Bradley Verge LVQD1 User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1842 Rev. H: ECO 20-08-028B
© 2021 Bradley
Page 1 of 83 1/21/2021
LVQD1
Verge®Lavatory System – LVQ-Series
with WashBar™Technology
Lave-mains Verge®– Série LVQ avec
technologie WashBar™
Sistema de lavabo Verge®– Serie LVQ
con tecnología WashBar™
Read the instructions in this manual before beginning installation. Save these instructions and refer to
them for inspection, maintenance, and troubleshooting information.
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at bradleycorp.com.
Lire les instructions du présent manuel avant de commencer l’installation. Sauvegarder ces instructions
et s’y reporter pour obtenir des renseignements relatifs à l’inspection, à l’entretien et au dépannage.
Lea las instrucciones de este manual antes de comenzar la instalación. Guarde estas instrucciones y
consúltelas para obtener información sobre la inspección, el mantenimiento y la solución de problemas.
Pour toute question concernant le fonctionnement ou l’installation de ce produit, consulter le site
www.bradleycorp.com ou appeler le 1-800-BRADLEY.
Les garanties de produits figurent sous la rubrique « Resources » (Ressources) sur notre site Internet à www.bradleycorp.com.
Para consultas sobre la operación o instalación de este producto, visite www.bradleycorp.com o llame al 1-800-BRADLEY.
Las garantías del producto se pueden encontrar en “Resources” (Recursos) de nuestro sitio Web, www.bradleycorp.com.
Shown with WB1
Illustré avec WB1
Se muestra con WB1
Shown with WB2
Illustré avec WB2
Se muestra con WB2

LVQD1 Installation
21/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Table of Contents
Safety Information .............................................................3
Supplies Required .............................................................3
Components ..................................................................4–6
Dimensions..................................................................7–10
Structural Rough-Ins........................................................11
Plumbing and Electrical Rough-Ins .................................12
Bracket Mounting.............................................................13
Drain Assembly ...............................................................13
WashBar Installation........................................................14
Aerator Installation...........................................................14
Attach Soap Motor and Soap Container Bracket ............15
Bowl Mounting with WashBar..........................................16
Install P-Trap ...................................................................16
Strainer and Drain Cap....................................................17
Dryer Motor Assembly.....................................................18
Attach Power Line Filter ..................................................19
Control Box and Valve Installation...................................19
Soap Installation..............................................................20
Electrical Connections.....................................................21
Adjust Temperature with Water Running .........................21
Access Panel...................................................................22
Master Control Box....................................................23–27
Cleaning and Maintenance........................................28–29
Table des matières
Informations de sécurité..................................................30
Fournitures requises........................................................30
Composants ..............................................................31–33
Dimensions................................................................34–37
Raccordements structurels..............................................38
Plomberie et raccordements électriques.........................39
Montage du support ........................................................40
Assemblage de l’écoulement...........................................40
Installation du WashBar...................................................41
Pose de l’aérateur ...........................................................41
Fixer le moteur de la pompe de savon et le
support du réservoir à savon...........................................42
Montage de la vasque avec le WashBar.........................43
Pose du siphon en P .......................................................43
Tamis et bonde d’écoulement..........................................44
Moteur de sèche-mains...................................................45
Raccorder le filtre de ligne électrique..............................46
Boîtier de commande et pose du robinet ........................46
Installation du savon........................................................47
Connexions électriques ...................................................48
Faire couler l’eau pour régler la température..................48
Panneau d’accès .............................................................49
Boîtier de commande principal..................................50–54
Nettoyage et entretien ...............................................55–56
Contenido
Informacion de seguridad................................................57
Materiales necesarios .....................................................57
Componentes ............................................................58–60
Dimensiones..............................................................61–64
Tuberías empotradas estructurales .................................65
Tuberías empotradas eléctricas y de plomería ...............66
Montaje de los soportes..................................................67
Conjunto de desagüe ......................................................67
Instalación del WashBar..................................................68
Instalación del aireador ...................................................68
Instale el motor de jabón y el soporte del recipiente
de jabón...........................................................................69
Montaje de la palangana con WashBar ..........................70
Instalación del sifón en P ................................................70
Filtro y tapa de desagüe..................................................71
Conjunto del motor del secador ......................................72
Instale el filtro de la línea de energía..............................73
Instalación de la caja de control y la válvula...................73
Instalación del jabón........................................................74
Conexiones eléctricas .....................................................75
Ajuste la temperatura con el agua corriendo ..................75
Panel de acceso..............................................................76
Caja de control maestro ............................................77–81
Limpieza y mantenimiento.........................................82–83

