Bradley Terreon WF3204 User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
TDB3104
Terreon®54" Semi-Circular Deep Bowl
Washfountain with Infrared Control
Terreon®Lavabo fontaine 1372 mm (54")
à cuvette profonde semi-circulaire avec
commande à infrarouge
Fuente de lavado semicircular con
palangana profunda Terreon®de
1372 mm (54") con control infrarrojo
WF3204
Terreon®Extra Height 54" Semi-Circular
Classic Washfountain with 9" Deep Bowl
and Infrared Control
Terreon®Lavabo fontaine 1372 mm (54") à
hauteur supplémentaire classique semi-
circulaire à cuvette profonde de 229 mm
(9") et commande à infrarouge
Fuente de lavado clásica semicircular
Terreon®de altura adicional de 1372 mm
(54") con palangana profunda de 229 mm
(9") y control infrarrojo
215-1078 Rev. T; ECN 12-00-004
© 2013 Bradley
Page 1 of 65 1/15/2013
TDB3104
with Infrared Control
TDB3104
avec commande à infrarouge
Modelo TDB3104
con control infrarrojo
TDB3104 Juvenile
with Infrared Control
TDB3104 Enfant
avec commande à infrarouge
Modelo infantil TDB3104
con control infrarrojo
WF3204
with Infrared Control
WF3204
avec commande à infrarouge
Modelo WF3204
con control infrarrojo
TDB3104 TAS Height
with Infrared Control
TDB3104 Hauteur TAS
avec commande à infrarouge
Altura TAS del modelo TDB3104
con control infrarrojo

TDB3104, WF3204 Installation
21/15/2013 Bradley • 215-1078 Rev. T; ECN 12-00-004
Table of Contents
Pre-Installation Information ...............................................................................3
Semi-Circular Washfountain Dimensions ..................................................................4-5
Rough-In Specifications............................................................................... 6-7
Installing the Drain......................................................................................8
Bowl/Pedestal Mounting and Assembly .....................................................................9
Installing Drain Spud in Bowl..............................................................................9
Connect Supply Tubing to Sprayhead ......................................................................10
Adaptive Infrared Installation..........................................................................11-14
Valve and Tubing Connections ...........................................................................15
Electrical Connections for Adaptive Infrared .................................................................16
Adjust the Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cleaning and Maintenance ...........................................................................17-18
Soap Valve Parts List and Maintenance .................................................................19-20
Sprayhead Parts List and Troubleshooting ..................................................................21
Solenoid Valve Troubleshooting...........................................................................22
Thermostatic Mixing Valve Troubleshooting..................................................................23
Sommaire
Informations sur la pré-installation ........................................................................24
Dimensions du lavabo fontaine semi-circulaire ............................................................25-26
Spécifications de mise en place des tuyauteries ..........................................................27-28
Installation du drain ....................................................................................29
Montage de l’ensemble cuvette et socle ....................................................................30
Installation de l’ergot de drain dans la cuvette ...............................................................30
Raccorder la tubulure d’alimentation au bec diffuseur .........................................................31
Ensemble à infrarouge Adaptive .......................................................................32-35
Connexions de robinets et de tubulures ....................................................................36
Connexions électriques pour Infrarouge adaptive.............................................................37
Faire couler l’eau pour régler la température ................................................................37
Instructions de nettoyage ............................................................................38-39
Nomenclature et conseils d’entretien pour le savon ........................................................40-41
Nomenclature et Suggestions pour réparer le bec diffuseur.....................................................42
Dépannage du bouton-poussoir électromagnétique ...........................................................43
Dépannage du robinet mitigeur thermostatique ..............................................................44
Índice
Información previa a la instalación ........................................................................45
Dimensiones de fuentes de lavado semicirculares .........................................................46-47
Especificaciones técnicas para colocación de tuberías empotradas ...........................................48-49
Instalación de desagüe .................................................................................50
Montaje y ensamblaje de palangana/pedestal ...............................................................51
Instalación del embudo de desagüe en la palangana..........................................................51
Conecte la tubería de suministro a la boquilla rociadora .......................................................52
Conjunto del dispositivo infrarrojo adaptive...............................................................53-56
Conexiones de válvulas y tuberías ........................................................................57
Conexiones eléctricas para el dispositivo Infrarrojo adaptive ....................................................58
Ajuste la temperatura con el agua corriendo ................................................................58
Instrucciones de limpieza y mantenimiento ..............................................................59-50
Lista de piezas y mantenimiento de los dispensadores de jabón..............................................61-62
Lista de piezas y solución de problemas de las boquillas rociadoras .............................................63
Solución de problemas de la válvula de solenoide............................................................64
Solución de problemas de la válvula mezcladora termostática ..................................................65

