Bosch Radion B810 User manual

RADION receiver SD
B810
en Installation manual

RADION receiver SD Table of contents | en 3
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Table of contents
1Introduction 6
1.1 About documentation 7
1.2 Bosch Security Systems, Inc. product manufacturing
dates
7
2General installation 8
2.1 Installation workflow 9
2.2 Unpacking information 9
2.3 Wall tamper switch installation 10
2.4 Magnet cover installation 11
2.5 Complete installation 11
2.6 Maintenance 11
3RADION receiver SD 13
3.1 Check-in interval and power level for RADION devices 13
3.2 Certifications and approvals 14
3.3 UL product requirements 18
3.4 Installation 22
3.4.1 Configuration 22
3.4.2 Base installation 24
3.4.3 Wiring considerations 25
3.4.4 Programming wireless points in the control panel 26
3.4.5 Enroll point RF ID for wireless points (Auto-learn mode) 29
3.4.6 Walk test (for motion detectors) 30
3.4.7 Signal level and margin 31
3.4.8 Complete the installation 33
3.4.9 B810 system test 33
3.5 External LED states 33
3.5.1 LEDs 35
3.6 Specifications 37
3.6.1 Battery requirements 37
4RADION repeater 41
4.1 Installation considerations 42
4.2 Wiring considerations 42
4.3 Specifications 42
4.4 LEDs 44

4en | Table of contents RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
5RADION glassbreak 46
5.1 Installation considerations 47
5.2 Testing 48
5.3 Low battery 51
5.4 Wall Tamper Tab 51
5.5 Maintenance 51
6RADION TriTech 52
6.1 Mounting height and range adjustment 53
6.2 Sensitivity settings 54
6.3 Walk testing 54
7RADION PIR 57
7.1 Walk testing 58
8RADION PIR C 60
8.1 Walk testing 61
9RADION smoke RFSM2 63
10 RADION CO 64
11 RADION heat 65
12 RADION smoke 66
12.1 Battery replacement 68
12.2 Smoke test 68
12.3 Sensitivity test 68
12.4 Test/Silence button 69
12.5 LED 70
12.6 Clean the detector and replace the optical chamber 70
13 RADION contact SM 72
13.1 Installation considerations 73
14 RADION contact RM 75
14.1 Installation considerations 76
15 RADION specialty 77
15.1 Applications for this product 78
15.2 Installation consideration 79
16 RADION universal transmitter 80
16.1 Installation considerations 81
16.2 Reed switch settings 83
17 RADION keyfob 84

RADION receiver SD Table of contents | en 5
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
17.1 RADION keyfob FB 86
17.2 RADION keyfob TB 87
18 RADION panic FP 89
19 Appendices 91

6en | Introduction RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
1 Introduction
This document contains the basic information that a trained
installer needs to install the RADION system. It supplements the
documents listed inside the packaging (graphical installation
guides).
This reference guide contains:
– A description of the general installation procedure.
– Device-specific installation procedures.
– Specification information.
How to use this document
The information contained in this document is constructed in a
manner that is systematic and sequential for the installer on a
“point of need” basis. The following represents a basic outline
of that information;
– Chapter 1 (this chapter) – introductory information and
how to use this document.
– Chapter 2 – basic RADION system-wide general installation
information and workflow check list.
– Chapter 3 – RADION receiver-specific installation
information.
– Remaining chapters – RADION device-specific installation
information.
– Appendix – description of various icons and symbols used
within the RADION documentation.
Icons and symbols
When you see the following logo in the RADION graphical
installation guides listed in Table 3.1, refer to the appropriate
section in this document.

RADION receiver SD Introduction | en 7
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Additional icons and symbols, which appear in the RADION
graphical installation guides, are explained in the appendix
section of this guide. Refer to the Appendices, page 91 for
more information.
1.1 About documentation
Copyright
This document is the intellectual property of Bosch Security
Systems, Inc. and is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document
are likely to be registered trademarks and must be treated
accordingly.
1.2 Bosch Security Systems, Inc. product
manufacturing dates
Use the serial number located on the product label and refer to
the Bosch Security Systems, Inc. website at http://
www.boschsecurity.com/datecodes/.

