ISW-EN4200 Serial Receiver Installation Guide
Overview
The Bosch Commercial Wireless ISW-EN4200 Serial Receiver,
powered by Inovonics wireless mesh network technology, connects
Commercial Wireless Sensors to supported Bosch control panels via
the ISW-D8125CW-V2 Interface Module.
These instructions cover installation of the ISW-EN4200 Serial
Receiver. For detailed programming instructions, refer to the
ISW-D8125CW-V2 Installation and Operation Guide
(P/N: F01U161691).
1.0 Installation
Use the provided anchors and screws to mount the ISW-EN4200 in
locations accessible for future maintenance.
For best transmitter reception results, place the
ISW-EN4200 in a central location among the transmitters. If
transmitters are too far away for the receiver to pick up the
transmission, install an ISW-EN5040-T Commercial Wireless RF
Repeater.
For UL Listed installations, install the
ISW-D8125CW-V2 Commercial Wireless Interface
Module within 20 ft (6 m) of, and within the same
room as, the ISW-EN4200.
Mount the serial receiver in a location removed from
metal. Metal objects (duct work, wire mesh screens,
boxes) reduce RF range.
2.0 Configuration
Bosch Commercial Wireless products use a range of radio
frequencies and must be configured for your geographic area.
All selection jumpers are shipped in their default positions
(Figure 1). If you want to keep the default selections, setting the
jumpers is not necessary. The ISW-EN4200 ships configured for
North America frequencies.
Figure 1: ISW-EN4200 Serial Receiver Components
TAMPER
TX Vs RXGND
NZ AUS
DEC
RX
TX
Vs
GND
TX
RX
1
2
4
3
5
6
7
8
9
10
11
1 - Side cabling knockout
2 - Bottom cabling knockout
3 - Housing release tab
4 - Tamper switch
5 - Reset button
6 - DEC (decode) LED
7 - Frequency Band pins:
- No jumper = North America (902 MHz to 928 MHz)
- AUS = Australia (915 MHz to 928 MHz)
- NZ = New Zealand (921 MHz to 928 MHz)
8 - RX (receive) LED
9 - TX (transmit) LED
10 - Serial data terminal
11 - Serial data port
T
To configure the serial receiver:
1. If the serial receiver is powered on, remove the power source
to reset the serial receiver.
2. Use a small screwdriver to press the housing release tab
(Figure 1). Separate the housing.
3. Place a jumper plug on the appropriate Frequency Band pins
(Figure 1). For North America, remove the jumper plug
(default position).

2 | F01U167054-01 | 8/10 ISW-EN4200 Serial Receiver Installation Guide ©2010 Bosch Security Systems, Inc.
3.0 Wiring Connections
Do not install long cable runs next to high-current
power feeds.
Keep cable lengths as short as possible to minimize
noise pickup.
Measure voltage at the serial receiver on long cable
runs.
To connect the ISW-EN4200 to the ISW-D8125CW-V2:
1. Remove all power from the system (AC and standby battery).
2. Route the cabling through either the bottom cabling knockout
or the side cabling knockout on the ISW-EN4200.
Refer to Figure 1.
3. Connect the serial data terminal block on the ISW-EN4200 to
the data terminal block on the ISW-D8125CW-V2.
Refer to Figure 2 below, or Figure 3 on page 3.
Ensure that the wiring used meets the following specifications:
- Four-conductor unshielded 20 AWG (or larger)
- Wire length must not exceed 30.5 m (100 ft)
For UL Listed installations, install the ISW-D8125CW-V2
Commercial Wireless Interface Module within 20 ft (6 m)
of, and within the same room as, the ISW-EN4200.
4. Connect the ISW-D8125CW-V2 to the control panel.
- For all versions of the D7412 and D7212 Control Panels,
you can connect one ISW-D8125CW-V2 Commercial
Wireless Interface Module, and up to two ISW-EN4200
Serial Receivers. Refer to Figure 2 below.
- For all versions of the D9412 Control Panel, and the
D9112 Control Panel, you can connect two
ISW-D8125CW-V2 Commercial Wireless Interface Modules
(one to Zonex 1 and the other to Zonex 2), and up to four
ISW-EN4200 Serial Receivers (two to each
ISW-D8125CW-V2). Refer to Figure 3 on page 3.
Figure 2: ISW-D8125CW-V2 to D7412 and D7212 (GV3, GV2, and G) Control Panel Wiring Diagram
ZONEX BUS RECEIVER 2RECEIVER 1
+12V
TX1
RX1
GND
+12V
IN
OUT
GND
+12V
TX2
RX2
GND
Vs
RX
TX
GND
Vs
RX
TX
GND
ZONEX OUT 1
ZONEX IN 1
27
28
2
1
3
4
3
+ AUX PO ER
COMMON
9
1 - ISW-D8125CW-V2 connected to Zonex 1 on control panel (Points 9 to 127)
2 - Control Panel
3 - ISW-EN4200 Receiver (RECEIVER 1 on ISW-D8125CW-V2)
4 - ISW-EN4200 Receiver (RECEIVER 2 on ISW-D8125CW-V2)

