BRAYER BR1114 User manual

Instruction manual
Инструкция по эксплуатации
Espresso machine BR1114
Рожковая кофеварка BR1114
brayer.ru

СОДЕРЖАНИЕ
EN......................................................................................................................................3
DE....................................................................................................................................16
RU ...................................................................................................................................32
KZ....................................................................................................................................47

3
EN
ATTENTION!
For additional protection it is reasonable to install a
residual current device (RCD) with nominal operation
current not exceeding 30 mA, to install RCD, contact
a specialist.
EN
ESPRESSO MACHINE BR1114
The co󰀨ee maker is intended for making «espresso»
and «cappuccino» co󰀨ee.
DESCRIPTION
1. Drip tray
2. Drip tray grid
3. Tray lling pop-up indicator
4. Filter holder handle
5. Filter holder
6. Co󰀨ee lter
7. Control panel
8. Cup warming tray
9. Steam supply control knob « »
10. Cappuccinator pipe
11. Cappuccinator pipe tip
12. Espresso machine body
13. Water tank handle
14. Water tank lid
15. Removable water tank
16. Measuring spoon with ground co󰀨ee tamper
Control panel
17. Espresso machine on/o󰀨 button « »
18. One cup button « »
19. Two cups button « »
20. Steam supply on button « »

4
EN
16
15
16
14
9
13
1
4
32
5
6
7
8
10 11 12
17 18 19 20

5
EN
SAFETY MEASURES AND COFFEE MAKER
OPERATION RECOMMENDATIONS
Read the operation instructions carefully before
using the co󰀨ee maker and keep it for future
reference.
• Use the co󰀨ee maker for its intended purpose only,
as specied in this manual.
• Mishandling the co󰀨ee maker can lead to its
breakage and cause harm to the user or damage to
his/her property and it is not covered by warranty.
• The co󰀨ee maker is intended for making espresso
and cappuccino co󰀨ee and warming up ready drinks.
Do not warm any other liquids.
• Make sure that the operating voltage of the co󰀨ee
maker indicated on the label corresponds to your
home mains voltage.
• The power plug is equipped with a grounding contact,
plug it into the socket with reliable grounding contact.
In case of short circuit the grounding reduces the risk
of electric shock.
• Contact an electrical technician, if you are not
sure that your sockets are installed properly and
grounded.
• To prevent re do not use adapters designed for
connecting the power plug to the mains socket
without grounding contact.
• In case of sparking in the mains socket and
occurrence of smell of burning, unplug the unit and
apply to the organization maintaining your home
mains.
• If smoke appears from the unit body, unplug the unit
and take measures to prevent re spreading.
• Use and store the co󰀨ee maker at the temperature
above 0 °C.
• Do not use the co󰀨ee maker outdoors.
• It is not recommended to use the unit during lightning
storms.
• Protect the unit from impacts, falling, vibrations and
other mechanical stress.
• Never leave the plugged-in co󰀨ee maker unattended.
• To avoid re, electric shock or physical injuries, do
not immerse the power plug, the power cord or the
co󰀨ee maker body into water or any other liquids.
• Do not use the co󰀨ee maker in proximity to the
kitchen sink, in bathrooms, near swimming pools or
other containers lled with water.
• If the unit is dropped into water, unplug it
immediately, and only then you can take the unit out
of water. Apply to the service center for testing or
repairing the unit.
• Do not use the co󰀨ee maker near heating appliances,
heat sources or open ame.
• Do not use the unit in places where aerosols are
used or sprayed, and in proximity to inammable
liquids.
• Place the co󰀨ee maker on a at stable surface; do
not place it on the edge of a table. Do not let the

6
EN
power cord hang from the edge of the table and
make sure it does not touch hot surfaces or sharp
edges of furniture.
• Do not place the co󰀨ee maker on hot surfaces.
• Do not touch the power cord and the power plug with
wet hands.
• Use only the co󰀨ee maker parts and accessories
supplied with the unit.
• Before switching the co󰀨ee maker on, make sure that
all removable parts are installed properly.
• Ensure that the water level in the water tank is not
below the minimal mark.
• Do not switch the co󰀨ee maker on if the water tank
is empty.
• To avoid getting burns by hot steam be careful when
frothing milk or warming the ready drinks.
• The lter holder surface, the cappuccinator pipe and
the cappuccinator tip can get rather hot. Be cautious
and careful when in contact with hot surfaces.
• Do not remove the lter holder during co󰀨ee maker
operation.
• Let the unit cool down completely before cleaning
and removing the accessories.
• Unplug the co󰀨ee maker before cleaning or when you
are not using it. When unplugging the co󰀨ee maker
hold only the power cord plug and carefully remove it
from the mains socket, do not pull the power cord —
this can lead to damage of the power cord or the
socket or cause short circuit.
• For children safety reasons do not leave polyethylene
bags, used as a packaging, unattended.
ATTENTION!
Do not allow children to play with polyethylene bags
or packaging lm. Danger of su󰀨ocation!
• The co󰀨ee maker is not intended for usage by
children.
• Do not leave children unattended to prevent using
the unit as a toy.
• Do not allow children to touch the unit and the power
cord during the co󰀨ee maker operation.
• Place the unit out of reach of children during the
operation and cooling down.
• This unit is not intended for usage by physically or
mentally disabled persons (including children) or by
persons lacking experience or knowledge if they are
not under supervision of a person who is responsible
for their safety or if they are not instructed by this
person on the usage of the unit.
• From time to time check the power cord and the
power plug integrity.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or
similar qualied personnel to avoid danger.
• Do not repair the unit by yourself. Do not
disassemble the unit by yourself, if any malfunction
is detected, and after it was dropped, unplug the unit
and apply to the service center.

