BRAYER BR1108 User manual

Instruction manual
Инструкция по эксплуатации
Espresso machine BR1108
Рожковая кофеварка BR1108
brayer.ru

СОДЕРЖАНИЕ
EN......................................................................................................................................3
DE....................................................................................................................................20
RU ...................................................................................................................................38
KZ....................................................................................................................................56

3
EN
ATTENTION!
For additional protection it is reasonable to install a
residual current device (RCD) with nominal operation
current not exceeding 30 mA, to install RCD, contact
a specialist.
EN
ESPRESSO MACHINE BR1108
The co󰀨ee maker is designed for brewing espresso
co󰀨ee, making cappuccino co󰀨ee or latte co󰀨ee.
DESCRIPTION
1. Removable tray
2. Removable tray grid
3. Pullout tray for small cups
4. Filter holder handle
5. Thermometer
6. Cup warming tray
7. «Espresso»-button for making espresso
8. Cappuccino button «Cappuccino»
9. Latte button «Latte»
10. Cappuccinator
11. Power switch «0/I»
12. Water tank lid
13. Removable water tank
14. Cappuccinator pipe angle adjustment bar
15. Cappuccinator pipe
16. Upper lid of the cappuccinator
17. Milk/frothed milk supply control knob
18. Removable milk container
19. Filter retainer
20. Filter holder
21. Small lter
22. Large co󰀨ee lter
23. Measuring spoon

4
EN
1
211
3
4
5
12
613
16
15
17
18
14
19 20 21 22 23
10
9
8
7

5
EN
Рiс. 1 Рiс. 3
Рiс. 7
Рiс. 11
Рiс. 5
Рiс. 9 Рiс. 10
Рiс. 2
Рiс. 6
Рiс. 4
Рiс. 8
Рiс. 12 Рiс. 13 Рiс. 14 Рiс. 15

6
EN
SAFETY MEASURES AND COFFEE MAKER
OPERATION RECOMMENDATIONS
Read the operation instructions carefully before using
the co󰀨ee maker and keep it for future reference.
• Use the co󰀨ee maker for its intended purpose only, as
specied in this manual.
• Mishandling the co󰀨ee maker can lead to its breakage
and cause harm to the user or damage to his/her
property and it is not covered by warranty.
• The co󰀨ee maker is intended for making espresso and
cappuccino co󰀨ee and warming up ready drinks. Do not
warm any other liquids.
• Make sure that the operating voltage of the co󰀨ee
maker indicated on the label corresponds to your home
mains voltage.
• The power plug is equipped with a grounding contact,
plug it into the socket with
• reliable grounding contact. In case of short circuit the
grounding reduces the risk of electric shock.
• Contact an electrical technician, if you are not sure that
your sockets are installed properly and grounded.
• To prevent re do not use adapters designed for
connecting the power plug to the mains socket without
grounding contact.
• In case of sparking in the mains socket and occurrence
of smell of burning, unplug the unit and apply to the
organization maintaining your home mains.
• If smoke appears from the unit body, unplug the unit
and take measures to prevent re spreading.
• Use and store the co󰀨ee maker at the temperature above
0 °C.
• Do not use the co󰀨ee maker outdoors.
• It is not recommended to use the unit during lightning
storms.
• Protect the unit from impacts, falling, vibrations and other
mechanical stress.
• Never leave the plugged-in co󰀨ee maker unattended.
• To avoid re, electric shock or physical injuries, do not
immerse the power plug, the power cord or the co󰀨ee
maker body into water or any other liquids.
• Do not use the co󰀨ee maker in proximity to the kitchen
sink, in bathrooms, near swimming pools or other
containers lled with water.
• If the unit is dropped into water, unplug it immediately,
and only then you can take the unit out of water.
• Do not use the co󰀨ee maker near heating appliances,
heat sources or open ame.
• Do not use the unit in places where aerosols are used or
sprayed, and in proximity to inammable liquids.
• Place the co󰀨ee maker on a at stable surface; do not
place it on the edge of a table. Do not let the power cord
hang from the edge of the table and make sure it does
not touch hot surfaces or sharp edges of furniture.
• Do not place the co󰀨ee maker on hot surfaces.
• Do not touch the power cord and the power plug with wet
hands.
• Use only the co󰀨ee maker parts and accessories
supplied with the unit.
• Before switching the co󰀨ee maker on, make sure that all
removable parts are installed properly.