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 3
WARNING
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation. Electrical
power MUST remain off until installation is complete.
Installer’s hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 pounds.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file this
manual with the owner or maintenance department. Compliance and conformity to local codes and ordinances
is the responsibility of the installer. Product warranties may be found under “Products” on our Website at
www.bradleycorp.com.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
For standard height mounting, do not exceed the recommended 33.5" distance from the fixture rim to the
finished floor.
Troubleshooting and internal maintenance must be performed by qualified service personnel.
Supplies Required
• (4) ³/₈" fasteners and wall anchors for bowl and wall bracket (minimum pull-out rating of 1,000 lb)
• (4) #10 fasteners and wall anchors for soap tank brackets (minimum pull-out rating of 100 lb)
• (4) #10 fasteners and wall anchors for access panel brackets (minimum pull-out rating of 100 lb)
• ¹/₂" hot/cold or tempered stub-out
• 1¹/₂" NPT drain stub-out(s)
• (1) Dedicated 120VAC, 15A GFCI outlet
• Drill
• Basin wrench
• Tape measure
• Phillips screw driver
• Flat head screw driver
• Level
• ⁵⁄₁₆" nut driver
• ⁵⁄₁₆" socket (with or without extension)

LVQD1 Installation
41/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Components
LVQD1BO
Contact your Bradley Representative for
color and drilling options
Chrome P-Trap (S29-094)
Plastic P-Trap (269-1697)
O-Ring
(125-111)
Drain
Adapter
Packing
Washer
#10-24
Screw
Drain
Adapter
Prepack
(S45-2480)
Access Panel
Stainless Steel (Standard)
(186-1911)
Stainless Coated Black
(186-1911-BLK)
Stainless Steel Cut for Cam Locks
(186-1945)
Stainless Steel Cut for Cam Locks
Coated Black
(186-1945-BLK)
Wall Bracket
(140-1153)
DC Lead Free Valve
Assembly, Single TMA
(S08-2401TMA)
DC Lead Free Valve
Assembly, Single TL
(S08-2401TL)
Master Control Box
(S39-845)
#10 x ³/₈" Screw (2x)
(P18-054)
DC Power
Adapter
(261-147)
Access Panel Bracket
(140-1172)
#10 Access Panel
Thumb Screw
(160-536)
Access Panel Security
Screw Option
(S45-2880)
Strainer Kit with Screws
(S65-473)
Drain Cap with Spacers
(S65-476)
Drain Cap (Slotted)
with Spacers
(S65-476A)
Hose/90 Stop Lead Free TMA
(S45-2730) Hose/90 Stop Lead Free TL (S45-2731)
Grounding Washer
¹/₄" QC (230-035)
Ground Wire Asembly
¹/₄" Quick Type B Outlet
(S83-423)
Grounding Kit, WashBar
(S65-493)

