Bosch B5512 User manual

Control Panel
B5512/B4512/B3512 (B5512E/B4512E/B3512E)
en Installation and System Reference Guide

Table of contents
1Certifications, approvals, listings, and safety 8
1.1 Listings and approvals 8
1.1.1 UL 8
1.1.2 ULC 8
1.1.3 Security Industry Association (SIA) 8
1.1.4 Department of Defense (DoD) 8
1.1.5 California State Fire Marshal (CSFM) 8
1.1.6 National Institute of Standards and Technology (NIST) 8
1.1.7 Federal Communications Commission (FCC) Rules 8
1.1.8 Industry Canada (IC) 9
1.2 Lightning 9
1.2.1 Effects of lighting 9
1.2.2 Installation precautions 9
1.2.3 Warranty 10
2Introduction 11
2.1 About documentation 11
2.1.1 Related documentation 11
2.2 Bosch Security Systems, Inc. product manufacturing dates 13
3System overview 14
3.1 Configuration and parts 15
3.1.1 Control panel capacities 15
3.1.2 Parts list 15
3.1.3 Order separately 16
3.2 Accessories 16
3.3 Features 20
3.3.1 SDI2 interconnect wiring 20
3.3.2 Points 20
3.3.3 Areas and accounts 20
3.3.4 Digital communication 21
3.3.5 Keypads 21
3.3.6 Events 21
3.3.7 Programming 21
3.3.8 Firmware updates 21
4Installation checklist 22
5Control panel installation 23
5.1 Install the enclosure and wiring label 23
5.2 Install the control panel 23
5.2.1 Mount the control panel 23
5.2.2 Connect earth ground 25
5.2.3 Configure OUTPUT A using the jumper 25
5.3 Control panel to module wiring overview 26
6Power supply 28
6.1 Primary (AC) power 28
6.1.1 Install the transformer 28
6.2 Secondary (DC) power 28
6.2.1 Install the battery 29
6.2.2 Battery maintenance 30
Control Panel Table of Contents | en 3
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

6.2.3 Battery supervision 31
6.2.4 Battery discharge and recharge schedule 31
6.3 B520 Auxiliary Power Supply 31
6.3.1 SDI2 address settings 31
6.3.2 Supervision 32
6.3.3 Auxiliary power supply trouble conditions 32
6.3.4 Installation and control panel wiring (B520) 32
6.3.5 Powered device and battery wiring 33
7Telephone communications 35
7.1 B430 Plug-in Telephone Communicator 35
7.1.1 Supervision 35
7.1.2 Installation and module wiring (B430) 35
7.1.3 Diagnostic LEDs 36
7.2 Phone jack location 36
7.3 Telephone line monitor 37
7.4 Called party disconnect 38
7.5 Communication failure 38
8IP communications 39
8.1 On-board Ethernet connection 39
8.1.1 Supervision 39
8.1.2 Local RPS programming 39
8.1.3 On-board Ethernet diagnostic LEDs 40
8.2 Conettix Plug-in Cellular Communicators 41
8.2.1 Supervision 41
8.2.2 Installation and module wiring (B44x) 41
8.2.3 Signal strength and diagnostic LEDs 42
8.3 B426 Ethernet Communication Module 43
8.3.1 Address and emulation settings 43
8.3.2 Supervision 43
8.3.3 B426 module faults 44
8.3.4 Local RPS programming 44
8.3.5 Installation and control panel wiring (B426) 44
8.3.6 Diagnostic LEDs 46
8.4 B450 Conettix Plug-in Communicator Interface 47
8.4.1 SDI2 address settings 48
8.4.2 Supervision 48
8.4.3 Installation and control panel wiring (B450) 48
8.4.4 Diagnostic LEDs 49
8.5 Compatible receivers for IP communication 50
9Keypads, keyswitches, keyfobs and transmitters 52
9.1 Keypads 52
9.1.1 B915 Basic Keypad 52
9.1.2 B920 Two-line Alphanumeric Keypad 52
9.1.3 B921C Two-line Capacitive Keypad with Inputs 52
9.1.4 B930 ATM Style Alphanumeric Keypad 52
9.1.5 B942 Touch Screen Keypad 53
9.1.6 Shortcuts and custom functions 53
9.1.7 Address settings 53
9.1.8 Supervision 53
4en | Table of Contents Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

