Bradley FREQUENCY FL-1H User manual

P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: [phone]
www.bradleycorp.com
Installation
215-1511 Rev. D; EN 07-808
© 2007 Bradley Corporation
Page 1 of 8 5/30/07
FL-1H, FL-1L
Frequency® Lavatory System
Table of Contents
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . .2
Cleaning and Maintenance for Terreon® . . . . . . .3
Dimensions - Front and Top Views .............3
Dimensions - Side Views .....................4
Rough-Ins ...................................5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .6–8
FL-1H
FL-1L
U.S. Pat. No. Des. 507,634
IMPORTANT!
Read this entire installation manual to ensure proper installation.
When finished with the installation, file this manual with the owner or
maintenance department. Compliance and conformity to local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted
for before discarding any packaging material. If any parts are missing,
do not begin installation until you obtain the missing parts.
Make sure that all water supply lines have been flushed and then
completely turned off before beginning installation. Debris in supply
lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all
electrical units prior to installation. Electrical power MUST remain off
until installation is completed. After installation is complete, turn on
the water supply first, then turn on the electrical power.
Hardware supplied by installer must be appropriate for wall
construction. Wall anchors used must have a minimum pull-out rating
of 1,000 lbs.
Product warranties may be found under “Product Information” on our
web site at www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List





FL-1H, FL-1L Installation
25/30/07 Bradley Corporation • 215-1511 Rev. D; EN 07-808
Bowl FL-1L (187-273)
Contact Bradley for
color options
Bowl FL-1H (187-274)
Contact Bradley for
color options
Prepack Trap Cover FL-1
(S45-2108 - Gray)
(S45-2108A - Putty)
(S45-2108B - Coal)
Soap
Dispenser
Model 6334
Support Bracket
(140-823L)
#10 Washer
(142-002AT)
#10-24 Screw
(P18-054)
Support Bracket
(140-823R)
Offset Strainer
(269-1751)
P-Trap
(269-1697)
Valve
(S01-524)
Screw
(P18-054)
Bracket
(140-934)
Aerada™ 1200 Series
CS Faucet
Model S53-315
Optional
Tempered Line
1/2" Flex
Hose
(269-653)
1/2" Nipple
(113-006DH)
Stop/Strainer/Check
Valve (S60-003)
Optional Tankless Water Heater
(269-1765 - EX55TMLB, 240/208 volts)
(269-1766 - EX60TMLB, 277 volts)
Optional
Single-Unit
Adapter
(153-443)
Vernatherm™
TMV Assembly
Components
Supplies Required:
• (4) 3/8" wall anchors, bolts and 1" min. O.D. washers to mount main frame and bowl to wall (minimum pull-out rating
of 1,000 lbs.)
• (2) #10 wall anchors (for optional mixing valve/bracket mounting)
• 1/2" NPT hot/cold or tempered supply piping
• 1-1/2" NPT drain piping
• OPTIONAL: 110 volt GFCI protected electrical outlet for 100–120 VAC plug-in transformer (for Bradley Faucets)
• OPTIONAL: 240/208 or 277 volts for electric tankless water heater