7
EN
• Ensure that the water level in the water tank is not
below the minimal mark.
• Do not switch the co󰀨ee maker on if the water tank is
empty.
• To avoid getting burns by hot steam be careful when
frothing milk or warming the ready drinks.
• The lter holder surface, the cappuccinator pipe and
the cappuccinator tip can get rather hot. Be cautious
and careful when in contact with hot surfaces.
• Do not remove the lter holder during co󰀨ee maker
operation.
• Let the unit cool down completely before cleaning and
removing the accessories.
• Unplug the co󰀨ee maker before cleaning or when you
are not using it. When unplugging the co󰀨ee maker
hold only the power cord plug and carefully remove it
from the mains socket, do not pull the power cord —
this can lead to damage of the power cord or the socket
or cause short circuit.
• For children safety reasons do not leave polyethylene
bags, used as a packaging, unattended.
ATTENTION! Do not allow children to play with
polyethylene bags or packaging lm. Danger of
su󰀨ocation!
• Place the unit out of reach of children during the
operation and cooling down.
• This unit is not intended for usage by physically or
mentally disabled persons (including children) or
• by persons lacking experience or knowledge if they are
not under supervision of a person who is responsible for
their safety or if they are not instructed by this person on
the usage of the unit.
• From time to time check the power cord and the power
plug integrity.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or similar
qualied personnel to avoid danger.
• Do not repair the unit by yourself. Do not disassemble
the unit by yourself, if any malfunction is detected, and
after it was dropped, unplug the unit and apply to the
service center.
• Transport the co󰀨ee maker in the original package.
• Keep the unit out of reach of children and disabled
persons.
COFFEE MAKER IS INTENDED FOR HOUSEHOLD
USE ONLY, DO NOT USE THE COFFEE MAKER FOR
COMMERCIAL OR LABORATORY PURPOSES.
BEFORE USING THE COFFEE MAKER
After unit transportation or storage at low temperature,
it is necessary to keep it for at least three hours at room
temperature.
• The co󰀨ee maker is not intended for usage by children.
• Do not leave children unattended to prevent using the
unit as a toy.
• Do not allow children to touch the unit and the power
cord during the co󰀨ee maker operation.

8
EN
• Unpack the co󰀨ee maker and remove all the packaging
materials.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the co󰀨ee maker for damages, in case of
damage do not plug it into the mains.
• Make sure that the specications of power supply
voltage specied on the lower panel of the unit
correspond to the specications of your mains. When
the unit is used in the mains with 60 Hz frequency, it
does not need any additional settings.
• Wipe the surface of the co󰀨ee maker body with a clean,
slightly damp cloth to remove dust.
• Before using the co󰀨ee maker for the rst time, wash
all removable parts (1, 2, 12, 13, 16, 18, 20, 21, 22, 23)
with warm water and neutral detergent and dry them.
BEFORE USING THE UNIT
ATTENTION! If you switch the co󰀨ee maker on and
don’t perform any actions, the co󰀨ee maker will
switch o󰀨 in 15 minutes. To switch the co󰀨ee maker
on press any button (7, 8, 9).
• Place the co󰀨ee maker on a steady at heat-resistant
surface, the distance from the side walls of the co󰀨ee
maker should be at least 20 cm, and the gap above the
co󰀨ee maker should be at least 30 cm.
• Do not use the co󰀨ee maker under kitchen shelves of
cupboards. They can be damaged by the steam released
during the co󰀨ee maker operation.
• The co󰀨ee maker should be placed out of reach of small
children.
Attention! Before making co󰀨ee for the rst time it is
recommended to wash the broiler, the cappuccinator lid (16)
and the milk container (18).
• Make sure that the removable tray (1) and the tray grid
(2) are installed to their places.
• Remove the lid (12), remove the water tank (13).
• Fill the tank (10) with cold water up to the maximal level
mark, install the tank (13) back to its place.
Note: the tank (13) is intended for water only, do not ll the
tank (10) with other liquids, such as milk.
• Take the container (18), pull it towards yourself and
remove it, remove the cappuccinator from the container
(18) (pic. 1). Fill the container with water up to the
maximal level mark.
Note: the cappuccinator container (18) is intended for milk
only, do not ll the container (18) with other liquids, use
water only in the cappuccinator lid (16) washing mode.
• Install the cappuccinator lid (16) on the container (18)
and install the cappuccinator back to its place until the
lock clicking.
Notes: after installing the container (18) with the lid (16)
back to its place always check if the cappuccinator is
installed and xed properly.

