Bosch AVENAR panel 8000 User manual

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
FPE‑8000‑SPC | FPE‑8000‑PPC | FPE‑2000‑SPC | FPE‑2000‑PPC |
FPE‑8000‑FMR
pt-BR Manual do utilizador

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 Sumário | pt-BR 3
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
Sumário
1For your safety 7
1.1 Operating the touch screen 7
1.2 Maintenance 7
1.3 Usage in accordance with regulations 8
1.4 Skills required by personnel 8
2Para sua informação 9
2.1 What is new 9
2.2 Open Source license agreement 10
2.3 Calling up the start menu 10
2.4 Changing language display 10
2.5 Warranty and liability 10
2.6 Copyright 10
3All functions at a glance 11
4In overview 13
4.1 Operating elements 13
4.2 Status LEDs 14
4.3 Touch screen 16
4.4 Standby screen 18
4.5 Informações de contato para suporte 19
5Operating principle 20
5.1 Switch on and switch off 20
5.2 Initial setup 21
5.3 Logging on and off 22
5.3.1 Logging on 22
5.3.2 Logging off 22
5.4 Access authorization 23
5.5 Calling up the start menu 23
5.6 Personalized menu 23
5.7 Selecting the menu 23
5.8 Returning to the previous selection 23
5.9 Working with lists 24
5.9.1 Scrolling through lists 25
5.9.2 Various states of list fields 25
5.9.3 Assigning mode 26
5.10 Search Function/Element 26
5.10.1 Search by name 26
5.10.2 Searching by number 27
5.11 Entering numbers and text 27
5.11.1 Changing an entry 28
5.11.2 Deleting all numbers 28
5.12 Changing language display 28
5.12.1 Entering by shortcut 28
5.12.2 Change language by menu 28
5.13 Switching between status bars 29
5.14 Standby 29
5.15 Logical and physical addressing 29
6Networking via Ethernet 30
6.1 IP settings 30

4pt-BR | Sumário AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
6.2 Diagnostics 30
7Teclado AVENAR 8000 32
8Teclados e painéis em rede 33
8.1 Configurações do FSP-5000-RPS 33
8.2 Como estabelecer/fechar uma conexão remota a um painel 33
9Alarm 35
9.1 Types of alarm 35
9.2 Entry delays 35
9.3 Day and night mode 36
9.4 Alarm message to the panel 37
9.4.1 Optical and acoustic signals 37
9.4.2 Displaying the detector zones in alarm state 37
9.4.3 Sequence of the alarm messages 38
9.4.4 Information about logical zones in the alarm state 38
9.4.5 The newest message 39
9.4.6 Displaying the individual detectors in a logical zone 39
9.4.7 Information about individual detectors 39
9.4.8 Displaying additional information 40
10 Fire alarm 41
10.1 Evacuation 41
10.2 Optical and acoustic signals 42
10.3 Acknowledging a message 42
10.4 Silence internal buzzer 42
10.5 Activate and silence signaling devices 42
10.6 Resetting signaling devices and transmission devices 42
10.7 Triggering fire verification 43
10.7.1 Alarm verification 43
10.7.2 Starting time to investigate 43
10.7.3 Triggering alarm manually 44
10.8 Resetting alarm message 44
10.9 Bypassing detectors 45
11 Fault message 46
11.1 Calling up fault indication 46
11.2 Fault message on the panel 46
11.2.1 Acknowledging a message 46
11.2.2 Sequence of the fault messages 47
11.2.3 Information about malfunctioning element groups 47
11.2.4 The newest message 47
11.2.5 Displaying individual elements of an element group 48
11.2.6 Information about individual elements 48
11.2.7 Displaying additional information 48
11.2.8 Signals 49
11.3 Resetting fault message 49
11.4 Blocking an element 50
12 Bypass 51
12.1 Menu overview 51
12.2 Bypassing and un-bypassing elements 51
12.3 Displaying and un-bypassing bypassed element groups 51
12.4 Displaying list of all bypassed elements 52