7
EN
• Transport the co󰀨ee maker in the original package.
• Keep the unit out of reach of children and disabled
• persons.
COFFEE MAKER IS INTENDED FOR HOUSEHOLD
USE ONLY, DO NOT USE THE COFFEE MAKER FOR
COMMERCIAL OR LABORATORY PURPOSES.
BEFORE USING THE COFFEE MAKER
After unit transportation or storage at low
temperature, it is necessary to keep it for at least
three hours at room temperature.
• Unpack the co󰀨ee maker and remove all the
packaging materials.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the co󰀨ee maker for damages, in case of
damage do not plug it into the mains.
• Make sure that the specications of power supply
voltage specied on the lower panel of the unit
correspond to the specications of your mains.
• Wipe the co󰀨ee maker body (12) surface with a
clean, slightly damp cloth to remove dust, wipe the
co󰀨ee maker body (12) dry.
• Make sure that the steam supply is closed. To do this
turn the knob (9) « » clockwise until bumping
«•».
• Before using the espresso machine for the rst time,
wash all removable parts (1, 2, 5, 6, 15, 16) with
warm water and neutral detergent, rinse and dry
them.
• Remove the water tank (15), ll it with cold water up
to the MAX mark and install it back to its place.
Notes:
- to ll the water tank (15) with water you can open
the lid (14) and pour water into the tank (15).
-to carry the water tank (15), take it by the handle
(13).
• Insert any co󰀨ee lter (6) into the holder (5) (do not
add ground co󰀨ee into the lter).
• Install the lter holder (5) into the co󰀨ee maker. The
holder (5) ledges should match the grooves on the
boiler «INSERT», after that turn the lter holder
handle (4) to the right until bumping «LOCK».
• Place a suitable cup on the grid (2).
• Insert the power plug into the mains socket.
• Switch the co󰀨ee maker on by pressing the on/o󰀨
button (17) « », the button (17) illumination will
light up, when the buttons (18, 19, 20) illumination
will light up, this means that preheating is completed.
Notes:
- the rst switching on of the pump may be
accompanied by an uncharacteristic sound, this
is a normal. After lling the boiler with water, the
sound of the pump will return to normal.

8
EN
• Wait until the buttons (18, 19, 20) illumination lights up,
then switch the water supply on by pressing the button
(19) « », the pump will switch on for 30 seconds,
drain the water from the cup and again press the button
(19) « » to switch the water supply on again. After
switching the pump o󰀨, drain the water from the cup.
• Repeat this procedure several times, the boiler will be
clean after that.
• To switch the espresso machine o󰀨, press the on/
o󰀨 button (17) « », the buttons (17, 18, 19, 20)
illumination will go out.
ATTENTION!
• Do not remove the lter holder (5) during espresso
machine operation.
• Do not remove the lter holder (5) immediately after
preparing co󰀨ee as there is redundant water and steam
pressure inside the lter (5), let the co󰀨ee maker cool
down completely.
• To remove the lter holder (5) turn the handle (4) to the
left «INSERT» and remove the lter holder (5).
AUTO SWITCH OFF FUNCTION
• If no actions were performed during 25 minutes
after switching on, the co󰀨ee maker will switch o󰀨
automatically.
HOW TO MAKE A GOOD ESPRESSO
• Use ground co󰀨ee for espresso co󰀨ee makers.
• Slightly tamp the ground co󰀨ee in the lter (6), you
can do it with the back side of the measuring spoon
(17).
• Co󰀨ee strength depends on the quality and grinding
degree of co󰀨ee beans. If co󰀨ee is pouring out too
long, this means the co󰀨ee powder is too ne or it is
tamped too strongly.
PREHEATING
• To make a cup of hot espresso, it is recommended to
preliminary heat up the co󰀨ee lter (6) and the lter
holder (5).
• Open the lid (14) and ll the tank (15) with water, or
remove the tank (15) and ll it with water, then install
the tank (15) back to its place.
• Insert one of the co󰀨ee lters (6) into the holder (5).
Notes:
- use the small lter (6) to make one cup of co󰀨ee
and press one cup button (18) « »;
- use the big lter (6) to make two cups of co󰀨ee
and press two cups button (19) « ».
• Install the lter holder (5) into the co󰀨ee maker. The
holder (5) ledges should match the grooves on the
boiler «INSERT », after that turn the lter holder
handle (4) to the right until bumping «LOCK».
• Place a suitable cup on the grid (2).
• Insert the power plug into the mains socket.
• Switch the co󰀨ee maker on by pressing the on/o󰀨
button (17) « », the button (17) illumination will