9.1.9 Installation and control panel wiring (keypads) 53
9.1.10 Sensor loops overview and wiring (B921C/B942/B942W only) 54
9.1.11 Output wiring (B942/B942W only) 55
9.1.12 Troubleshooting 55
9.2 Keyswitches 55
9.2.1 Operation 56
9.2.2 Installation and control panel wiring (keyswitches) 56
9.3 RADION keyfobs and Inovonics pendant transmitters 57
10 On-board outputs 58
10.1 Circuit protection 58
10.2 Total available power 58
10.3 Open collector outputs 59
11 Off-board outputs 60
11.1 B308 Octo-output Module 60
11.1.1 SDI2 address settings 60
11.1.2 Supervision 61
11.1.3 Installation and control panel wiring (B308) 61
12 On-board points 63
12.1 Point sensor loops 63
12.1.1 Single EOL resistor circuit style 63
12.1.2 Dual EOL resistor circuit style 65
12.2 Point response time 65
13 Off-board points 66
13.1 B208 Octo-input Module 66
13.1.1 SDI2 address settings 66
13.1.2 Supervision 66
13.1.3 Installation and control panel wiring (B208) 67
13.1.4 Sensor loops overview and wiring 68
13.2 Test off-board points 70
13.3 Extra Point events 70
14 Wireless modules 71
14.1 B810 receiver 71
14.1.1 SDI2 address settings 71
14.1.2 Supervision 71
14.1.3 Installation and control panel wiring (B810) 71
14.2 B820 SDI2 Inovonics Interface Module 72
14.2.1 SDI2 address settings 72
14.2.2 Supervision 72
14.2.3 Installation and control panel wiring (B820) 72
15 Program and test the control panel 74
15.1 Program the control panel 74
15.2 Perform walk tests 74
15.2.1 Fire walk test 74
15.2.2 Intrusion walk test 75
15.2.3 Service walk test 75
15.2.4 Invisible walk test 76
16 Control panel board overview 77
17 System wiring diagrams 79
17.1 System wiring overview 79
Control Panel Table of Contents | en 5
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

17.2 Battery lead supervision wiring 81
17.3 2-wire smoke wiring (B201) 82
17.4 2-wire smoke wiring (D125B) 83
17.5 Notification appliance circuit wiring 83
17.6 SDI2 devices general system wiring 85
17.6.1 SDI2 bus wiring recommendations 85
17.7 Wiring label 89
18 Approved applications 90
18.1 Optional compatible equipment 90
18.1.1 Burglar applications 90
18.1.2 Bank safe and vault applications 90
18.1.3 Fire applications 93
18.1.4 Enclosures 94
18.2 Combination fire and intrusion alarm systems 95
18.3 Compatible UL listed components 95
18.4 Standby battery requirements and calculations 97
18.4.1 Household Fire Warning equipment 99
18.5 UL 365 - Police Station Connected Burglar Alarm Units and Systems 99
18.6 UL 636 - Holdup Alarm Units and System 100
18.7 ULC 100
19 Keypad Installer menu 101
19.1 [1] Program menu 107
19.1.1 [1] Reporting > [1] Phone menu parameters 107
19.1.2 [1] Reporting > [2] Network menu parameters 108
19.1.3 [1] Reporting > [3] Routing menu parameters 110
19.1.4 [1] Reporting > [4] Personal Note menu parameters 112
19.1.5 [2] Network > [1] Ethernet > (choose the bus module or on-board) > [1] Module
Parameters menu
113
19.1.6 [2] Network > [1] Ethernet > (choose the bus module or on-board) > [2] Address
Parameters menu
114
19.1.7 [2] Network > [1] Ethernet > (choose the bus module or on-board) > [3] DNS
Parameters menu
116
19.1.8 [2] Network > [2] Cellular > (choose the SDI2 cellular module or plug-in module) 117
19.1.9 [3] RPS > [1] RPS Passcode menu parameters 119
19.1.10 [3] RPS > [2] RPS Phone Number menu parameters 120
19.1.11 [3] RPS > [3] RPS IP Address menu parameters 120
19.1.12 [3] RPS > [4] RPS Port Number menu parameters 121
19.1.13 [4] Area Options menu parameters 121
19.1.14 [5] Keypad menu parameters 122
19.1.15 [6] Users menu parameters 123
19.1.16 [7] Points menu parameters 124
19.1.17 [8] Disable Programming menu 133
19.2 [2] Wireless menu 134
19.2.1 [1] RF Point Menu> [1] Enroll Point RFID 134
19.2.2 [1] RF Point Menu> [2] Replace Point RFID 134
19.2.3 [1] RF Point Menu> [3] Remove Point RFID 135
19.2.4 [2] RF Repeater Menu > [1] Add Repeater 135
19.2.5 [2] RF Repeater Menu > [2] Replace Repeater 136
19.2.6 [2] RF Repeater Menu > [3] Remove Repeater 137
6en | Table of Contents Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

