BOSSCO BR-1600CD Assembly instructions

BR-1600CD Digital Recording Studio Stuff To Know
Record 8 XLR Mic Preamps w/Phantom Power at once!
16 Recording Tracks/Separate Master Tracks/256 V-Tracks
Built-in COSM Effects (GT6 On-Board!) and Vocal Tool Box
Drum machine, Bass sequencer and Phrase sequencer
USB WAV Import & Export, SMF Import
256 Virtual Tracks
•16 audio tracks including Mastering Tracks.
•Record alternate takes to virtual tracks without running out of tracks.
•One button bouncing and mastering mode for easy mix down.
•Scene memor
y
and sna
p
shot automation for creatin
g
com
p
lex mixes.
Effects Power
•Full internal GT-6 guitar effects processor features Rectifier Models.
•5 separate multi-effect Processors - No need to purchase external effects.
•Includes 3-band parametric EQ and Compressor on all inputs AND tracks.
•Vocal Tool Box with Harmonizer and Pitch Correction.
•Same Mastering Tool Kit found in Roland VS-2XXX series workstations!
USB for Sharing with the World
•Drag and drop song data to computer for backup.
•Import .WAV or AIFF files from PC or Mac!
•Export files from BR-1600CD as .WAV files via USB to your computer.
Built-in Rhythm Guide with Real Drum Sounds
•1000 user programmable drum patterns and 1000 bass patterns.
•Program drums or bass patterns from front panel or external MIDI controller
.
•.WAV Import with auto tempo matching of imported loops.
•Includes 100 arrangements, 600 preset drum loops and 583 preset bass
patterns. 9 drum kits and 13 bass sounds.
•Includes Discrete Drums percussion and drum loops in .WAV format.
Digital Recording and CDR Mastering in one unit
•8 XLR connectors w/ phantom power plus 8 ¼” inputs.
•Record 8 Inputs at once. Each input has separate dynamics and EQ!
•2 front mounted Headphone outs with separate volume controls.
•LEVEL CALIBRATION feature automatically sets multi-track record levels!
•40 GB hard drive for over 120 Hours of recording time.

® BR-1600CD Digital Recording Studio Stuff To Show
Cool Stuff to Show:
8-INPUT RECORDING: Press MULTI-TRACK. Press EFFECTS to see COMPRESSORs and EQs.
EFFECTS: Press EFFECTS, press GUITAR, BASS, MULTI and STEREO to show EFFECT types.
CHANNEL EDIT: Press COMP and EQ. Use the KNOBS to adjust settings.
PROGRAMMABLE RHYTHM GUIDE: Press EDIT to SHOW drum and bass arrangement.
Show the Harmony Function in the Vocal Tool Box
1) Press the VOCAL TOOL BOX button so it is lit.
2) Press MARKER search to get to “Chors” Marker, then PLAY.
3) Press the VOCAL TOOL BOX button to toggle ON/OFF. When finished, press STOP.
Rhythm Guide: Create a Drum Pattern
1) Press ARRANGEMENT [PATTERN] so it’s OFF. Press EDIT to open PATTERN
display.
2) Press F4 EDIT to open the drum pattern display.
3) Use the DIAL to change “P” (preset) to “S” (song). Press ENTER.
4) Use the DIAL to select a pattern number. Press ENTER.
5) Press F1 REALTIME.
6) Press the round TRACK buttons to play the drum kit.
7) Cursor to “KIT”. Use the DIAL to change kit.
8) Cursor to “QTZ” to adjust quantizing.
9) Cursor to “METRO” to adjust the volume of the metronome.
10) Press PLAY to start pattern loop recording. Press STOP when finished.
An easy way to create or edit patterns is to use the STEP EDITOR:
1) To edit the pattern you just created, press F2 STEP. Press PLAY.
2) Move the cursor to an empty box in the grid and press ENTER to add a drum hit.
3) Cursor to another drum hit, and use the DIAL to change its loudness.
Load the Demo Song
1) Press UTILITY. Press F2 SONG.
2) Use the DIAL to select “Baby Calls”. Press ENTER. Answer NO to “Save”.
3) Press PLAY. Use the Track Mixer to mix the song.
4) Press the EQ, Compressor and FX buttons. Use KNOBS to control their parameter
s
5) Press STOP.

® BR-1600CD Digital Recording Studio Stuff To Show
Stuff To Show
Show Channel Edit
1) Press EQ under CHANNEL EDIT.
2) Press TRACK button 9/10.
3) Use KNOBS to cut or boost LOWs, MIDs, and HIGHs.
4) Press F3 MID.
5) Rotate KNOB 4 to change “Q” of MID filter.
6) Press COMP.
7) Use KNOBS to control THRESHOLD, ATTACK, and RELEASE of COMPRESSOR.
Automatic Level Calibration
1) Press MULTI-TRACK.
2) Press LEVEL CALIBRATION.
3) PLAY INSTRUMENT CALIBRATION.
4
)
Press F4 CALCULATE. That’s it!
Show Multi-Track Effects
1) Press MULTI-TRACK.
2) Press EFFECTS.
3) Press F2 EDIT.
4) Use CURSOR to select LCUT, COMP, or EQ.
5) Press ENTER to enable editing.
OR
1) Press MULTI-TRACK.
2) Press EFFECTS.
3) Use DIAL to scroll through LCUT, COMP, or EQ.
4) Use VALUE 1 KNOB to edit parameters.
Rhythm Guide: Create a Bass Pattern
1) From the main display, press ARRANGEMENT [PATTERN] so it is OFF.
2) Press EDIT. Press F3 EDIT to open the Bass pattern display.
3) Use the DIAL to change “P” (preset) to “S” (song). Press ENTER.
4) Use the DIAL to select a pattern number. Press ENTER.
5) Press F1 REALTIME.
6) Cursor to “TONE”. Use the DIAL to change
Bass. Press the Track buttons to he
7) Cursor to “QTZ” to adjust quantizing. Cursor to “METRO” to adjust the click vol
u
8) Press PLAY to start pattern loop recording. Press STOP when finished.