8en | General installation RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
2 General installation
Phases of installation
The installation of the RADION system is achieved by following
the sequential process as defined in this chapter. Overall, there
are four main phases;
– Planning
– Physical installation of the devices
– System enrollment/configuration
– System testing (walk test, pattern test)
It is essential that these steps or phases are adhered to in the
order mentioned above for proper functionality and operation.
When installing a RADION system, you must plan your
installation based on the control panel and RADION device
specifications, and the radio-frequency signal strength (RFSS)
between devices, receivers, and control panels.
Installation considerations
– RADION devices are intended only for indoor, dry
applications.
– Mount RADION devices on flat, rigid surfaces. Some devices
can be optionally corner mounted as indicated in the
installation instructions.
– Avoid mounting RADION devices in areas with large,
metallic objects, electrical panels, or electric motors. They
might reduce the radio-frequency (RF) range of a RADION
device.
– Avoid installing the devices where excessive humidity,
moisture, or temperatures outside of the acceptable
operating range exist.
– Wire all objects according to their specifications.
– RADION devices use batteries of varying types. When
installing batteries, observe safety and polarity
recommendations as indicated in the documentation for
those products.

RADION receiver SD General installation | en 9
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
2.1 Installation workflow
To install, configure, and test the system, use the workflow
below and follow in sequential order, from top to bottom,
checking each box as you complete a step.
Notice!
Always power down the control panel when connecting
modules, or other wiring. Power down the control panel by
unplugging the transformer and disconnecting the battery
Plan the installation of the RADION system
Install the RADION components (refer to the graphical
installation guides and this system reference guide for details)
Program wireless points in the control panel
Enroll point RF ID for wireless points
Verify LED responses on devices
Perform a local walk test for installed detectors
Review signal strength and margin of each point
Complete the installation
2.2 Unpacking information
When unpacking the receiver, repeater, or bill trap device, it is
important to remove the cardboard insert as illustrated below;

10 en | General installation RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
Figure2.1: Insert for the receiver and repeater
Figure2.2: Insert for the bill trap
2.3 Wall tamper switch installation
RADION transmitter devices contain a feature that activates the
wall tamper switch located on the base of the device. In order to
properly install the device, you must consider the following:
– To properly install a device with active wall tamper
functionality, insert a screw in the designated screw slot
location.
– Failure to insert a screw into the wall tamper slot prevents
the wall tamper feature from generating a tamper signal
when the transmitter is pulled away from a wall.

RADION receiver SD General installation | en 11
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
2.4 Magnet cover installation
During the installation of the plastic magnet cover, the cover is
not designed to be separated from the base after the base and
cover are snapped together. Damage to the plastics may occur if
separated.
2.5 Complete installation
Testing the entire RADION system can only be achieved by
performing an area wide test through the control panel and
corresponding keypad(s). This is achieved by performing an
overall service walk test. Refer to your control panel
documentation for system-walk, or other system-wide testing
procedures.
To ensure proper operation of the RADION devices, test the
basic functionality of the device locally. Depending on the
RADION device to be tested, perform the following procedures
for functionality:
– When testing the receiver, power up the compatible control
panel in which the receiver is connected to and observe the
LED behavior on the receiver.
– Local walk testing can be performed on the motion
detectors as defined in the tritech and PIR chapters of this
guide.
– Magnet testing can be performed by opening or closing the
door/window in which the magnet is installed on.
2.6 Maintenance

12 en | General installation RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
It is recommended to check the battery of each device annually.
This will ensure proper operation and functionality of the
devices.
Battery Life Extension feature (PIR and TriTech)
In the normal operating mode, an alarm can be transmitted only
after three (3) minutes have passed since the previous alarm
restoral. This 3 minute lockout time reduces unnecessary RF
transmissions in high traffic areas, thereby extending battery
life.