19.2.7 [3] RF Diagnostic Menu > [1] RF Points 137
19.2.8 [3] RF Diagnostic Menu > [2] RF Repeater Menu 138
19.3 [3] Diags menu 139
19.3.1 [1] Wireless 139
19.3.2 [2] Network menu 139
19.3.3 [3] Cellular menu 140
19.3.4 [4] IP Camera 140
19.4 [4] Serv Byp (Service Bypass) menu 141
19.5 [5] Versions menu 141
19.6 [6] Cloud menu 143
19.6.1 [1] Setup 143
19.6.2 [2] Status 144
20 Specifications 145
20.1 Wire requirements 147
21 Reporting and device number information 148
21.1 Report format definitions 148
21.2 SDI2 address information 156
21.3 Device numbers (zzz, dddd) 157
21.4 Communication Trouble device numbers (zzzz) 157
21.5 Special User IDs (uuuu, iiii) 157
21.6 Keypad alarm virtual point numbers (ppp, pppp) 158
Control Panel Table of Contents | en 7
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

Certifications, approvals, listings, and safety
This section provides certification and approval listings and safety information.
Listings and approvals
This document includes the section Approved applications, page 90. Refer to this section for
guidelines on installing the control panels in Underwriters Laboratories Inc. (UL) and fire-
specific applications.
UL
Listed for:
– UL 365 - Police Station Connected Burglar Alarm Units and System
– UL 609 - Local Burglar Alarm Units and System
– UL 636 - Holdup Alarm Units and System
– UL 985 - Household Fire Warning System Units
– UL 1023 - Household Burglar Alarm Units and System
– UL 1076 - Proprietary Burglar Alarm Units and System
– UL 1610 - Central Station Burglar Alarm Units
– UL 1635 - Digital Alarm Communicator System Units
ULC
Listed for:
– ULC C1023 - Household Burglar Alarm System Units
– ULC C1076 - Proprietary Burglar Alarm Units and System
– ULC S303 - Local Burglar Alarm Units and System
– ULC S304 - Central and Monitoring Station Burglar Alarm Units
– ULC S545 - Residential Fire Warning System Control Units
Security Industry Association (SIA)
Listed for Control Panel Standard - Features for False Alarm Reduction ANSI/SIA CP-01-2010.
Department of Defense (DoD)
The B5512/B4512/B3512 control panels were granted approval for Department of Defense
(DoD) installations in Sensitive Compartmented Information Facilities (SCIF).
California State Fire Marshal (CSFM)
Listed for Household Fire Alarm.
National Institute of Standards and Technology (NIST)
When communicating via a network, listed for Advanced Encryption Standard (AES), Federal
Information Processing Standards Publication 197 (FIPS 197).
Federal Communications Commission (FCC) Rules
Part 15
This equipment was tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy; and if not installed
and used according to the instructions, can cause harmful interference to radio
communications.
1
1.1
1.1.1
1.1.2
1.1.3
1.1.4
1.1.5
1.1.6
1.1.7
8en | Certifications, approvals, listings, and safety Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

