Bosch DIVAR IP 2000 DIP-2040EZ-00N User manual

DIVAR IP 2000
DIP-2040EZ-00N, DIP-2042EZ-4HD, DIP-2042EZ-2HD
en Installation Manual

Table of contents
1Safety precautions 4
1.1 General safety precautions 4
1.2 Electrical safety precautions 7
1.3 ESD precautions 8
1.4 Operating precautions 9
2Available documentation 10
3System overview 11
3.1 Device views 11
3.2 LED description - front panel 14
3.3 LAN port LED description - rear panel 15
4Chassis setup 16
4.1 Removing hard drive trays 16
4.2 Installing a hard drive 17
5Installation - first steps 18
5.1 Setup notes 18
5.2 Connecting the unit 18
6Obtainging a basic configuration 20
7Advanced configuration 21
8Maintaining the system 23
8.1 Monitoring the system 23
8.2 Recovering the unit 24
8.3 Backing up the configuration 25
8.4 Adding/replacing hard disks 26
8.4.1 Extending a 2-disk unit 26
8.4.2 Extending an empty unit 27
8.4.3 Replacing hard disks 27
8.5 Updating the system 28
8.6 Using the IP Helper tool 29
9End-user license agreement (EULA) 30
DIVAR IP 2000 Table of Contents | en 3
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Safety precautions
Observe the safety precautions in this chapter.
General safety precautions
Follow these rules to ensure general safety:
– Keep the area around the system clean and free of clutter.
– Place the chassis top cover and any system components
that have been removed away from the system or on a table
so that they won't accidentally be stepped on.
– While working on the system, do not wear loose clothing
such as neckties and unbuttoned shirt sleeves, which can
come into contact with electrical circuits or be pulled into a
cooling fan.
– Remove any jewelry or metal objects from your body, which
are excellent metal conductors that can create short
circuits and harm you if they come into contact with printed
circuit boards or areas where power is present.
!
Warning!
Interruption of mains supply:
Voltage is applied as soon as the mains plug is inserted into the
mains socket.
However, for devices with a mains switch, the device is only
ready for operation when the mains switch (ON/OFF) is in the
ON position. When the mains plug is pulled out of the socket,
the supply of power to the device is completely interrupted.
1
1.1
4en | Safety precautions DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

!
Warning!
Removing the housing:
To avoid electric shock, the housing must only be removed by
qualified service personnel.
Before removing the housing, the plug must always be removed
from the mains socket and remain disconnected while the
housing is removed. Servicing must only be carried out by
qualified service personnel. The user must not carry out any
repairs.
!
Warning!
Power cable and AC adapter:
When installing the product, use the provided or designated
connection cables, power cables and AC adaptors. Using any
other cables and adaptors could cause a malfunction or a fire.
Electrical Appliance and Material Safety Law prohibits the use
of UL or CSA-certified cables (that have UL/CSA shown on the
code) for any other electrical devices.
!
Warning!
Lithium battery:
Batteries that have been inserted wrongly can cause an
explosion. Always replace empty batteries with batteries of the
same type or a similar type recommended by the manufacturer.
Handle used batteries carefully. Do not damage the battery in
any way. A damaged battery may release hazardous materials
into the environment.
Dispose of empty batteries according to the manufacturer's
instructions.
DIVAR IP 2000 Safety precautions | en 5
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

!
Warning!
Handling of lead solder materials used in this product may
expose you to lead, a chemical known to the State of California
to cause birth defects and other reproductive harm.
Notice!
Electrostatically sensitive device:
To avoid electrostatic discharges, the CMOS/MOSFET
protection measures must be carried out correctly.
When handling electrostatically sensitive printed circuits,
grounded anti-static wrist bands must be worn and the ESD
safety precautions observed.
Notice!
Installation should only be carried out by qualified customer
service personnel in accordance with the applicable electrical
regulations.
Disposal
Your Bosch product has been developed and
manufactured using high-quality materials and
components that can be reused.
This symbol means that electronic and electrical
devices that have reached the end of their working
life must be disposed of separately from
household waste.
In the EU, separate collecting systems are already
in place for used electrical and electronic
products. Please dispose of these devices at your
local communal waste collection point or at a
recycling center.
6en | Safety precautions DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

