Boss Audio Systems HIR7BLK User manual

Available in black,gray,and beige
Adjustable mounting poles to t any seat
Poles adjustable from 4 inches apart to 8 inches apart
7" wide TFT LED Monitor
1Set wired AV input
Faceplate mini-stereo jack output for wired headphones
Color System:NTSC/PAL selectable
Built in dual channel IR Transmitter
Frequency:2.3 MHZ(Left),2.8MHZ(Right)
Dual Function remote control:RC-701N
Operating temperature:32°F to 140°F
Storage temperature:-4°F to 176°F
Environmental Humidity:<90%
Features
*
*
*
*
*
*
*
*
*
*
*
*
*
1
2
Thank you for purchasing Boss Audio Systerms products!To ensure
long-term trouble-free service of the product,Please read this manual
carefully before using the monitor.
Installation of this product must be performed by a professional installer.
We strongly recommend connecting this product and testing it
before installing it in the vehicle.improper installation will void
warranty.
READ THIS MANUAL BEFORE USING THIS PRODUCT.
THIS PRODUCT IS COMPOSED OF PRECISION COMPONENTS
AND SHALL NOT BE DISASSEMBLED.
PROTECT THE PRODUCT FROM MOISTURE AND SHOCK
BROKEN WARRANTY SEAL WILL VOID THE WARRANTY

1.POWER
2.SOURCE
3.-
4.MENU
5.+
6.MODE
7.SYSTEM 123 4 5 6 7
Red Audio R input
Left Audio L input
NX-HRM743
POWER SOURCE
-
MENU
+
MODE SYSTEM
HIR7BLK
To adjust the headrest posts simply pull apart or push together
to adjust for the seat. If the larger diameter posts are needed
make sure to install them before running any wires.
1
2
34
5
6
34
Since the spacing of the mounting holes can vary
on different vehicles we supply two adapter poles
{12mm diameter},Use these adapter poles when
the headrest mounting holes in your seat are too
large for the posts of the headrest monitor.
1.POWER SWITCH
2.VIDEO SELECT
3.MENU
4.NEXT
5.PREVIOUS
6.MODE SELECT
RED WIRE TO A SWITCHED IGN S OURCE
BLACK WIRE CHASSIS GROUND