9
EN
light up, when the buttons (18, 19, 20) illumination
lights up, it means preheating is completed.
• Switch the water supply on by pressing the button
(19) « », the pump will switch on for 30 seconds
and hot water will be poured into the cup. After
switching the pump o󰀨, pour the water out from the
cup.Preheating is over.
MAKING ESPRESSO
ATTENTION! When making co󰀨ee do not leave the
operating co󰀨ee maker unattended, as it is necessary to
watch the cup being lled with ready co󰀨ee!
AFTER PREHEATING:
• Make sure that the steam supply is closed. To do this
turn the knob (9) « » clockwise until bumping
«•».
• Remove the lter holder (5) by turning the handle (4)
to the left «INSERT» and remove the lter holder (5).
• Put ground co󰀨ee in the small or large lter (6),
slightly tamp the ground co󰀨ee with the back side of
the measuring spoon (16).
• Install the lter holder (5) into the co󰀨ee maker. The
holder (5) ledges should match the grooves on the
boiler «INSERT», after that turn the lter holder
handle (4) to the right until bumping «LOCK».
• Wait until the buttons (18, 19, 20) illumination lights
up, the co󰀨ee maker is ready for making co󰀨ee.
• If you use a small lter (6), switch the water supply
on by pressing the button (18) « » to prepare one
cup of co󰀨ee, the pump will switch on and work for 15
seconds, the pump operation time of 15 seconds is set
by default.
• To prepare two cups of co󰀨ee, use a large lter (6) and
press the button (19) « », the pump will switch on
and work for 30 seconds, the pump operation time of 30
seconds is set by default.
Note: - watch the cup lling with the ready co󰀨ee, if you
need t switch the water supply o󰀨, press again the button
(18) « » or the button (19) « ».
• Switch the espresso machine o󰀨 by pressing the on/
o󰀨 button (17) « », the buttons (17, 18, 19, 20)
illumination will go out.
• Wait until the co󰀨ee maker cools down and remove
the lter holder (5) by turning the handle (4) to the left
«INSERT». Remove the ground co󰀨ee remnants and
wash the lter (6).
• For easy removing of the co󰀨ee remnants use the
retainer on the handle (4) to prevent the lter (6) from
falling o󰀨 the holder (5).
• Notes:
-the cups should be preliminary heated up, when
water heats up in the boiler, put the cups on the tray
(8).
- if you need to promptly remove the lter holder (5),
you have to reduce the pressure in the boiler, switch
the co󰀨ee maker o󰀨 by pressing the on/o󰀨 button
(17) « », place a suitable cup under the tip
(11) and slightly open the steam supply by turning
the knob (9) « » counterclockwise. After the

10
EN
pressure in the boiler is released, you can remove
the lter holder (5).
ESPRESSO PORTION SETTING
-To enter the programming mode, press and hold
the one cup button (18) « » for 3 seconds, the
button (18) « » illumination will be ashing.
Press the button (18) « » again. After the
required amount of ready co󰀨ee is poured into the
cup, press the button (18) « » again to nish
setting. Maximum time of water supply for making
one cup of co󰀨ee is 45 seconds.
-To enter the programming mode, press and hold
the two cups button (19) « » for 3 seconds,
the button (19) « » illumination will be
ashing. Press the button (19) « » again. After
the required amount of ready co󰀨ee is poured into
the cup, press the button (19) « » again to
nish setting. Maximum time of water supply for
making two cups of co󰀨ee is 90 seconds.
Notes:
- if you have programmed the water supply time
for making one cup of co󰀨ee, then the water
supply time for making two cups of co󰀨ee will be
automatically set doubled;
- water supply time for two cups of co󰀨ee can be set
up to 90 seconds. If the water supply time for two
cups of co󰀨ee was set, then the water supply time
for making one cup of co󰀨ee will be automatically
set as half the time for making two cups of co󰀨ee.
RETURN TO THE FACTORY SETTINGS
• Switch the co󰀨ee maker on and wait for preheating, the
button (18, 19, 20) indicators will light up.
• After the preheating is nished, press and hold
simultaneously the buttons (20) « » and (19) «
» for 3 seconds, the buttons (19 and 20) illumination will
ash 3 times, and the espresso machine will return to the
factory settings.
• Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨 button
(17) « », the buttons (17, 18, 19, 20) illumination will
go out.
• Switch the co󰀨ee maker on by pressing the on/o󰀨 button
(17) « », the settings will return to default.
MAKING CAPPUCCINO
ATTENTION!
Be careful to avoid burns by the released hot steam.
• Make co󰀨ee, as described in the chapter «MAKING
ESPRESSO», in a cup with enough capacity to add
frothed milk.
• Make sure that the steam control knob (9) « » is in
the position «the steam supply is o󰀨 «•».
• Press the steam supply button (19) « » and wait until
the button (20) « » illumination glows constantly. Place
any suitable bowl under the tip (11) for water. Carefully
turn the steam supply knob (9) « » counterclockwise
for a quarter of a turn to remove the condensed uid from
the cappuccinator pipe (10).