Operation of this equipment in a residential area is likely to cause harmful interference, in
which case the user is required to correct the interference at his or her own expense.
Part 68
The B430 module by Bosch Security Systems, Inc. is registered with the Federal
Communication Commission (FCC) under Part 68, for connection to the public telephone
system using an RJ31X or RJ38X phone line connection jack installed by the local telephone
company.
Do not connect registered equipment to party lines or coin-operated telephones. Notify the
local telephone company and provide the following information before connecting the control
panel to the telephone network:
– The particular line to which you connect the module
– Make (Bosch Security Systems, Inc.), model (B5512/B4512/B3512), and serial number of
the control panel
– FCC registration number: ESVAL00BB430
– Ringer eq: 0.0B
Industry Canada (IC)
ICES-003 - Information Technology Equipment
This Class B digital equipment meets all requirements of the Canadian interference-causing
equipment regulations.
Cet appareil numérique de la Class A respecte toutes les exifences de règlement sue le
matériel brouilleur du Canada.
CS-03 - Compliance Specification for Terminal Equipment
The B430 module by Bosch Security Systems, Inc. meets the applicable Industry Canada
technical specifications. The Ringer Equivalence Number (REN) is an indication of the
maximum number of devices allowed to be connected to a telephone interface. The
termination of an interface may consist of any combination of devices subject only to the
requirement that the sum of the RENs of all the devices not exceed five.
Le présent matériel est conforme aux spécifications techniques applicables d'Industrie
Canada.
L'indice d'équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de terminaux qui
peuvent être raccordés à une interface téléphonique. La terminaison d'une interface peut
consister en une combinaison quelconque de dispositifs, à la seule condition que la somme
d'indices d'équivalence de la sonnerie de tous les dispositifs n'excède pas cinq.
Lightning
The control panel design significantly reduces the adverse effects of lightning. Taking
installation precautions can further reduce these adverse effects.
Effects of lighting
Electronics involved in a direct lightning strike or near a lightning strike can show adverse
effects. When lightning strikes, several things happen:
– An electromagnetic wave spreads from the center point of the strike inducing high
voltages onto nearby conductors.
– The voltage changes substantially on electrical grounds near the lightning strike.
– High voltages are induced onto anything directly struck by lightning.
The effects of lightning can include trouble events, alarm events, and physical damage.
Installation precautions
To minimize the undesirable effects from lightning:
1.1.8
1.2
1.2.1
1.2.2
Control Panel Certifications, approvals, listings, and safety | en 9
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

– Do not run wiring outside the building.
– If you install the unit in a metal building, keep the wiring at least 2 ft (0.61 m) away from
external metal surfaces. Make a proper earth ground connection.
– Earth ground the unit correctly. Do not use an electrical ground or telephone ground.
– Avoid running wires near telephone, data, or power lines. Locating control panel wiring at
least 2 ft (0.61 m) away helps reduce the effects of lightning.
– When your data lines must cross the path of AC or other wiring, cross perpendicular to
the lines.
Warranty
The warranty does not cover physical damage due to lightning.
1.2.3
10 en | Certifications, approvals, listings, and safety Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

Introduction
This section includes an introduction to documents for this product and other document-
related instructions.
About documentation
This document contains instructions for a trained installer to properly install, configure, and
operate this control panel, and optional peripheral devices. Review this document before
beginning the installation to determine the hardware and wiring requirements for the features
used.
(Bosch Security Systems, Inc. recommends that installers follow good wiring practices such as
those descibed in NFPA 731, Standard for the Installation of Electronics Premises Security
Systems.)
Throughout this document, the words “control panel” refer to all control panels covered by
this document (B5512/B5512E/B4512/B4512E/B3512/B3512E).
Notifications
This document uses Notices, Cautions, and Warnings to draw your attention to important
information.
Notice!
These include important notes for successful operation and programming of equipment, or
indicate a risk of damage to the equipment or environment.
!
Caution!
These indicate a hazardous situation which, if not avoided, could result in minor or moderate
injury.
!
Warning!
These indicate a hazardous situation which, if not avoided, could result in death or serious
injury.
Copyright
This document is the intellectual property of Bosch Security Systems, Inc. and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
Related documentation
To obtain any of the documents listed in this section, download them from the web.
Downloading documentation:
1. Go to the Bosch website (us.boschsecurity.com).
2. In the Search text box on the right side of the page, enter the name for the product for
which you want to download the documentation.
3. Press [ENTER].
2
2.1
2.1.1
Control Panel Introduction | en 11
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