Installation FL-1H, FL-1L
Bradley Corporation • 215-1511 Rev. D; EN 07-808 5/30/07 3
Cleaning and Maintenance for Terreon®
Material Description: Terreon®is an NAHB Certified densified solid surface material composed of polyester resin and is
resistant to chemicals, stains, burns and impact. Surface damage can be easily repaired with everyday cleansers or fine grit
abrasives.
Routine Cleaning: Clean daily or as often as conditions require using a standard commercial or household cleaner such as
Formula 409®or Windex®.
Stubborn Stains: Remove tough stains with Ajax®, Comet®, or Soft-Scrub®and a green Scotch-Brite®pad or lightly sand in
a circular motion with 240 grit wet/dry sandpaper. The finish can be renewed with a maroon Scotch-Brite®pad.
Special Situations for Material
Scratches: Remove scratches with a green Scotch-Brite®pad. The finish can then be renewed with a maroon Scotch-Brite®
pad, followed by a white Scotch-Brite®pad or 30-micron sandpaper.
Hard Water Deposits: Remove hard water deposits with a mild solution of vinegar and water. Always rinse the unit
thoroughly after cleaning.
Restoring the surface: Use Hope’s®Solid Surface cleaner and polish to refresh and protect the Terreon®Solid Surface
material. Bradley recommends additional care and maintenance for the darker colored Terreon®, for complete instructions on
this additional maintenance refer to Bradley technical document #1505.
Do not use strong acid or alkaline chemicals and cleansers to clean Terreon®. If these chemicals come in
contact with the surface, wipe them off immediately and rinse with soapy water. Avoid contact with harsh
chemicals such as paint remover, bleach, acetone, etc. Avoid contact with hot pans and objects.
Repair Kits: Terreon®repair kits are available. Contact your Bradley representative or distributor for part numbers and pricing
Repair kits are made to order and have a shelf life of 30 days.
Terreon®is a unique, cast solid surface material. Aggregate flow and distribution as well as shades of color can vary from
product to product creating natural characteristics.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an endorsement,
nor does the omission of any brand name cleaner imply inadequacy. Many products named are regional in distribution, and
can be found in local supermarkets, department and hardware stores, or through your cleaning service. It is emphasized that
all products should be used in strict accordance with package instructions.
Dimensions - Front and Top Views
7-3/4"
(197mm)
22"
(559mm)
30"
(762mm)
37-3/4"
(959mm)
36"
(914mm)
30"
(762mm)
34"
(864mm)
12-1/4"
(311mm)
30"
(762mm)
37-3/4"
(959mm)
32"
(813mm)
30" ADA
(762mm)
34" ADA
(864mm)
12-1/4" ADA
(311mm)
ADA
COMPLIANT
FL-1H shown
FL-1L is similar
FL-1H FL-1L

FL-1H, FL-1L Installation
45/30/07 Bradley Corporation • 215-1511 Rev. D; EN 07-808
Dimensions - Side Views
4-5/8"
(117mm)
28"
(711mm)
4-5/8"
(117mm)
4-5/8"
(117mm) 4-5/8"
(117mm)
30"
(762mm)
12-1/4"
(311mm)
34"
(864mm)
Rim
Height
Standard
Height
22" (559mm)
19-3/4" (502mm)
14"
(356mm)
22" (559mm)
19-3/4" (502mm)
14"
(356mm)
22" (559mm)
19-3/4" (502mm)
14"
(356mm)
22" (559mm)
19-3/4" (502mm)
14"
(356mm)
37-3/4"
(959mm)
31"
(787mm)
Rim
Height
30"
(762mm)
Rim
Height
Juvenile
Height
Ages 6–12
34-3/4"
(883mm)
9-1/4"
(235mm)
8-1/4" (210mm)
33-3/4"
(857mm)
26"
(660mm)
32"
(813mm)
Rim
Height
TAS Height
Grades Pre-K
through 5 or 6
TAS Height
Grades 6 through
8 or 9
10-1/4"
(260mm)
35-3/4"
(908mm)
A
D
A
C
O
M
P
L
I
A
N
T
A
D
A
C
O
M
P
L
I
A
N
T
27"
(686mm)
22" (559mm)
19-3/4" (502mm)
14"
(356mm)
36"
(914mm)
Rim Height
Not ADA
Compliant
30"
(762mm)
4-5/8"
(117mm)
37-3/4"
(959mm)
12-1/4"
(311mm)
TAS TAS
FL-1H
FL-1L

