Bosch DVR4C Series User manual

Digital Video Recorders Quick Guide
Bosch Digital Video Recorders DVR1A DVR1C DVR4C Divar MR Divar DiBos Micro DiBos
System
Operating System Embedded Embedded Embedded Embedded Embedded Windows XP Embedded Windows XP Embedded
Rack Mountable No No No Yes Yes Yes Yes
SDK Available No No No No Yes HTML Interface HTML Interface
Warranty 3 Years 3 Years 3 Years 3 Years 3 Years 3 Years 3 Years
Video
Input Channels 1 1 4 8, 16 6, 9, 16 Analog: 6, 12
IP: 8
Analog: 6, 12, 18, 24, 30
IP: 16, 32
Output
Looping Video Yes Yes Yes Yes Yes Yes Yes
Composite Outs 1 1 1 2 2 2 2
VGA No No No 1 No 1 1 (plus optional 2nd)
Spot Monitor No No No 1 Yes 2 2
Audio
Input 0 2 4 4, 8 n/a 2, 4
(plus 8 from IP)
2, 4, 6, 8, 10
(plus up to 32 from IP cameras)
Output 0 2 4 1 n/a 1 1
Associate Multiple Cameras to 1 Audio n/a n/a No Yes n/a Yes Yes
Alarms
Inputs 1 1 4 8, 16 6, 9 or 16 (one per video channel) 12 32
Relay Outputs 1 1 4 4, 8 4 12 16
Call Ip Pre-position on Dome Cameras n/a n/a n/a No Yes Yes Yes
Increase Frame Rate on Alarm Yes Yes Yes Yes Yes Yes Yes
Multiple Camera Linking on Alarm Event n/a n/a Yes No No Yes Yes
Notification via e-mail No No Yes Yes No Yes Yes
Notification to Remote PC No No Yes Yes Yes Yes Yes
Pre-alarm Up to 220 Seconds Up to 220 Seconds Up to 30 Seconds Up to 60 Seconds 30 Seconds Yes Yes
Post-alarm Unlimited Unlimited Up to 120 Seconds Up to 10 Minutes Up to 60 Seconds Yes Yes
Motion Detection No No Yes Yes Yes Yes Yes
Recording
Compression Video M-JPEG M-JPEG MPEG-4 MPEG-4 Wavelet MPEG-4, JPEG MPEG-4, JPEG
Software or Hardware Hardware Hardware Hardware Hardware Hardware Video Hardware, Audio Software
Frame Rate
(IPS)
PAL 50 IPS 50 IPS 100 IPS 400 IPS 50 IPS 75/150 75/150/225/300/375
NTSC 60 IPS 60 IPS 120 IPS 480 IPS 60 IPS 90/180 90/180/270/360/450
IPS per
Camera
PAL 25 IPS (Normal)
50 IPS (Alarm)
25 IPS (Normal)
50 IPS (Alarm) 25 IPS 25 IPS
6 Channels: 8.3 IPS
9 Channels: 5.0 IPS
16 Channels: 3.1 IPS
25 Per Camera Max
150 on a 12 Channel Unit
25 Per Camera Max
375 on a 30 Channel Unit
NTSC 30 IPS (Normal)
60 IPS (Alarm)
30 IPS (Normal)
60 IPS (Alarm)
30 IPS 30 IPS
6 Channels: 10 IPS
9 Channels: 6.5 IPS
16 Channels: 3.75 IPS
30 Per Camera Max
180 on a 12 Channel Unit
30 Per Camera Max
450 on a 30 Channel Unit
File Size Range 15 KB - 40 KB 15 KB - 40 KB 1 KB - 23 KB 1 KB - 30 KB 16 KB - 40 KB 1 KB - 30 KB 1 KB - 30 KB
Recorded
Video
Resolution
PAL 352 x 288 352 x 288 352 x 288 352 x 288/704 x 288/704 x 576 720 x 288 CIF/2CIF/4CIF Analog and IP Cameras
NTSC 352 x 240 352 x 240 352 x 240 352 x 240/704 x 240/704 x 480 720 x 240 CIF/2CIF/4CIF Analog and IP Cameras
Individual Camera Adjustment (IPS & Quality) n/a n/a No Yes Yes Yes Yes
Schedule Recording Modes Daily/Weekday/Weekend/Specific Day Day/Night/Weekend Day/Week/Specific Day Day/Night/Weekend/Specific Day Day/Night/Weekend/Holiday/Specific Day
HDD Overwrite Warning No No Yes Yes No Yes Yes
Recording
Times
Best Quality/Highest Res., 1
IPS Continuous, 50% Motion,
Very Busy Scene (Outdoor)
23 Days (80 GB) 46 Days (160 GB)
13 Days (80 GB)
26 Days (160 GB)
53 Days (320 GB)
99 Days (600 GB)
8 Channels: 13 Days (500 GB)
8 Channels: 27 Days (1000 GB)
