Braun 5302 User manual

5-301-087 Flex 400 - (5441) 23.10.2000 KURTZ DESIGN
Clean&Charge
Type 5302
5-302-450 Korr 22.01.2001
5302450_C&C_S 1 Seite 1 Dienstag, 23. Januar 2001 2:49 14

Deutsch 6, 33, 38
English 8, 33, 38
Français 10, 33, 38
Español 12, 34, 38
Português 14, 34, 38
Italiano 16, 35, 38
Nederlands 18, 35, 38
Dansk 20, 35, 38
Norsk 22, 36, 38
Svenska 24, 36, 38
Suomi 26, 36, 38
Türkçe 28, 38
Ελληνικ 30, 36 , 38
Internet:
www.braun.com
5-302-450/01/Vl-01
D/GB/F/E/P/I/NL/DK/N/S/FIN/TR/GR
Printed in Germany
Braun Infoline
Haben Sie Fragen zu diesem Produkt?
Rufen Sie an: (in Deutschland und
Österreich zum Nulltarif)
00 800 27 28 64 63
00 800 BRAUNINFOLINE
08 44 - 88 40 10
Servicio al consumidor para España:
9 01-11 61 84
Serviço ao Consumidor para Portugal:
080 820 00 33
Servizio consumatori:
(02) 6 67 86 23
Heeft u vragen over dit produkt?
Bel Braun Consumenten-infolijn:
(070) 4 13 16 58
Vous avez des questions sur ce produit?
Appelez Braun Belgique
(02) 711 92 11
Har du spørgsmål om produktet? Så ring
70 15 00 13
Spørsmål om dette produktet? Ring
88 02 55 03
Frågor om apparaten? Ring Kundservice
020 - 21 33 21
Onko Sinulla kysyttävää tuotteesta? Soita
0203 77877
Türkiye’deki Tüketici Danıs¸ ma Servisi:
0 800 261 19 53
D
A
CH
E
P
I
NL
B
DK
N
S
FIN
TR
5302450_C&C_S 2 Seite 1 Montag, 11. Juni 2001 3:29 15

4
A
select
clean
charge
cartridge
1
3
2
8
4
5
6
7
5302450_C&C_S 4 Seite 1 Dienstag, 23. Januar 2001 2:54 14

5
BC
on/off
clean
charge
cartridgee
3
select
select
2
1
select
clean
charge
cartridge
7570
5441
5441
5441
5441
old
new
new
5302450_C&C_S 5 Seite 1 Dienstag, 23. Januar 2001 2:54 14

8
English
Braun Clean&Charge has been developed
for cleaning, charging and storing your
shaver. Clean your shaver daily in the
Clean&Charge.
During the automated cleaning process,
the shaver is switched on and off at intervals
to obtain best cleaning results. Since the
specially formulated cleaning fluid contains a
small amount of oil, the cleaning procedure
also fulfills the lubrication needs of the
shaver.
Important
•
Only use the power supply cord set supplied
with the shaver.
• In order to avoid any leakage of the cleaning
fluid, place the appliance on a flat, stable
surface or use the wall holder (not included
in all versions). Do not tip, move suddenly
or transport in any way if a cleaning cartridge
is installed.
• Do not place the appliance in a mirror cabi-
net, nor store it over radiators, nor place it
on polished or laquered surfaces. Do not
expose to direct sunlight.
• The appliance contains highly
flammable liquid. Keep it away from
sources of ignition. No smoking.
Keep out of reach of children. Do not refill
cartridge. Use only original Braun refill
cartridge.
• When cleaning the shaver, its protection
cap should be removed.
A Description
1 Lift button for cartridge exchange
2 Contact bow
3 Release button
4 Operation mode selector
5 «clean» light:
cleaning process indicator
6 «charge» light:
charging process indicator
7 «cartridge» light:
cartridge replacement indicator
8 Cleaning cartridge
Wall holder
(not included in all versions)
Mount the wall holder with plugs and screws
to a smooth wall so that the standing surface
for the Clean&Charge is horizontal.
Technical specifications
•
Power consumption:
3 W when cleaning
7 W when charging
• Power supply: 100-240 V 2 /50 or 60 Hz
(automatic adaptation)
• Input voltage: 12 V
B Before using Clean&Charge
First charge:
For the first charge of the shaver, connect
the power supply cord set directly to the
shaver, charge it for 4 hours and shave at
least once.
Only then can the shaver be cleaned or
recharged in the Clean&Charge.
If the rechargeable battery is discharged,
select the combined «clean» + «charge»
programme rather than the «clean»
programme alone.
Installing the cartridge
•
Press the lift button (1) to open the housing.
• Hold the cartridge down on a flat, stable
surface (e.g. table). Carefully remove the lid
from the cartridge. Slide the cartridge into the
base as far as it will go.
• Slowly close the housing by pushing it down
until it locks.
Replacing the cartridge
After having pressed the lift button to open
the housing, wait for a few seconds before
removing the used cartridge.
Before discarding the used cartridge, make
sure to close the openings using the lid of the
new cartridge, since the used cartridge will
contain contaminated cleaning solution.
5302450_C&C_S6-44 Seite 8 Montag, 11. Juni 2001 3:41 15

