you
are not using your e-bike:
• At low outdoor temperatures, take the rechargeable battery out
of the holder and store it (see chapter “Notes > Rechargeable
battery > Storing the rechargeable battery”).
• Only put it back in the holder directly before cycling.
Cycling with an empty rechargeable battery
If the rechargeable battery is completely used up during the ride,
you can use your e-bike as you would a normal bike (see chapter
“Operation > Rechargeable battery > Charging indicator”).
NOTICE: If the battery charge has been used up, the drive will
switch off. The lighting will be supplied with energy for another
2 hours.

15
Notes
Drive overheat protection
CAUTION
Risk of injury!
The drive and rechargeable battery can become very hot
if a fault is at hand. You could injure yourself in the event
of contact with your skin.
• Do not touch the drive and the rechargeable battery.
The drive is automatically protected against damage caused by
overheating. If the temperature of the drive is too high, the drive
will automatically switch off.
• To prevent the drive from overheating, set a low level of assis-
tance at high outdoor temperatures or roads or paths with a
substantial incline (see chapter “Operation» E-bike > Setting
the level of assistance”).
• If the drive is switched off when the rechargeable battery is
charged and at a speed of under 25 km/h, do not use the e-bike
temporarily to allow the drive to cool off.
• If allowing the drive to cool off does not resolve the
disturbance,
have your specialist bike dealer inspect the
e-bike.
Rechargeable battery
Your e-bike is equipped with a high-quality lithium-ion recharge-
able battery (Li-ion rechargeable battery). Li-ion rechargeable
batteries are safe if used properly.
Li-ion rechargeable batteries have a relatively high energy den-
sity. Therefore, this rechargeable battery must be handled with
great care. For your safety, be absolutely sure to observe the
following notes to ensure reliable operation and a long life-cycle:
Partial charging does not damage the rechargeable battery as
it does not have a memory effect. Partial charging is evaluated
according to its capacitance (a charge of 50 % corresponds to
½ charge cycle).
NOTICE
Risk of damage!
Self-discharge of the rechargeable battery for technical
reasons may cause irreparable damages.
• Immediately recharge the rechargeable battery if empty.
• Take note of the temperature limits of the rechargeable battery
(see chapter “Technical data”).
• Please note that outside temperatures under +10°C may
reduce the power of the rechargeable battery.
• Keep in mind that the output of the rechargeable battery
may begin to decline after 500 complete charging processes
(charging cycles).
• Keep in mind that you will get used to cycling with electrical
assistance after a while. This may result in a perceived drop in
the output of the rechargeable battery.
• If there is a loss of power or the operating time is significantly
reduced, contact your specialist dealer.

16
Notes
• Never perform any modifications on the rechargeable battery.
NOTICE: You can find more information about the rechargeable
battery in the chapter “Operation > Rechargeable battery”.
Charging times
If the rechargeable battery is empty, a full charge cycle requires
4 to 6 hours. The duration of the rechargeable battery charge
cycle depends on the following factors:
-Battery capacitance
-Charge level of the rechargeable battery.
-Temperature of the rechargeable battery and surroundings.
Storing the rechargeable battery
If you do not use the rechargeable battery for a prolonged period
of time, please store it as follows:
• Charge the rechargeable battery to approximately 60 to 80%
of the capacitance.
• For storage, take the rechargeable battery out of the holder
and place it in a safe location.
• Store the rechargeable battery so that there is no risk of it falling
down and so that it is out of reach of children and animals.
• If possible, store the rechargeable battery at room temperature
in a dry, well ventilated area.
• If you are not using the rechargeable battery for a prolonged
period of time,
it is best to store the rechargeable battery in
a well ventilated location such as a basement at approx. +10 to
+15 °C.
• Protect the rechargeable battery against moisture and water.
• Make sure that the top and bottom temperature limit is not
exceeded or underrun during storage (see chapter “Technical
data”).
• For storage exceeding 3 months, please recharge the
rechargeable battery every quarter to half year depending on
storage conditions. Then charge the rechargeable battery to
approx. 60 to 80% of the capacitance.
• After the charging process, always disconnect the charger
from the rechargeable battery and pull the mains plug out of
the socket.
Transporting or shipping the rechargeable
battery
Lithium ion rechargeable batteries are subject to the requirements
of dangerous goods legislation. The private user may transport
undamaged rechargeable batteries on the road without any
further requirements.
• Please note that the special requirements for packaging and
labelling e.g. during air transport or shipping orders apply for
commercial transport.
• Contact the forwarding company or your specialist bicycle
dealer directly for information regarding the transport of the
rechargeable battery and suitable transport packaging.
NOTICE: Read the chapter “Notes > Use > Transport” for
information on how to transport the e-bike.

17
Notes
Protective equipment
Overheat protection
The rechargeable battery is equipped with a temperature monitor.
It can only be charged at temperatures between 0 °C and 40 °C.
If the rechargeable battery is not within the temperature range for
charging, the three LEDs on the charge indicator will flash.
• Disconnect the rechargeable battery from the charger and let
it reach the operating temperature.
• Only connect the rechargeable battery to the charger again
once it has reached the permissible charging temperature.
CAUTION
Risk of injury!
Temperatures of over 40 °C can cause injury to the skin.
• If the charging process has ended prematurely, let the
rechargeable battery cool off.
1. Pull the mains plug out of the socket.
2. Once the rechargeable battery has cooled off, pull the charging
plug out of the charging slot.
3. Have your specialist dealer inspect the rechargeable battery.
Fig.: H-1 Indicator for errors “Overheat protection” (left) and “ECP”
(right) on the rechargeable battery indicator.
Electronic cell protection (ECP)
The “electronic cell protection (ECP)” protects the rechargeable
battery against
deep discharge, overcharging and short-
circuiting. If
there is a risk, a protective circuit will automatically
deactivate the rechargeable battery. If a defect is detected in the
rechargeable battery, two LEDs on the charge indicator will flash
(see Fig.: H-1).
• If the “ECP” error appears, have the rechargeable battery
inspected by your specialist dealer.
Use
Information regarding road traffic
The assistance provided by e-bikes is effective up to a speed of
25 km/h. The technical configuration of your e-bike complies with
the European standard EN15194 for electrically power assisted
bicycles and the bicycle standard DIN ENISO 4210.
• Seek information regarding the relevant applicable
road traffic
regulations for the country or the region, e.g. from
the Ministry
of Transport.

