Bristan CR SHXDIVFF C Mounting instructions

2
Rotate the shroud until
the opening aligns with
the isolation screw.
Turn the screw to isolate
the water. Reverse the
process when turning
the water back on.
1
Isolation 2
Remove the concealing
cap from the shroud.
Operation
5
Identify the
required positition of
the valve and prepare
the water supply pipes.
Supply pipes should be
150mm apart.
Using the backplate
supplied with the
wallmount, mark and
drill holes.
Secure the isolator
onto the backplate
ensuring the olive is
positioned over the
pipework correctly.
Push shrouds to the
back of the wall outlet,
securing them against
the rubber fixing plate
4
3
IMPORTANT
1
Pack Contents
150mm
Centres
1.0
5.0
Pressure
BAR
0.2
4.0
2.0 3.0
Pressure
BAR
1.0
5.0
0.2
4.0
2.0 3.0 60°C
65°C
Specifications
Maximum Static Pressure: 10.0 bar
Inlet Water Temperature
15mm
Compression
Inlet Connections
Min: 0.2 bar Max: 5.0 bar
Working Pressures
The inlet hot water must
be at least 10°C above the
required blend temperature.
Factory pre-set
42°C
Inlet Dimensions
5°C
25°C
Cold Water Supply
Min: 5°C Max: 25°C
Hot Water Supply
Tools You’ll need
Flat head Screwdriver Cross head Screwdriver Hexagonal Keys Socket SpannerPipe CutterPencil Drill Spanner
Installation Instructions
& User Guide
Please leave these instructions
with the end user
Product Code: CR SHXDIVFF C (D2)
All products manufactured and supplied by Bristan are safe to use provided that
they are installed, operated and receive regular maintenance in
accordance with these instructions.
This product needs to be installed in accordance with, and meet the
requirements of the Water Supply (Water Fittings) Regulations 1999 and
current by-laws. For full Installation Requirements & Notes (IRN) please
visit wras.co.uk/directory.
Isolation valves must be fitted to the inlet water supplies to ensure ease of future
maintenance.
Before installing this product the water supply must be thoroughly flushed in
order to remove any swarf, solder etc.
This product must not be modified in any way as this will invalidate the
guarantee.
Full access must be made available for future maintenance/servicing purposes.
Before drilling into walls, check that there are no hidden electrical wires,
cables or water supply pipes. This can be checked with the aid of an
electronic detector.
If power tools are used do not forget to:
- Wear eye protection
- Unplug equipment after use
If in doubt, contact a registered plumber or your Local Water Authority or
the Secretary of the Institute of Plumbing, address as follows:-
The Institute of Plumbing,
64 Station Lane,
Hornchurch,
Essex,
RM12 6NB, Tel: [phone]
Prior to Installation
Installation
60-65°C Recommended
REMEMBER
hot on the left,
cold on the
right
150mm Centres
Secure the rubber backplate
and backplate into place.
Secure the shower to
the wall mount.
21mm
REMEMBER
To service
your
product!
Hot
Cold
On
O
x1
x2
x2
x1
x1
x1
x1
x1
x1
x2
All manuals and user guides at all-guides.com
all-guides.com

7
4
4
2
1
Turn flow handle to ‘on’
position, letting temperature
stablise.
Turn cartridge spindle clockwise
to decrease the temperature.
Turn cartridge spindle
anti-clockwise to increase the
temperature.
3
5
2
Using the wall
mount, isolate
both shower inlets
before carrying out
any maintenance.
Unscrew the
cartridge using a
socket or box spanner.
Troubleshooting
To reduce the build up of
limescale and to ensure this
shower works to its maximum
performance we recommend
this shower is serviced every
6-12 months depending on the
hardness of your water.
To replace any spare parts for
your shower why not scan the
below QR Code and search for
your product.
Spare Parts
Servicing Intervals
Temperature Setting
Maintenance - Cartridge Cleaning
3
1
6
Symptom Cause Remedy
No flow or
low flow rate
partially closed isolation valve. Open isolation valve.
Instantaneous water heater cycles on and o
as flow rate or pressure is too low.
Increase water flow rate or
pressure through system.
Head of water is below the
minimum distance required.
2 meters minimum required.
Hot or cold water being drawn o elsewhere
causing pressure changes or instantaneous
boiler temperature changes.
Do not use other water outlets when using the taps.
Airlock or partial blockage in the supply
pipework.
Flush through pipework to ensure removal of debris and
any airlocks.
Water
dripping
from shower
This is normal for a short time after using the
shower.
This is caused by residual water tension, the build up of
water in the shower.
If water continues to drip,
possibly due to the cartridge
Remove cartridge and clean, refer to 'Maintenance' section
before starting any maintenance.
Shower does
not turn on
Closed isolation valve. Open isolation valve.
Mains water supply turned o. Turn on mains water supply.
REMEMBER
To service
your
product!
At Bristan, we want to make things as easy as possible for our customers. That’s why we oer solid guarantees on
all our products, eective from the date of purchase, to give you peace of mind.
To start your free guarantee simply scan the QR code and register your product.
Alternatively visit www.bristan.com/register.
For any other queries, please call our Customer Service on 0330 026 6273 where our expert team of advisors
will be able to oer you any help and advice.
For full guarantee terms and conditions visit www.bristan.com/guarantees.
34
5
Remove
temperature and
flow handles
Remove O-rings
and soak all
components in
de-scaler and wash o in clean
water. Examine all seals and
replace if needed. Use WRAS
approved silicon based grease
on all seals.
Reverse steps 5-2 to
reinstall the valve,
cartridge and handles.
Turn the water
supply to the
shower back on.
Remove cartridge
retainer and
cartridge
Remove
temperature
handle
Replace
temperature
handle
4
1
56
Riser Installation 23
Attach handset and fixed
head
Attach shroud and
secure riser to bracket by
tightening grub screws
Secure bracket to wall
using screws and plugs
provided
Disassemble bracket, align on
the wall in the correct position
and mark location of holes to
be drilled.
Using a spirit level to ensure
the riser is positioned
correctly, use the assembled
riser to mark the desired
position of the brackets.
Asseble the riser
rail and attach
slider to the
riser, setting the
desired length
useing the
telescopic riser.