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 Sumário | pt-BR 5
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
12.4.1 Using the menu 52
12.4.2 Via the status bar 52
12.5 Bypassing/Un-bypassing buzzer 52
12.6 Bypassing/Un-bypassing the output to fault warning routing equipment 53
12.6.1 Bypassing the output to fault warning routing equipment 53
12.6.2 Un-bypassing the output to fault warning routing equipment 53
13 Block 55
13.1 Menu overview 55
13.2 Blocking and unblocking elements 55
13.3 Displaying list of all blocked elements 55
13.3.1 Using the menu 56
13.3.2 Via the status bar 56
14 Diagnostics 57
14.1 Menu overview 57
14.2 Element details 57
14.3 Modules 58
14.4 Hardware 58
14.4.1 Teste de LED 58
14.4.2 Teste de tela 58
14.4.3 Informações de rastreamento 59
14.4.4 CAN-Bus 60
14.5 ID do painel 60
14.6 LED Test on modules 60
14.7 Network services 61
14.7.1 Routing table 61
14.7.2 Consistency check 61
14.7.3 Ethernet ports 62
14.7.4 Send ping command 62
14.7.5 Remote Services 62
14.8 Sistemas de alarme por voz (VAS) 64
14.8.1 Plena 64
14.8.2 PRAESENSA/PAVIRO/Praesideo 64
15 Maintenance 66
15.1 Menu overview 66
15.2 Change language 66
15.3 Activate Outputs 66
15.4 Activate Transmission Device 67
15.5 Bypassing/Un-bypassing buzzer 67
16 Maintenance – walktest 68
16.1 Walktest groups 68
16.1.1 Adding or deleting elements 68
16.2 Starting and ending walktest 70
16.2.1 Starting the walktest 70
16.2.2 Ending the walktest 71
16.3 Ending walktest for all elements 71
16.4 Displaying tested or untested elements 71
16.5 Assigning tested elements to a walktest group 71
17 Maintenance – history log 72
17.1 Selecting filters 72

6pt-BR | Sumário AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
17.2 Setting filters 72
17.3 Change Filter 73
17.4 Combining several filters 73
17.5 Status bar functions 73
17.6 Printing out data 73
18 Day and night mode 75
18.1 Switching between day and night mode 75
18.2 Showing details 76
18.3 Changing the time for resetting to night mode 76
19 Configuration 78
19.1 Menu overview 78
19.2 Physical node address (PNA/RSN) 78
19.3 Group setting 78
19.3.1 Adding or deleting 78
19.3.2 Change name 80
19.4 Detector sensitivity 80
19.5 Operator 80
19.5.1 Change password 81
19.5.2 Change universal password 81
19.5.3 Set Default Password 81
19.6 Rename elements 81
19.7 Network services 82
19.7.1 Ethernet 82
19.7.2 Change date/time 82
19.7.3 Remote Services 82
19.8 Overview 82
20 Further functions 84
20.1 Menu overview 84
20.2 Change Date / Time 84
20.3 Master password 84
20.3.1 Enter the master password that is valid indefinitely 84
20.3.2 Enter the 24-hour master password 84
20.4 Remote Services 85
20.5 Change password 86
20.6 Performing a fire drill 86
20.7 Alarm Counters 87
21 Reset 88
21.1 Menu overview 88
21.2 Resetting elements 88
22 Control / Monitor 89
22.1 Menu overview 89
22.2 Activate doorholder, control element or HVAC 89
22.3 Go to element 89
22.4 Search for function 90
23 Boot menu 91
Index 92

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 For your safety | pt-BR 7
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
1 For your safety
Before using the device, familiarize yourself with these instructions. If you do not read and
understand these explanations, you will not be able to operate the device faultlessly.
The operating instructions do not do away with the need for training by authorized personnel.
i
Aviso!
The device may only be operated by trained personnel. See Skills required by personnel,
página 8 .
This user guide does not contain any general or special knowledge about safety issues.
Information on such issues is only given to the extent that it is needed for operation of the
device.
Ensure that you are familiar with all safety-related processes and regulations in your area. This
also includes how to behave in the event of an alarm and the initial steps to take if a fire
breaks out.
The user guide is a statutory part of the system and must be made known to the new owner if
the system is ever sold.
i
Aviso!
The personal access code (consisting of user ID and password) must not be made known to
third parties.
!
Advertência!
The device must be shut down by power button. Don’t unplug the device from power supply
while the system is in operation. This could result in the damage of the device. After shutting
down the device correctly restart it via the power button.
1.1 Operating the touch screen
!
Cuidado!
Do not use any pointed or sharp objects (e.g. screw drivers, pens, etc.) when operating the
touch-sensitive display. The touchscreen may not be exposed to direct sunlight. Both can
seriously damage the touchscreen.
!
Cuidado!
The recalibration of the panel touchscreen must be performed at least once a year. Otherwise
the operation of the panel may be limited or become even impossible without prior
recalibration.
1.2 Maintenance
Clean the touch screen and surfaces with a slightly damp soft cloth only. Do not use any
cleaning agents and make sure that no liquid enters the inside of the device.