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 5
WB1 Service Kits (Incl. castings, shanks,
deck gaskets, and LED bar)
S65-506-PC (Polished Chrome)
S65-506-BB (Brushed Black SS)
S65-506-BN (Brushed Nickel)
S65-506-BR (Brushed Brass)
S65-506-BS (Brushed Stainless)
S65-506-BZ (Brushed Bronze)
WB2 Service Kits (Incl. casting, shanks,
deck gaskets, and LED bar)
S65-505-PC (Polished Chrome)
S65-505-BB (Brushed Black SS)
S65-505-BN (Brushed Nickel)
S65-505-BR (Brushed Brass)
S65-505-BS (Brushed Stainless)
S65-505-BZ (Brushed Bronze)
Union Tube, ¹/₄" OD
(269-624)
¹/₄" x 60 Tubing (269-547C)
For Service - 1’ Increments (R68-600011)
¹/₄" x 60 Tubing (269-547C)
For Service - 1' Increments
(R68-600011)
Elbow, ¹/₄x 3.4mm
Hose Barb (145-221)
Elbow, ¹/₄x 3.4mm Hose Barb
(145-221)
Gasket WashBar
Deck, Soap Side
(124-101)
Soap Tube
5.5mm OD x 70cm long
(269-2522)
Soap Tube
5.5mm OD x 70cm long
(269-2522)
Access Plate Soap
Assembly Kit (S65-479)
Aerator 0.50 GPM (S05-175)
Aerator 0.35 GPM (S05-215)
(Aerators are shipped loose
in bag with red service key)
Aerator 0.50 GPM (S05-175)
Aerator 0.35 GPM (S05-215)
(Aerators are shipped loose
in bag with red service key)
Nut, WashBar, 1³/₈-18
(110-256)
Nut, WashBar, 1³/₈-18
(110-256)
Nut, WashBar, 1³/₈-18
(110-256)
WashBar Grounding Kit (S65-493)
Ground Wire Assembly ¹/₄"
Quick Type B Outlet
(S83-423)
Grounding Washer ¹/₄" QC
(230-035)
Ground Washer Assembly Kit
¹/₄" QC to Type B Outlet
(S65-493)
Gasket, WashBar Deck,
Air Side (124-102)
Gasket, WashBar Deck, Air Side
(124-114)
Spacer, Custom WB2
(182-142)
Access Plate Hardware
Kit (S65-481)
Access Plate Hardware
Kit (S65-504)
Access Plate Air Water
Assembly Kit (S65-480)
Access Plate Assembly Kit
(S65-503)
Union Elbow
(269-2531)
Union Elbow
(269-2531)
Nut, WashBar,
1³/₈-18
(110-256)
Components
WB1
WB2

LVQD1 Installation
61/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Soap System Components
Control Box Assembly with
Liquid Pump (S52-166)
Control Box Assembly with
Foam Pump (S52-167)
Gallon Jug
(May be supplied by
others)
Soap Tank Bracket
(140-1171)
Hose Clamps - 2¹/₂" Dia
(269-678)
Flexible PVC
(269-2561A)
Dryer Motor
(S39-859)
Dryer Vibration Pad
4" x 10"
(124-105)
(Not Shown)
Hook & Loop Strap
(269-2574)
Hook and Loop Strap
(not shown)
(269-2574)
Liquid Pump with External
Rubber Sleeve Connection
(269-2518)
Foam Pump with Internal
Press Fit Connection
(269-2519)
15½"
(394)
13¼"
(337)
6⁵⁄₈" (168)
12"
(305)
(mm)

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 7
Dimensions – WB1 (mm)
Top View
Front View
26¾" (681)
21"
(533)
5½" (140)
1½" (40)
14³⁄₈"
(366)
2x Ø 1⁷⁄₁₆" (37)
13½" (343)
2¾" (70)
11" (279)
5" (127)
20" (508)
29¾" (756)
20"
(509)
5" (127) 5" (127)
30" (762)
3¾" (95)

LVQD1 Installation
81/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Dimensions – WB2 (mm)
Top View
Front View
26¾" (681)
21"
(533)
5½" (140)
14³⁄₈"
(366)
2x Ø 1⁷⁄₁₆" (36)
13½" (343)
2¾" (70)
1½" (40)
1¾" (44)
5" (127)
20" (508)
29¾" (756)
20"
(509)
5" (127) 5" (127)
30" (762)
3¾" (95)