9
EN
• Set the milk supply intensity control knob (17) to the
middle position.
• Install one of the co󰀨ee lters (21 or 22) into the lter
holder (20) matching the ledge on the lter (21 or 22)
with the hole on the holder (20) and turn the lter (21
or 22) counter/clockwise. Do not add ground co󰀨ee
into the lter (21 or 22) when preparing the co󰀨ee
maker for work.
• Install the lter holder (20) into the installation place «
» and turn the handle (4) to the right as far as it will
go « » (pic. 2, 3, 4).
• Place a cup of suitable height and capacity of at least
300 ml on the tray grid (2).
• Direct the cappuccinator pipe (15) into the cup using
the cappuccinator pipe angle adjustment bar (14).
Note: You can change the length of the cappuccinator
pipe (15) by turning the pipe (15) counterclockwise, then
extend it to the required length, and x the pipe (15) by
turning it clockwise (g. 9).
• Insert the power plug into the mains socket.
• Switch the co󰀨ee maker on by setting the power switch
(11) «0/I» to the position «I», the indicator (7, 8, 9) will
light up and start ashing.
• When the co󰀨ee maker is ready for operation, the
indicator (7, 8, 9) will glow constantly.
• To switch the cleaning mode on press the
«Cappuccino»-button (8) twice. After cleaning is
nished, all the light indicators of the control buttons
(7, 8, 9) will light up.
• After you nish cleaning the co󰀨ee maker, switch the
co󰀨ee maker o󰀨 by setting the switch (11) «0/I» to the
position «0».
• Pour the water out of the cup, take the container (18),
pull it towards yourself and remove (pic. 1), remove the
cappuccinator lid (16) from the container (18), pour the
remaining water from the container (18). Slightly lift the
front part of the tray (1) and remove it, pour the water
out of it and install the tray (1) back to its place.
• Turn the lter holder handle (4) to the left and remove it
(pic. 2, 3, 4). Wait until the lter holder (20) cools down
completely and remove the installed lter (21 or 22)
turning it counter/clockwise. Wash the lter (21 or 22)
and install it into the lter holder (20).
• If necessary, clean the boiler and the cappuccinator lid
(16) several times.
• After cleaning the co󰀨ee maker is ready for operation.
CHOOSING THE APPROPRIATE CUP
• Before making co󰀨ee, please, select a cup of
appropriate capacity according to the table:
Drink Estimated amount of the ready
drink
Espresso: оne / double 90 ml/130 ml
Cappuccino: оne / double
150 ml/270 ml
Latte: one / double
280 ml/400 ml

10
EN
Notes: this table has guide values of the amount of the
ready drink and is only used to select the volume of the
required cup.
RULES OF MAKING ESPRESSO
• Use fresh-ground co󰀨ee beans or ground co󰀨ee for
«espresso» co󰀨ee makers.
• Make even and slightly tamp the ground co󰀨ee in the
lter (21 or 22), you can do it with the back side of
the measuring spoon (23) (pic. 5, 6, 7).
• Strength of ready co󰀨ee depends on the quality and
grinding degree of co󰀨ee beans.
• If co󰀨ee is pouring out too long, this means the
co󰀨ee powder is too ne it is tamped too strongly; in
this case use coarse-ground co󰀨ee and choose the
tamping degree experimentally.
THERMOMETER (5)
• The built-in thermometer (5) shows the boiler
temperature, if the boiler temperature is over 80°С,
you can make co󰀨ee.
• When the co󰀨ee maker is not used, the thermometer
(5) will show the room temperature.
MAKING ESPRESSO
ATTENTION!
- Do not remove the lter holder (20) during making
co󰀨ee.
- Do not remove the lter holder (20) right after making
co󰀨ee, as there is redundant pressure inside, wait a
little before removing the lter holder (20).
• Remove the lid (12), remove the water tank (13).
• Fill the tank (13) with cold water, do not exceed the
maximal level mark, install the tank (13) back to its place.
• Install one of the co󰀨ee lters (21 or 22), depending on
the amount of ready co󰀨ee, into the lter holder (20)
matching the ledge on the lter (21 or 22) with the hole
on the holder (20) and turn the lter (21 or 22) counter/
clockwise.
• Add the required amount of ground co󰀨ee into the lter
(21 or 22) with a measuring spoon (23) and slightly tamp
the co󰀨ee in the lter (21 or 22) with the back side of the
measuring spoon (23) (pic. 5, 6, 7).
• Install the lter holder (20) into the installation place «
» and turn the handle (4) to the right as far as it will go «
» (pic. 2, 3, 4).
• Place a cup of suitable height and capacity (see the table
CHOOSING THE APPROPRIATE CUP) on the grid (2); if
you use small cups, take the pullout tray (3) by the lower
part and pull it towards yourself, place the cups on it.
• Insert the power plug into the mains socket (pic. 8).
• Note: - During preliminary heating, you can warm up the
cups that will be used for making co󰀨ee by placing them
on the tray (6).
• Switch the co󰀨ee maker on by setting the power switch
(11) «0/I» to the position «I», the indicator (7, 8, 9) will
light up and start ashing.