8pt-BR | For your safety AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
1.3 Usage in accordance with regulations
i
Aviso!
Terminologia
O termo teste de caminhada, que é usado no painel de incêndio e na documentação,
corresponde ao termo Condição de teste da norma EN54-2.
The panel controller is designed for operating the AVENAR panel 8000/2000 fire panel. It can
perform the following tasks:
– Displaying and processing various message types such as alarm and trouble messages
– Bypassing, blocking and resetting elements
– Monitoring and controlling of sounders and outputs
– Performing a walktest
– Display diagnostic information about every LSN element
– Configuration of detectors (short texts and detector sensitivity)
– Performing a drill
– Saving, displaying and printing out events
– Switching the system to day or night mode.
i
Aviso!
The manual control of evacuation zones and the outputs connected to fire protection
equipment (e-Matrix) are user features without regulatory requirements, as these features are
not within the scope of EN54-2.
1.4 Skills required by personnel
Display of event messages on the panel controller must only be processed by trained
personnel.
The system walk test and detector configuration must only be performed by trained,
authorized personnel.

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 Para sua informação | pt-BR 9
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
2 Para sua informação
Este guia do usuário contém informações e notas importantes sobre a operação do AVENAR
panel 8000/2000.
Usando as instruções passo a passo, você pode se familiarizar com as funções individuais:
– In overview, página 13 fornece uma visão geral dos elementos de operação e exibição e
da tela sensível ao toque.
– Em Operating principle, página 20 , você aprenderá como navegar pelos menus
individuais e quais possibilidades de seleção estão disponíveis para você.
Cada função é descrita detalhadamente em um capítulo individual.
Você encontrará tópicos específicos no índice. Se você já tem prática no manuseio de menus,
pode usar a visão geral de todos os menus em All functions at a glance, página 11 .
i
Aviso!
Este guia do usuário é aplicável para o painel do firmware versão 4.x.
2.1 What is new
O FPE-8000-SPC/PPC / FPE-2000-SPC/PPC é o painel sucessor do painel de incêndio modular
AVENAR panel 8000/2000.FPE-8000-SPC/PPC /FPE-2000-SPC/PPC combina uma nova e
poderosa plataforma do controlador de painel com todos os recursos de segurança estáveis
conhecidos.
Ao operar o FPE-8000-SPC/PPC/FPE-2000-SPC/PPC, observe as seguintes inovações
importantes:
Physical node address (PNA/RSN)
The physical node address of the panel is set in the panel firmware when switching on the
panel for the first time. The physical node address dialog replaces the mechanical rotary
switches.
For details see Initial setup, página 21 .
Power button
The panel must be switched on and off with a power button which is located at the right side
of the panel. Also a reboot of the panel is done via the power button.
For details see Switch on and switch off, página 20 .
Calibration of the touchscreen
The calibration of the touchscreen is started via the boot menu, which can be called up during
the boot process of the panel, for details see Boot menu, página 91 .