11
EN
• Making the milk foam is an art. You may not make it at
the rst try, don’t worry and experiment until you achieve
good results.
• When frothing milk you can remove the tip (11) and try
to froth milk directly with the steam releasing from the
cappuccinator pipe (10).
• Close the steam supply by turning the knob (9) « »
clockwise until bumping «•».
• Add frothed milk to the ready espresso, and the
cappuccino is ready. Add sugar to your taste, you can
decorate frothed milk with cocoa powder.
• Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨 button
(17) « », the buttons (17, 18, 19, 20) illumination
will go out.
IMPORTANT:
- It is important that milk for making frothed milk is fresh
and without additives.
- Take usual whole milk with fat status from 4% to 6%,
cream fat status is not less than 10%.
- Clean the cappuccinator pipe tip (11) right after milk
or cream frothing — to do this put the cappuccinator
pipe tip (11) into a glass of water and switch the steam
supply on by pressing the button (9), turn the steam
supply knob (9) « » counterclockwise to release
some steam. After that close the steam supply by
turning the knob (9) « » clockwise until bumping
«•». Switch the steam supply o󰀨 by pressing the
steam supply button (9) and switch the co󰀨ee maker
o󰀨.
• After removing the condensed uid close the steam
supply by turning the knob (9) « » clockwise until
bumping «•».
Note: some water or steam may appear from the lter
holder (5), it is normal.
• Put the cappuccinator pipe tip (11) into a glass with
cold milk or cream, the amount of milk or cream
should be about 100 ml. Carefully turn the steam
supply control knob (9) « » counterclockwise for a
quarter of a turn or more. The tip (11) should not touch
the bottom of the glass, as this can hinder the steam
release; you can make thick frothed milk in several
seconds.
Note:
-to avoid splashing milk always immerse the tip (12)
deeper than 1 cm from the milk surface.
-to avoid splashing milk or cream, do not open the
steam supply with a sharp turn of the knob (9) «
», always turn the knob (9) « » carefully.
- when selecting a cup for milk or cream, keep in mind
that the frothed milk amount increases approximately
twice;
-during the operation in the steam supply mode
the button (20) « » illumination will be ashing
and glowing constantly; it means that the water
temperature in the boiler is maintained within the set
limits;
• The outgoing steam creates whirls which froths milk;
from time to time lift and lower the bowl with milk
against the tip (11) to make the milk foam.

12
EN
- Wait until the co󰀨ee maker cools down and remove
the tip (11) from the cappuccinator pipe (10), wipe
the outer side of the cappuccinator pipe (10) with a
soft damp cloth and wash the tip (11) under a water
jet.
Note: after frothing milk, if you press the water supply
button (18) « » or the button (20) « », and
the button (18) « », (20) « » and (19) «
» illumination will be ashing quickly, the pump will
not switch on, because the water temperature in the
boiler is high. To decrease the water temperature,
place a cup under the tip (11), turn the knob (9) « »
counterclockwise and drain hot water. When the buttons
(18, 19, 20) illumination glows constantly, the pump will
stop operating, turn the knob (9) « » to the position
«•». After that you can continue making co󰀨ee.
HOT WATER AND ITS USAGE
• You can use hot water for warming the cups before
making co󰀨ee or, for instance, for brewing tea.
• Drain hot water to decrease the boiler temperature after
frothing the milk.
• Switch the co󰀨ee maker on and wait for the co󰀨ee
maker to preheat, the buttons (18, 19, 20) illumination
will light up.
• Place a cup under the tip (11), carefully turn the steam
supply control knob (9) « » counterclockwise a
quarter of a turn or more, switch the water supply on
by pressing the button (19) « », hot water will ow
into the cup.
• Switch the water supply o󰀨 by pressing the button (19) «
», turn the steam supply control knob (9) « »
clockwise to the position «•» to stop the hot water supply.
Notes:
- if you need to stop the water supply, press the button
(19) « » again;
-you can set up the pump operation time (see the
chapter «ESPRESSO PORTION SETTING»).
WARMING THE DRINKS
You can warm up your drinks by putting the cappuccinator
pipe (10) without the tip (11) into the cup with the drink.
• Switch the co󰀨ee maker on and wait for the co󰀨ee maker
to preheat, the buttons (18, 19, 20) illumination will light
up.
• Press the steam supply button (20) « ».
• Put the cappuccinator pipe (10) without the tip (11) into
the cup with the drink you want to warm up. Carefully
turn the steam supply control knob (9) « »
counterclockwise.
• Close the steam supply by turning the knob (15) «
» clockwise until bumping «•».
• Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨 button
(17) « », the buttons (17, 18, 19, 20) illumination
will go out.
Note: some water or steam may appear from the lter
holder (5), it is normal.

