brennenstuhl MULTI 6053 MH User manual

MULTI 6053 MH
Operating instructions
If the oodlight is connected to the mains, the rechargeable battery is not charged.
If the oodlight is connected to the power supply, the oodlight is operated with mains voltage by default.
In case of power failure or if the device is unplugged from the mains, the oodlight will automatically switch to battery
operation if a rechargeable battery with sucient charging is inserted into the battery holder.This is signalled by the
oodlight ashing three times.
CHARGING THE RECHARGEABLE BATTERY
Only use one of the manufacturer’s original charging device: Bosch, Dewalt, Makita, Metabo (CAS), Milwaukee.
TRIPOD MOUNTING
By means of the holes in the holding bracket, the oodlight can be mounted on a Brennenstuhl tripod.
SCOPE OF DELIVERY
Floodlight, plug-in connection cable, 4 multi adapters: Bosch, Makita, Metabo,
Milwaukee/Dewalt, bag.
ACCESSORIES
Suitable accessories are available on our homepage www.brennenstuhl.com.
CLEANING
Before cleaning, disconnect the product from the power supply. Do not use solvents, caustic cleaning agents or similar products.
Only use a dry or slightly moistened cloth for cleaning.
MAINTENANCE
ATTENTION: The LED lamp does not contain components that require maintenance.
The light source of this lamp cannot be replaced. If the light source has reached the end of its service life, the entire lamp
has to be replaced.The lamp may not be opened.
EU DECLARATION OF CONFORMITY
The declaration of conformity is deposited with the manufacturer.
DISPOSAL
Dispose of electric appliances in an environmentally friendly manner!
Electric appliances must not be disposed of in household waste!
The European Directive 2012/19/EU onWaste Electrical and Electronic Equipment rules that used electric
appliances should be collected separately and recycled in an environmentally friendly manner.
For possibilities of disposal of the used appliance, please contact your local or municipal administration.
MANUFACTURER
Hugo Brennenstuhl GmbH & Co. KG, Seestraße 1-3 · D-72074 Tübingen
Brennenstuhl UK Ltd., No 1 Royal Exchange · London EC3V 3DG, UK
For more information, we recommend the Service/FAQs section on our homepage www.brennenstuhl.com.
0533654/4521
Operating instructions
Multi Battery LED Hybrid Spotlight
MULTI 6053 MH
Attention: Before using the product, please carefully read the operating instructions and store them in a proper location!
SAFETY INSTRUCTIONS
• Always check the product for damage before use.
Never use the product in case of any damage. In case you nd the product to be damaged, please refer to an electrician
or the manufacturer’s service address.
Non-compliance poses a risk of fatal injury from electrical current!
• Do not use the product in potentially explosive atmospheres – danger of death!
• Keep the oodlight away from children.
Children are not aware of the risks posed by electric current.
• For operating the oodlight, only use original rechargeable batteries of the following manufacturers:
Bosch, Dewalt, Makita, Metabo (CAS), Milwaukee.
Use of other rechargeable batteries may cause damage.
Only use the supplied connection cable to operate the hybrid function.
• Please never look directly into the light.
• A destroyed protective cover cannot be replaced. The oodlight has to be disposed of.
• The outer exible line of this lamp may be exchanged and is available as accessory.
Hot surface.
Not suitable for applications with external dimmers.
If the minimum distance is not complied with, illuminated objects may overheat.
• The product is not IP65-compliant (dust-protected and protected against splashing water)
- with removed battery protective cover.
The protective cover can only be used up to and including ProCORE 18V 8.0 Ah.
Without closed protective cover IP20.
TECHNICAL DATA
Protection class: II
IP class/shock resistance: IP65, IK08
Temperature range: -10 °C to +40 °C
Connection cable: H05VV-F 2x1.0
Mains plug: GB (IP20)

MULTI 6053 MH MULTI 6053 MH
Operating instructions Operating instructions
Compatible battery types: Bosch Professional batteries 18 V/2-12 Ah
Dewalt, Makita, Metabo (CAS), Milwaukee (18V rechargeable batteries)
Nominal voltage: 100-240 V~ 50/60 Hz
Power consumption: 60 W
Max. current: 0.8 A
Power factor: > 0.9
Max. projected area: 684 cm2
Dimensions: 25.6x16x27.5 cm
Dimensions of protective cover: 6.8x10 cm
Weight: 3.25 kg
This product is suitable for indoor and outdoor lighting purposes.
COMMISSIONING
Place the oodlight on a dry and level surface.
The adjustable bracket can be used to set various inclinations for the oodlight.
INSERTING AND REMOVING THE BATTERY
The oodlight is intended for operation with the subsequently listed batteries:
brennenstuhl® professionalLINE battery AB 1805
Bosch battery GBA 18 V x.x Ah Professional
Bosch ProCORE 18 V (up to a max. of 12 Ah) Professional
Dewalt 18 Volt rechargeable batteries
Makita 18 Volt rechargeable batteries
Metabo (CAS) 18Volt rechargeable batteries
Milwaukee 18Volt rechargeable batteries
The adapter can be inserted easily and quickly. To do so, open the lock (Fig. 1a) and fold the battery cover to the side
(Fig. 1a). Now insert the suitable adapter (Fig. 1c) into the Brennenstuhl interface (Fig. 1b) and lock it using the red locking
mechanism (Fig. 1d). Insert the charged 18 Volt rechargeable battery into the battery holder from the side (Fig. 1e) until it
noticeably engages in the end position. To remove the rechargeable battery, press the battery unlocking button and pull
the rechargeable battery out of the battery holder to the side. Afterwards, close the cover again (Fig. 1f).
To ensure IP65 (dust-protected and protected against splashing water), the oodlight may only be operated with correctly
closed battery cover.
If the device is not used for a longer period of time, remove the rechargeable battery.
1a 1b 1c
1d 1e 1f
The oodlight can also be operated without battery cover up to 12 Ah rechargeable batteries; in this case, the IP class will,
however, be reduced to IP20 and the oodlight may only be operated in a dry environment. To do so, open the battery
cover locking (Fig. 1f). Afterwards, remove the battery cover.
OPERATION OF THE HYBRID MAINS FLOODLIGHT WITH RECHARGEABLE BATTERY
To switch the oodlight on, press the button at the back (Fig. 2).
Press the switch multiple times (Fig. 2) to set the brightness to 100%, then 75%, 50%, then 25% and then“o”.
The lower the brightness selected, the longer the oodlight will burn.
If the switch is left in any of its“on”positions for longer than 5 seconds, then pressing it once again will always turn it o.
If the rechargeable battery is almost at and the connection cable is not connected, the LED oodlight will ash 5 times.
Afterwards, the oodlight remains on for approx.
10 minutes with 50% brightness before it is switched o by the deep discharge protection function.
If the connection cable is connected while the oodlight is switched on (Fig. 3), the oodlight will ash 3 times and then
automatically switch into mains operation with 100% light.
2
100% 75% 50% 25%
3
100% 75% 50% 25%
OPERATION OF THE HYBRID FLOODLIGHT WITH POWER SUPPLY
The oodlight can be connected to the power supply using the supplied plug-in cable via the connection socket at the back side
(Fig. 3).
To switch the oodlight on, operate the button on the back (Fig. 2).
Press the switch multiple times (Fig. 2) to set the brightness to 100%, then 75%, 50%, then 25% and then“o”.
If the switch is left in any of its“on”positions for longer than 5 seconds, then pressing it once again will always turn it o.