10 pt-BR | Para sua informação AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
Consulte
– Boot menu, página 91
2.2 Open Source license agreement
i
Aviso!
A Bosch Sicherheitssysteme GmbH usa software de código aberto. Para obter mais
informações, consulte https://www.boschsecurity.com/xc/en/oss/.
2.3 Calling up the start menu
4Press .
You can use this key to return from any submenu back to the start menu.
2.4 Changing language display
O idioma do painel pode ser alterado rapidamente com um atalho:
1. Pressione para abrir o menu inicial.
2. Pressione 1 no teclado alfanumérico.
3. Selecione OK para confirmar a entrada ou Cancelar para cancelar a operação.
Uma lista dos idiomas existentes é exibida.
4. Selecione o idioma desejado.
Todos os elementos da tela agora são mostrados no idioma selecionado.
i
Aviso!
After a system reboot following a power cut or battery failure, the default language set in the
FSP‑5000‑RPS is displayed again.
2.5 Warranty and liability
Warranty and liability claims for personal and property damage are excluded if these were
caused by one or several of the following causes:
– Use of the fire panel contrary to the regulations
– Improper set-up, installation, start-up, operation or maintenance
– Disregarding of the user manual
– Subsequent constructional changes
– Faulty repairs
– Catastrophes, influence of foreign bodies, and force majeure.
Without the permission of Bosch, no changes or additions to or rebuilding of the panel
including the panel controller may be undertaken.
Rebuilding requires written permission. In case of non-approved constructional changes, any
warranty claims against Bosch are voided.
2.6 Copyright
Bosch Sicherheitssysteme GmbH, Robert-Bosch-Ring 5, 85630 Grasbrunn, Germany retains
the complete copyright to the whole documentation. Without the express written permission
of Bosch, no part of these documents may be duplicated or transmitted in any form.
Bosch reserves the right to make changes to this manual without prior notice.

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 All functions at a glance | pt-BR 11
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
3 All functions at a glance
Main menu
Inibir Bloquear Diagnósticos
Manutenção Configuração
Mudar p/ Modo Dia Outras funções
Controlar monitorização Reset
Bypass/Block
Inibir
Bloq.
-> Show
blocked/
bypassed
devices
Selecionar
por número
Inibir avisador
sonoro
Impressora
NAC Disp. de
transmissão
AVAC Retentor de
porta
Detetor Zona lógica Sistema de
extinção
Avisador
Inibir/
Bloq. group
Mais... -> Elemento de
controlo
Módulo interface
Diagnósticos
Diagnósticos -> Detalhes do elemento Módulos
Hardware ID do painel
Teste de LEDs nos
módulos
Histórico de eventos
Serviços de rede SAV (VAS)
Manutenção
Manutenção -> Teste aos elementos Alterar idioma
Activar saídas Activar dispositivo de
transmissão
Histórico de eventos Inibir avisador sonoro
Configuração
Configuração -> Definir end de nó físico
(PNA/RSN)
Definir grupos
Sensib. do detetor Operador
Renomear elementos Informação Geral
Serviços de rede Sobre o...

12 pt-BR | All functions at a glance AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
Further functions
Outras funções -> Alterar data / hora Palavra-passe master
Remote Services Alterar palavra-passe
Teste de evacuação Contadores de alarmes
Control / Monitoring
Ativar retentor de porta Ativar AVAC
Ativar elemento de controlo Função de Procura
Ir para o elemento
Redefinir
Reset -> Tipo de evento Âmbito
Zona lógica Detetor
Este painel

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 In overview | pt-BR 13
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
4 In overview
This chapter contains information about the following elements of the panel controller:
– Operating elements, página 13
– Status LEDs, página 14
– Touch screen, página 16
– Informações de contato para suporte, página 19
Fire
2
Control
2
Fault
0
Bypass
0Status
Bypass
Block Diagnostics
Maintenance Configuration
Switch to day mode Further functions
Control
Monitoring Reset
* Level 3 logged in
1
2
4 3 5 6 7 8 9
10
11
DEF
21
ABC
3
4 5 6
GHI JKL MNO
7 8 9
PQRS TUV WXYZ
*0#
F1 F2 F3
,.-_
1 Status LEDs 6 Display a list of the networked panels and establish a
remote connection with a networked panel
2 Information bar 7 Display and control all alarm zones
3 Status bar 8 Log-in to the panel and call up personalized menu
4 Open start menu 9 Silence internal buzzer
5 Go back 10 Function keys, programmable
11 Display support information
4.1 Operating elements
Teclas fixas
Para selecionar uma função, toque na tecla apropriada.
As seguintes funções podem ser executadas com as teclas fixas na parte inferior da tela:
Tecla “Início”. Acesse o menu inicial.
Retorne à seleção anterior.
Exibir uma lista de painéis em rede e estabelecer uma conexão remota
com um painel em rede ou um teclado remoto.
Exibir e controlar todas as zonas de alarme.