Installation TDB3104, WF3204
Bradley • 215-1078 Rev. T; ECN 12-00-004 1/15/2013 3
Supplies Required by Installer
• (4) 1/2" lag bolts, screws or other fasteners to anchor washfountain pedestal
• 1/2" nominal copper tubing for hot and cold water supply lines.
• Standard P-trap (vented trap supplied by Bradley when required)
• 2" drain lines and fittings
• 1-1/2" vent or tie pipe on fixtures vented through washfountain column
• Teflon tape or pipe dope
• 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied
• OPTIONAL: Bradley recommends installing an electrical cutoff switch to the unit. This feature allows no accidental
water delivery during regular maintenance and service.
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished with the
installation, file this manual with the owner or maintenance department.
Separate parts from packaging and make sure all parts are accounted for before discarding
any packaging material. If any parts are missing, do not begin installation until you obtain
the missing parts.
Make sure that all water supply lines have been flushed and then completely turned off
before beginning installation. Debris in supply lines can cause valves to malfunction.
Hardware supplied by installer must be appropriate for wall construction. Wall anchors used
must have a minimum pull-out rating of 1,000 lbs.
The Adaptive®Infrared control must be connected with a 24 VAC Class II transformer.
Connections to 110 VAC can cause personal injury and will result in damage to the
electronics.
Product warranties may be found under “Product Information” on our web site
at www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•
Pre-Installation Information
Terreon®Material
The Washfountain is constructed of Terreon®, a densified solid surface material composed of polyester resin. Terreon is resistant to
chemicals, stains, burns and impact. Surface damage can be easily repaired with everyday cleaners or fine-grit abrasives. Terreon
is NAHB certified to meet ANSI Z124.3, Z124.6 and ANSI/ICPA SS-1-2001.
Adaptive Infrared
The sprayhead is controlled by a solenoid valve, allowing the user to activate a flow of water. The Infrared sensor will take a few
minutes to adapt to its environment when the unit is powered up.

TDB3104, WF3204 Installation
41/15/2013 Bradley • 215-1078 Rev. T; ECN 12-00-004
Semi-Circular Washfountain Dimensions
Model TDB3104
54" Semi-circular - side view
32-1/4"
(819)
5-1/4"
(133)
Adjust to Towel Dispenser
Mounting Holes
6"
(152) 64" (1626)
w/ soap
55-1/2"
(1410)
w/o soap
55-3/4"
(1416)
47-1/4"
(1200)
43-3/4"
(1111)
34"
(864)
27"
(686)
23-1/2"
(597)
15"
(381)
40"
(1016)
Model TDB3104 is ADA Compliant
Optional equipment may not comply with all
ADA dimensional guidelines
Model TDB3104 (Juvenile Height)
54" Semi-circular - side view
32-1/4"
(819)
5-1/4"
(133)
22-3/4"
(577)
Adjust to Towel Dispenser
Mounting Holes
6"
(152)
22-3/4"
(577)
34"*
(864)
15"
(381)
23-1/2"*
(597)
30"*
(762)
39-1/8"*
(994)
45-5/8"*
(1084)
51-1/4"*
(1301)
59-1/2"*
(1511) w/
soap
51"*
(1295)
w/o soap
* Add 2" (51) for TAS height unit
Model TDB3104
54" Semi-circular - rear view
pedestal access
12-1/2"
(318)
3-1/2"*
(89) 17-1/2"
(444)
1" (25)
8"*
(203)
Check local codes for electrical outlet
location before roughing in. Some codes
require a remote location for the outlet.