Electrical safety precautions
Basic electrical safety precautions should be followed to protect
you from harm and the system from damage:
– Be aware of the locations of the power on/off switch on the
chassis as well as the room's emergency power-off switch,
disconnection switch or electrical outlet. If an electrical
accident occurs, you can then quickly remove power from
the system.
– Do not work alone when working with high voltage
components.
– Power should always be disconnected from the system
when removing or installing main system components, such
as the motherboard or memory modules. When
disconnecting power, you should first turn off the system
and then unplug the power cords from all the power supply
modules in the system.
– When working around exposed electrical circuits, another
person who is familiar with the power-off controls should
be nearby to switch off the power if necessary.
– Use only one hand when working with powered-on
electrical equipment. This is to avoid making a complete
circuit, which will cause electrical shock. Use extreme
caution when using metal tools, which can easily damage
any electrical components or circuit boards they come into
contact with.
– The power supply power cords must include a grounding
plug and must be plugged into grounded electrical outlets.
The unit has more than one power supply cord. Disconnect
both power supply cords before servicing to avoid electrical
shock.
– Mainboard replaceable soldered-in fuses: Self-resetting PTC
(Positive Temperature Coefficient) fuses on the mainboard
must be replaced by trained service technicians only. The
1.2
DIVAR IP 2000 Safety precautions | en 7
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

new fuse must be the same or equivalent as the one
replaced. Contact technical support for details and
support.
!
Caution!
Mainboard Battery: There is a danger of explosion if the
onboard battery is installed upside down, which will reverse its
polarities. This battery must be replaced only with the same or
an equivalent type recommended by the manufacturer
(CR2032). Dispose of used batteries according to the
manufacturer's instructions.
ESD precautions
Electrostatic Discharge (ESD) is generated by two objects with
different electrical charges coming into contact with each other.
An electrical discharge is created to neutralize this difference,
which can damage electronic components and printed circuit
boards. The following measures are generally sufficient to
neutralize this difference before contact is made to protect your
equipment from ESD:
– Do not use mats designed to decrease electrostatic
discharge as protection from electrical shock. Instead, use
rubber mats that have been specifically designed as
electrical insulators.
– Use a grounded wrist strap designed to prevent static
discharge.
– Keep all components and printed circuit boards (PCBs) in
their antistatic bags until ready for use.
– Touch a grounded metal object before removing the board
from the antistatic bag.
– Do not let components or printed circuit boards come into
contact with your clothing, which may retain a charge even
if you are wearing a wrist strap.
1.3
8en | Safety precautions DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

– Handle a board by its edges only. Do not touch its
components, peripheral chips, memory modules or
contacts.
– When handling chips or modules, avoid touching their pins.
– Put the mainboard and peripherals back into their antistatic
bags when not in use.
– For grounding purposes, make sure your computer chassis
provides excellent conductivity between the power supply,
the case, the mounting fasteners and the mainboard.
Operating precautions
The chassis cover must be in place when the system is operating
to assure proper cooling. Out of warranty damage to the system
can occur if this practice is not strictly followed.
Note:
Please handle used batteries carefully. Do not damage the
battery in any way. A damaged battery may release hazardous
materials into the environment. Do not discard a used battery in
the garbage or a public landfill. Please comply with the
regulations set up by your local hazardous waste management
agency to dispose of your used battery properly.
1.4
DIVAR IP 2000 Safety precautions | en 9
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Available documentation
This manual is available in different languages. You can find all
manuals in the online product catalog.
Documentation for Bosch Security Systems products can be
found as follows:
4Open any browser > enter www.boschsecurity.com > select
your region and your country > start a search for your
product > select the product in the search results to show
the existing documents.
2
10 en | Available documentation DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