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 9
Dimensions – WB1 (mm)
A
B
12³⁄₈" (314)
Dryer
11¾" (299)
Faucet
C
3⁵⁄₈"
(92)
21" (534)
ADA/TAS Standard
Height ADA/TAS Juvenile Height (Children 6-12 years)
Dim A 33½" (851) 30½" (775)
Dim B 27" (686) 24" (610)
Dim C 13½" (343) 10½" (267)
20"
(507)
7½"
(189)
3¾"
(95)
6½"
(165)
20°
3⁷⁄₈" (99)
A
B
12³⁄₈" (314)
Dryer
11¾" (299)
Faucet
C
3⁵⁄₈"
(92)
21" (534)
20"
(507)
7½"
(189)
3¾"
(95)
6½"
(165)
20°
3⁷⁄₈" (99)
28¹⁵⁄₁₆"
(735)
CSA Standard Height
Dim A 33½" (851)
Dim B 29²⁹⁄₃₂" (760)
Dim C 13½" (536)
Side View

LVQD1 Installation
10 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Dimensions – WB2 (mm)
A
B
13" (326)
Dryer
12³⁄₈" (299)
Faucet
C
3⁵⁄₈"
(92)
21" (534)
ADA/TAS Standard
Height ADA/TAS Juvenile Height (Children 6-12 years)
Dim A 33²⁄₅" (848) 30½" (775)
Dim B 27" (686) 24" (610)
Dim C 13½" (343) 10½" (267)
20"
(507)
7½"
(189)
3¾" (95)
6½" (165)
20°
4¼" (107)
A
B
C
20"
(507)
7½"
(189)
3¾" (95)
6½" (165)
20°
28¹⁵⁄₁₆"
(735)
CSA Standard Height
Dim A 33½" (851)
Dim B 29²⁹⁄₃₂" (760)
Dim C 13½" (536)
Side View
21" (534)
3⁵⁄₈"
(92)
4¼" (107)
13" (326)
Dryer
12³⁄₈" (299)
Faucet

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 11
Mounting for Standard ADA and TAS height shown.
Structural Rough-Ins
Points A, B, and C require sufficient backing compliant with
local building codes.
WARNING Ensure bowl is completely seated in
the wall bracket and securely fastened
to the wall at point A.
31½"
(800)
AA
BB
10" (254)
C
L
29⁵⁄₈"
(753)
Bottom of
Bracket
CODE DESCRIPTION QTY.
AInstall (1) ³/₈" wall anchor with a minimum pull-out force of 1,000 lb per local codes at locations shown 2
B Provide structural backing compliant with local building codes. 2
C Install wall anchor with a minimum pull-out force of 100 lb per local codes at locations shown 4
S #10 Wall Anchors for Soap Control Box Bracket 2
S1 #10 Wall Anchors for Soap Tank Bracket (100 lb pull out) 2
* Measured from center of top slot on access panel bracket
Wall Bracket
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FIXTURE STYLE
33½" No Adjustment Standard Height ADA, TAS, and CSA
30½" Subtract 3" Juvenile ADA and TAS
CC
25¼"
(654)
33½"
(851)
15³⁄₈"*
(390)
12⁵⁄₈" (320) 12⁵⁄₈" (320)
10" (254) 10" (254)
Access
Panel
Bracket
9¹⁄₈" (231) 9¹⁄₈" (231)
Finished Floor
Access
Panel
Bracket
(mm)
Secure bracket to wall using min. ³/₈"
anchor bolt to the left of C/L and min. ³/₈"
anchor bolt to the right of C/L. The anchor
bolt to the right of C/L must be min. 5"
apart from the anchor bolt to the left of
C/L. When mounting is complete, check
to ensure the bracket is level. See Step 1:
Bracket Mounting for more information.
5"
(127) 2½"
(64)
S S
5½"
(140)
S1 S1
28"
(711)
2¼" (57)
13¼"
(337)