RADION receiver SD RADION receiver SD | en 13
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
3 RADION receiver SD
The receiver connects RADION wireless peripherals to
supported Bosch control panels using the SDI2 bus connection.
A compatible control panel powers the receiver through the
wiring connection. Features include:
– Easy addressing via a rotary switch
– Cover and wall tamper protection
– RFID and configuration data are contained in persistent
memory
– External LED
– Detection and reporting radio frequency interference
– Supports supervision of wireless points (504), keyfobs
(1000), and repeaters (8)
3.1 Check-in interval and power level for
RADION devices
The RADION suite of devices come in three varieties and are
compatible with three RADION receivers. The three varieties are:
-A versions (ex. RFRP -A), Non -A versions (ex. RFRP), or CHI
versions (ex. RFRP-CHI).
Each variety of detector was originally designed for a certain
geographical region, and catered to that specific region's
regulatory requirements. The B810 receiver supports all device
versions. The slight differences are described below:
– -A version. The -A version is called the "American" version
and complies with applicable regulatory requirements, and
is used in North and South America. -A devices are sold in
North and South America. The supervision message is 3 dB
lower than the alarm message, and the supervision interval
is (approx.) every 65 minutes.
– Non -A version. The Non -A version is the European version
and complies with applicable regulatory requirements in
Europe. Non - A devices are sold in Europe, Africa, and

14 en | RADION receiver SD RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
Australia. The supervision and alarm messages operate at
the same power level and the check-in interval is 13
minutes.
– CHI version. The CHI version is the Chinese version and
complies with applicable regulatory requirements in China.
CHI devices are sold exclusively in China. The supervision
and alarm messages operate at the same power level and
the check-in interval is 13 minutes.
The following table shows check-in intervals and power levels
for all RADION devices within the B810 wireless receiver
security system.
Check-in differences between -A and non -A RADION devices
Item -A version Non -A/CHI
version
Devices
affected
Check-in
interval
65 minutes 13 minutes All RADION
devices
Power level
for check-in
messages
3 db less than
alarm
message
Same as alarm
message
All RADION
devices
Tab.3.1: Check-in differences
3.2 Certifications and approvals
Listings and approvals
UL
The B810 is UL listed for Commercial/Residential Burglar Alarm
Systems, and Household Fire Warning System Units.

RADION receiver SD RADION receiver SD | en 15
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Products evaluated by UL
The following products have been evaluated by UL:
– B810 wireless receiver
– RFRP-A repeater
– RFBT-A specialty (billtrap)
– RFDW-SM-A standard door/window contact
– RFDW-RM-A recessed door/window contact
– RFDL-11-A motion detector
– RFPR-12-A PIR motion detector
– RFPR-C12-A PIR motion detector (curtain)
– RFUN-A universal transmitter
– RFSM-A smoke detector
– RFSM2-A smoke detector
– RFHT-A heat detector
– RFCO-A CO detector
– RFKF-TB-A keyfob
– RFKF-FB-A keyfob
– RFPB-TB-A panic
– RFPB-SB-A panic
– RFPB-FP-A fixed position panic
– RFKF-FBS-A keyfob
– RFKF-TBS-A keyfob
Products not evaluated by UL
The following products have not been evaluated by UL:
– RFGB-A/RFGB/RFGB-CHI glassbreak
– RFRP/RFRP-CHI repeater
– RFBT/RFBT-CHI specialty (billtrap)
– RFDW-SM/RFDW-SM-CHI standard door/window contact
– RRDW-RM/RFDW-RM-CHI recessed door/window contact
– RFDL-11/RFDL-11-CHI motion detector
– RFPR-12/RFPR-12-CHI motion detector
– RFPR-C12/RFPR-C12-CHI motion detector (curtain)
– RFUN/RFUN-CHI universal transmitter
– RFSM/RFSM-CHI smoke detector
– RFKF-FB/RFKF-FB-CHI keyfob