Installation TDB3104, WF3204
Bradley • 215-1078 Rev. T; ECN 12-00-004 1/15/2013 5
Semi-Circular Washfountain Dimensions
Model WF3204 is not ADA compliant
Model WF3204
54" Semi-circular - side view
32-1/4"
(819)
22-3/4"
(577)
Adjust to Towel Dispenser
Mounting Holes
6"
(152) 64" (1626)
w/ Soap
55-1/2"
(1410)
w/o Soap
55-3/4"
(1416)
47-1/4"
(1200)
43-3/4"
(1111)
34"
(864)
23-1/2"
(597)
41"
(1041)
15"
(381)
5-1/4"
(133)

TDB3104, WF3204 Installation
61/15/2013 Bradley • 215-1078 Rev. T; ECN 12-00-004
Rough-In Specifications (mm)
Type B Drain
- Supplies from above
- Vent through ceiling
off trap inside pedestal
Type A Drain
- Supplies from below
or through wall
- Vent from below or
through wall off-drain
2" NPT Drain Through Floor, Stub
up 3" (76) Above Floor
1/2" Nominal Copper Tubing for Cold Supply Through
Floor (optional), Stub Up 2-1/2" (64) Above Floor
13" R Top Access
54" (1372) Bowl
7-3/8" R Bottom Access
1/2" Nominal Copper Tubing for Hot Supply Through
Floor (optional), Stub Up 2-1/2" (64) Above Floor
3-1/4"
(83)
5-1/4"
(133)
4"
(102)
7-5/8"
(194)
7-5/8"
(194)
Trap for Wall Outlet Only
4" (102) Clearance Hole
Drain Through Wall
Supplies Through Wall
12"
(305)
6" to 13-1/4"
(152 to 337)
(mm)
1-1/2" NPT Vent to Ceiling
13" R Top Access
54" (1372) Bowl
7-3/8" R Bottom Access
2" NPT Drain, Stub Out
3" (76) Above Floor
5-1/4"
(133)
WallWall
Vent
Drain Through Floor
1/2" Nominal Copper
Tubing Supply from Above
7/8"
(22)
Hot
Cold
7/8"
(22)
1-1/4"
(32)
Wall
Drain and Supplies Through Floor Trap
Located Below Floor (Optional)
4" (102)
1/2" Nominal Copper
Tubing Supplies
Through Wall

Installation TDB3104, WF3204
Bradley • 215-1078 Rev. T; ECN 12-00-004 1/15/2013 7
Rough-In Specifications (mm)
(mm)
Type O Drain
- Supplies from above
- Vented from below or
through wall off drain
Type H Drain
- Supplies from below or
through wall
- Vented through ceiling off
trap inside pedestal
13" R Top Access
7-3/8" R Bottom Access
1-1/2" NPT Vent to Ceiling
1/2" Nominal Copper
Tubing Supplies
Through Floor
(optional), Stub Up
2-1/2" (64) Above Floor
54" (1372) Bowl
2" NPT Drain, Stub Up
3" (76) Above Floor
3-1/4"
(83)
5-1/4"
(133)
Vent
12"
(305)
Drain Through Floor
Supplies Through Floor (Optional)
13" R Top Access
2" NPT Drain Through Floor,
Stub Up 3" (76) Above Floor
54" (1372) Bowl
7-3/8" R Bottom Access
5-1/4"
(133)
1-1/4"
(32)
7/8"
(22)
Hot
Cold
7/8"
(22)
Tra p
4"
(102)
2" NPT Drain Through Wall (Stub
Out to Suit Trap Dimension)
1/2" Nominal Copper Tubing
Supplies From Above
Trap For Wall Outlet Only
4" (102) Clearance Hole
6" to 13-1/4"
(152 to 337) Drain Through Wall
Drain Through Floor Trap Located
Below Floor (Optional)
1/2" Nominal
Copper Tubing
Supplies Through
Wall
7-5/8"
(194)
Cold
7-5/8"
(194)
Hot
Wall
4"
(102)
Wall