4. If you see the desired document in the search results, click the link for the document to
open it. Otherwise, click the desired product’s Product Page button. The product page
opens with the Details tab selected.
5. Click on the Documents tab, and then click the desired language listed to the right of the
desired document.
Call Bosch Security Systems, Inc., Technical Support (1-800-289-0096) if you need additional
assistance.
Control panel documents
Control Panels (B5512/B4512/B3512) Release Notes*
Control Panels (B5512/B4512/B3512) Installation and System Reference Guide (this document)
(P/N: F01U287180)+
Control Panels (B9512G/B8512G/B5512/B4512/B3512) Owner’s Manual (P/N: F01U287181)* +
Control Panels (B5512/B4512/B3512) Program Entry Guide (P/N: F01U287183)+
Control Panels (B5512/B4512/B3512) UL Installation Guide (P/N: F01U287185)* +
Control Panels (B5512/B4512/B3512) SIA Quick Reference Guide (P/N: F01U287184)* +
*Shipped with the control panel.
+Located on the documentation CD shipped with the control panel.
Keypad documents
Basic Keypad (B915) Installation Guide (P/N: F01U297873)*
Two-line Alphanumeric Keypad (B920) Installation Guide (P/N: F01U265450)*
Two-line Capacitive Keypad with Inputs (B921C) Installation Guide (P/N: F01U297887)*
ATM Style Alphanumeric Keypad (B930) Installation Guide (P/N: F01U265451)*
Touch Screen Keypad (B942/B942W) Installation Guide (P/N: F01U294527)*
*Shipped with the keypad.
Optional module documents
2-wire Powered Loop Module (B201) Installation and Operation Guide (P/N: F01U301248)*
Octo-input Module (B208) Installation and Operation Guide (P/N: F01U265456)*
Octo-output Module (B308) Installation and Operation Guide (P/N: F01U265458)*
Conettix Ethernet Communication Module (B426) Installation and Operation Guide (P/N:
F01U281208)* +
Plug-in Telephone Communicator (B430) Installation Guide Installation Guide (P/N:
F01U265454)*
Conettix Plug-in Cellular Communicator (B440) Installation and Operation Guide (P/N:
F01U265455)*
Conettix Plug-in CDMA Cellular Communicator (B441) Installation and Operation Guide (P/N:
F01U282233)*
Conettix Plug-in GPRS Cellular Communicator (B442) Installation and Operation Guide (P/N:
F01U283180)*
12 en | Introduction Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

Conettix Plug-in HSPA+ Cellular Communicator (B443) Installation and Operation Guide (P/N:
F01U283181)*
Conettix Plug-in Communicator Interface (B450) Installation and Operation Guide (P/N:
F01U300740)* +
Auxiliary Power Supply (B520) Installation and Operation Guide (P/N: F01U265445)*
RADION receiver SD (B810) Installation Guide (P/N: F01U261834)*
SDI2 Inovonics Interface Module (B820) Installation Guide (P/N: F01U265460)*
*Shipped with the module.
+Located on the documentation CD shipped with the module.
Bosch Security Systems, Inc. product manufacturing dates
Use the serial number located on the product label and refer to the Bosch Security Systems,
Inc. website at http://www.boschsecurity.com/datecodes/.
The following image shows an example of a product label and highlights where to find the
manufacturing date within the serial number.
2.2
Control Panel Introduction | en 13
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

System overview
B430
Plug-in Tephone Communicator
provides a single
telephone RJ-45 connector
to allow communication
over telephone lines.
Control
Panel
On-board Points
1 to 8
B44x
Conettix Plug-In Cellular
Communicator allows
communciation over
a cellular network.
B208
Octo-input modules allow
the addition of up to 8
input devices.
B308
Octo-output modules allow
the addition of up to 8
output devices.
B520
Auxiliary Power Supply modules
expand power by connecting to
an SDI2 device bus or
other 12 volt devices.
B810
RADION receiver SDs
connect RADION wireless devices
to the control panel.
B820
SDI2 Inovonics Interface modules
interface with an Inovonics
wireless receiver.
B91x/B92x/B93x/B94x
Use keypads to operate
the control panel by area.
B5512 control panels support up to 4 areas.
B4512 control panels support up to 2 areas.
B3512 control panels support 1 area.
Each area can have its own account number
or you can group together areas
with a common account number.
B450
Conettix Plug-In Communicator
Interface allows communciation
over a cellular network through
the SDI2 bus.
B426
The B426 provides off-board
communication over a network.
3
14 en | System overview Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

