Bose®FreeStyle™
Earbuds
Owner’s Guide

2 - English
Important Safety Information
©2014 Bose Corporation. No part of this work may be reproduced, modied, distributed, or otherwise used without
prior written permission.
Please read this owner’s guide carefully and save it for future reference.
CAUTIONS
• Sounds that you rely on as reminders or warnings may have an unfamiliar char-
acter when using headsets. Be aware of how these sounds may vary in character
so you can recognize them as needed.
• Do not drop, sit on, or allow the headset to be immersed in water.
WARNINGS
• Contains small parts which may be a choking hazard. Not suitable for
children under age 3.
• This product contains magnetic material. Contact your physician if
you have questions on whether this might affect the operation of your
implantable medical device.
• Long-term exposure to loud music may cause hearing damage. It is best to avoid
high volume levels when using headset, especially for extended periods.
• Use caution when using your headset while operating a vehicle or engaging in
any activity that requires your full attention. Check and follow local laws regard-
ing headset use. Some jurisdictions impose specic limitations, such as single
earpiece conguration, on the use of such products while driving.
Limited Warranty
Your Bose® headphones are covered by a limited warranty. Details of the limited
warranty are provided on the product registration card that is included in the car-
ton. Please refer to the card for instructions on how to register. Failure to register
will not affect your limited warranty rights.
This product conforms to all applicable EU Directive requirements. The
complete Declaration of Conformity can be found at www.Bose.com/
compliance.

Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part Name Lead (Pb) Mercury (Hg) Cadmium (Cd)
Hexavalent
(CR(VI))
Polybrominated Biphenyl
(PBB)
Polybrominated
diphenylether (PBDE)
Metal parts X 0 0 0 0 0
Plastic parts 0 0 0 0 0 0
Speakers X 0 0 0 0 0
Cables X 0 0 0 0 0
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit require-
ment in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the
limit requirement in SJ/T 11363-2006.
iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been
designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the
developer to meet Apple performance standards. Apple is not responsible for the operation of this device
or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod,
iPhone, or iPad may affect wireless performance.

4 - English
Contents
Please complete and retain for your records:
The serial and model number can be found on the warranty card.
Serial number __________________________________________________________________
Model number _________________________________________________________________
Purchase date__________________________________________________________________
We suggest you keep your receipt with this owner’s guide.
Welcome.............................................................................................................. 5
Carton contents................................................................................................. 5
Connecting to your iPhone, iPod, or iPad...................................................... 6
Using the earbuds with your iPhone, iPod, or iPad ..................................... 6
For use with ................................................................................................ 6
Earbud controls .......................................................................................... 6
Basic functions ........................................................................................... 7
Media playback functions......................................................................... 7
Importance of proper fit ................................................................................... 8
Fitting the headphones to your ear ........................................................ 8
Changing eartips ........................................................................................ 9
Adjusting for comfort and stability................................................................ 9
Using the adjustment slider .................................................................... 9
Using the clothing clip .............................................................................. 9
Troubleshooting ................................................................................................ 10
Cleaning............................................................................................................... 11

Using the earbuds
English - 5
Welcome
Thank you for purchasing the Bose® FreeStyle™ earbuds for use with select
iPhone, iPod and iPad models. The Bose FreeStyle earbuds offers a combination
of lifelike audio performance and comfortable t not available from most
conventional headsets.
Carton contents
Volume Up
Answer/End
button
Volume Down
Clothing clip Adjustment slider
Carrying case
StayHear® tips
Large
(black)
Medium
(gray)
Small
(white)
left right
Microphone
(back of button)
left right
left right
Note: The earbuds comes with medium StayHear®tips attached.

Using the earbuds
6 - English
Connecting to your iPhone, iPod, or iPad
You can connect the earbuds to the standard 3.5 mm headphone jack on your
iPhone, iPod, or iPad.
Using the earbuds with your iPhone, iPod,
or iPad
The Bose® FreeStyle™ earbuds include a small in-line remote with an integrated
microphone and easy to access Answer/End and volume control buttons.
For use with
The remote and mic are supported only by iPhone 3GS or later, iPad, iPod touch
(2nd generation or later), iPod classic (120GB, 160GB), and iPod nano (4th gen-
eration or later). The remote is supported by iPod shufe (3rd generation or later).
Audio is supported by all iPad and iPod models.
Note: Full controls may not be available for some iPhone, iPod, or iPad models.
Note: For information on using your earbuds with other devices, refer to
http://global.Bose.com
Earbud controls
Volume up
Answer/End
Volume down

