Broadata LBN-MST User manual

QUICK START GUIDE
AVoIP HDMI/VGA
Encoder(Tx)- LBN-MST
Decoder(Rx)- LBN-MSR
Controller- LBN-MSC

STEP 1: CONNECTING THE HARDWARE
Quick Install Guide-LBN-MSx2
1Connect the Ethernet Port on the PC/Laptop Computer using a Category 5
(CAT5) Unshielded Twisted-Pair (UTP) cable to any available Ethernet Port on the
Network Switch.
PC or Laptop Computer
2Connect the Ethernet Port on the AVoIP Controller to any available Ethernet Port
on the Network Switch. Use a CAT5 UTP cable terminated with a RJ-45 connector
to make the connection.
Network Switch Front Panel
AVoIP Matrix Switching Controller
Back Panel Ethernet Port

STEP 1: CONNECTING THE HARDWARE
Quick Install Guide-LBN-MSx 3
3Connect each AVoIP Encoder to an RJ45 network port on the Switch front panel.
Use Category 5 Unshielded Twisted-Pair (UTP) cable terminated with a RJ-45
connector to make these connections.
Network Switch Front Panel
AVoIP Encoder Back Panel AVoIP Encoder Back Panel
4
Network Switch Front Panel
AVoIP Decoder Back Panel AVoIP Decoder Back Panel
Connect each AVoIP Decoder to an RJ45 network port on the Switch front panel.
Use Category 5 Unshielded Twisted-Pair (UTP) cable terminated with a RJ-45
connector to make these connections.

STEP 2: POWERING UP THE DEVICES
Quick Install Guide-LBN-MSx4
Power Over Ethernet (PoE) allows you to supply power to the AVoIP
Encoders and Decoders via a PoE-enabled Network Switch, removing the
need for additional power supplies at each location.
5Connect the supplied AC Power Cord to the power recepticle on the back of the
switch and the other end to a power source such as an electrical outlet or surge
protector.
Power Recepticle
6Connect the supplied Power adapter to the 19V Power Port on the back of the
AVoIP Matrix Switching Controller and the other end to a power source such as an
electrical outlet or surge protector.
Power Port
Network Switch Back Panel
AVoIP Matrix Switching Controller
Back Panel
Allow 1-2 minutes for the Switch and Controller to initialize to supply power
to all connected devices.
7You are now ready to connect Audio/Video Sources to the HDMI or VGA Connector
on the Encoder and Monitors/Displays to the AVoIP Decoder.
!
!

STEP 3: ACCESSING AND CONFIGURING THE SYSTEM
Quick Install Guide-LBN-MSx 5
8Open a web browser and enter the URL http://lbn1g-msx to access the WebGUI
9The following AVoIP Controller Login Window Appear:
Enter the User Name and Password as provided:
Default User Name: admin
Default Password: admin
!

STEP 3: ACCESSING AND CONFIGURING THE SYSTEM
Quick Install Guide-LBN-MSx6
10 The Routing Page will appears and displays all AVoIP Encoders and Decoders that
have been added to the Network
11 Click on the Receivers or Transmitter tabs and you are now ready to configure the
networked devices. Select the icon for each Encoder(Tx) and Decoder(Rx) to
edit settings.
Icon
