Bosch EL800A User manual

IMPORTANT NOTICE
Please read this user manual carefully. It contains important information
on the Smart Door Lock and maintenance.
Make sure that the mechanical key is kept in a safe place outdoors, i.e.
inside your car, office etc.
Do not expose the lock to rain, sunlight and outdoor environments.
Do not try to repair/disassemble the lock to avoid unnecessary loss.
Do not hit the lock with any hard objects.
Make sure that the door is properly locked when you are going out.
Do not use water or any chemical substances such as oil or benzene to
clean the lock. This will result in short circuit, ageing and/or paint
stripping.
Make sure to change your PIN Code regularly.
Do not use rechargeable batteries for the lock. This product is only
compatible with alkaline batteries.
The virtual PIN Code is up to 32 digits. E.g. Actual PIN Code + **** or **** +
Actual PIN Code (Do not key in garbled character before or after the virtual
PIN Code).
If the touch screen is out of order, try to restart the device with the
emergency power supply below, which is connected to the Micro-USB.
When using the key to open the lock, please turn the key back to its
original position before removing it.
Please follow the above instructions to avoid any injuries and/or damages
on the lock.
USER MANUAL
BOSCH SMART LOCK
Do not put any flammable material such as gas, paint, gasoline,
etc, near the smart lock to avoid explosion and fire, including
explosive materials such as alcohol, gasoline, etc.
We are not responsible for any damage or property loss resulting
from improper installation, readjustment, use and/or repair by
user or third parties.
EL800A
PRODUCT INTRODUCTION
OUTER BODY PARTS
INNER BODY PARTS AND LOCK CASE
SPECIFICATIONS
Outer Lock Size: 20(D)x80(W)x400(H)mm
: 65(D)x80(W)x400(H)mm
Operating Temperature: -25° C ~+55° C
Operating Humidity: 25~93% RH, non-coolant
Unlock PIN Code Memory: 100 sets
Unlock Fingerprint Memory: 100 sets
Unlock Card Memory: 100 sets
Supports Mechanical Key unlocking
Supports long-distance unlocking (optional) with purchase of online
component
Battery: 1.5VAA (LR6) alkaline batteries X4 (Operating Voltage: 4.5V~6V)
NAME OF PARTS
HOW TO USE
I Switch
Short press to enforce lock / Long press for default setting
I Switch
Volume Control
Choose 3 levels of volume
Volume Control
Emergency Power
Port
Card Reader
Smart Number Pad
Battery Cover
OPERATION DESCRIPTION
ADD USER PIN CODE
Add Master
PIN Code
Press S switch, enter initial master PIN code
when prompted by the voice guide (if it has been
changed, enter the changed master PIN code)
and press # followed by 1, 1. Enter the new PIN
code, and press # to confirm. Re-enter the new
PIN code and press # to save.
Add Normal
PIN Code
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 1, 2. Enter user code: 002~090, and
press # . Enter the normal user PIN code, and
press # to confirm. Re-enter the PIN code and
press # to save.
Add One-Time
PIN Code
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 1, 3. Enter user code: 091~0100, and
press # . Enter the One-Time PIN code, and press
# to confirm. Re-enter the One-Time PIN code
and press # to save.
Delete Single
PIN Code
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 1, 4. Enter user code: 002~100 and
press #. Successfully deleted.
Master PIN code cannot be deleted before the
default setting is restored.
Delete All
PIN Code
Press S switch, enter master PIN code when
prompted by the voice guide, and press # followed
by 1, 5, and press #. Successfully deleted.
Master PIN code cannot be deleted before the
default setting is restored.
Add Normal
Key Card
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 2, 1. Enter user code: 101~190 and
press #. Successfully added.
Add One-Time
Key Card
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 2, 2. Enter user code: 191~200 and
press #. Successfully added.
Delete Single
Key Card
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 2, 3. Enter user code: 101~200 and
press # to confirm. Press # again. Successfully
deleted.
