Bradley Terrazzo WF2613 User manual

IMPORTANT
Read this entire installation manual
to ensure proper installation.
Flush all the water supply lines
before making connections.
Main water supply to the unit
should be ON at all times.
This installation manual and parts
list should be filed by the owner’s
maintenance department.
215-609 Rev. J; EN 06-915B
© 2007 Bradley Corporation
Page 1 of 26 4/6/2007
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY FAX [phone]
http://www.bradleycorp.com
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . 2
Semi-Circular Washfountain Dimensions . . . . . . . 3
Rough-In Specifications . . . . . . . . . . . . . . . . . . . 4-5
Drain Rough-In Specifications . . . . . . . . . . . . . . . .6
Pedestal Assembly and Drain Spud Installation . .7-8
Supplies w/Optional Soap Dispenser (A/O drains) .....9-10
Supplies w/Optional Soap Dispenser (B/H drains) ....11-12
Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing the Operating Rod . . . . . . . . . . . . . . . .14
Soap Recommendations and Maintenance . . . . . .15
Check Valve Troubleshooting . . . . . . . . . . . . . . .15
Soap Valve Repair Parts . . . . . . . . . . . . . . . . . . . .16
Stop, Strainer and Check Valve Repair Parts . . . .17
Sprayhead Troubleshooting/Repair Parts . . . . . . 18
Foot Valve Breakdown and Repair Kit . . . . . . . .19
Manual Mixing Valve Repair Parts . . . . . . . . . . .20
Angle Volume Control Valve Repair Parts . . . . . .21
Vernatherm™ Mixing Valve Maintenance . . .22-24
Cleaning and Maintenance Instructions . . . . .25-26
WF2613
Classic Corner 54"
Washfountain with Foot
Control
Installation
Instructions
UPC Certified
UPC
R
C

Classic Terrazzo®Corner Washfountain with Foot Control
WF2613 Installation Instructions
Bradley Corporation • 215-609 Rev. J; EN 06-915B
2 4/6/2007
Pre-Installation Information
Operation
The system used on your Bradley Foot Controlled Washfountain actuates the valve when the foot rail is
depressed. The valve then stays open until the foot rail is released.
Supplies Required:
• (6) lag bolts, screws or other fasteners to anchor washfountain pedestal to floor.
• 1" hot and cold water supply lines and fittings (refer to rough-ins on pages 4-5).
• Reducing fittings and 1/2" nominal copper tubing for models with supplies from above.
• Standard P-trap (refer to rough-ins on pages 4-5). Vented trap supplied by Bradley when
required.
• 2" drain lines and fittings (refer to rough-ins on pages 4-5).
• Pipe sealant and plumber’s putty.
• 1-1/2" vent pipe on types vented through washfountain column (see page 3 for lengths required).
NOTE: Supply lines for one or two washfountains should be 1"; for three washfountains, 1-1/4". For
more than three washfountains pipe size should increase proportionally. Vent pipe to be 1-1/2" on
models vented through washfountain.
Bradley Classic Washfountain Warranty Information
Product warranties may be found under “Product Information” on our website at www.bradleycorp.com

Material A B C D E F G H J K
Inches 19 29-1/4 39-1/8 47-5/8 36-1/4 56 26 28 37-1/4 10-1/4
Millimeters 483 743 994 1210 921 1422 660 711 946 260
Classic Terrazzo®Corner Washfountain with Foot Control
Installation Instructions WF2613
Bradley Corporation • 215-609 Rev. J; EN 06-915B 34/6/2007
Length of Tie Pipe Required for Vent through Washfountain Column
54" Less Soap Dispenser 21-1/2" (546mm)
54" With Soap Dispenser 30" (762mm)
54" Less Soap Dispenser With Towel Dispenser 55-1/2" (1410mm)
54" With Soap Dispenser With Towel Dispenser 48" (1219mm)
54" With Cube Adapter 32" (813mm)
54" With Cube Adapter With Towel Dispenser 50" (1270mm)
54" With Cube Adapter And Soap Dispenser 40" (1016mm)
Type Pipe Length
NOTE: Drain must be connected with 2" schedule 40 welded wrought iron pipe, minimum, to provide
lower support for this installation. Vent or support pipe must be of the same material in 1-1/2".
For juvenile height, subtract 4" from dimensions A-E.
Corner Washfountain Dimensions
6" (152)
ADJUST TO TOWEL DISPENSER
MOUTING HOLES
K
E
J
H
G
A
B
C
D
F