LVQD1 Installation
12 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Plumbing and Electrical Rough-Ins (mm)
Mounting for Standard ADA and TAS height shown.
CODE DESCRIPTION QTY.
A1¹/₂" NPT Drain, Stub-out 2" from wall 1
H,C ¹/₂" Nominal (⁵/₈" O.D. Comp.) Hot/Cold supplies, Stub-out 2" from wall 1
EDedicated 120VAC, 15A GFCI minimum outlet must be provided, which is properly grounded and no more
than 4 ft from the installation of the dryer assembly.* 1
* If no GFCI outlet is provided, contact a licensed electrician to assure proper electrical connections in accordance with local building codes.
Troubleshooting and internal maintenance must be performed by qualified service personnel.
33½"
(851)
10" (254)
23¾"
(603)
A
E
H C
2¼" (57)
1" (25)
Finished Floor
17½"
(444)
Min.
Tempered
Supply

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 13
Bracket Mounting
Typical installation is shown. It may be necessary to repair the wall after
mounting. The fixture may not cover all of the wall modifications.
1
5"
(127mm)
min.
Install wall bracket to wall
per structural rough-in
dimensions. Check to
ensure the bracket is
level. Example anchor
locations shown.
A
Mounting height per structural rough-in dimensions.
For ease of drain installation, lay the bowl on its back.
2Drain Assembly
O-Ring
Drain
Adapter
Packing
Washer
#10-24
Screw
Assemble the remaining components as
shown and thread the four screws through
the drain adapter and into the basin inserts.
Ensure the screws compress the drain adapter
evenly onto the basin. Do not overtighten.
A
C
L

LVQD1 Installation
14 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
WashBar Installation – WB1 & WB2
3
Assemble WashBar through basin
WashBar holes. Run cables and
tubes on left side only.
BFor WB1 & WB2: Secure
from underside with (2)
nuts and (1) grounding
washer (right side only).
For WB2 Only: Install the
custom spacer (182-142)
between deck and nut
(left side only) with spacer
groove side up against
deck. Refer to page 5.
C
WashBar
Grounding Washer,
0.25 QC
Nut, WashBar,
1³⁄₈-18
Connect grounding wire spade
terminal end to grounding washer
tab. Do not attach grounding wire
plug adapter to wall outlet until later
in the installation procedure.
E
Position bowl on the
floor, upright, as shown.
A
Soap Tube (Clear), ¹/₄" Water Tube,
LED Cable (Gray), Soap Sensor
Cable (Shorter Cable), and Air/
Water Cable (Longer Cable)
Aerator Installation – WB1 & WB2
4
Red Service Key
Aerator
(0.35 gpm or
0.5 gpm)
Carefully thread the aerator into
the WashBar casting using the red
service key provided. Ensure no
leaks after installation.
A
WashBar comes pre-assembled,
with the exception of the aerator.
WB1 is shown for these instructions.
WB1 is shown for these instructions.
Attach flexible PVC dryer
tube to shank using
hose clamp. Tighten to
30-35 ft-lb using ⁵/₁₆"
socket.
D
Attach the ¹/₄" supply
tube to the ¹/₄" union
elbow.
F
When attaching flexible PVC
dryer tube, be sure tube is
touching the WashBar nut
when complete.