16 Channels: 13 Days (1000 GB)
16 Channels: 27 Days (2000 GB)
6 Channels: 17 Days (320 GB)
9 Channels: 12 Days (320 GB)
9 Channels: 22 Days (600 GB)
16 Channels: 13 Days (600 GB)
16 Channels: 21 Days (1000 GB)
6 Channels: 75 Days (400 GB)
12 Channels: 37 Days (400 GB)
6 Channels: 140 Days (750 GB)
12 Channels: 70 Days (750 GB)
18 Channels: 62 Days (1000 GB)
24 Channels: 75 Days (1600 GB)
30 Channels: 60 Days (1600 GB)
Normal Quality/Standard
Res., 1 IPS Continuous, 50%
Motion, Very Busy Scene
(Outdoor)
37 Days (160 GB) 75 Days (160 GB)
40 Days (80 GB)
78 Days (160 GB)
157 Days (320 GB)
294 Days (600 GB)
8 Channels: 58 Days (500 GB)
8 Channels: 117 Days (1000 GB)
16 Channels: 58 Days (1000 GB)
16 Channels: 234 Days (2000 GB)
6 Channels: 53 Days (320 GB)
9 Channels: 36 Days (320 GB)
9 Channels: 66 Days (600 GB)
16 Channels: 38 Days (600 GB)
16 Channels: 63 Days (1000 GB)
6 Channels: 449 Days (400 GB)
12 Channels: 225 Days (400 GB)
6 Channels: 842 Days (750 GB)
12 Channels: 422 Days (750 GB)
18 Channels: 375 Days (1000 GB)
24 Channels: 450 Days (1600 GB)
30 Channels: 360 Days (1600 GB)

Digital Video Recorders Quick Guide
F01U012210 01.28.08
Bosch Digital Video Recorders DVR1A DVR1C DVR4C Divar MR Divar DiBos Micro DiBos
Storage
Internal HDD 80 GB 160 GB 80 - 160 - 320 - 600 GB 160-320-500-1000-2000GB 80 - 160 - 320 - 600 - 1000GB 120 - 250 - 400 GB 250 - 500 - 750 - 1000 - 1600 GB
Export
Supported Devices Compact Flash Compact Flash USB 1.1 Internal CD/DVD Writer, USB 2.0 Internal CD/DVD Writer
Remote Client
CD-RW, DVD, USB 2.0,
Network Drive, SCSI
CD-RW, DVD, USB 2.0,
Network Drive, SCSI
Data Format JPEG JPEG Native, AVI, or JPEG Native File Format Native File Format Bosch, ASF Bosch, ASF
Back-up Mode Manual Manual Manual Manual or Automatic Manual Manual or Automatic Manual or Automatic
Support SCSI Disk Array No No No No Yes, DVSA (Lite and Premium) Yes, DVSA (Lite and Premium) Yes, DVSA (Lite and Premium)
Max. SCSI Array Configuration n/a n/a n/a n/a 12 TB* 13.8 TB** 13.8 TB**
Search
Timeline Search Bar (Color Coded) No No Yes on Remote Software Yes Yes on Remote Software Yes Yes
Zoom and Movement No No Yes No Yes Yes Yes
Search Mode Date/time, Events, or Recordings List Date/time, Events, Motion, Text
Date/time, Camera Number, Events,
Motion, Bookmark, Smart Motion
Search
Date/time, Camera Number, Events,
Motion, Smart Motion Search Date/time, Camera Name, Events, Pre-Alarm, Motion, Smart Motion Search
Smart Motion Search – Motion in specific area No No No Yes Yes Yes Yes
Display
Live
Resolution
PAL 720 x 576 720 x 576 720 x 576 720 x 576 720 x 576 CIF/2CIF/4CIF Analog and IP
Cameras
CIF/2CIF/4CIF Analog and IP
Cameras
NTSC 720 x 484 720 x 484 720 x 484 720 x 484 720 x 484 CIF/2CIF/4CIF Analog and IP
Cameras
CIF/2CIF/4CIF Analog and IP
Cameras
Screen Division (Multi-screen) Full
2x2, 3x3 (w/ Quad or Mux attached)
Full
2x2, 3x3 (w/ Quad or Mux attached) Full, 2x2, Sequence Full, Sequence, 2x2, 3x3, 4x4, 5+1, 7+1 Full, 2x2, 3x3, 4x4 Full, 2x2, 3x3, 4x4, 5x6 Full, 2x2, 3x3, 4x4, 5x6
Camera Lock-outs by User No No No Yes Yes Yes Yes
Security/User
Management
User Control
User Levels 1 3 2 3 6 Unlimited Unlimited
Add/Delete No No No Yes Yes Yes Yes