Delete All
Key Card
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 2, 4 to confirm. Press # again.
Successfully deleted.
Add Master
Fingerprint
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 3, 1. Enter your fingerprint 3 times.
Successfully added. Re-enter if fail.
Add Normal
Fingerprint
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 3, 2. Enter user code: 202~290 and
press # to confirm. Enter your fingerprint 3 times.
Successfully added. Re-enter if fail.
Add SOS
Fingerprint
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 3, 3. Enter user code: 291~300 and
press # to confirm. Enter your fingerprint 3 times.
Successfully added. Re-enter if fail.
Delete Single
Fingerprint
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 3, 4. Enter user code: 202~300 and
press # to confirm. Press # again. Successfully
deleted.
Master fingerprint cannot be deleted before the
default setting is restored.
1 2 3
4
7
5 6
8 9
ADD USER FINGERPRINT
ADD USER KEY CARD
INITIALISATION AND RESTORE PROGRAM
Initialise User PIN Code: 1234567890
New changed password for 6 digits. “*” key as back. “#” key as confirm.
Master information included master PIN code and master fingerprint.
Restore Default Setting: Long press “I” switch for 5 seconds until you
hear the voice guide.
Include Handle
Speaker
Handle (Exterior)
Mechanical Key
S Switch - Short press for system menu /
Long press for normal mode
Volume Control
I Switch - Short press to
activate lock / Long press
for default settings
Sensor Bolt
Main Bolt
Two-Way
Bolt
Inner Body Handle
Child’s Lock
Emergency Unlock
Knob
Unlock Key (Inside)
S Switch
Short press for system menu / Long press for normal mode
S Switch
Fingerprint Reading Panel (Interior)
• User Manual
• Installation Guide
• Parts Pack
• 2 Card Keys
• 2 Mechanical Keys
Strike Plate
AA Alkaline Batteries
• 1 Smart Lock
Strike Box

OPENING THE DOOR
OPERATION DESCRIPTION
Unlock Mode Press S switch, enter master PIN code when
prompted by the voice guide, and press #.
Activate safe mode: Enter 5, 1, 1
Deactivate safe mode: Enter 5, 1, 2.
Change
Language
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
Chinese: Enter 5, 2, 1
English: Enter 5, 1, 2
Activate One
Touch Security
Press 2, 2, #
Deactivate One
Touch Security
Press 4, 4, # followed by master PIN code and
press #
Long Distance
Call *(optional
function)
Press 6, 6, #
Activate Force
Lock
Short press “I” key
Deactivate
Force Lock
Enter master information. Open the door for once.
Active Child's
Lock Press for 3-5 seconds to active the child’s lock
Deactivated
Child's Lock
1. Deactive by presssing the unlock buttom from inside
2. Press for 3-5 seconds again to deactive the
child’s lock.
Deactivate
Network
*(optional
function)
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 4, 2
Successfully deactivated.
SYSTEM SETTINGS
INSTANT FUNCTION SETTINGS
OPEN WITH PIN CODE
Touch the number pad >>> Enter your registered PIN code
>>> Press # to open door
OPEN WITH MECHANICAL KEY
TO REPLACE BATTERY
This product uses four 1.5V alkaline AA batteries. It is sustainable for 1
year if used 10 times a day. (Users are advised to use genuine alkaline
batteries.)
Make sure to replace all 4 batteries in the following manner:
* Upon hearing the low battery reminder;
* Using or replacing wrong type of batteries, which may cause
an explosion;
* Dispose of old batteries responsibly;
1.5V alkaline AA battery
ALARM AND USUAL FUNCTION
BREAK IN / DAMAGED ALARM
• Board anti-pry alarm: Alarm will go off when the front board is being
pried.
• Handle anti-pry alarm: System will lock down when the handle is
being pried.
• One touch security alarm: In single mode, alarm will go off when
someone is breaking the lock. In network mode, alarm will go off
when someone is breaking the lock and will be reported to the
terminal (network version requires the purchase of network
components separately).