Configuration and parts
This section lists each control panel's capacities and a parts list.
Control panel capacities
Features B5512 B4512 B3512
Number of users 50 32 10
Number of custom functions 4 2 1
Number of areas 4 2 1
Number of points 48 28 16
Number of outputs 43 27 3
Number of keypads 8 8 4
Number of B208 Octo-input Modules 4 2 0
Number of B308 Octo-output Modules 5 3 0
Number of on-board Ethernet ports (“E” control panel variants do not
include an Ethernet port)
1 1 1
Number of B426 Conettix Ethernet Communication Modules or B450
Conettix Plug-in Communicator Interfaces
1 1 1
Number of B430 Plug-in Telephone Communicators, B440 Conettix Plug-in
Cellular Communicators, B441 Conettix Plug-in CDMA Cellular
Communicators, B442 Conettix Plug-in Cellular Communicators, or B443
Conettix Plug-in Cellular Communicators
1 1 1
Number of B520 Auxiliary Power Supply Modules 4 2 2
Number of RADION receiver SDs (B810) or B820 SDI2 Inovonics Interface
Modules
1 1 1
Parts list
Control panels ship assembled from the factory with the following parts:
Literature
–Control Panels (B5512/B4512/B3512) UL Installation Guide
–Control Panels (B5512/B4512/B3512) Owner’s Manual
–Control Panels (B5512/B4512/B3512) SIA Quick Reference Guide
–Control Panels (B5512/B4512/B3512) Documentation CD
–Enclosure Wiring Label (B5512/B4512/B3512)
HW pack
– Mounting clips
– EOL resistors
– Battery wires
– Four #6 x 3/4 in self threading screws
Assembly
– PC board
3.1
3.1.1
3.1.2
Control Panel System overview | en 15
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

Order separately
Order the accessories listed below to aid in the installation of your control panel. If you
ordered your control panel in a kit, you might already have these parts.
– B91x/B92x/B93x/B94x keypad
– 18VAC, 22VA approved plug-in transformer
– D126 or D1218 Battery
– B430 Plug-in Telephone Communicator or a B440 Conettix Plug-in Cellular
Communicator/B441 Conettix Plug-in Cellular Communicator/B442 Conettix Plug-in
Cellular Communicator/B443 Conettix Plug-in Cellular Communicator
– D161 or D162 Phone Cord
– B10 Medium Control Panel Enclosure or B11 Small Control Panel Enclosure
Accessories
Accessory compatibility
The following table lists accessories that are compatible with the control panel. An X in a
column indicates the accessory is compatible with the standards.
CTN Name UL 985
Fire
Intrusion cUL
B10 Medium Control Panel Enclosure x x x
B11 Small Control Panel Enclosure x x x
B12 Mounting Plate for D8103 Enclosure
B201 2-wire Powered Loop Module1X X x
B208 Octo-input Module x x x
B308 Octo-output Module x x x
B426 Conettix Ethernet Communication Module x x x
B430 Plug-in Telephone Communicator x x x
B440 Conettix Plug-in Cellular Communicator x x
B441 Conettix Plug-in Cellular Communicator x x
B450 Conettix Plug-in Communicator Interface x x x
B520 Auxiliary Power Supply Module x x x
B810 RADION receiver SD2x x
B820 SDI2 Inovonics Interface Module3x x
B915 Basic Keypad x x x
B920 Two-line Alphanumeric Keypad (SDI2) x x x
B921C Two-line Capacitive Keypad with Inputs (SDI2)4x x x
B930 ATM Style Alphanumeric Keypad (SDI2) x x x
B942 Touch Screen Keypad (B942W white)
CX4010 UL Listed Class 2 Transformer 18 VAC 22 VA 60 Hz x x
D125B Dual Class B Initiating Module5x x x
3.1.3
3.2
16 en | System overview Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

