FMR-7033 |Installation Instructions | 1.0 Introduction
.
Bosch Security Systems, Inc. | 9/08 | F01U010583-01 3
1.0 Introduction
These instructions cover the installation of the Bosch
Security Systems, Inc. (Bosch) FMR-7033 Addressable
Fire System Controller in a fire system supervised by a
Bosch FPD-7024 Fire Alarm Control Panel (FACP).
Follow these instructions to avoid personal
injury and/or damage to equipment.
Install, test, and maintain these devices
according to these instructions, NFPA 72,
Local Codes, and the Authority Having
Jurisdiction (AHJ). Failure to follow these
instructions might result in failure of the
device to initiate a proper response. Bosch
is not responsible for improperly installed,
tested or maintained devices.
2.0 Description
The FMR-7033 Addressable Fire System Controller is
a four-wire alphanumeric LCD keypad that combines
fire system annunciator and controller functions. It
operates identically to the built-in user interface on the
FACP. Up to four FMR-7033 controllers might be
connected to an FPD-7024.
The FMR-7033 can be surface mounted, mounted to a
single or double gang box or to a four-inch square box.
3.0 Device Mounting
The FMR-7033 should be mounted no higher than
shoulder height of the shortest person using the system.
Remove the keypad’s cover by inserting a small flat-
head screwdriver in each slot at the bottom of the base.
Press up and pull the cover off (Figure 1).
Figure 1: Removing the FMR-7033 Cover
(Bottom front view of FMR-7033)
1
2
1 - Keypad Keys
2 Insert small flat screwdriver in each slot to
remove FMR-7033 cover
3.1 Mounting the FMR-7033 to a Surface
1. Use the base as a template and mark the location
of the mounting holes (use any holes).
2. Provide an opening in the mounting surface for
the wiring.
3. Partially install the mounting screws.
Do not tighten the mounting screws.
3.2 Mounting the FMR-7033 to an
Electrical Box
Refer to Figure 2 on page 5 to select mounting holes.
Do not tighten the mounting screws.

FMR-7033 |Installation Instructions | 4.0 Wiring the FMR-7033
4 Bosch Security Systems, Inc. | 9/08 | F01U010583-01
Figure 2: Location of the FMR-7033 Base
Mounting Holes
Inside of FMR-7033 Keypad
DO NOT USE THIS PIN!!
Back of FMR-7033 Keypad
12
3
4
5
6
7
1- Address Pins
2- Terminal Strip
3- Double Gang Mounting Slots
4- Terminal Strip Opening
DO NOT USE AS A WIRE ENTRANCE.
5- Sounder Opening
6- Wire Entrance
7- Single Gang Mounting Slots
4.0 Wiring the FMR-7033
Ensure that power is removed from all
wiring before routing. Keypad wiring cannot
be shared with multiplex, option bus,
telephone or siren wiring.
Up to three keypads can be used on any
single 1,000 ft (305 m) run of #18 AWG
(1.2 mm) wire. Refer to the FACP’s
installation guide for more detailed
instructions.
Table 1: FMR-7033 Wiring Guidelines
Wiring Specifications Value
Wire Gauge #18 AWG (1.2 mm)
Wire Type Non-shielded; 4-wire
Maximum number of keypad
allowed per system
4
Distance allowed between FACP
and Keypad
2000 ft (610 m)
Maximum distance of keypad
wiring and bus
4000 ft (1219 m)
To wire the FMR-7033 Fire System Controller:
1. Route the wiring from the FACP to the keypads.
Refer to the FACP’s installation guide for details.
2. Bring the base wiring through the wire entrance
in the keypad’s base. Refer to Item 6 in Figure 2
for wire entrance location.
3. Connect the wiring to the FMR-7033’s terminal
strip. Refer to Figure 3.
4. Place the keypad onto the base.
5. While feeding the excess wiring out of the rear
of the base, press the cover straight in until it
latches.
Figure 3: Wiring the FMR-7033’s Terminal Strip
R
+12V
B
Com
G
Data In
Y
Data Out
1
2
1 - FMR-7033 Terminal Strip
2 - FPD-7024 Option Bus
5.0 Powering the FMR-7033
The power supplied to the FMR-7033 from the R and
B terminals on the FACP is 12 VDC with a maximum
draw of 100 mA per FMR-7033 keypad. This power is
supplied from a 24 VDC battery when AC power fails.