System overview
The DIVAR IP 2000 system is an affordable, easy to use all-in-one
recording and management solution for network surveillance
systems of up to 16 channels. All channels are pre-licensed.
Running the full Bosch recording solution, DIVAR IP 2000 is an
intelligent IP storage device that provides both, a professional
video recording solution and ease of operation.
DIVAR IP 2000 is a 4-bay mini tower unit that combines
advanced management and state-of-the-art recording
management into a single cost-effective, plug and play IP
recording appliance for IT-minded customers which are seeking
for a “second generation” NVR recording solution.
DIVAR IP 2000 utilizes a highly energy efficient, embedded
design at a very affordable price which nevertheless boasts
Bosch quality through-and-through.
Easy to install and operate, DIVAR IP 2000 features wizard-
based set-up and centralized configuration to reduce installation
times. All components are pre-installed and pre-configured.
Simply connect to the network and turn on the unit —
DIVAR IP 2000 is ready to begin recording straight out-of-the-
box.
DIVAR IP 2000 features front-swappable SATA-II hard drives. All
system software is pre-installed and pre-activated — creating a
ready-to-use video recording appliance.
Device views
There are several LEDs on the front and rear of the chassis. The
LEDs show the over-all status of the system and the activity and
health of specific components.
3
3.1
DIVAR IP 2000 System overview | en 11
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Front view:
1
52 3 4
6
1Lock for front cover 4LAN activity LED
2Power on/off LED 5System status LED
3Hard disk access LED 6Individual hard disk LED
12 en | System overview DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

DIVAR IP rear view:
2 3 4 5
16
11x eSATA (not used) 42x USB 3.0
Note: Do not use.
21x Ethernet (RJ45) 51x VGA (monitor)
Note: Only for
troubleshooting.
32x USB 2.0
Note: Only for
troubleshooting.
6Mains connection 100 -
240 VAC
DIVAR IP 2000 System overview | en 13
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

LED description - front panel
This chapter describes the LED displays on the front of the
chassis.
LED
indicator
LED
color
LED
state
Description
Power
LED
N/A Off Power off
Blue On
(default)
Working
HDD LED N/A Off No disk access
Blue Blinking Disk access
LAN LED N/A Off Network disconnected
Blue On Network connected
Blue Blinking Network activity
System
LED
N/A Off System has booted in normal
operation.
Blue Blinking System is booting or a
software update is being
applied.
Red On Undefined software error.
Contact technical support.
Individual
hard disk
LED
N/A Off
(default)
No hard drive configured for
this bay.
Blue On Hard drive present and
working.
3.2
14 en | System overview DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

LED
indicator
LED
color
LED
state
Description
Blue Blinking Hard drive health not optimal
— needs attention.
Red On Hard drive is configured for
this bay, but is not working.
LAN port LED description - rear panel
This chapter describes the LAN port LED on the rear of the
chassis.
LAN connector:
12
Nr. LED
indicator
LED
color
LED
state
NIC state
1RJ45 LED
(left)
N/A Off No connection or
10 Mb/s
Green On 100 Mb/s
Yellow On 1000 Mb/s
2RJ45 LED
(right)
Yellow On Active connection
Yellow Blinking Transmit or receive
activity
3.3
DIVAR IP 2000 System overview | en 15
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Chassis setup
This chapter covers the steps required to install components
and perform maintenance on the chassis.
!
Caution!
Review the warnings and precautions listed in the manual
before setting up or servicing this chassis.
Observe the following prerequisites when adding or replacing
hard disks.
Prerequisites:
– DIVAR IP only supports an even number of hard disks (2 or
4)
– Bay 1 and bay 2 must be populated with hard disks
– All hard disks of the unit must have the same capacity
Notice!
Insert the hard disks before initial system start.
See also:
–Safety precautions, page 4
–Installing a hard drive, page 17
Removing hard drive trays
The drives are mounted in drive carriers to simplify their
installation and removal from the chassis. These carriers also
help promote proper airflow for the drive bays.
To remove hard drive trays from the chassis:
1. Turn off the system.
2. Press the release button on the drive carrier. This extends
the drive carrier handle.
3. Use the handle to pull the drive carrier with the drive out of
the chassis.
4
4.1
16 en | Chassis setup DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