13
EN
REMOVING MINERAL SCALE
For e󰀨ective operation of the co󰀨ee maker we recommend
removing scale every 2-3 months and when using »hard”
water more often.
1. Make sure that the power plug is not inserted into the
mains socket.
2. Make sure that the steam supply is closed. To do this
turn the knob (9) « » clockwise until bumping
«•».
3. Make citric acid solution: 2 teaspoons of acid to 1
litre of water and pour the solution into the water tank
(15). Install the tank (15) back to its place.
4. Insert one of the co󰀨ee lters (6) into the holder (5).
Do not put ground co󰀨ee into the lter (6).
5. Install the lter holder (5) into the co󰀨ee maker. The
holder (5) ledges should match the grooves on the
boiler «INSERT», after that turn the lter holder
handle (4) to the right until bumping «LOCK».
6. Place a suitable cup on the grid (2).
7. Insert the power plug into the mains socket.
8. Switch the co󰀨ee maker on by pressing the on/o󰀨
button (17) « », the button (17) illumination will
light up, when the buttons (18, 19, 20) illumination
lights up, it means preheating is completed.
9. Press the button (19) « », depending on the
preset water supply time, press the button (19) «
» once or twice, ll a cup of approximately 100 ml
capacity with water (it is necessary to remove water
from the boiler and ll it with citric acid solution), if
necessary, switch the water supply o󰀨 by pressing the
button (19) « » again. Pour the liquid out from the
cup.
10. Switch the water supply on by pressing the button (19)
«» and ll a cup of about 100 ml capacity, press
the button (19) « » again to switch the water supply
o󰀨 and pour the liquid out of the cup.
11. After a while repeat the procedure described in the
paragraph 10 and ll the cup of about 100 ml capacity
again.
12. Press the steam supply button (20) « ». Put a
suitable bowl under the tip (11) and slightly open
the steam supply by turning the knob (9) « »
counterclockwise. Carefully turn the knob (9) « »
to the maximal steam release position, release the
steam for about 1 minute, then close the steam by
turning the knob (9) « » clockwise until bumping
«•».
13. Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨
button (17) « »,. Wait for 10-15 minutes.
14. Perform the steps 10 and 11 at least 3 times.
15. Repeat the cleaning procedure for the steam release
channels described in the paragraph 12.
16. With small intervals, repeat the boiler cleaning
procedure (paragraph 10) until the citric acid solution
dissolves in the tank (20) completely.
17. Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨
button (17) « ».

14
EN
• If necessary, wash the tray (1) and the grid (2) with
water and soft detergent, rinse and dry.
STORAGE
• Before taking the co󰀨ee maker away for long storage,
unplug it and let the unit cool down.
• Clean the co󰀨ee maker.
• Pack the co󰀨ee maker in the original package.
• Use and store the co󰀨ee maker at the temperature
above 0 °C.
• Keep the co󰀨ee maker in a dry cool place out of reach
of children and disabled persons.
TROUBLESHOOTING
Problem Cause Solution
Water leaks from
the bottom of the
co󰀨ee maker
The tray is full of
water. Please, clean the tray.
The co󰀨ee
maker is
damaged.
Please, apply to the service
center for repairing the
co󰀨ee maker.
Water leaks from
the lter holder.
There is ground
co󰀨ee on the
lter.
Clean the lter edges from
ground co󰀨ee.
Ready co󰀨ee
has unpleasant
taste.
The co󰀨ee
maker was not
washed after
descaling.
Clean the co󰀨ee maker
from mineral scale and
wash it from the remaining
descaling agent.
Ground co󰀨ee
was stored in a
humid place for
a long time.
Please, use fresh ground
co󰀨ee. Keep unused
ground co󰀨ee in a hermetic
package in a dry cool place.
18. Fill the water tank (15) with clear water until maximal
level and repeat the steps 10, 12 at least 3 times
without the 10-15 minute break.
19. Switch the co󰀨ee maker o󰀨 by pressing the on/o󰀨
button (17) « », the buttons (17, 18, 19, 20)
illumination will go out.
Note: to remove the scale you can use special descaling
agents for co󰀨ee makers and co󰀨ee machines, strictly
following the instructions on their usage.
CLEANING THE COFFEE MAKER
• If there is ground co󰀨ee scale remainin in the lter (6)
openings, clean the lter (6) with a small brush.
• Wipe the co󰀨ee maker body with a soft, slightly damp
cloth and then wipe the co󰀨ee maker body (12) dry.
Do not use abrasives and solvents to clean the co󰀨ee
maker body.
• Do not immerse the co󰀨ee maker body (12), the power
cord and the power plug into water or any other liquids.
• Wash the removable parts of the co󰀨ee maker with
warm water and neutral detergent, then rinse them and
dry.
DRIP TRAY
• A red pop-up indicator (3) in the grid (2) will show when
the tray (1) is full.
• Remove the grid (2) from the tray (1), remove the tray
(1) and pour out water, install the tray back to its place,
put the grid (2) on the tray (1).

