Bristan Java Mini J MBAS C User manual

AFTERCARE INSTRUCTIONS
Your fitting has a high quality finish and should be treated with care to preserve the
visible surfaces. All surface finishes will wear if not cleaned correctly, the only safe
way to clean your mixer is to wipe with a soft damp cloth. Stains can be removed
using washing up liquid. All bath cleaning powders and liquids will damage the
surface of your fitting - even non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 5 year guarantee
covers any defect in manufacture.
NOTE: he 5 year guarantee on the valves is invalidated if damaged by any
waterborne debris.
In the interests of continuous product development we reserve the right to alter
specification as necessary.
PRODUCT CODE: J MBAS C
TELEPHONE HELP LINE: 0844 701 6273
Bristan Group Ltd
Birch Coppice Business Park
Dordon
amworth
Staffordshire
B78 1SG
UK
A Masco Company
Web Site: www.bristan.com
elephone: 0844 701 6274
Facsimile: 0844 701 6275
Email: [e-mail]
(FI J MBAS) (R2) (H)
Java Mini Basin Mixer
Fitting Instructions
& Contents List
Ple se keep these instructions for future reference nd for the
ordering of sp re p rts.

6
5
4
3
2
1
8
9
710
12
11
13
15
d
e
f
c
ba
14
WATER PRESSURE
his mixer is suitable for use at all supply pressures. However for optimum use both
the hot and cold supplies should be reasonably balanced. If the fitting is installed at
low pressure (tank fed), then the minimum distance from the outlet of the nozzle to
the underside of the cold tank should be approximately 5 metres to ensure
adequate performance.
his mixer should be installed in compliance with Water Regulations. Where the
supplies are unbalanced, i.e. hot water from the cylinder tank/cold from the mains,
approved check valves must be fitted in the supply pipes. For further details contact
your Local Water Authority.
CON EN S
1. Mixer body
2. Pop-up operating rod (2 piece)
3. Plinth
4. C-shaped rubber washer
5. C-shaped metal washer
6. Securing nuts (x2)
7. ailpipes (x2)
8. hreaded rods (x2)
9. Waste rod
10. Waste body
11. Washer
12. Washer
13. Waste flange
14. Plug
15. O-ring
INSTALLATION
1. Identify all components and check for completeness, particularly before arranging
fitting.
2. Fit the mixer body (1) to the basin using the 'C' plate fixing kit. he plinth (3) and
‘O’ ring (15) go between the fitting and the basin, and the 'C' shaped rubber (4) and
metal washers (5) on the underside of the basin. Secure into position using
threaded rods (8) and nuts (6).
3. Screw in the inlet connection tailpipes by hand (7) to the fitting and connect the
hot and cold supplies.
4. Fit the pop up waste, using washers (11) below & (12) above the basin/bidet and
connect it to the mixer. It is recommended that a silicon sealant be applied to both
sealing faces of washers (11) and (12) he waste can be set by adjusting the waste
rod (9) / operating rod (2) connecting bracket and the screw in the base of the plug
(14).
5. Fully open the mixer in the mid position, letting it run for a few minutes to check
all joints and connections for leaks.
6. See over the page for aftercare instructions.
MAINTENANCE
If the fitting begins to drip:
1. urn off the water supply.
2. Remove indices cap (a), loosen grub screw (b) with a hexagon key and pull off
head (c), unscrew shroud (d) retaining nut (e).
3. Remove cartridge (f).
4. Clean or replace cartridge, clean and grease seal and refit.
Note: that there are locating pins on the bottom of the cartridge that fit in holes
inside the tap, to ensure it is fitted the right way round.
5. Replace cartridge and head and turn on the water supply.
6. Contact our helpline if problem persists.
Please Note: In the unlikely event you find a part missing please contact our
Customer Service Helpline on 0844 701 6273 or email enquir[email protected] for
immediate despatch of part.