14 pt-BR | In overview AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
Fazer login e logout: insira ID de usuário e senha ou acesse o menu
personalizado, caso você já esteja conectado.
Silencie temporariamente o aviso sonoro interno.
Tecla “seta para a esquerda”. Mova o cursor um espaço para a
esquerda na tela de pesquisa.
Tecla “seta para a direita”. Mova o cursor um espaço para a direita na
tela de pesquisa.
Tecla “seta dupla”. Alterne entre as barras de status, caso haja duas ou
mais barras disponíveis. Abra a barra de status para navegar por listas
rapidamente.
Tecla “Enter”. Confirme uma entrada alfanumérica. Confirme uma
entrada que não foi confirmada selecionando o campo OK na tela
sensível ao toque.
Alphanumeric keypad
Entry of letters, special characters, and numbers.
Function keys
There are three function keys F1, F2 and F3 which are freely programmable with frequently
used functions of the panel via the Programming Software. If a function key is active it is
marked with a green bar.
Alphanumeric keypad
Entry of letters, special characters, and numbers.
4.2 Status LEDs
18 status LEDs show information on the operating status of the fire panel.
Cor* Significado
R Alarme de Incêndio
R Evacuação em andamento
R Transmissão do alarme de incêndio ativada
R Equipamento de proteção contra incêndio ativado
Y Modo de manutenção
Y Modo diurno/atrasos ativos

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 In overview | pt-BR 15
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
Y Geral desativado
Y Falha geral
Y** Detector de incêndio com falha/desativado
Y** Dispositivo de sinalização com falha/desativado
Y** Dispositivo de transmissão do alarme com falha/desativado
Y** Saída para equipamento de proteção contra incêndio com falha/
desativada
Y Falha de energia
G Energia disponível
Y Sistema/painel com falha
G Sistema em operação
R LED programável para um alarme autoconfigurado
Y** LED programável para um alarme autoconfigurado com falha/
desativado
*Y=yellow (amarelo), R=red (vermelho), G=green (verde)
**piscante: com falha, constante: desativado
The LEDs for the status of devices like detectors , signaling devices , alarm
transmission devices and the outputs to fire protection equipment always light up in
combination with the general fault or general disabled icon according to their
status. Additionally, in case of a fault the LED of the respective element is blinking while the
LED indicating the general fault lights up steadily yellow.

16 pt-BR | In overview AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
Example:
1 2 3
1 Fault indication for a device
2 Device disabled
3 Device disabled and in fault status
i
Aviso!
As neither the panel nor the power supply can have the status “disabled”, the system fault
and the power fault icon light up steadily in yellow in the status “fault”.
4.3 Touch screen
!
Cuidado!
Do not use any pointed or sharp objects (e.g. screw drivers, pens, etc.) when operating the
touch-sensitive display. The touchscreen may not be exposed to direct sunlight. Both can
seriously damage the touchscreen.

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 In overview | pt-BR 17
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
Fire
2
Control
2
Fault
0
Bypass
0Status
Bypass
Block Diagnostics
Maintenance Configuration
Switch to day mode Further functions
Control
Monitoring Reset
* Level 3 logged in
1
2
3
4
5
DEF
21
ABC
3
4 5 6
GHI JKL MNO
7 8 9
PQRS TUV WXYZ
*0#
F1 F2 F3 6
1 Information bar 4 Fixed operation keys
2 Menu field 5 Alphanumeric keyboard
3 Status bar 6 Function keys, programmable
Information bar
The information bar displays general information as text or icons.
Icon Meaning
No connection established.
Only displayed on the panel.
No connection established.
Only displayed on the keypad.
Remote connection established.
Operator has restricted use of the remote panel: no control, only
monitoring.
Remote connection established.
Operator is in full control of the remote panel.
Remote connection established.
A remote operator is in full control of the panel.
The panel is locked for local access.
Ground fault detected.
Operator logged in.