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 15
The liquid soap pump has a rubber sleeve
that fits over the soap container opening.
The foam soap pump has an interior white
cylinder that fits into the soap container.
The fit may be tight. Move the gallon soap
container laterally while applying pressure
to seat them together approximately
¹/₄" (6 mm) into soap container opening.
Attach Soap Motor and Soap Container Bracket
5
Attach soap motor control box and soap
container bracket to wall using #10 screws
at the locations shown in the Structural
Rough-In drawing.
A
Attach soap syphon tube to the bottom
of the soap pump.
Install soap pump into the soap control box.
Clear soap bracket and hold in place
against the wall.
Secure soap pump to the soap control box
using the small hook and loop strap.
Slide the gallon soap container over
the soap syphon tube, and push the
soap container up into the soap pump
approximately ¹/₄" (6 mm).
B
C
F
D
E
Soap
Container
Bracket
Gallon
Soap
Container
Soap Syphon
Tube
Soap Pump
(Liquid or Foam)
Attach soap
supply tube
here.
Ensure soap pump flange
is positioned below control
lever box.
Slide soap container bracket up until
it touches the bottom of gallon soap
container. Tighten the #10 screws to secure
the soap container bracket to the wall.
Remove the gallon soap container by
swinging it away from the wall and lowering
it from the soap syphon tube (see below).
Store soap container for later installation.
G
H
Liquid soap pump
shown. Foam soap
pump similar.
Small Hook &
Loop Strap
Soap Motor
Control Box
Alternate location
for adding a small
hook & hoop strap
to an older soap
pump assembly

LVQD1 Installation
16 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Bowl Mounting with WashBar (to Bracket & Wall)
6
Position bowl above wall bracket.
Press firmly on the back of the bowl
to seat the bowl flange into the wall
bracket lip. Ensure bowl is level.
A
Secure the bowl to the wall anchors
using fasteners per the structural
rough-in requirement (supplied by
installer).
B
WARNING Ensure bowl is completely
seated in the wall bracket
and securely fastened to
the wall at point A.
CAUTION Bracket is not intended to
support the weight of bowl
for an extended period of
time. Be sure to secure
the bowl to the wall using
appropriate fasteners.
Install P-Trap
7
Drain Adapter
P-Trap

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 17
Strainer and Standard Drain Cap
Strainer and Slotted Drain Cap
8a
8b
Position drain cap over trough strainer,
aligning tabs into drain. Push drain
cap down until drain cap is flush with
basin. Grommets should hold drain cap
securely against drain trough walls.
Install the trough strainer and secure
in place using the #10 x 1" supplied
screws.
Install the trough strainer and slotted drain
cap as shown. Secure in place using the
#10 x 1½" supplied vandal screws.
B
A
A
To remove drain cap, carefully slip flat
screwdriver into left or right hand corner
of drain cap and gently lift upwards.
C
WashBar removed for clarity.
WashBar removed for clarity.
Front Note Angle of
Drain Cap
Standard Drain
Cap
Slotted Drain
Cap
#10 x 1"
Screw
#10 x 1½"
Vandal
Screw
Trough
Strainer
Trough
Strainer
#10 x 1"
Screw
#10 x 1½"
Vandal
Screw
Drain cap is labeled front and back. Be sure front is
facing the user. Top surface of drain cap should be
sloped away from user.
Drain cap is labeled front and back. Be
sure front is facing the user. Top surface
of drain cap should be sloped away
from user.

LVQD1 Installation
18 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Dryer Motor Assembly
9
Dryer Outlet Nozzle
Dryer Motor
Foam Bumper
Dryer Motor Feet
Power Cord to GFCI Outlet
Dryer Motor, 120V/60Hz
Power Cord to DC Adapter Only
Flexible Hose
Hose Clamp
Front View of Motor
CAUTION If dryer motor is not secured properly to flexible PVC
dryer tube, motor may come lose and detach from tube.
RJ45 Connector Cable
(unplug and discard)
Discard water detector
wire (shipped loose) and
RJ45 connector cable
from motor and discard.
G
Water Detector
Wire
WB1 is shown for these instructions.
WB2 is similar.
Slide the hose clamp onto the
flexible PVC dryer tube and
begin to tighten clamp so that
it does not fall off.
A
After assembly, dryer motor is
designed to hang freely. Do not
fasten to wall unless required by
building codes. Secure dryer motor
foam bumper to finished wall, in-line
with the dryer motor feet.
E
Bundle loose cords to motor using
hook and loop cable tie.
F
While holding the motor from
the bottom with one hand,
insert dryer outlet nozzle into
the flexible PVC dryer tube.
B
Tighten hose clamp using the ⁵/₁₆"
socket wrench. Tighten clamp to
30-35 in-lb.
C
Check to be sure motor is securely
attached to flexible PVC dryer tube
by gently pulling down on motor.
Motor should stay attached to tube.
D