Classic Terrazzo®Corner Washfountain with Foot Control
WF2613 Installation Instructions
Bradley Corporation • 215-609 Rev. J; EN 06-915B
4 4/6/2007
RIGHT WALL LEFT WALL
Std. Ht. Juv. Ht. Std. Ht. Juv. Ht.
11-1/4" to 13-1/4" 9-1/4" to 10-1/4" 6" to 11" 6" to 8-1/2"
286mm to 337mm 235mm to 260mm 152mm to 279mm 152mm to 216mm
12" 8-1/4" 12" 8-1/4"
305mm 210mm 305mm 210mm
DIM.
A
B
Rough-In Specifications
Use this range of heights
when hook-up is made with
a coupling and nipple (2"
drain through wall must not
interfere with diagonal
frame member on pedestal).
Rough-In Notes:
1. All pipes and fittings not furnished by Bradley are shown in broken lines.
2. Supply lines for one to two washfountains should be 1"; for three washfountains 1-1/4"; for more than three washfountains, pipe sizes
should be increased proportionately.
3. Overhead supplies must be reduced to 1/2" copper tube to pass through support tube.
4. Check valve inlets are 1/2" NPT.
5. Dimensions shown in parentheses are millimeters.
g
Type A
Off-line vent with supplies from below. Type O
Off-line vent with supplies from above.
54” (1372)
WASHFOUNTAIN
TOP VIEW
SIDE VIEW SIDE VIEW
TOP VIEW
COLD
HOT
TRAP
54” (1372)
WASHFOUNTAIN
BOWL
HOT
COLD
TRAP
2” NPT DRAIN THRU FLOOR
(OPTIONAL) STUB UP 3” (76)
ABOVE FLOOR
1” NPT SUPPLIES THRU
FLOOR (STUB UP 2-1/2” (64)
ABOVE FLOOR)
CENTER OF
WASHFOUNTAIN
10”
(254) 10”
(254)
18-1/2”
(470)
10”
(254)
8-1/2”
(216)
9-3/4”
(248)
9-3/4”
(248)
12-3/4”
(324)
7-1/4”
(184)
A
B
7-1/4”
(184)
18-1/2”
(470)
12-3/4”
(324)
8-3/8”
(213)
8-3/8”
(213) 10”
(254)
A
TRAP FOR
WALL
OUTLET ONLY
DRAIN THRU
FLOOR
TRAP LOCATED
BELOW FLOOR
4”
(102)
DRAIN
THRU WALL
SUPPLIES
THRU
WALL
TRAP FOR WALL
OUTLET ONLY
DRAIN
TRHU WALL
SUPPLIES AND DRAIN THRU FLOOR,
TRAP LOCATED BELOW FLOOR.
1” NPT SUPPLIES FROM ABOVE
MUST REDUCE TO 1/2” NOM.
COPPER TUB ON THESE
CENTERS TO PASS THRU WASH
FOUNTAIN
4”
(102)
2” NPT
DRAIN
THRU WALL
(STUB OUT
TO
SUIT TRAP
DIMENSION)
(OPTIONAL)
1” NPT
SUPPLIES
THRU WALL
(OPTIONAL)
4-1/2”
(114)
CLEARANCE HOLE
CENTER OF
WASHFOUNTAIN
2” NPT DRAIN THRU FLOOR
(OPTIONAL) STUB UP 3” (76)
ABOVE FLOOR
2” NPT DRAIN
THRU WALL
(STUB OUT TO
SUIT TRAP
DIMENSION)
(OPTIONAL)
CLEARANCE HOLE
RIGHT WALL
LEFT WALL
FLOOR
LEFT WALL
RIGHT WALL
LEFT WALL
FLOOR
NOTE: UPC AND IPC RESTRICT THE VERTICAL
DISTANCE FROM THE FIXTURE OUTLET TO THE TRAP
WEIR TO NOT MORE THAN 24". CHECK STATE AND
LOCAL CODES FOR VARIANCES.

Classic Terrazzo®Corner Washfountain with Foot Control
Installation Instructions WF2613
Bradley Corporation • 215-609 Rev. J; EN 06-915B 54/6/2007
RIGHT WALL LEFT WALL
Std. Ht. Juv. Ht. Std. Ht. Juv. Ht.
11-1/4" to 13-1/4" 9-1/4" to 10-1/4" 6" to 11" 6" to 8-1/2"
286mm to 337mm 235mm to 260mm 152mm to 279mm 152mm to 216mm
DIM.
A
Rough-In Specifications
Use this range of heights
when hook-up is made with a
coupling and nipple (2" drain
through wall must not
interfere with diagonal frame
member on pedestal).

Classic Terrazzo®Corner Washfountain with Foot Control
WF2613 Installation Instructions
Bradley Corporation • 215-609 Rev. J; EN 06-915B
6 4/6/2007
Installation Instructions
Step 1: Installing the Drain
1. Rough-in supply and drain piping as required for your installation (see pages 4-5 for rough-ins).
2. Assemble the drain to the dimension shown in Figure 1 or Figure 2.
NOTE: All piping shown in dotted lines to be supplied by the installer.
Figure 1
(mm)
Types A and O Types B and H
Figure 2
Vented Trap
(111-024)