18 pt-BR | In overview AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
Text Meaning
Panel 4-1 Logical node address
Level 3 logged in Access level of the operator who is logged in.
Possible levels: 2, 3 or 4
Only displayed in the main menu.
Bypass Block\Block\Detector Menu path of the selected menu
For reasons of space it is not always possible to display the
complete path.
Menu field
To select a main menu, touch the corresponding menu field on the touch screen. In All
functions at a glance, página 11 , there is an overview of all main menus with their respective
submenus.
Barra de status
0
Incêndio
0
Controlo
8
Falha
0
Inibido Estad
o
Esta barra de status está disponível em todos os menus. Além disso, outras barras de status
são oferecidas em alguns menus; veja também Switching between status bars, página 29 :
O número inicial especifica o número de elementos no respectivo estado:
Incêndio Número dos grupos que acionaram um alarme de incêndio
Controlo Elementos que estão ativados
Falha Elementos que relataram uma falha
Inibido Elementos desativados
Além disso, é possível exibir uma visão geral do tipo e da natureza de todos os tipos de
mensagens recebidas pelo painel:
Estado Exibição de uma lista de vários tipos de mensagens e de status e
do número de elementos no respectivo estado.
Para exibir os elementos individuais, toque no campo relevante com o dedo.
Os campos de status Controlo e Falha são identificados pelas letras “B” e/ou “C”:
– “B” significa que os controladores para equipamentos de proteção contra incêndio tipo B
(G-B) estão afetados (por exemplo, elementos de controle sem reconhecimento).
– “C” significa que os controladores para equipamentos de proteção contra incêndio tipo C
(G-C) estão afetados (por exemplo, sistemas de extinção).
4.4 Standby screen
When the touchscreen is not operated, its backlight switches off after 5 minutes.
i
Aviso!
In case of an active alarm or fault message, the backlight switches off after 60 minutes. The
display switches back to this message from any other element of the menu after 30 seconds.
If the screen is black, touch it gently to display the standby screen. The following information
is displayed on the standby screen:

AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000 In overview | pt-BR 19
Bosch Sicherheitssysteme GmbH Manual do utilizador 2023-08 | 8.0 | F.01U.378.877
– Date
– Time
– Night mode
or
– Day mode
or
– Night/day combination
Depending on the configuration, additional information may be displayed.
In a networked fire detection system, further icons can be displayed in the standby display
depending on the network setting.
4.5 Informações de contato para suporte
Para exibir as informações de contato da empresa que fornece o suporte, pressione o logotipo
da Bosch no canto superior direito da interface do usuário.
As seguintes informações de contato são exibidas:
–Nome empresa
–Nome contacto
–Telefone
–Endereço
–C. Postal
–E-mail
i
Aviso!
As informações de contato para suporte são exibidas apenas quando as informações foram
inseridas na caixa de diálogo de informações de suporte no FSP‑5000‑RPS.
Além das informações de contato, são exibidas as seguintes informações:
–Data instal. sistema: a data, a hora e o fuso horário do último download de configuração.
–Versão do firmware: versão do firmware atualmente em execução no hardware do
controlador.
–Versão do hardware: com a versão de hardware, você pode identificar qual versão de
firmware pode ser executada no controlador. Para mais informações, consulte o capítulo
Firmware do controlador do painel no manual do sistema.

20 pt-BR | Operating principle AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
2023-08 | 8.0 | F.01U.378.877 Manual do utilizador Bosch Sicherheitssysteme GmbH
5 Operating principle
5.1 Switch on and switch off
Power button
The fire panel must be switched on and off with a power button which is located at the right
side of the panel. Also a reboot of the panel is done via the power button.
!
Advertência!
Don’t unplug the panel for restarting it! Always use the power button. Unplugging the running
panel can cause a serious damage of the hardware and software.
The functions of the power button are:
– Press once shortly: Start the panel
– Press once shortly at a running panel: Shut down the panel
i
Aviso!
A confirmation sound is played when the shutdown-sequence is starting. The shutdown is
completed when the “general fault” and the “system/panel fault” status LEDs light
up. Wait until the shutdown is completed before you interrupt the power.
i
Aviso!
After having shut down the panel please interrupt the power supply. If a panel was shut down
but is not unplugged, after 10 seconds a warning tone will sound as a reminder.
– Press for 8 seconds: Interrupt the panel and reboot it (for example in case of a software
failure).
!
Advertência!
You must only use this way of interrupting the panel if the system does not react anymore or
if you are asked to do so in case the panel ran into the safe state.
Safe state
