English
Safety Notes
Read and observe all instructions. SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
fHave the remote control repaired only through a qualified repair person and
only using identical replacement parts. This will ensure that the functionality of
the remote control is maintained.
fDo not operate the remote control in explosive atmospheres, such as in the
presence of flammable liquids, gases or dusts. Sparks can be created in the re-
mote control which may ignite the dust or fumes.
fReadandstrictlyobservethesafetywarningsintheoperatinginstructionsof
the rotational laser.
Product Description and Specifications
While reading the operating instructions, unfold the graphics page with the illustra-
tion of the remote control and leave it open.
Intended Use
The remote control is intended for controlling rotational laser levels in indoor and out-
door use.
OBJ_BUCH-934-003.book Page 12 Wednesday, July 13, 2011 9:51 AM

English | 13
Bosch Power Tools 2 610 A12 918 | (13.7.11)
Product Features
The numbering of the product features refers to the illustration of the remote control
on the graphics page.
1Button for rotational operation and selection of the rotation speed
2Button for line operation and line length selection
3Shock-warning reset button
4Button for “rotation in clockwise direction”
5Button for “rotation in anticlockwise direction”
6Operation indicator
7Outlet opening for infra-red beam
8Battery lid
9Latch of battery lid
10 Serial number
The accessories illustrated or described are not included as standard delivery.
Technical Data
Assembly
Inserting/Replacing the Battery
Using alkali-manganese batteries is recommended for operation of the remote control.
To open the battery lid 8, press the latch 9in the direction of the arrow and remove
the battery lid. Insert the battery provided. When inserting, pay attention to the cor-
Remote control RC 1
Professional
Article number 3 601 K69 900
Working range1) 30 m
Operating temperature –10 °C...+50 °C
Storage temperature –20 °C...+70 °C
Battery 1x1.5VLR06(AA)
Weight according to EPTA-Procedure 01/2003 69 g
1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun
irradiation).
Please observe the article number on the type plate of your remote control. The trade names of indi-
vidual remote controls may vary.
For clear identification of your remote control, see the serial number 10 on the type plate.
OBJ_BUCH-934-003.book Page 13 Wednesday, July 13, 2011 9:51 AM

14 | English
2 610 A12 918 | (13.7.11) Bosch Power Tools
rect polarity according to the representation on the inside of the battery compart-
ment.
fRemove the battery from the remote control when not using it for longer pe-
riods. When storing for longer periods, the battery can corrode and discharge itself.
Operation
Initial Operation
fProtect the remote control against moisture and direct sunlight.
fDo not subject the remote control to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for longer periods. In case
of large variations in temperature, allow the remote control to adjust to the am-
bient temperature before putting it into operation.
The remote control remains ready for operation as long as a battery with sufficient
voltage is inserted.
Set up the rotational laser in such a manner that the signals of the remote control di-
rectly reach one of the receiption lenses on the rotational laser (for this, see the oper-
atinginstructions of the rotational laser). When the remote controlcannotbepointed
directly against a receiption lens, the working range is reduced. By reflecting the sig-
nal (e.g. against walls), the working range can be improved, even for indirect signals.
After pressing a button on the remote control, the illuminated operation indicator 6
indicates that a signal was sent out.
Switching the rotational laser on/off with the remote control is not possible.
Operating Modes
For detailed information of the rotational laser functions, see the operating instruc-
tions of the rotational laser.
Rotational Operation
(150/300/600 min-1)
The function of the button for rotational operation 1on the remote control is identical
with that on the rotational laser.
Each time after switching on, the rotational laser is in rotational operation mode with
average rotational speed.
To switch from line operation to rotational operation, press the rotational operation
button 1. Rotational operation starts with average rotational speed.
Tochangetherotationalspeed,presstherotationaloperationbutton1againuntilthe
requested speed is reached.
OBJ_BUCH-934-003.book Page 14 Wednesday, July 13, 2011 9:51 AM

English | 15
Bosch Power Tools 2 610 A12 918 | (13.7.11)
Line Operation, Point Operation
(10°/25°/50°,0°)
The function of the button for line operation 2on the remote control is identical with
that on the rotational laser.
To switch to line or point operation, press the line operation button 2. The rotational
laser switches to line operation with the smallest aperture angle.
Tochange the aperture angle, press the line operation button 2. The apertureangleis
increased in two steps; at the same time, the rotational speed is increased with each
step. When pressing the line operation button 2a third time, the rotational laser
switches to point operation after brief post-pulsation. Pressing button 2again takes
you back to line operation with the smallest aperture angle.
Note: Due to inertia, it is possible for the laser to slightly move beyond the end point
of the laser line.
Rotating the Laser Line/Laser Dot or the Rotational Plane
(see figure A)
Rotating the laser line/laser dot or the rotational plane is possible only with the
remote control.
When the rotational laser is in the horizontal position, the laser line (in line opera-
tion)orthe laser dot (in pointoperation)canbepositioned within the rotational plane
of the laser. Rotation is possible by 360°.
Pressbutton 4to rotateinclockwisedirection, and button 5torotatein anticlockwise
direction. In rotational operation, pressing the buttons has no effect.
When the rotational laser is in the vertical position, it is possible to rotate the laser
point, laser line or rotational plane around the vertical axis. Rotating is possible only
within the self-levelling range (5° toward the left or right).
Pressbutton 4to rotateinclockwisedirection, and button 5torotatein anticlockwise
direction.
Reset Shock-warning Function
The rotational laser has a shock-warning function; after position changes or shock to
the rotational laser, or in case of ground vibrations, it keeps the rotational laser from
levelling in at changed heights, and thus prevents vertical errors.
Switching the shock-warning function on and off is possible only on the rotational
laser. Once the shock-warning function has actuated, is can be restarted via the
remote control.
OBJ_BUCH-934-003.book Page 15 Wednesday, July 13, 2011 9:51 AM