Classic Terrazzo®Corner Washfountain with Foot Control
Installation Instructions WF2613
Bradley Corporation • 215-609 Rev. J; EN 06-915B 74/6/2007
Installation Instructions continued . . .
Step 2: Assembling the Pedestal
1. Assemble the legs and scuff base panels with the 5/16" carriage bolts and nuts provided (see
Figure 3).
2. Attach the pedestal frame members, the rear support members and the rear legs with the 5/16"
stove bolts and nuts provided (see Figure 3).
3. Add the foot levers and operating cross to the pedestal assembly (see Figures 3 and 4).
4 Attach the spacers, foot rail and spring pins to the foot valve levers (the bend in the center of the
foot rail must be pointing up) (see Figures 3 and 5).
Diagonal Support
(194-043) STD Hgt.
(194-043A) JUV. Hgt.
Figure 3
Figure 4 Figure 5

Classic Terrazzo®Corner Washfountain with Foot Control
WF2613 Installation Instructions
Bradley Corporation • 215-609 Rev. J; EN 06-915B
8 4/6/2007
Installation Instructions continued . . .
Step 3: Anchoring the Pedestal to the Floor and Installing Drain
IMPORTANT: FOR PROPER DRAINAGE, THE BOWL AND PEDESTAL MUST BE
LEVEL WHEN THEY ARE SECURED TO THE FLOOR .
WARNING: USE SUITABLE LIFTING EQUIPMENT TO POSITION THE BOWL AND
PEDESTAL ASSEMBLY. HANDLE WITH CARE! FAILURE TO DO SO
COULD RESULT IN SERIOUS PERSONAL INJURIES.
1. Position the pedestal assembly.
2. Anchor the pedestal assembly to the floor with suitable anchors (supplied by installer) (Figure 6).
3. Place the bowl on the pedestal using suitable lifting equipment.
CAUTION: Bowl Surface is smooth. Use suitable lifting equipment to position the
bowl and pedestal assembly. Handle with CARE!
4. Screw the spud into the drain with the lock nut and washer between the drain and bowl (see
Figure 7).
5. Tighten the spud and locknut against the bowl (see Figure 7).
Figure 6 Figure 7
STRAINER
(S45-067)
SPUD
112-015 (Terrazzo)
112-016 (Bradstone
and Stainless Steel)
BOWL
WASHER
(142-068)
LOCKNUT
(161-021)

Classic Terrazzo®Corner Washfountain with Foot Control
Installation Instructions WF2613
Bradley Corporation • 215-609 Rev. J; EN 06-915B 94/6/2007
Installation Instructions continued . . .
Step 4a: Installing Supplies with Optional Soap Dispenser for A/O drain units
NOTE: See Step 4b for units with type B/H drain.
NOTE: For models with optional paper towel dispensers, tie pipe assembly, or shroud, see separate
instruction sheets and Step 4b for units with type B/H drain.
NOTE: Flush the supply lines before making connections.
1. Install the hemmed end (not sharp end) of the support tube (welded seam toward the walls) with the
gasket into the bowl (see Figure 8 on page 10).
2. Using pipe sealant, connect the supply pipe to the sprayhead and place on top of the support tube. Make
sure spray holes point away from the wall.
3a.For Unit with Soap Option:
1. Place the upper tie bar on top of the sprayhead and join the upper and lower tie rod (the longer threaded
rod) with the coupling nut and setscrews (Tie bar must be parallel to wall).
2. Insert the tie rod assembly through the hole in the upper tie bar and secure with the lower tie bar, tie rod
nut and setscrew from below (see Figure 8).
3. Install the spacer, soap dispenser, dispenser cover and restraining bracket and secure with the acorn nut
and socket setscrew.
4. Continue installation with Step 5 on Page 13.
3b.For Unit without Soap Option:
1. Place the dispenser cover on the sprayhead. Thread the acorn nut onto the lower tie rod, run the tie rod
through the dispenser cover and restraining bracket and secure from below with the lower tie bar, tie rod
nut and socket setscrew (see Figure 8).
2. Continue installation with Step 5 on Page 13.

Classic Terrazzo®Corner Washfountain with Foot Control
WF2613 Installation Instructions
Bradley Corporation • 215-609 Rev. J; EN 06-915B
10 4/6/2007
Installation Instructions continued . . .
Operating Rod
(S14-007, Std. Ht.)
(S14-007A, Juv. Ht.)
Lower Tie Bar
(159-009)
Tie Rod Nut
(110-064)
& Set Screws
(160-208)
Gasket
(125-011)
Support Tube
(S57-005, 54") Sprayhead
(S05-054C)
Upper Tie Bar
(159-009A)
(notched at corners)
Soap
Dispenser
Soap Dispenser Lid
TYPE "A" DRAIN
TYPE "O" DRAIN
Acorn Nut (110-052A)
& Set Screw (160-093)
Dispenser Cover
Upper Tie Rod
(176-010)
Spacer
(113-155A) PARTS SHOWN IN
BOX ARE FOR
UNITS WITH SOAP
DISPENSER.
Coupling Nut (110-051D)
Set Screws (160-208)
Lower Tie Rod
(176-008A, 54")
Sprayhead Supply
Pipe (3/8")
(See Figure 10 on page 13
for valving assembly)
HOT
COLD
(Supplies from above)
CORNER RESTRAINING
BRACKET (S70-061E)
(FITS AROUND SUPPORT TUBE)
UPPER TIE BAR
(159-009A)
Figure 8
