Bradley S19-270C User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1326 Rev. V; ECN 15-05-042
© 2017 Bradley
Page 1 of 35 10/5/2017
S19-270C, S19-270E,
S19274C, S19274E
Swing-Activated Eyewash and Eye/Face
Wash
Douche oculaire et oculaire/faciale
activée par bras mobile
Lavador de ojos y de ojos/rostro
activado por brazo oscilante
S19-270C eyewash
douche oculaire
lavador de ojos
S19-270E eye/face wash
douche oculaire/faciale
lavador de ojos/rostro
S19274C Halo™ eyewash
douche oculaire
lavador de ojos
S19274E Halo™ eye/face wash
douche oculaire/faciale
lavador de ojos/rostro

2
S19-270C, S19-270E, S19274C, S19274E Installation
10/5/2017 Bradley • 215-1326 Rev. V; ECN 15-05-042
Table of Contents
Pre-Installation Information ..................................................................3
S19-270C, S19274C Dimensions .............................................................4
S19-270E, S19274E Dimensions .............................................................5
Installation .............................................................................6–7
Installation Left-Hand Units ................................................................8–9
S19-270C Assembly of Components and Parts List ..............................................10
S19274C Assembly of Components and Parts List ..............................................11
S19-270E Assembly of Components and Parts List ..............................................12
S19274E Assembly of Components and Parts List...............................................13
Table des matières
Avant l’installation ........................................................................14
S19-270C, S19274C Dimensions ............................................................15
S19-270E, S19274E Dimensions ............................................................16
Installation ...........................................................................17–18
Installation Gaucher....................................................................19–20
S19-270C Assemblage des composantes et liste des pièces.......................................21
S19274C Assemblage des composantes et liste des pièces .......................................22
S19-270E Assemblage des composantes et liste des pièces.......................................23
S19274E Assemblage des composantes et liste des pièces .......................................24
Contenido
Información previa a la instalación ...........................................................25
S19-270C, S19274C Dimensiones ...........................................................26
S19-270E, S19274E Dimensiones ...........................................................27
Instalación ...........................................................................28–29
Instalación de Mano Izquierda............................................................30–31
S19-270C Armado de los componentes y lista de piezas .........................................32
S19274C Armado de los componentes y lista de piezas ..........................................33
S19-270E Armado de los componentes y lista de piezas..........................................34
S19274E Armado de los componentes y lista de piezas ..........................................35

3
Installation S19-270C, S19-270E, S19274C, S19274E
Bradley • 215-1326 Rev. V; ECN 15-05-042 10/5/2017
WARNING
The installation and location of all Safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI Z358.1.
Emergency equipment must be supplied with tepid water (60-100°F/ 15.6-37.8°C). Any prolonged
exposure to near freezing water affects the body’s ability to maintain body temperature, increasing
the risk of hypothermia.
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
The ANSI Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21 MPa) flowing pressure. Flushing fluid should
be tepid per ANSI Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a suitable
flushing fluid supply is present and any sediment build-up in the supply line is cleared. Emergency
Equipment should be inspected monthly to address any maintenance issues ensuring the
equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained regarding
the placement and proper operation of emergency equipment per ANSI Z358.1.
NOTICE
Before installing this product ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions
For classic eye/face wash units, avoid cleaners containing organic solvents, alcohols, and
hydrocarbons. Rinse with water after cleaning.
IMPORTANT
Read this installation manual completely to ensure proper installation, then file it with the owner
or maintenance department. Compliance and conformity to drain requirements and other local
codes/ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding
any packaging material. If any parts are missing, do not begin installation until you obtain the
missing parts.
For questions regarding the operation or installation of this product, visit bradleycorp.com or
call 800.BRADLEY (800.272.3539).
Product warranties may also be found under ”Products” on our web site at bradleycorp.com.
Supplies Required:
• Piping to ½" NPT water supply inlet on unit
• Pipe sealant
• Inlet strainer (recommended)
• Sign-mounting hardware
Local codes may require the installation of a backflow prevention
valve to complete proper installation. Compliance with local codes
is the responsibility of the installer. Valve must be tested annually
to verify that it is functioning properly. Backflow prevention valves
are not included with the fixture and may be supplied by the
contractor or purchased from Bradley Corporation.