CTN Name UL 985
Fire
Intrusion cUL
D126 Battery (12.0 VDC, 7 Ah)
D1218 Battery (12 V, 18 Ah)
D161 Phone Cord
D162 Phone Cord
D130 Auxiliary Relay Module x x x
D132A Smoke Detector Reversing Relay Module x
D133 Single Relay Module x x
D134 Dual Relay Module x x
FCC-380 Carbon Monoxide Detector (example of UL listed device,
other UL listed devices are available)
x
F220-P with
F220‑B6
Photoelectric Smoke Detector with Detector Base (example of
UL listed detector, other UL listed detectors are available)
x
HUB Potter HUB Holdup Button (example of UL listed holdup
device, other UL listed devices are available)
x
ICP-EZTS Tamper Switch x x x
ICP-TR1822-CAN Plug-in Transformer 120 VAC primary, 18 VAC 22 VA secondary x
ISC-BDL2-WP12 Blue Line Gen2 Pet Friendly TriTech Motion Detector
(example of UL listed detector, other UL listed devices are
available)
x x
MB-G6-12-R Wheelock MB Series 12V 6 " Fire Bell (Red) (example of UL
listed device, other UL listed devices are available)
x
5110/4001-42 Rothenbuhler High Security Bell x
Latin America:
B442 Plug-in GPRS Cellular Communicator x x x
Canada:
B443 Plug-in HSPA+ Cellular Communicator x x x
1Refer to the 2-wire Powered loop Module (B201) Installation Guide (P/N: F01U296412) for compatible B201
devices.
2Refer to the section within this section for compatible RADION devices.
3Refer to the section within this section for compatible Inovonics devices.
4Only ULC listed for Proprietary Burglary and Residential Fire.
5Refer to the Dual Class B Inititating Module (D125B) Installation Instructions (P/N: F01U036340) for compatible
D125B devices.
Compatible detectors
The following is a sampling of wired detectors suitable for use on approved applications.
Other UL listed devices are available.
Control Panel System overview | en 17
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

Model Name
FCC-380 Carbon Monoxide Detector
F220-P with F220-B6 Photoelectric Smoke Detector with Detector Base
HUB Potter HUB Holdup Button
ISC-BDL2-WP12 Wheelock MB Series 12V 6 " Fire Bell (Red)
MB-G6-12-R Wheelock MB Series 12V 6 " Fire Bell (Red)
ZX776Z PIR Motion Sensor [15 m (50 ft)] with POPIT
ZX794Z PIR Motion Sensor [24 m (80 ft)] with POPIT
ZX865 PIR/Microwave Motion Sensor [+1.7°C (+35°F)] with POPIT
ZX938Z PIR Motion Sensor [18 m (60 ft)] with POPIT
ZX970 PIR/Microwave Motion Sensor [+1.7°C (+35°F)] with POPIT
5110/4001-42 Rothenbuhler High Security Bell
B810 wireless receiver compatible accessories
Refer to RADION receiver SD (B810) Installation Guide.
Model Name Description
RFBT-A RADION specialty Bill trap
RFDL-11-A RADION TriTech Motion detector
RFDW-RM-A RADION contact RM Recessed door/window contact
RFDW-SM-A RADION contact SM Surface mount door/window contact
RFGB-A RADION glassbreak Glassbreak detector
RFKF-FB-A RADION keyfob FB Four-button keyfob
RFKF-TB-A RADION keyfob TB Two-button keyfob
RFPB-SB-A RADION panic SB Single button panic
RFPB-TB-A RADION panic TB Two button panic
RFRP-A RADION repeater Repeater
RFSM-A RADION smoke1Smoke detector
RFPR-12-A RADION PIR PIR detector
RFPR-C12-A RADION PIR C PIR curtain detector
RFUN-A RADION universal Universal transmitter
1 UL 985 only.
18 en | System overview Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.