Installation FL-1H, FL-1L
Bradley Corporation • 215-1511 Rev. D; EN 07-808 5/30/07 5
E
D
D
BB
A
A
AA
HC
W
12-7/8"
(327mm)
12-7/8"
(327mm)
11"
(279mm)
11"
(279mm)
10-1/2"
(267mm)
3/4"
(19mm)
4"
(102mm)
5"
(127mm)
5"
(127mm)
1-3/8"
(35mm)
33"
(838mm)
30"
(762mm)
26-3/8"
(670mm)
24"
(610mm)
18-3/4"
(476mm)
17"
(432mm)
10"
(254mm)
24"
(610mm)
Recommended 240v/208v
or 277v electrical rough-in
location (approx. 3" x 6")
1Rough-Ins
CODE DESCRIPTION QTY.
A 3/8" Lav Deck Anchors with a Minimum Pull-Out Force of 1,000 lbs. 4
B #10 Wall Anchors/Fasteners for Mounting Trap/Transition Covers 2
H, C 1/2" NPT Hot/Cold Supplies, Stub-Out 2" From Wall 1
D #10 Wall Anchors/Fasteners for Valve Mounting 2
E 110v GFI Protected Electrical Outlet 1
W 1-1/2" NPT Drain, Stub-Out 2" from Wall 1
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FOR CODES
A–E, H, C and W FIXTURE STYLE
34" None Standard Height
32" Subtract 2" TAS, Grades 6 through 8 or 9
31" Subtract 3" TAS, Pre-K through Grades 5 or 6
30" Subtract 4" Juvenile Height
A
A
B
E
C
A
A
B
D
D
W
H
12-7/8"
(327mm)
12-7/8"
(327mm)
11"
(279mm)
11"
(279mm)
10-1/2"
(267mm)
4"
(102mm)
5"
(127mm)
5"
(127mm)
1-3/8"
(35mm)
31"
(787mm)
28"
(711mm)
26-3/8"
(670mm)
24"
(610mm)
18-3/4"
(476mm)
17"
(432mm)
3/4"
(19mm)
10"
(254mm)
24"
(610mm)
Recommended 240v/208v
or 277v electrical rough-in
location (approx. 3" x 6")
FL-1H
FL-1L

FL-1H, FL-1L Installation
65/30/07 Bradley Corporation • 215-1511 Rev. D; EN 07-808
Drywall
Metal Studs 16"
(406mm)
12"
(305mm)
25"
(635mm)
35"
(889mm)
Securely fasten plywood
to at least (3) metal studs
(plywood to equal
thickness of drywall, 1/2"
minimum
Use 3/8" toggle bolts
and washers to secure
the support brackets to
plywood (2) places.
2Lavatory Deck
Backing Information
If necessary, adjust the fixture
height before securing to the
support brackets.
Refer to the rough-ins to determine
wall-mounting location for optional
mixing valve.
Installer may prefer to install the
faucet before mounting the fixture
to the wall. Refer to page 8 for
faucet installation details.
FL-1L shown
FL-1H is similar

Installation FL-1H, FL-1L
Bradley Corporation • 215-1511 Rev. D; EN 07-808 5/30/07 7
4Faucet Battery Box
3Drain and Tailpiece
4" (102mm)
Friction
Rubber
Nut
Friction
Rubber
Nut
Tailpiece Tailpiece
FL-1H FL-1L
BInstall the faucet according to
manufacturer’s instructions
Faucet Valve
Control Module
1/2" Flexible Hose (qty. 3)
(269-1735)
Hot
Cold
Mixing Valve
AMount the Faucet
Battery Box to the wall
at desired location.
Sto
p
/Check Valve
FL-1L shown
FL-1H is similar

FL-1H, FL-1L Installation
85/30/07 Bradley Corporation • 215-1511 Rev. D; EN 07-808
5Optional Tankless Water Heater
6P-Trap and Trap Cover
Outlet
Inlet
Faucet Inlet
20"
(508mm)
Stop/Check Valve,
Cold Supply Outlet
3/4" (19mm)
Model FL-1L shown,
Model FL-1H is similar
Electric Tankless
Water Heater
Finished Floor
FL-1L shown
FL-1H is similar
FL-1L shown
FL-1H is similar