TDB3104, WF3204 Installation
81/15/2013 Bradley • 215-1078 Rev. T; ECN 12-00-004
All piping shown in dotted lines to be
supplied by installer.
Table 1 — “B”Trap Dimensions
Dim Standard Height Juvenile Height TAS
B 23-3/8" (594mm) 22-1/2" (572mm) 24-1/2" (622mm)
1Installing the Drain
ARough in supply and drain piping
as required for your installation.
BAssemble the drain to the dimension
for the bowl you are installing.
Vent or Tie Pipe
(Supplied by
Installer) Vented Trap
(111-024)
B - See Table 1
4"
(102)
Centerline of
Washfountain
Types B, H
2" NPT Coupling if Tie
Pipe is Not Required
(Supplied by Installer)
B - See Table 1
4"
(102)
Centerline of
Washfountain
Types A, O
Vent or Tie Pipe
(Supplied by
Installer) Optional Tie Pipe
Bracket (S70-082)
B - See Table 1
4"
(102)
Centerline of
Washfountain
Types A, O with Tie
Pipe Bracket Option
See Rough-In information for
dimensions not shown.

Installation TDB3104, WF3204
Bradley • 215-1078 Rev. T; ECN 12-00-004 1/15/2013 9
CAUTION! Bowl surface is very smooth. Approximate
weight of bowl is 146 pounds (model TDB3104),
136 pounds (model WF3204) or 101 pounds (model
TDB3104/JUV). Handle with Care!
2Bowl/Pedestal Mounting and Assembly
APosition the pedestal at desired location and
mark the position of the (2) pedestal wall
mounting locations and (2) pedestal floor
mounting locations.
TAS OPTION: Place TAS spacer on floor
over the mounting holes. Place pedestal on
top of the spacer.
BSecure pedestal to floor with suitable
fasteners, 1/2" anchors and bolts (supplied
by installer). Do not overtighten.
CUsing two to three people, carefully lift bowl
onto pedestal.
DPosition the bowl so that the threaded rods
in the bowl mate with the slotted holes in
the pedestal.
EUsing 1/4" wing nuts and washers, secure
the bowl to the pedestal, three places.
Top View
Drain
Front View
Place Hands
Here When
Lifting Bowl
Threaded Rod
(Secured by 1/4"
wing nut and
washer)
Pedestal
Floor Mounting Locations
Wall
Mounting
Locations
Place Hands
Here When
Lifting Bowl
3Installing Drain Spud in Bowl
ALoosely attach the drain spud to the bowl
with the locknut and washer.
B TRAP OPTION: attach B trap to drain spud.
Tie Pipe OPTION: attach tie pipe bracket to
drain spud.
BTighten the spud and lock nut against the
bowl.
CSecure the strainer to drain spud with the
screws provided.
DConnect spud (or B Trap or Tie Pipe Bracket)
to drain.
Seal between drain spud and drain hole with
plumber’s putty (supplied by installer).
Strainer (S45-067)
Spud (112-015)
Bowl
Washer (142-068)
Locknut (161-021)
Drain Pre-Pack
(S45-273)

TDB3104, WF3204 Installation
10 1/15/2013 Bradley • 215-1078 Rev. T; ECN 12-00-004
A
Install 1/2" supply tubing in the sprayhead
using the male connector.
• Using a sharp razor, cut tubing squarely
and remove any burrs. DO NOT pinch or
crush end of tubing.
• Loosen nut on fitting. Moisten end of
tube and push into fitting until it is firmly
seated. Tighten nut to secure tube
to fitting (make sure nut is securely
tightened).
• If connector leaks, reseat tubing. If
leaking persists, replace male connector,
or call your Bradley representative for
assistance.
Sprayhead
Tubing
Male Tube
Connector
Nut
Tubing
4Connect Supply Tubing to Sprayhead