Using the earbuds
English - 7
Basic functions
Increase volume Press and release the + button.
Decrease volume Press and release the – button.
Answer a call When you receive an incoming call,
press and release the Answer/End
button to answer.
End a call Press and release the Answer/End
button.
Decline an incoming call Press and hold the Answer/End button
for about two seconds, then release.
Switch to an incoming or on-hold call
and put the current call on hold While on a call, press and release the Answer/End button once. Press and
release again to switch back to the rst
call.
Switch to an incoming or on-hold call
and end the current call While on a call, press and hold the Answer/End button for about two
seconds, then release.
Use Voice Control Press and hold the Answer/End button.
See iPhone User Guide for compat-
ibility and usage information about this
feature.
Media playback functions
Play or pause a song or video Press and release the Answer/End
button.
Skip to the next song or chapter Press and release the Answer/End
button twice quickly.
Fast forward Press and release the Answer/End
button twice quickly and hold the
second press.
Go to the previous song or chapter Press and release the Answer/End
button three times quickly.
Rewind Press and release the Answer/End
button three times quickly and hold the
third press.

Using the earbuds
8 - English
Importance of proper fit
When you wear the earbuds properly, they provide the comfort and clarity you
expect from Bose.
Fitting the headphones to your ear
The headphone earpiece has a soft StayHear® tip attached, allowing it to rest
comfortably in the bowl of your ear. The wing part of the tip ts just under your ear
ridge.
Note: Each tip is marked with a either an L or an R to indicate
which earpiece it is for. Be sure to attach the left StayHear®tip to
the left earpiece and the right StayHear®tip to the right earpiece.
To determine if the tip is the right size:
1. Insert the earpiece into the canal just enough for the headphone to rest lightly
against your ear.
2. Tilt the headphone back and press the tip wing under the ear ridge until it is
secure.
The tips should t comfortably yet securely in the bowl of the ear.
12

Using the earbuds
English - 9
Changing eartips
Select the type and size of eartip that provides you with the best comfort and t.
1. Gently peel the edges of the attached tip away from the earpiece, using care
not to tear the tip.
CAUTION: To prevent damage, do not pull on the StayHear®tip wing.
2. Position the opening of the new tip over the nozzle and the small slot over the
nozzle hook.
Note: Each tip is marked with a either an L or an R to indicate which earpiece it is for.
Be sure to attach the left StayHear®tip to the left earpiece and the right StayHear®tip
to the right earpiece.
3. Ease the base of the tip down around the base of the earpiece until the tip
feels secured.
13
2
Adjusting for comfort and stability
There are several ways you can adjust your earbuds to provide additional comfort
and stability. Using the adjustment slider and clothing clip you can customize how
you wear your earbuds.
Using the adjustment slider
Move the adjustment slider up or down to reduce or increase
the amount of loose cord between the left and right earpiece.
Finding the right position for the slider can help optimize the
placement of the Answer/End button and integrated micro-
phone.
Using the clothing clip
Use the clothing clip to fasten the
cable to your clothing, for conve-
nience, stability, and to help
manage the cable. This can be
helpful during high-movement
activities or when using the ear-
buds in a single earpiece congura-
tion.

Using the earbuds
10 - English
Troubleshooting
If you experience any trouble using your earbuds, try the following troubleshooting
instructions. If you still need help, contact Bose customer support.
Problem What to do
No audio/Intermittent • Make sure that the headphone plug is
securely connected to the headphone
jack.
• Try another audio device.
Excessive bass • Turn off any audio enhancement
features on the audio source.
Microphone is not picking up sound • Make sure that the headphone plug is
securely connected to the headphone
jack.
• Make sure the microphone is not being
blocked or covered.
The microphone is located on the back of
the Answer/End button. (You may notice
the small opening for the microphone.)
Phone not responding to button
presses • Make sure that the headphone plug is securely connected to the headphone
jack.
• For multi-press functions: Vary speed of
presses.
iPhone, iPod or iPad not responding
to remote • Full controls may not be available for some iPhone, iPod and iPad models.
Eartips falling off • Make sure the eartips are securely at-
tached to the earpiece and nozzle hook.
Lost eartip • Visit owners.Bose.com for replacement
tips.
Sound is mufed from earpiece • Make sure eartips and earbud nozzles
are clear of any debris or wax build-up.
• Unplug the earbuds from the audio
source, then plug back in making sure
they are securely connected.
• Try another audio device.