15
EN
RECYCLING
To prevent possible damage to the
environment or harm to the health of people
by uncontrolled waste disposal, after
expiration of the service life of the unit or
the batteries (if included), do not discard
them with usual household waste, take the
unit and the batteries to specialized stations for further
recycling.
The waste generated during the disposal of products
is subject to mandatory collection and consequent
disposal in the prescribed manner.
For further information about recycling of this product
apply to a local municipal administration, a household
waste disposal service or to the shop where you
purchased this product.
The unit cannot
be switched on
No voltage in the
mains socket.
The power plug
is not completely
inserted into the
socket.
Make sure that the mains
socket is properly operating.
Check whether the power
plug is completely inserted
into the socket.
Steam doesn’t
froth milk
The steam ready
indicator is
ashing.
You can use steam to froth
milk only after the indicator
starts glowing white.
The used cup
does not suit
for proper milk
frothing.
Use a tall and narrow cup.
You used
skimmed milk.
Use only whole milk with fat
content 4-6%.
DELIVERY SET
• Co󰀨ee maker — 1 pc.
• Co󰀨ee lters – 2 pcs.
• Measuring spoon — 1 pc.
• Manual — 1 pc.
TECHNICAL SPECIFICATIONS
• Power supply 220-240 V, ~ 50 Hz
• Rated input power: 1100 W
• Water tank capacity: 1,5 l
The manufacturer reserves the right to change the
design, structure and specications not a󰀨ecting
general operation principles of the unit, without prior
notice.
The unit operating life is 3 years
The manufacturing date is specied in the serial
number.
In case of any malfunctions, it is necessary to apply
promptly to the authorized service center.
Bei Störungsfeststellung wenden Sie sich baldigst an
einen autorisierten Kundendienst.

16
DE
ACHTUNG!
Als zusätzlicher Schutz ist es zweckmäßig, den
FI-Schalter mit Nennstrom maximal bis 30 mA im
Stromversorgungskreis aufzustellen; wenden Sie sich
dafür an einen Spezialisten.
DE
ESPRESSOKAFFEEMASCHINE
BR1114
Die Ka󰀨eemaschine ist für die Zubereitung von
Espresso und Cappuccino bestimmt.
BESCHREIBUNG
1. Tropfschale
2. Gitter der Tropfschale
3. Popup-Anzeige der Tropfschalenau󰀨üllung
4. Gri󰀨 des Filterhalters
5. Filterhalter
6. Ka󰀨eelter
7. Bedienungsplatte
8. Tassenaufheizplatte
9. Gri󰀨 des Dampfreglers « »
10. Cappuccinatore-Rohr
11. Endstück des Cappuccinatore-Rohrs
12. Ka󰀨eemaschinengehäuse
13. Gri󰀨 des Wasserbehälters
14. Deckel des Wasserbehälters
15. Abnehmbarer Wasserbehälter
16. Messlö󰀨el mit Mahlka󰀨eepresse
Bedienungsplatte
17. Ein-/Ausschalttaste der Ka󰀨eemaschine « »
18. Taste für eine Tasse Ka󰀨ee « »
19. Taste für zwei Tassen Ka󰀨ee « »
20. Dampfzufuhrtaste « »