9
C Operating your Clean&Charge
•
Connect your Clean&Charge with the cord
set to the mains electricity supply.
Open the contact bow (2) by pressing the
release button (3). After shaving, switch the
shaver off and place it upside down into the
Clean&Charge. The swivel head must not be
locked (switch «head lock» position down).
• Select the operation mode by toggling with
the mode selector (4):
«clean» (about 15 min)
«clean« + «charge» (about 75 min)
«charge» (about 60 min)
The corresponding lights will come on.
(With cord shavers, only the «clean» function
can be selected.)
• Slide down the contact bow (2) to connect
the shaver and to start the selected
programme.
If no programme is selected, the default
function «clean» will be started.
• Do not interrupt a running programme,
as it leaves the shaver wet and not fit for use.
If interruption is needed nonetheless, press
the release button (3).
• After a programme has finished, the corre-
sponding light will go out. If later on, the
charging light of the shaver comes on again,
this indicates that the shaver is being
recharged to maintain its full capacity.
Prior to the next shave, press the release
button to release the shaver.
• When the «cartridge» light starts flashing,
the remaining fluid in the cartridge is
sufficient for about 5 more cleaning cycles.
After these 5 cycles, the cleaning
performance will be reduced and the
cartridge has to be replaced.
• When the «cartridge» light illuminates
constantly, the cleaning function is locked
and a new cartridge has to be installed.
Only then, the next cleaning cycle can be
started.
• A cleaning cartridge should be sufficient
for about 30 cleaning cycles. With daily use,
the cleaning cartridge should be replaced
approx. every 4 weeks.
• The hygienic cleaning solution cartridge
contains alcohol which, once opened, will
naturally evaporate slowly into the surround-
ing air. Each cartridge, if not used daily,
should be replaced after approx. 8 weeks.
• Do not leave the appliance plugged-in
without the shaver inserted.
• Clean the housing from time to time with a
damp cloth, especially the opening where
the shaver rests.
Subject to change without notice.
This product conforms to the
EMC-Requirements as laid down
by the Council Directive 89/336/EEC
and to the Low Voltage Regulation
(73/23 EEC).
5302450_C&C_S6-44 Seite 9 Montag, 11. Juni 2001 3:41 15

33
Deutsch
Garantie
Als Hersteller übernehmen wir für dieses Gerät –
nach Wahl des Käufers zusätzlich zu den ge-
setzlichen Gewährleistungsansprüchen gegen
den Verkäufer – eine Garantie von 1 Jahr ab
Kaufdatum. Innerhalb dieser Garantiezeit be-
seitigen wir nach unserer Wahl durch Reparatur
oder Austausch des Gerätes unentgeltlich alle
Mängel, die auf Material- oder Herstellungs-
fehlern beruhen. Die Garantie kann in allen
Ländern in Anspruch genommen werden, in
denen dieses Braun Gerät von uns autorisiert
verkauft wird.
Von der Garantie sind ausgenommen: Schäden
durch unsachgemäßen Gebrauch, normaler
Verschleiß und Verbrauch sowie Mängel, die den
Wert oder die Gebrauchstauglichkeit des Gerätes
nur unerheblich beeinflussen. Bei Eingriffen durch
nicht von uns autorisierte Braun
Kundendienstpartner sowie bei Verwendung
anderer als Original Braun Ersatzteile erlischt die
Garantie.
Im Garantiefall senden Sie das Gerät mit
Kaufbeleg bitte an einen autorisierten Braun
Kundendienstpartner. Die Anschrift für
Deutschland können Sie kostenlos unter 0800/
27 28 64 63 erfragen.
English
Guarantee
We grant 1 year guarantee on the product
commencing on the date of purchase. Within the
guarantee period we will eliminate, free of charge,
any defects in the appliance resulting from faults
in materials or workmanship, either by repairing or
replacing the complete appliance as we may
choose.
This guarantee extends to every country where
this appliance is supplied by Braun or its
appointed distributor.
This guarantee does not cover: damage due to
improper use, normal wear or use as well as
defects that have a negligible effect on the value
or operation of the appliance. The guarantee
becomes void if repairs are undertaken by
unauthorised persons and if original Braun parts
are not used.
To obtain service within the guarantee period,
hand in or send the complete appliance with your
sales receipt to an authorised Braun Customer
Service Centre.
For UK only:
This guarantee in no way affects your rights under
statutory law.
Français
Garantie
Garantie
Nous accordons une garantie d’un an sur ce pro-
duit, à partir de la date d’achat.
Pendant la durée de la garantie, Braun prendra
gratuitement à sa charge la réparation des vices
de fabrication ou de matières, en se réservant le
droit de décider si certaines pièces doivent être
réparées ou échangées, ou encore si l’appareil
lui-même doit être échangé.
Les dommages occasionnés par une utilisation
inadéquate ou rangement (branchement sur cou-
rant continu, erreur de voltage, prise inappro-
priée, choc, l’utilisation de détartrants vendus
dans le commerce, le rangement du fer avec une
semelle humide), l’usure normale et les défauts ne
portant préjudice ni au bon fonctionnement ni à la
valeur de l’appareil excluent toute prétention à la
garantie.
La garantie devient caduque si des réparations
ont été effectuées par des personnes non ag-
réées par Braun et si des pièces de rechange ne
provenant pas de Braun ont été utilisées.
La garantie ne sera valable que si, la date d’achat
ainsi que le cachet et la signature du magasin fi-
gurent sur la carte de garantie et la carte de con-
trôle.
Cette garantie est reconnue dans tous les pays où
Braun ou son distributeur exclusif commercialise
l’appareil et où aucune restriction d’importation
ou règlement officiel n’empêchent d’assurer le
service prévu par la garantie.
5302450_C&C_S6-44 Seite 33 Montag, 11. Juni 2001 3:41 15