FMR-7033 |Installation Instructions | 6.0 Installing the FMR-7033 Instruction Label and Slide
.
Bosch Security Systems, Inc. | 9/08 | F01U010583-01 5
For battery standby calculations, assume that the
FMR-7033 draws 75 mA from the 24 VDC battery.
The FPD-7024 FACP uses a switching power supply to
convert 24 VDC battery power to 12 VDC option bus
power. This conversion reduces the current drawn
from the battery.
6.0 Installing the FMR-7033
Instruction Label and Slide
An instruction label is provided for placement on the
pullout slide. The slide can be installed to pull from the
left or right (slide it into rear of base).
Use care when installing the label. Place it
as close to the pull-tab as possible.
Figure 4: Installing the Instruction Label and
Slide
Slide in either side
Back of FMR-7033 Keypad
Label
Label
Label
(writing on other side)
7.0 Setting the FMR-7033’s
Address
Each keypad must have its own address
set with its address pins. This address
must not conflict with the addresses of
other keypads or other option bus devices.
Each keypad address can support only one
device. All keypads must also be
programmed at the FACP.
Select the keypad address (1-15) by placing the
shorting jumpers over the address pins as shown in
Figure 5.
Figure 5: FMR-7033 Keypad Addresses
1248
1248
1248
1248
1248
Address 1
Address 4
Address 7
Address 10
Address 13
1248
1248
1248
1248
1248
Address 2
Address 5
Address 8
Address 11
Address 14
1248
1248
1248
1248
1248
Address 3
Address 6
Address 9
Address 12
Address 15
8.0 Programming the
FMR-7033
The control panel does not recognize the keypad until
the option bus is updated.
To update the option bus from the local keypad:
1. Enter programming mode using the correct
programming code.
2. Select menu item 3 – System.
3. Select menu item 4 – Option Bus
4. Select menu item 1 – Update Bus
5. Press */back to exit from programming mode.
Ensure that the number of devices found
on the bus agrees with the number
installed.
9.0 Troubleshooting the
FMR-7033
Refer to Table 2 on page 6 when troubleshooting
problems with the FMR-7033.

FMR-7033 |Installation Instructions | Specifications
6 Bosch Security Systems, Inc. | 9/08 | F01U010583-01
Table 2: FMR-7033 Troubleshooting Tips
FMR-7033 Keypad
Notification
Possible Causes
Continuous keypad sounder
plus “System Fault” display
- The yellow and green
ground wires are
disconnected.
- The keypad is not
programmed properly at
the FACP.
- The FACP
malfunctioned. Replace
the FACP.
FACP does not respond to
keypad input
- The keypad’s address
was not set.
Three-beep error tone at all
keypads
- Invalid key input.
10.0 Specifications
Table 3: FMR-7033 Specifications
Nominal Supply Voltage 12 VDC from Option Bus
Standby Current 100 mA (75 mA for battery
calculation)
Alarm Current 100 mA (75 mA for battery
calculation)
Environment Use Indoor/Dry
Operating Temperature +32°F to 120°F (0°C to
+49°C)
Relative Humidity 93%
Width 6.25 in (15.9 cm)
Height 4.6 in (11.7 cm)
Depth 1.3 in (2.9 cm)
Listings and Approvals UL864, FM
Wiring Supervised Communication
Circuit Class B, Style 4

FMR-7033 |Installation Instructions | 11.0 Operating the FMR-7033
.
Bosch Security Systems, Inc. | 9/08 | F01U010583-01 7
11. Use the [Test] key to select one of seven
special test modes (refer to FPD-7024 O&I
Guide; P/N F01U008458).
11.0 Operating the FMR-7033
12. Use the [Disable] key to disable or re-enable
inputs NACs or relays (outputs), and the
dialer.
Figure 6: Keypad Features
Alarm
Si lenc ed
Su pe r viso ry
Tr oub le
123
456
789
0
Program
*
#
Enter
Silence
Drill
Test
Disable
Reset
ACK
Back
History
TE ST WEEK LY
1
2
3
4
5
6
78910
11
12
13
14
15
16
13. Use the [Drill] key to activate the NACs
manually. It creates a history log entry and can
be optionally reported to the central station.
14. The [Reset] key (programmable from 1 to 16
sec) briefly turns off power to the detectors to
reset them and clears any off-normal
conditions.
15. Use the [Acknowledge] key to silence local
keypad sounders and to view off-normal
conditions.
16. The [Silence] key quiets the bell or sirens for
an alarm or trouble condition only if the system
is so configured.
1. The two-line character display can show all
messages normally displayed on an FPD-7024
or an FMR-7036 keypad.
2. The red Alarm LED lights whenever the system
registers an alarm and was not reset.
3. The yellow Silenced LED lights when the user
manually silences an alarm or trouble
condition. It turns off when the condition that
was silenced is corrected.
4. The yellow Supervisory LED lights whenever
the system registers a supervisory condition.
5. The yellow Trouble LED lights whenever the
system detects a problem with wiring or
internal circuitry. The Trouble LED flashes
while programming mode is active and
whenever inputs are not active, such as during
smoke power reset or alarm verification.
6. Scroll keys are used to move through the off-
normal events indicated on the display.
7. During the programming, use the [Back] key to
exit from menus or exit from the programming
mode entirely.
8. Use the [Programming] key to select the
programming mode.
9. Use the [History] key to view system events.
10. Use the [Enter] key to accept data when in the
programming mode.

© 2008 Bosch Security Systems, Inc.
F01U010583-01
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450-9199
[phone]
www.boschsecurity.com