17
DE
16
15
16
14
9
13
1
4
32
5
6
7
8
10 11 12
17 18 19 20

18
DE
SICHERHEITSHINWEISEUNDBEDIENUNGS-
ANLEITUNG FÜR DIE KAFFEEMASCHINE
Bevor Sie die Ka󰀨eemaschine benutzen, lesen Sie
die Bedienungsanleitung aufmerksam durch und
bewahren Sie sie zum späteren Gebrauch auf.
• Benutzen Sie die Ka󰀨eemaschine nur bestimmungs-
mäßig und laut dieser Bedienungsanleitung.
• Der Missbrauch der Ka󰀨eemaschine kann zu ihrer
Störung führen, den Benutzer oder sein Eigentum
beschädigen und ist kein Garantiefall.
• Die Ka󰀨eemaschine ist zum Zubereiten von Espres-
so und Cappuccino, zum Aufheizen von Fertiggeträn-
ken und zu keinem Erhitzen anderer Flüssigkeiten
bestimmt.
• Vergewissern Sie sich, dass die auf dem Bezeich-
nungszettel angegebene Betriebsspannung der Kaf-
feemaschine und die Netzspannung übereinstimmen.
• Der Netzstecker hat einen Erdungskontakt; stecken
Sie ihn nur in eine Steckdose mit dem zuverlässigen
Erdungskontakt. Bei einem Kurzschluss verringert
die Erdung das Stromschlagrisiko.
• Wenden Sie sich an einen Elektriker, wenn Sie sich
nicht sicher sind, ob Ihre Steckdosen richtig installiert
und geerdet sind.
• Verwenden Sie keine Adapterstecker, die zum An-
schließen des Netzsteckers an eine Steckdose ohne
Erdungskontakt bestimmt sind, um das Brandrisiko
zu vermeiden.
• Bei Brandgeruch und Funken in der Steckdose zie-
hen Sie den Netzstecker aus der Steckdose heraus
und wenden Sie sich an den Ihr Hausstromnetz
leistenden Dienst.
• Wenn Rauch aus dem Gerätegehäuse austritt,
ziehen Sie das Netzkabel aus der Steckdose heraus
und tre󰀨en Sie die Feuerverhinderungsmaßnahmen.
• Benutzen und lagern Sie die Ka󰀨eemaschine bei
einer Temperatur über 0°C.
• Es ist nicht gestattet, die Ka󰀨eemaschine draußen
zu benutzen.
• Es ist nicht empfohlen, das Gerät bei Gewitter zu
benutzen.
• Schützen Sie das Gerät vor Stößen, Stürzen, Vibrati-
onen und anderen mechanischen Einwirkungen.
• Lassen Sie die ans Stromnetz angeschlossene
Ka󰀨eemaschine nie unbeaufsichtigt.
• Um Brand, Stromschlag oder Verletzungen zu ver-
meiden, tauchen Sie den Netzstecker, das Netzkabel
oder das Gehäuse der Ka󰀨eemaschine ins Wasser
oder jegliche andere Flüssigkeiten nicht ein.
• Benutzen Sie die Ka󰀨eemaschine in der Nähe
von Spülbecken, in Badezimmern und neben den
Wasserbecken oder anderen mit Wasser gefüllten
Behältern nicht.
• Falls das Gerät ins Wasser gefallen ist, ziehen Sie
den Netzstecker aus der Steckdose sofort heraus,
erst danach holen Sie das Gerät aus dem Wasser
heraus. Wenden Sie sich an einen autorisierten

19
DE
Kundendienst, um das Gerät prüfen oder reparieren
zu lassen.
• Benutzen Sie die Ka󰀨eemaschine in direkter Nähe
von Heizgeräten, Wärmequellen oder o󰀨enem Feuer
nicht.
• Es ist verboten, das Gerät an den Orten, wo Sprays
verwendet werden, sowie in der Nähe von leichtent-
zündbaren Flüssigkeiten, zu benutzen.
• Stellen Sie die Ka󰀨eemaschine auf eine ebene
standfeste Oberäche auf, stellen Sie sie an den
Tischrand nicht auf. Achten Sie darauf, dass das
Netzkabel vom Tisch nicht herabhängt und heiße
Oberächen und scharfe Möbelkanten nicht berührt.
• Es ist nicht gestattet, die Ka󰀨eemaschine auf heiße
Oberächen zu stellen.
• Berühren Sie das Netzkabel und den Netzstecker mit
nassen Händen nicht.
• Benutzen Sie nur die mitgelieferten Ka󰀨eemaschi-
nenteile und -zubehör.
• Vergewissern Sie sich vor der Einschaltung der Kaf-
feemaschine, dass alle abnehmbaren Teile korrekt
aufgestellt sind.
• Achten Sie darauf, dass der Wasserstand im Behäl-
ter nicht unter der Minimalmarke liegt.
• Schalten Sie die Ka󰀨eemaschine ohne Wasser nicht
ein.
• Seien Sie beim Zubereiten von Milchschaum oder
beim Erhitzen von Fertiggetränken vorsichtig, um
Verbrühung durch heißen Dampf zu vermeiden.
• Die Oberäche des Filterhalters, des Cappuccinato-
re-Rohres und des Cappuccinatore- Aufsatzes kann
ziemlich heiß sein. • Seinen Sie beim Kontakt mit
heißen Oberächen vorsichtig und sorgfältig.
• Es ist nicht gestattet, den Filterhalter während des
Betriebs der Ka󰀨eemaschine abzunehmen.
• Lassen Sie das Gerät vollständig abkühlen, bevor
Sie das Zubehör entfernen und reinigen.
• Trennen Sie die Ka󰀨eemaschine vor der Reinigung
oder wenn Sie sie nicht benutzen vom Stromnetz
ab. Wenn Sie die Ka󰀨eemaschine vom Stromnetz
abtrennen, halten Sie nur den Netzstecker fest und
ziehen Sie ihn aus der Steckdose vorsichtig heraus;
ziehen Sie das Netzkabel nicht, da es zu seiner
Beschädigung und Steckdosenstörung sowie einem
Kurzschluss führen kann.
• Aus Kindersicherheitsgründen lassen Sie Plastiktü-
ten, die als Verpackung verwendet werden, nie ohne
Aufsicht.
ACHTUNG!
Lassen Sie Kinder mit Plastiktüten oder Verpa-
ckungsfolien nicht spielen. Erstickungsgefahr!
• Die Ka󰀨eemaschine ist nicht für Kinder bestimmt.
• Beaufsichtigen Sie Kinder, damit sie das Gerät als
Spielzeug nicht benutzen.
• Lassen Sie Kinder das Gerät und das Netzkabel
während des Ka󰀨eemaschinenbetriebs nicht berüh-
ren.