18
Notes
• Ensure that you regularly obtain information regarding changes
to the content of valid regulations.
Areas of application of the rechargeable battery
and charger
The drive unit, rechargeable battery and charger are configured
for use with one another and are approved only for use with your
e-bike.
Insurance
• Check whether the conditions of your insurance policies (e.g.
liability insurance, household contents insurance) sufficiently
cover damages.
• In case of doubt, contact your insurer.
Lighting
Your e-bike is equipped with rechargeable battery-powered lighting.
The rechargeable battery must always be inserted when using
public roads so that the lighting is operational at all times.
Admissible total weight
The total admissible weight of your e-bike is specified on the
CE sticker. The sticker is located on the inside of the chain stays.
gefertigt nach DIN 15194
Nenndauerleistung 250W bis 25km/h
zulässiges Gesamtgewicht Kg
Hermann Hartje KG .Deichstraße 120-122
27318 Hoya/Weser .Germany .www.e-rad.de
BJ: 2017
140
Fig.: CE sticker specifying the total admissible weight.
Exclusion of wearable parts
In addition to the wearable parts listed in the user manual for
the bicycle, the rechargeable battery – with the exception of
production defects – is not covered by the warranty.
Disclaimer
The manufacturer cannot be held liable for damages or break-
downs resulting from direct or indirect use of the e-bike.

19
Notes
Transport
WARNING
Risk of short-circuiting and fire!
The lithium ion rechargeable battery is considered a
dangerous good and may be damaged if exposed to
shocks and impacts without such damages being
externally apparent.
• When transporting your e-bike, remove the rechargea-
ble battery and store it separately.
• Transport the rechargeable battery with special care.
• To rule out any risks and damages, transport the e-bike as
follows:
• Remove the rechargeable battery before transport (see the
chapter “Notes > Rechargeable battery > Transporting or
shipping the rechargeable battery”).
By car
• Store the rechargeable battery so as to prevent slipping and
collision with other objects during the trip.
• Properly secure the load to protect the rechargeable battery
against compressive loads and avoid shocks.
• Store the rechargeable battery so that it is unable to be heated
up by exposure to the sun or other heat sources.
With e-bikes, the forces from braking and lateral forces that act
on the bike rack are stronger than with conventional bicycles.
• Check whether your bike rack is suitable for e-bikes.
• Ask your specialist dealer about suitable bike racks for your
e-bike.
Using other forms of transportation
When transporting e-bikes with the rechargeable battery, special
guidelines, which are constantly being expanded or updated, apply.
These guidelines may differ from one another depending on the
form of transportation.
• Contact the airline, train or ferry company in due time to get
informed regarding valid provisions that apply for the trans-
port of e-bikes. Have the technical data handy for this purpose.
Shipping
• If you ship your e-bike, ship the rechargeable battery separately
and well packed in a suitable transport container (see chapter
“Notes > Rechargeable battery > Transporting or shipping the
rechargeable battery”).
Disposal
• Read the explanation of the symbols printed or stamped on
the packaging, the rechargeable battery and the charger (see
chapter “Fundamental information > Symbols and terms”).
• Contact your specialist dealer or the appropriate authorities for
information on disposal.

20
Notes
Packaging
• Dispose of the packaging material for environmentally-friendly
recycling using the collection systems provided.
Rechargeable battery and charger
• Do not dispose of rechargeable batteries, electric components
and the charger with household waste.
According to European Directive 2012/19/EU, electrical devices
that are no longer functional must be collected separately and
made available for environmentally-friendly use.
According to European Directive 2006/66/EC, defective or used up
rechargeable batteries and batteries must be collected separately
and made available for environmentally-friendly re-use.
• Dispose of the rechargeable battery and the charger at a
collection point for electrical devices.
E-bike
• Dispose of the e-bike at your specialist dealer or a waste handler.
Before each ride
• Check your e-bike according to the chapter “Check list” in this
user manual and in the user manual for your bicycle.
CAUTION
Risk of injury!
The e-bike may respond in a manner other than you
expect if operated incorrectly.
• Read the chapter “Operation” completely before you
switch it on for the first time.
• Fully charge the rechargeable battery before your first ride (see
chapter “Start-up”).
Your first ride
• Practice operating and using it in an open area away from
public traffic.
• Practice on level, solid ground with adequate grip.
1. Select the lowest level of assistance on the control unit (see
chapter “Operation > E-bike > Setting the level of assistance”).
Start slow.
2. Operate the brakes with care and get used to the braking effect.
3. Once you are able to safely operate the brakes, familiarise
yourself with the fully automatic assistance.
4. Once you are able to ride safely, repeat the familiarisation
phase and test the brake in other riding modes.
5. Practice using the walk assistance function (see chapter
“Operation > E-bike > Walk assistance”).