Set Viewing Permissions No No Yes Yes Yes Yes Yes
Centralized User Management n/a No No No No Yes - LDAP Yes - LDAP
Event Logging by User No No No No No Yes Yes
Data Integrity Check (Watermarking, etc.) Yes Yes Yes Yes Yes Yes Yes
Remote Access
Network Connection 10BaseT Ethernet 10BaseT Ethernet 10/100 Ethernet 10/100 Ethernet 10/100 Ethernet 10/100/1000 Ethernet 10/100/1000 Ethernet
Protocol TCP/IP TCP/IP TCP/IP TCP/IP TCP/IP TCP/IP, UDP Tunneling TCP/IP, UDP Tunneling
Web Browser Access No Yes No Yes Yes Yes Yes
Simultaneous Accessible Users n/a 4 5 5 6 20 with software; 5 with web browser
Remote PC
Client
Resolution n/a n/a 720 x 576 (PAL)
720 x 484 (NTSC)
352 x 288 (PAL)
352 x 240 (NTSC)
720 x 576 (PAL)
720 x 484 (NTSC)
CIF/2CIF/4CIF Analog and IP
Cameras
CIF/2CIF/4CIF Analog and IP
Cameras
Full Admin Control n/a n/a Yes Yes Yes Yes, Remote Desktop Yes, Remote Desktop
PTZ Control n/a n/a n/a Yes Yes Yes Yes
Export Options n/a n/a Native, AVI, or JPEG Native File Format Native File Format (all cameras),
.AVI (single camera)
Bosch (All Cameras)
ASF (Individual and Multiple Camers)
Other Features
Instant Playback No No No Yes Yes Yes Yes
Bilinx/Up-the-Coax Camera Control No No No No Yes Yes Yes
Integrates with G Series Panels No No No No Yes Yes Yes
PTZ Joystick Control No No No Yes Yes Yes - DiBos/BVMS Yes - DiBos/BVMS
ATM/POS Interface No No No No Yes No No
OPC Support No No No No Yes Yes Yes
Ordering Information
Part Numbers/Ordering Charts DVR1A1081 DVR1C1161
DVR4C1081 (80 GB)
DVR4C1161 (160 GB)
DVR4C2161 (320 GB)
DVR4C2301 (600 GB
DVR-8K-016A (160 GB)
DVR-16K-032A (320 GB)
DVR-8L-016A (160 GB/DVD)
DVR-8L-032A (320 GB/DVD)
DVR-8L-050A (500 GB/DVD)
DVR-8L-100A (1000 GB/DVD)
DVR-16L-032A (320 GB/DVD)
DVR-16L-050A (500 GB/DVD)
DVR-16L-100A (1000 GB/DVD)
DVR-16L-200A (2000 GB/DVD)
* Due to SCSI specifications, the daisy chaining of more than two Digital Video Storage Array subsystems (DVA-08K/DVA-16K) on a single Divar is NOT RECOMMENDED. Divar can address up to 6 SCSI IDs (7
for units without DVD writer) and a maximum of 2TB per ID (12TB with DVD writer or 14TB for units without a DVD writer) Stated capacities assume JBOD configuration 8% overhead on the HDDs.
** Due to SCSI specifications, the daisy chaining of more than three Digital Video Storage Array subsystems (DVA-08K/DVA-16K) on a single DiBos is NOT RECOMMENDED. The maximum configuration is (2)
DVA-16Ks or (1) DVA16K and (2) DVA08Ks daisy chained. Stated capacities assume JBOD configuration and 8% overhead on the HDDs.
DB D2
06
12
C1
C2
040
025
Version
Capacity (x 10 GB)
Inputs
Model
Type
6 inputs and
120, 250, 400 GB
12 inputs and
250, 400 GB
012
DVR 2
06
16
09
G
E
F
H
2
1
30
08
16
50
Revision
Capacity Multiplier†
Inputs
Type
Divar
Divar with DVD writer
Divar with Bilinx
Divar with Bilinx
and DVD Writer
Capacity
(x 10 GB)
DB
06
18
12
Inputs
Type 160
075
100
050
025
6 inputs and 750 GB
Capacity (x 10 GB)
24
30
R2
S
Version
SCSI
Adapter
C5
C3
C4
C2
C1
Model
12 inputs and 750 GB
18 inputs and 250,
500, 1000, 1600 GB
24 inputs and 250,
500, 1000, 1600 GB
30 inputs and 250,
500, 1000, 1600 GB
† This factor is multiplied by the capacity to determine the
overall storage capacity (ex. 2 x 50 x 10 = 1000 GB)