Installation LVQD1
Bradley • 215-1842 Rev. H: ECO 20-08-028B 1/21/2021 19
Control Box and Valve Installation
11
Secure control box to
underside of bowl using
(2) #10 x ³/₈" long screws
provided.
A
¹/₄" Water Supply
Outlet with
Compression Nut
Cold Supply/
Stop Valve
Hot Supply/
Stop Valve
Cold
Hot
Attach ¹/₄" supply tube from the
WashBar to the ¹/₄" supply valve
outlet. Loosen the compression
nut on the valve body. Push
the ¹/₄" supply tube firmly into
the tube connector until it is
fully seated. Hand tighten the
compression nut.
B
For thermostatic mixing valve installation, secure ¹/₂" supply
hose to hot water supply valve inlet. Secure the other supply
hose from cold water supply to cold water supply valve inlet.
Secure valve to bowl using (2) #10 x ³/₈" long screws and
washers (install washer between the bowl and valve bracket).
For tempered line installation, secure ¹/₂" supply hose to
tempered water supply and TL valve inlet (not shown).
Secure valve to bowl using (2) #10 x ³/₈" long screws and
washers (install washer between the bowl and valve bracket).
C
Attach Power Line Filter
10
Secure dryer power line
filter to underside of
bowl using (2) #10 x ³/₈"
screws provided.
A
Remove ³/₈" compression nut/sleeve from the hot
and cold supply stop valves. Connect ³/₈" end
of flexible supply hose to ³/₈" compression on
supply stop valve. Ensure hot and cold supply
hoses are connected to hot and cold supply stop
valve. For TL option, only connect cold supply.
D
³/₈"
Compression
Nut

LVQD1 Installation
20 1/21/2021 Bradley • 215-1842 Rev. H: ECO 20-08-028B
Soap Installation
12
The soap system is designed to be used with a standard U.S.
gallon soap container. For accurate low soap indication, user
needs to set soap type (see Configuration Mode on page 25
to set soap type).
Attach soap supply tube from the
WashBar to the top of the soap pump.
A
To manually prime the soap, press
down on the control box lever arm 6 to
8 times.
F
Use the provided cable tie hook and
loop strap to secure container to soap
bracket. Feed end of cable tie (smooth
side facing you) through the right side
slot of bracket flange at top. Feed
through left side flange slot and wrap
around jug. Secure with the hook and
loop end.
D
Ensure that the soap tube is not
kinked. Position hand above soap
motor control box and adjust tube if
needed.
E
Slide gallon soap container over soap
syphon tube and into soap pump.
Set gallon soap container onto lower
soap tank bracket and hold in place.
B
C
For ease of soap container removal,
swing it away from the wall to clear the
soap container bracket and lower it to
clear the soap syphon tube.
Ensure soap pump flange
is positioned below
control box lever.
Attach soap supply tube from
WashBar here.
Top Flange
Cable Tie Slot
Soap Container
Bracket
Cable Tie Hook
and Loop Strap
Soap Pump
Soap Syphon
Tube
Soap cycle count defaults to liquid soap configuration. If you
have the foam soap option, please see Setting the Soap Type
under Configuration Mode on page 25.
The liquid soap pump has a rubber
sleeve that fits over the soap
container opening. The foam soap
pump has an interior white cylinder
that fits into the soap container. The
fit may be tight. Move the soap pump
laterally while applying pressure to
seat into soap container opening.
Small hook and loop strap
not shown for clarity.