B820 SDI2 Inovonics Interface Module compatible accessories
Model Name
EN1210 Universal Transmitter (Single-input)
EN1210EOL Universal Transmitter with EOL Resistor
EN1210W Door-Window Transmitter with Reed Switch
EN1215EOL Universal Transmitter with Wall Tamper and EOL Resistor
EN1215WEOL Door-Window Transmitter with Wall Tamper, Reed Switch, and EOL Resistor
EN1223D* Water-resistant Pendant Transmitter (Double-button)
EN1223S* Water-resistant Pendant Transmitter (Single-button)
EN1224-ON Multiple-Condition On/Off Pendant Transmitter
EN1233D Necklace Pendant Transmitter (Double-button)
EN1233S Necklace Pendant Transmitter (Single-button)
EN1235D Beltclip Pendant Transmitter (Double-button)
EN1235DF Fixed-location Transmitter (Double-button)
EN1235S Beltclip Pendant Transmitter (Single-button)
EN1235SF Fixed-location Transmitter (Single-button)
EN1242 Smoke Detector Transmitter
EN1247 Glass-break Detector Transmitter
EN1249 Bill Trap Transmitter
EN1260 Wall Mount Motion Detector
EN1261HT High Traffic Motion Detector
EN1262 Motion Detector With Pet Immunity
EN1265 360° Ceiling Mount Motion Detector
EN4200 Serial Receiver
EN4204R Four Zone Add-on Receiver With Relay Outputs
EN5040-T High Power Repeater With Transformer
EN7016* Wireless Survey Kit
ENKIT-SDI2 B820 and EN4200 Kit
*Not investigated by UL.
Notice!
No wireless detectors have been approved for use with alarm verification points.
For specific installation and operation instructions, please refer to manufacturers' manuals.
D125B 2-wire smoke compatibility table
Refer to the Dual Class B Initiating Module (D125B) Installation Instructions.
Control Panel System overview | en 19
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

Features
This section includes the control panel's notable features.
SDI2 interconnect wiring
Most SDI2 modules include one or two interconnect wiring connectors. You can use these
connectors to connect the modules to the control panel, and then to each other, without
having to connect wires individually to the SDI2 terminals. For installations using multiple
SDI2 modules in the same enclosure, interconnect wiring makes the installation quicker and
easier than using terminal strip wiring. Each SDI2 module that has an SDI2 interconnect wiring
connector comes with a 12 in (30 cm) interconnect cable.
Points
B5512 control panels provide up to 48 points of protection. B4512 control panels provide up
to 28 points of protection. B3512 control panels provide up to 16 points of protection.
Point programming parameters determine the control panel’s response to open and shorted
conditions on the sensor loop for the point. Several options allow individual point
programming to custom-fit the protection to the installation.
The control panel has eight on-board points, points 1 to 8.
The SDI2 bus allows for point expansion. For example, the SDI2 bus supports a combination
of B208 Octo-input Modules, and a B810 wireless receiver or B820 SDI2 Inovonics Interface
Module.
Areas and accounts
B5512 control panels support up to 4 areas. B4512 control panels support up to 2 areas.
B3512 control panels support 1 area.
You can assign all points to a single area or distribute them over multiple areas.
Users can turn areas on and off individually or together. You can assign an authority level to a
user that allows the user to turn an area on from a remote keypad in another area.
Assigning each area its own account number creates up to 4 separate accounts in the B5512,
and up to 2 separate accounts in the B4512.
Assigning the same account number to different areas groups them together in a single
account.
Area options include exit tone and delay, separate fire and burglary outputs, and multiple
opening and closing windows. Use area types to create area relationships.
For systems with more than one area, all areas must be under the responsibility of one
ownership and management. This may be a group of buildings attached or unattached and
may even have different addresses but are under the responsibility of someone having mutual
interest (other than the alarm installing company). This does not apply to strip mall
applications where each independent business must have their own separate alarm system.
An example for a commercial system would be a business that has an OFFICE area and a
WAREHOUSE area in a building where each area can be armed or disarmed independently.
As a residential example a system could be configured with the garage and house as separate
areas.
In each of the examples above, all of the areas are under the sole responsibility of a single
owner.
In multi-area systems, the bell (or siren) and control panel must be in one of the protected
areas.
The bell or siren must be located where it can be heard by users who turn areas on and off
(arm and disarm).
3.3
3.3.1
3.3.2
3.3.3
20 en | System overview Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.
