Bradley Drench Shower - Horizontal Supply
Model No. E19-120A
Installation Instructions
Pre-Installation Information
Operation
The drench shower is easily activated by pulling the triangular pull rod downward, and
deactivated by pushing the triangular pull rod upward.
Components
Showerhead: The corrosion-resistant stainless steel showerhead has a 254 mm (10”) diameter.
Shower Valve: The 1” IPS stay-open valve is operated by a stainless steel pull rod with a
triangle handle.
Water Supply: Water supply connection is 1” BSP horizontal.
Pipe and Fittings: Pipe and fittings are galvanized steel, coated with BradtectTM safety yellow.
Check Contents
Separate all parts from packaging and check each part with Figure 2 and the Parts List on
page 4. Make sure all parts are accounted for before discarding any packaging material. If any
parts are missing, do not attempt to install your Bradley Drench Shower until you obtain the
missing parts.
Bradley Drench Shower Warranty
Bradley Corporation warrants to commercial and institutional purchasers only each fixture free from defects in
material and workmanship under normal use and service upon the following terms and conditions:
1. We will replace, without charge, any part which proves to be defective within one year from the date of our
invoice at our option, F.O.B. Menomonee Falls, Wisconsin.
2. This warranty does not cover installation or any other labor charge and does not apply to fixtures which have
been damaged by accident, abuse or improper maintenance.
3. The repair or replacement of the defective fixtures as stated in this warranty shall constitute the sole remedy
of the purchaser, and the sole liability of the Bradley Corporation under this warranty. Bradley Corporation
shall not otherwise be liable under any circumstances for incidental, consequential or indirect charges caused
by defects in fixtures or any delay in the repair or replacement thereof.
4. This warranty extends only to commercial and institutional purchases and does not extend to any others,
including consumer, customers of commercial and institutional purchasers.
5. This warranty is in lieu of all other warranties expressed or implied, including any implied warranty of mer-
chants ability or fitness for a particular purpose, or otherwise.
6. Bradley emergency fixtures are to be used as a supplement to first aid treatment. Bradley Corporation cannot
guarantee that when used this emergency equipment will prevent serious injury or the aggravation of existing
or prior injuries. No other warranties, expressed or implied are authorized, provided or guaranteed by
Bradley Corporation.
2
Bradley Corporation l 2%148AE Ref. G; EN 98-579

Installation Instructions
Bradley Drench Shower - Horizontal Supply
Model No. E19-120A
Installation Instructions
Supplies Required:
l Pipe sealant
l Piping to 1” BSP water supply inlet on unit
l Adequate supply pipe supports
l Minimum 102 mm (4”) drain to accommodate 115 liters per minute discharge for drench
shower waste
Step 1: Assemble drench shower
I
NOTE: Flush the water supply line before beginning
installation.
1. Assemble drench shower components as shown
in Figure 2 on page 4.
2. Apply pipe sealant or tape (supplied by installer)
to all male-threaded pipe joints.
NOTE: Use a strap wrench around the pipes when
tightening to prevent mm-ring.
3. The bottom edge of the showerhead should be
2134 mm (7-O”) from the floor.
-J
Step 2: Connect water supply
IMPORTANT: Do not rely on Bradley’s
Drench Shower to support
Figure 1
supply piping.
1. Connect water supply piping to l-1/4”BSP inlet on unit (piping supplied by installer).
Provide adequate supports (supplied by installer) for supply pipe using pipe hangers or
other means.
2. Mount safety sign to wall or pipe using sign mounting hardware supplied.
3. Open water supply lines. Test for leaks and adequate water flow.
Installation Instructions continued.. .
Bradley Corporation l 215148AE Ref. G; EN 98-579
3

Bradley Drench Shower - Horizontal Supply
Model No. EM-120A
Installation Instructions
Assembly of
Figure 2
Comk3onents
1” BSP SUPPLY INLET
I
i
0
4c
IService Parts List
ITEM PART NO.
QTY. DESCRIPTION
ITEM PART NO. QTY. DESCRIPTION
1 S30-059
1 STAYaPEN BALL VALVE 4c180-138
2SCREW
1A 142-002DC
1 LOCKWASHER 4D 153-235
1 ADAPTER
1c S27-278
1
1” BALL VALVE
4E 125-OOlDP 1 WASHER
1D 128-129
1 HANDLE 4F 157-005 4DIFFUSER PADS
1E 140-720
1 STOP BRAcKEl 5* S45-314
1 SIGN-MOUNTING HARDWARE
2 113-005LKE
1 PIPE 1” IPS 812&158A
1 PULL ROD - 809mm LONG
3 189-723
1 90” STREET ELBOW 1’ IPS r 204-421
1 EMERGENCY TAG
4 S24-084E
1 STN. STL SHOWERHEAD ASSY. 8’
114-05OE
1 SAFETY SIGN
4A 187-053
1 SHOWERHEAD SHELL 9153-298
1 BSP ADAPTOR
48 155-008
1 DIFFUSER 10 110-214
1 JAM NUT
l Not Shown
4