4
S19-270C, S19-270E, S19274C, S19274E Installation
10/5/2017 Bradley • 215-1326 Rev. V; ECN 15-05-042
Dimensions — S19-270C
Ø ⁷⁄₈"
11⁵⁄₈"
(295mm)
4¹⁄₈"
(105mm)
28-7/8" to 40-7/8"
(733 mm to 1038 mm)
to finished floor
30-1/8" to 42-1/8"
(765 mm to 1070 mm)
to finished floor
Off
On
1³⁄₈"
(35mm)
Max.
3¹⁄₈"
(79mm)
2³⁄₈"
(60mm)
Ø 2³⁄₈"
(60mm)
Ø ⁷⁄₈"
7¼"
(181mm)
2⁷⁄₈"
(73mm)
Off
On
1³⁄₈"
(35mm)
Max.
2³⁄₈"
(60mm)
Ø 1¹⁄₈"
Ø 2³⁄₈"
(60mm)
Dimensions — S19274C
1⁵⁄₈"
(41mm)
2½"
(64mm)
2½"
(64mm)

5
Installation S19-270C, S19-270E, S19274C, S19274E
Bradley • 215-1326 Rev. V; ECN 15-05-042 10/5/2017
27-1/4" to 39-1/4"
(692 mm to 997 mm)
to finished floor
29-5/8" to 41-5/8"
(752 mm to 1057 mm)
to finished floor
Ø ⁷⁄₈"
11³⁄₈"
(289mm)
5¾"
(146mm)
Off
On
1³⁄₈"
(35mm)
Max.
3¹⁄₈"
(79mm)
2³⁄₈"
(60mm)
Ø 2³⁄₈"
(60mm)
Dimensions — S19-270E
Ø ⁷⁄₈"
11"
(279mm)
3³⁄₈"
(86mm)
Off
On
1³⁄₈"
(35mm)
Max.
2³⁄₈"
(60mm)
Ø 2³⁄₈"
(60mm)
1⁵⁄₈"
(41mm)
Dimensions — S19274E
2½"
(64mm)
2½"
(64mm)

6
S19-270C, S19-270E, S19274C, S19274E Installation
10/5/2017 Bradley • 215-1326 Rev. V; ECN 15-05-042
Installation — Eyewash
Halo eyewash right-hand unit is shown on a sample 25" deck. Other units are similar. For classic eyewash installation,
refer to the dimensions on page 4 to determine optimal mounting position. Refer to page 8 for left-hand units.
Minimum dimensions necessary to contain splashing from Halo units are shown.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints. The top of the eyewash heads should be
positioned a minimum of 33" and a maximum of 45" from the floor and 6" from the nearest obstruction.
25"
(635mm)
7¾"
(197mm)
Ref.
2"
(51mm)
Ref.
¾" (19mm)
Min.
Deck
B
P.O.BOX 309,MENOMONEE FALLS, WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
D
To
Wall
Connect the water supply using
piping (supplied by installer) with
½" NPT female threaded end.
C
Slowly open the water
supply lines to relieve air
and pressurize the valve.
Test the unit for leaks
and adequate flow.
E
Proper faucet shank/handle
clearance and recommended
minimum splash containment
dimensions must be considered
when selecting the desired
location for mounting.
5¾"
(146mm)
Ref.
2⁵⁄₈" (67mm)
Ref.
5¼"
(133mm)
Min.
"ON" Position
"OFF" Position
8"
(203mm)
Radius
Deck Mounting Pattern
(drill (3) holes as shown)
A2"
(51mm)
Ø ³⁄₁₆"
Ø 1¹⁄₈"