• Key open sensor alarm: Alarm will go off when the mechanical key is
being used.
• Main bolt alarm: Alarm will go off when the main bolt is not locked.
• SOS alarm (only for network version): Both single mode and network
mode alarm will not go off, but will be reported to the terminal (network
version requires the purchase of network components separately).
3-MINUTE SYSTEM LOCK
• System will lock down for 3 minutes after 3 failed attempts. The
number pad will indicate the countdown time.
FORCE LOCK
• Short press I key and the voice guide will say “Force lock activated”.
Then you can use your master PIN code or master fingerprint or
mechanical key to unlock the door to which you will hear “Force lock
deactivated”.
IC CARD FEATURE REMINDER
• Other IC cards using the NFC feature may not function on other devices
once it is registered on Bosch Smart Lock.
SERVICE AND WARRANTY
• 24 hours hotline
• Genuine parts
• Lifetime service
• Extended warranty plan
PRODUCT STANDARD
This smart lock series is certified with the following national standards:
GA701-2007
General specifications for burglary-resistant fingerprint locks
GB21556-2008
General safety-technique requirements of locks
For more services and details, kindly call: [phone]
OPEN WITH FINGERPRINT
OPEN WITH EMERGENCY POWER SUPPLY
Connect with power bank
during emergency
Touch the number pad >>> Enter your registered PIN code
and press # OR enter registered card OR
scan your registered fingerprint
Tap registered card key
OPEN WITH CARD KEY
FRIENDLY REMINDER
In the event that your smart lock has malfunctioned, kindly contact your
reseller or customer service and provide the following information:
Address and contact number. Description of malfunction, purchase
date and received date, product model and product code. The
information above will help us serve you better and save you
unnecessary costs.
TERMS OF WARRANTY
The warranty service applies to manufacturing defects and regular-use
coverage only. It does not cover the following:
• Any damage caused by the user(s);
• Incorrect installation, testing and/or use other than instructed
by user manual;
• Unauthorized repair and/or modification to the product;
• Any accidental, misuse and/or intentional damages that
causes malfunction;
• Damage caused by acts of nature;
• Any loss and/or damage caused by the product’s environment
such as electricity, temperature, moisture, magnetic field
and/or any other unavoidable reasons.
• Any other reason except for product quality.
This product is under 3 (three) years warranty from the date of purchase
(as stated on the original receipt). The company provides free warranty
service for successful register user under the following terms:
Make sure to send your original purchase receipt or serial number
together with your product for our distributor. You are not entitled
to the warranty service should you fail to present the items
mentioned above.
You are not entitled to the warranty service should the purchase
receipt and/or serial number have been tampered with or altered
in any fashion.
WARRANTY AND SERVICES
PRODUCT WARRANTY CARD
SCAN the QR Code
SEND the following details:
Register via
WhatsApp
([phone])
Full Name (as per NRIC)
Email Address
Smart Lock Serial No. #
Please allow up to
3 working days for processing
and confirmation.
STEP 1
STEP 3
STEP 2
ATD LIFETECH CORPORATE SDN. BHD.
42A-1, Jalan OP 1/3, Pusat Perdagangan One Puchong,
Off Jalan Puchong 47160, Selangor
Contact:
[phone] (Sales)
[phone] (Helpline)
* (optional function) Network version requires the purchase of
network components separately.
Activate
Network
*(optional
function)
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 4, 1
Network requires the support of network
components. Refer to network components user
guide for details.
ADD NETWORK
Delete All
Fingerprint
Press S switch, enter master PIN code when
prompted by the voice guide, and press #
followed by 3, 5. Press #. Successfully deleted.
Master fingerprint cannot be deleted before the
default setting is restored.
ADD USER FINGERPRINT Enter the registered
fingerprint (Inside)
Key Hole
Use your mechanical key
when unable to use the door
lock. E.g. forgot PIN code /
electrical failure.