4. Insert the drive carrier with the new drive into the chassis
bay, making sure that the drive carrier handle is completely
closed.
Notice!
Except for short periods of time, do not operate the unit with
the hard drives removed from the bays.
Installing a hard drive
The drives are mounted in drive carriers.
To install a hard drive to the hard drive carrier:
1. Remove the drive from the carrier.
2. Install a new drive into the carrier with the printed circuit
board side facing down so that the mounting holes align
with those in the carrier.
3. Replace the drive carrier into the chassis bay, making sure
that the drive carrier handle is completely closed.
Notice!
We recommend using the respective Bosch hard disk drives.
The hard disk drives as one of the critical component are
carefully selected by Bosch based on available failure rates.
HDD – not delivered from Bosch – are not supported.
Information on supported HDDs can be found in the datasheet
in the Bosch Online Product Catalog.
4.2
DIVAR IP 2000 Chassis setup | en 17
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Installation - first steps
DIVAR IP systems are shipped with a pre-installed Configuration
Wizard from factory.
Setup notes
By default all DIVAR IP systems are configured to obtain a valid
network address from DHCP server in the local network. In
small networks this task is usually performed by an internet
router. If there is no DHCP server in the network, DIVAR IP will
use the following network settings:
– IP Address: 192.168.0.200
– Subnet mask: 255.255.255.0
Notice!
We strongly recommend that you do not change any operating
system settings. Operating system access should only be used
for troubleshooting. Changes can result in malfunctioning of the
system.
Connecting the unit
DIVAR IP system is ready to go out of the box. The application
provides a simple to install and intuitive to use solution for
network surveillance systems.
Connecting the unit:
1. Connect the unit and the cameras to the network.
2. Connect the unit to the power supply.
3. Turn on the unit.
A series of scripts perform important setup tasks. This can
take several minutes. Do not turn off the computer.
Note: During this initial setup the system LED is blinking.
After the system is ready for operation, the system LED
stops blinking. The web based wizard pages of the DIVAR IP
5
5.1
5.2
18 en | Installation - first steps DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH

can now be accessed from any browser within the network.
Use this web page wizard pages to obtain a basic system
configuration.
See also:
–Device views, page 11
–Obtainging a basic configuration, page 20
DIVAR IP 2000 Installation - first steps | en 19
Bosch Sicherheitssysteme GmbH 2014.07 | V1 | DOC

Obtainging a basic configuration
DIVAR IP 2000 offers an easy-to-use configuration wizard to
obtain quickly a basic configuration of a smaller system.
To achieve a basic configuration using the Configuration Wizard:
1. Open a web browser from any PC in the network, enter the
IP address of DIVAR IP in the address bar, then press
ENTER. The Welcome page of the Configuration Wizard is
displayed.
Note:
If you do not know the IP address, proceed as follows:
– Only one DIVAR IP 2000 is in the network:
Enter http://mydivar or https://mydivar, then
press ENTER. The Welcome page of the Configuration
Wizard is displayed.
!! Use mydivar only if there is one DIVAR IP in the
same network, not if there are multiple DIVAR IP.!!
– Multiple DIVAR IP 2000 are in the same network:
Use the IP Helper tool to display all devices with their
IP addresses. The tool is available in the online catalog
on the DIVAR IP 2000 product page.
2. On the Welcome page select your preferred language, then
click Start configuration.
3. Run-through the wizard and follow the instructions. Each
page provides you with information how to use it.
4. After finishing the Configuration Wizard your system has a
basic configuration available. If the basic configuration
needs to be extended, use the advanced configuration.
See also:
–Using the IP Helper tool, page 29
–Advanced configuration, page 21
6
20 en | Obtainging a basic configuration DIVAR IP 2000
2014.07 | V1 | DOC Bosch Sicherheitssysteme GmbH