16 | English
2 610 A12 918 | (13.7.11) Bosch Power Tools
Afteractuationoftheshock-warningfunction,the rotation of the laser is stopped, the
laserflashes,the levelling indicator goes out, andtheshock-warningindicatorflashes
red. The current operating mode is stored.
After the shock-warning function has actuated, press the shock-warning reset button
3. The shock-warning function is restarted and the rotational laser starts levelling. As
soon as the rotational laser is levelled in (the levelling indicator on the rotational laser
continuously lights up green), it starts in the stored operating mode. Now, check the
height of the laser beam with a reference point and correct the height, if required.
Application Example
Turning the Rotational Plane when in the Vertical Position (see figure B)
To align the vertical laser line or the rotational plane against a reference point on a
wall, set up the rotational laser in the vertical position, and roughly align the laser line
or the rotational plane with the reference point. For precise alignment with the refer-
ence point, press button 4(clockwise rotation) or 5(anticlockwise rotation).
Maintenance and Service
Maintenance and Cleaning
Keep the remote control clean at all times.
Do not immerse the remote control into water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or sol-
vents.
If the remote control should fail despite the care taken in manufacture and testing,
repair should be carried out by an authorised customer services agent for Bosch
power tools. Do not open the remote control yourself.
In all correspondence and spare parts orders, please always include the 10-digit
article number given on the type plate of the remote control.
After-sales Service and Customer Assistance
Our after-sales service responds to your questions concerning maintenance and re-
pair of your product as well as spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Our customer service representatives can answer your questions concerning possi-
ble applications and adjustment of products and accessories.
OBJ_BUCH-934-003.book Page 16 Wednesday, July 13, 2011 9:51 AM

English | 17
Bosch Power Tools 2 610 A12 918 | (13.7.11)
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: [email protected]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
OBJ_BUCH-934-003.book Page 17 Wednesday, July 13, 2011 9:51 AM

18 | English
2 610 A12 918 | (13.7.11) Bosch Power Tools
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Bosch Headquarters
Midrand, Gauteng
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
People’s Republic of China
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.cn
OBJ_BUCH-934-003.book Page 18 Wednesday, July 13, 2011 9:51 AM

English | 19
Bosch Power Tools 2 610 A12 918 | (13.7.11)
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.hk
Indonesia
PT. Multi Mayaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No. 2
Jakarta 13930
Indonesia
Tel.: [phone]
Fax: [phone] 23
E-Mail: [email protected]
www.bosch-pt.co.id
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio Global City,
1634 Taguig City, Philippines
Tel.: [phone]
Fax: [phone]
[email protected]
www.bosch-pt.com.ph
Bosch Service Center:
9725-27 Kamagong Street
San Antonio Village
Makati City, Philippines
Tel.: [phone]
Fax: [phone]
[email protected]
OBJ_BUCH-934-003.book Page 19 Wednesday, July 13, 2011 9:51 AM

20 | English
2 610 A12 918 | (13.7.11) Bosch Power Tools
Malaysia
Robert Bosch (S.E.A.) Pte. Ltd.
No. 8A, Jalan 13/6
G.P.O. Box 10818
46200 Petaling Jaya
Selangor, Malaysia
Tel.: [phone]
Fax: [phone]
[email protected]
Toll-Free: 1800 880 188
www.bosch-pt.com.my
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: [phone] – 18 88 (10 lines)
Fax: [phone]
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501, Thailand
Bosch Service – Training Centre
2869-2869/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway)
Prakanong District
10110 Bangkok
Thailand
Tel.: [phone] – 4
Fax: [phone]
Fax: [phone]
Singapore
Robert Bosch (SEA) Pte. Ltd.
11 Bishan Street 21
Singapore 573943
Tel.: [phone]
Fax: [phone]
[email protected]
Toll-Free: 1800 333 8333
www.bosch-pt.com.sg
OBJ_BUCH-934-003.book Page 20 Wednesday, July 13, 2011 9:51 AM

English | 21
Bosch Power Tools 2 610 A12 918 | (13.7.11)
Vietnam
Robert Bosch Vietnam Co. Ltd
10/F, 194 Golden Building
473 Dien Bien Phu Street
Ward 25, Binh Thanh District
84 Ho Chi Minh City
Vietnam
Tel.: [phone] ext. 413
Fax: [phone]
[email protected]
www.bosch-pt.com
Disposal
The remote control, accessories and packaging should be sorted for environmental-
friendly recycling.
Do not dispose of remote controls and batteries/rechargeable batteries into house-
hold waste!
Only for EC countries:
According to the European Guideline 2002/96/EC, electrical
devices/tools that are no longer usable, and according to the Euro-
pean Guideline 2006/66/EC, defective or used battery packs/bat-
teries, must be collected separately and disposed of in an environ-
mentally correct manner.
Batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: [email protected]
Subject to change without notice.
OBJ_BUCH-934-003.book Page 21 Wednesday, July 13, 2011 9:51 AM