7
Installation S19-270C, S19-270E, S19274C, S19274E
Bradley • 215-1326 Rev. V; ECN 15-05-042 10/5/2017
Installation — Eye/Face Wash
25"
(635mm)
9¼"
(235mm)
Ref.
2½"
(64mm)
Min.
Deck
B
P.O.BOX 309,MENOMONEE FALLS, WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
D
To
Wall
Connect the water supply using
piping (supplied by installer) with
½" NPT female threaded end.
C
Proper faucet shank/handle
clearance and recommended
minimum splash containment
dimensions must be considered
when selecting the desired
location for mounting.
5¾"
(146mm)
Ref.
2¹⁄₈"
(54mm)
Min.
"ON" Position
"OFF" Position
13⁷⁄₈"
(352mm)
Radius
Deck Mounting Pattern
Drill (3) holes as shown.
A2"
(51mm)
Ø ³⁄₁₆"
Ø 1¹⁄₈"
13"
(330mm)
Ref.
Halo eye/face wash right-hand unit is shown on a sample 25" deck. Other units are similar. For classic eye/face wash
installation, refer to the dimensions on page 5 to determine optimal mounting position. Refer to page 8 for left-hand units.
Minimum dimensions necessary to contain splashing from Halo units are shown.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints. The top of the eyewash heads should be positioned
a minimum of 33" (838mm) and a maximum of 45" (1143mm) from the floor and 6" (152mm) from the nearest obstruction.
Slowly open the water
supply lines to relieve air
and pressurize the valve.
Test the unit for leaks
and adequate flow.
E

8
S19-270C, S19-270E, S19274C, S19274E Installation
10/5/2017 Bradley • 215-1326 Rev. V; ECN 15-05-042
Installation — Left-Hand Units (Classic)
Classic eyewash unit is shown. Classic eye/face wash unit is similar.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints.
Slowly open the water supply lines to
relieve air and pressurize the valve. Test
the unit for leaks and adequate flow.
F
Rotate the bent arm 180°
around the valve.Using
low strength thread locker,
reinstall the set screw
into the valve in the new
location shown until it
bottoms out, then back off
½ turn.
Arm must swing freely.
C
Mount the unit onto the deck. Refer to the instructions on page 6 for
eyewash units or page 7 for eye/face wash units.
The left-hand unit must be installed on the left side of the deck.
E
Remove the sprayhead from the
bent arm. Remove the set screw
from the valve assembly with an
Allen key (1/16"(1.5mm)). Set
the two items aside.
A
Rotate the bent arm
180° around the valve.
B
Reattach the sprayhead to the
bent arm, resealing as necessary.
D

9
Installation S19-270C, S19-270E, S19274C, S19274E
Bradley • 215-1326 Rev. V; ECN 15-05-042 10/5/2017
Installation — Left-Hand Units (Halo)
Halo eyewash unit is shown. Halo eye/face wash unit is similar.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints.
Slowly open the water supply lines to
relieve air and pressurize the valve. Test
the unit for leaks and adequate flow.
G
Mount the unit onto the deck. Refer to the instructions on page 6 for
eyewash units or page 7 for eye/face wash units.
The left-hand unit must be installed on the left side of the deck.
F
Remove the set screw from
the valve assembly with an
Allen key (1/16"(1.5mm)) and
set aside.
A
Rotate the
arm 180°
around the
valve.
B
Tighten cap assembly,
ensuring head is level.
E
C
Using low strength thread locker,
reinstall the set screw into the valve
in the new location shown until it
bottoms out, then back off ½ turn.
Arm must swing freely.
Rotate the head and body 180°
around the arm.
Loosen the cap assembly with
an Allen key (5/16"(8mm)) and
rotate the sprayhead 180°.
D

10
S19-270C, S19-270E, S19274C, S19274E Installation
10/5/2017 Bradley • 215-1326 Rev. V; ECN 15-05-042
Assembly of Components and Parts List —S19-270C
Right-hand swivel version is shown in the "ON" position.
P.O. Box 309, Menomonee Falls, WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
bradleycorp.com
114-051
1
14
15
16
19
21
30
31
2
13
Deck
23
1 N/A 1 Valve not available for service; must
replace complete fixture.
2 160-473 2 Screw, Set
13 160-474 2 Screw, Set
14 113-514 1 Shank, ½" x 2½"
15 142-002CB 1 Washer, Flat ⁷⁄₈" x 2"
16 110-115 1 Nut, Brass ½"-14 NPSM
19 113-1032 1 Pipe, Bent Plated
21 S05-092 1 Eyewash Yoke 90°
23 107-371 2 Tethered Dust Cover
30 114-051 1 Safety Sign
31 204-421 1 Emergency Inspection Tag
Item Part No. Qty Description Item Part No. Qty Description