16 en | RADION receiver SD RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
– RFKF-TB/RFKF-TB-CHI keyfob
– RFKF-FBS/RFKF-FBS-CHI keyfob
– RFKF-TBS/RFKF-TBS-CHI keyfob
– RFPB-TB/RFPB-TB-CHI panic
– RFPB-SB/RFPB-SB-CHI panic
UL battery requirements
UL recommends to check the battery of each device annually.
This will ensure proper operation and functionality of the
devices.
For the RFBT-A bill trap, UL requires the battery to be replaced
annually to ensure optimal performance.
Battery testing
To ensure proper functionality of each RADION device, it is
recommended to test your batteries annually via your supported
control panels wireless diagnostics routine. For specific
information related to system diagnostics and battery testing,
refer to your supported control panel documentation.
Federal Communications Commission (FCC) Rules
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference

RADION receiver SD RADION receiver SD | en 17
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician
for help.
INDUSTRY CANADA (IC) Rules
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada.
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le
présent émetteur radio peut fonctionner avec une antenne d'un
type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada.

18 en | RADION receiver SD RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
Dans le but de réduire les risques de brouillage radioélectrique
à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communication satisfaisante.
CE
RCM
This device is RCM marked and complies with applicable
Australian requirements.
3.3 UL product requirements
Notice!
For all wireless devices, receivers, and/or repeaters, do not
install on removable surfaces such as ceiling tiles.
For product-specific UL requirements, refer to desired product
title below for more information.
RADION Repeater
When selecting a suitable 16.5 VAC Class 2 plug in transformer,
the following transformers are suggested:
– MG Electronics (MGT-1640)
– Codex SEP-1640
The transformers mentioned above are Primary Rated 120 VAC,
60 Hz, 0.48 Amps, Secondary 16.5 VAC, 40 VA.
When selecting a suitable 18 VAC Class 2 plug-in transformer,
the following transformers are suggested:
– TDC Part No DA-22-18, Primary Rated 120 VAC, 60 Hz, 30
VA, Secondary Rated 18 VAC, 1.22 Amps, 22 VA.

RADION receiver SD RADION receiver SD | en 19
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Notice!
For UL installations when transformer is used, restraining tab is
to be connected.
Notice!
For UL installations when a repeater is installed, a minimum of
two repeaters must be installed for proper signal routing.
Information related to the internal standby battery is as follows:
– Power/voltage (Standby Battery): Rated 3.7 VDC,
3050mAH, EVE ENERGY CO Part No P0046-LF (Not user
replaceable)
Notice!
For standby battery to be operative, the tamper switch is
required to be engaged.
Standby battery is capable of providing 72 hours of standby
power to the RF repeater for a UL Burglar Alarm Installation
(Bank Safe and Vault).
– 24 Hours for Household Fire Warning Systems
– 8 Hours for HOLD UP Burglar Alarms
– 4 Hours for Burglar Alarm Mercantile Installations
RADION glassbreak
Notice!
The RFGB-A has not been investigated by UL, and not part of a
UL Listed system.

20 en | RADION receiver SD RADION receiver SD
2020.05 | 13 | F.01U.261.834 Bosch Security Systems B.V.
RADION TriTech
Notice!
Pet Immunity has not been evaluated by UL.
Notice!
Draft and Insect Immunity has not been evaluated by UL.
RADION smoke
For UL installations THIS UNIT INCLUDES AN ALARM
VERIFICATION FEATURE THAT WILL RESULT IN A DELAY OF THE
SYSTEM ALARM SIGNAL FROM THE INDICATED CIRCUITS. THE
TOTAL DELAY (CONTROL UNIT PLUS SMOKE DETECTORS)
SHALL NOT EXCEED 60 SECONDS. NO OTHER SMOKE
DETECTOR SHALL BE CONNECTED TO THESE CIRCUITS
UNLESS APPROVED BY THE LOCAL AUTHORITY HAVING
JURISDICTION.
RADION contact SM
During the installation of the device, UL installations primary
securement means shall be screws.
RADION contact RM
During the installation of the device, UL installations primary
securement means shall be screws.
RADION specialty
When programming the bill trap, special programming for a hold
up device is required. Program the point as follows:
– P## Type = 2 (Point is constantly armed regardless of the
status of the system).