20
DE
• Während des Betriebs und des Abkühlens stellen
Sie das Gerät an einen für Kinder unzugänglichen
Ort auf.
• Dieses Gerät ist für Personen (darunter Kinder) mit
Körper-, Nerven- und Geistesstörungen oder Perso-
nen ohne ausreichende Erfahrung und Kenntnisse
nicht geeignet, wenn sie sich unter Aufsicht der
Person, die für ihre Sicherheit verantwortlich ist, nicht
benden oder entsprechende Anweisungen über die
Nutzung des Geräts nicht bekommen haben.
• Überprüfen Sie regelmäßig den Zustand des Netzka-
bels und des Netzsteckers.
• Wenn das Netzkabel beschädigt ist, soll es vom
Hersteller, vom Kundendienst oder von ähnlich
qualiziertem Personal ersetzt werden, um Gefahren
zu vermeiden.
• Es ist nicht gestattet, das Gerät selbständig zu repa-
rieren. Es ist nicht gestattet, das Gerät selbständig
auseinanderzunehmen; bei der Feststellung jeglicher
Beschädigungen, sowie im Sturzfall, trennen Sie das
Gerät vom Stromnetz ab und wenden Sie sich an
einen Kundendienst.
• Transportieren Sie die Ka󰀨eemaschine nur in der
Fabrikverpackung.
• Bewahren Sie das Gerät an einem für Kinder und
behinderte Personen unzugänglichen Ort auf.
DIE KAFFEEMASCHINE IST NUR FÜR DEN GE-
BRAUCH IM HAUSHALT GEEIGNET, ES IST VERBO-
TEN, SIE ZU INDUSTRIE- ODER LABORZWECKEN
ZU BENUTZEN.
VORBEREITUNG DER KAFFEEMASCHINE
ZUR INBETRIEBNAHME
Nachdem Sie das Gerät bei niedriger Temperatur
transportiert oder gelagert haben, müssen Sie es
mindestens drei Stunden bei Raumtemperatur
aufbewahren.
• Packen Sie die Ka󰀨eemaschine aus und entfernen
Sie alle Verpackungsmaterialien.
• Bewahren Sie die Originalverpackung auf.
• Lesen Sie die Sicherheitsmaßnahmen und Bedie-
nungsempfehlungen.
• Prüfen Sie die Komplettheit.
• Prüfen Sie die Ka󰀨eemaschine auf Beschädigun-
gen; wenn sie beschädigt ist, schließen Sie sie ans
Stromnetz nicht an.
• Vergewissern Sie sich, dass die Stromversor-
gungsparameter auf der Geräteunterplatte und die
Netzstromparameter übereinstimmen.
• Wischen Sie die Gehäuseoberäche (12) der
Ka󰀨eemaschine mit einem sauberen, leicht feuchten
Staubabsaugtuch ab und wischen Sie das Gehäuse
(12) der Ka󰀨eemaschine trocken.
• Vergewissern Sie sich, dass die Dampfzufuhr ge-
schlossen ist, drehen Sie dafür den Gri󰀨 (9) « »
im Uhrzeigersinn bis zum Anschlag «•» um.
• Vor dem ersten Gebrauch der Ka󰀨eemaschine wa-
schen Sie alle abnehmbaren Teile (1, 2, 5, 6, 15, 16)
mit Warmwasser und einem neutralen Reinigungs-
mittel, spülen und trocknen Sie sie ab.