©2010 Bosch Security Systems, Inc. ISW-EN4200 Serial Receiver Installation Guide 8/10 | F01U167054-01 | 3
Figure 3: ISW-D8125CW-V2 to D9412 (GV3, GV2, and G) and D9112 Control Panel Wiring Diagram
ZONEX OUT 2
ZONEX IN 2
ZONEX PO ER +
ZONEX COMMON
23
24
25
26
27
28
ZONEX OUT 1
ZONEX IN 1
ZONEX BUS RECEIVER 2RECEIVER 1
+12V
TX1
RX1
GND
+12V
IN
OUT
GND
+12V
TX2
RX2
GND
Vs
RX
TX
GND
Vs
RX
TX
GND
ZONEX BUS RECEIVER 2RECEIVER 1
+12V
TX1
RX1
GND
+12V
IN
OUT
GND
+12V
TX2
RX2
GND
Vs
RX
TX
GND
Vs
RX
TX
GND
3
1
4
5
2
6
7
1 - ISW-D8125CW-V2 connected to Zonex 1 on control panel (Points 9 to 127)
2 - ISW-D8125CW-V2 connected to Zonex 2 on control panel (Points 129 to 247)
3 - Control Panel
4 - ISW-EN4200 Receiver (RECEIVER 1 on first ISW-D8125CW-V2)
5 - ISW-EN4200 Receiver (RECEIVER 2 on first ISW-D8125CW-V2)
6 - ISW-EN4200 Receiver (RECEIVER 1 on second ISW-D8125CW-V2)
7 - ISW-EN4200 Receiver (RECEIVER 2 on second ISW-D8125CW-V2)

Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450
USA
www.boschsecurity.com
© Bosch Security Systems, Inc., 2010
F01U167054-01
Installation Guide
8/1
0
ISW-EN4200 Serial Receive
r
Page 4 of
4
4.0 Register the RF Transmitters
You must register all transmitters and repeaters with the
ISW-D8125CW-V2. Bosch Commercial Wireless devices employ
wireless registration, so there is no need to connect the transmitter
to the ISW-D8125CW-V2. No data is written to the transmitter
during registration.
To register transmitters and repeaters (end devices):
1. Program the transmitter as described in the ISW-D8125CW-V2
Installation and Operation Guide (P/N: F01U161691).
2. When prompted by the ISW-D8125CW-V2, press the RESET
button on the end device.
- Press the end device’s RESET button once if the
ISW-D8125CW-V2 is set to accept registration after a
single reset message
- Press the end device’s RESET button twice if the
ISW-D8125CW-V2 is set for a double button push.
- Depending on which ISW-EN4200 Serial Receiver received
the reset message, either the RX1 LED or the RX2 LED on
the ISW-D8125CW-V2 lights when the first reset message
is received.
- Depending on which ISW-EN4200 Serial Receiver received
the reset message, either the RX1 LED or the RX2 LED on
the ISW-D8125CW-V2 lights when the last reset message is
received.
3. When the end device is successfully registered, the
ISW-D8125CW-V2 shows “Programmed”on its keypad display.
4. From the control panel, perform a walk test to ensure all
registered devices work as expected. To perform a walk test,
refer to your control panel documentation.
5.0 ISW-EN4200 LEDs
Use the following LEDs to monitor serial receiver operation.
Refer to Table 1 below and Figure 1 on page 1.
Table 1: ISW-EN4200 LEDs
LED Description
TX Transmit LED
Lights when the serial receiver is transmitting
data to the ISW-D8125CW-V2.
RX Receive LED
Lights when the serial receiver is receiving data
from the ISW-D8125CW-V2.
DEC Decode LED
Lights when the serial receiver is decoding an RF
transmission from a Commercial Wireless device.
6.0 Specifications
Housing Dimensions
(H x W x D) 162 x 91.4 x 27.9 mm (6.4 x 3.6 x 1.1 in.)
Weight 14.2 g (0.5 oz)
Power Requirements 12 VDC at 1 W
Maximum Current Draw 100 mA
Operating Environment 0°to 60°C (32°to 140°F), 90%
relative humidity, non-condensing
Compatible Control
Panels
GV3 Series: D9412GV3,
D7412GV3, D7212GV3
GV2 Series: D9412GV2,
D7412GV2, D7212GV2
G Series: D9412G, D7412G,
D7212G
9000 Series: D9412, D9112,
D7412, D7212
(Firmware 6.3 or later)
