Broan InVent 80 CFM Series Installation guide

© 2016 Broan-NuTone LLC
99045716A
Humidity Sensing Fan/Light
Ventilador/Lámpara
con sensor de humedad
AE80SL
AE110SL
Model numbers:
Números de modelo:
INSTALLATION AND
USE & CARE INSTRUCTIONS
INSTRUCCIONES PARA INSTALACIÓN,
USO Y CUIDADO
English - See page 2
Español - Consulte la página 9

INSTALLATION AND USE & CARE INSTRUCTIONS SAFETY
2
WARNING
To reduce the risk of fire, electric
shock, or injury to persons, observe the
following:
•Use this unit only in the manner intended
by the manufacturer. If you have
questions, contact the manufacturer at
the address or telephone number listed in
the warranty.
•Before servicing or cleaning unit,
switch power off at service panel and
lock the service disconnecting means
to prevent power from being switched
on accidentally. When the service
disconnecting means cannot be locked,
securely fasten a prominent warning
device, such as a tag, to the service
panel.
•Installation work and electrical wiring
must be done by a qualified person(s)
in accordance with all applicable codes
and standards, including fire-rated
construction codes and standards.
•Sufficient air is needed for proper
combustion and exhausting of gases
through the flue (chimney) of fuel burning
equipment to prevent backdrafting. Follow
the heating equipment manufacturer’s
guideline and safety standards such
as those published by the National
Fire Protection Association (NFPA),
and the American Society for Heating,
Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code
authorities.
•When cutting or drilling into wall or ceiling,
do not damage electrical wiring and other
hidden utilities.
•Ducted fans must always be vented to
the outdoors.
•If this unit is to be installed over a tub or
shower, it must be marked as appropriate
for the application and be connected to a
GFCI (Ground Fault Circuit Interrupter) -
protected branch circuit.
•This unit must be grounded.
•Some metal edges and/or corners may
be sharp. Use of gloves during installation
and removal is recommended.
CAUTION
•For general ventilating use only. Do not
use to exhaust hazardous or explosive
materials and vapors.
•For installation in flat ceilings only. DO
NOT MOUNT THIS PRODUCT IN A
WALL.
•To avoid motor bearing damage and
noisy and/or unbalanced impellers, keep
drywall spray, construction dust, etc. off
power unit.
•DO NOT TOUCH THE HUMIDITY-
SENSING CIRCUIT BOARD.
Electrostatic discharge may damage the
circuit board.
•Please read specification label on
product for further information and
requirements.
Please visit our website - www.broan.com
to register this product and to view installation tips and videos.
Installer: Leave this manual with the homeowner.
READ AND SAVE THESE INSTRUCTIONS

INSTALLATION AND USE & CARE INSTRUCTIONS
OPERATION
3
CLEANING & MAINTENANCE
For quiet and efficient operation, long life, and
attractive appearance - lower or remove grille
and vacuum interior of unit with the dusting brush
attachment.
The motor is permanently lubricated and never needs
oiling. If the motor bearings are making excessive
or unusual noises, replace the blower assembly
(includes motor and impeller).
OPERATION
The humidity control, fan, and light can be operated
separately. Use a 2- or 3-function wall control. Do
not use a dimmer switch to operate the humidity
control.
SENSOR OPERATION
This humidity-sensing fan uses a sophisticated
humidity sensor that responds to: (a) rapid to
moderate increases in humidity or (b) humidity above
a set-point. The humidity sensor may occasionally
turn the fan ON when environmental conditions
change.
MANUAL ON WITH TIMED OFF
This humidity sensing fan has an additional operation
feature. For odor or vapor control, the fan can be
energized by cycling the power switch. Once the fan
has been energized in this manner, it will remain on
for the set timer period.
To manually energize the fan:
1. If fan power switch is already ON, proceed to
Step 2; otherwise, turn power switch ON for more
than 1 second.
2. Turn fan power switch OFF for less than 1
second.
3. Turn fan power switch back ON and fan will turn
ON.
50
60
80
70
10
560
15 40
20 30
50
%HUMIDITY MINUTES
% HUMIDITY ADJUSTMENT
%HUMIDITY has been factory set at 80% for most
shower applications. If fan is not responding to changing
humidity conditions, adjust toward 50%. If fan is
responding too often to changing humidity conditions,
adjust toward 80%. If fan is still responding too often at
80%, contact Broan Technical Support.
To adjust the %HUMIDITY:
1. Turn power off at electrical service panel.
2. Use a small screwdriver to carefully rotate
%HUMIDITY control to desired level.
3. Turn power on.
4. Repeat above steps if necessary.
MINUTES ADJUSTMENT (TIMER)
This humidity-sensing fan has a timer that controls how
long the fan remains on after (a) rise in humidity and
(b) humidity level are both below the user-adjustable
%HUMIDITY setting, or after being energized by cycling
power switch.
To adjust the timer:
1. Disconnect power at electrical service panel.
2. Use a small screwdriver to carefully rotate MINUTES
control to increase or decrease time.
3. Turn power on.
4. Repeat above steps if necessary.
Factory settings shown.
SENSOR CLEANING
The humidity sensor is mounted in the control housing. The
sensor will operate most reliably when cleaned occasionally
as follows:
1. Disconnect power at service entrance.
2. Remove the grille. Use a dry dustcloth, clean toothbrush,
or lightly vacuum to clean sensor and grille. DO NOT
USE ABRASIVE CLOTH, STEEL WOOL PADS, OR
SCOURING POWDERS.
3. DO NOT USE cleaning sprays, solvents, or water on or
near the sensor!

INSTALLATION AND USE & CARE INSTRUCTIONS INSTALLATION
4
OPTION - To mount housing anywhere between ceiling
framing: Use optional Hanger Bar Kit (sold separately from local
distributors or website). Follow mounting instructions included
with kit.
1. Remove blower and all
packing material from fan
housing.
2. Remove wiring panel from
fan housing.
ROOF CAP *(with built-in damper)
WALL CAP *
(with built-in
damper)
4-IN. ROUND
ELBOWS *
FAN
HOUSING
Seal gaps
around
housing.
Seal duct joints
with tape.
INSULATION
(Place around and
over fan housing.)
POWER
CABLE *
*Purchase separately.
OR
Keep duct
runs short.
4-IN. ROUND
DUCT *
ALL INSTALLATIONS
Start here.
IMPORTANT - The ducting from this fan to the outside
of the building has a strong effect on the air flow, noise and
energy use of the fan. Use the shortest, straightest duct routing
possible for best performance, and avoid installing the fan with
smaller ducts than recommended. Insulation around the ducts
can reduce energy loss and inhibit mold growth. Fans installed
with existing ducts may not achieve their rated airflow.
Cooking
Equipment
Floor
COOKING AREA
Do not install above or
inside this area.
45o45o
NOT FOR USE IN
A COOKING AREA.
WARNING
•Disconnect the electrical power supply and lock
out the service panel.

INSTALLATION AND USE & CARE INSTRUCTIONS
INSTALLATION
5
5. Connect 4-in. round duct.
6. Connect wiring.
Bend tab to expose desired access hole. Connect
power cable to housing with appropriate UL approved
connector. Connect wires per diagram on page 8. Re-
install wiring panel and secure with screw from parts
bag.
3. Attach damper/duct connector
to fan housing.
Push connector through opening from inside of housing.
Engage tabs and secure with screw from parts bag.
4. Mount housing to ceiling
structure.
TABS
Make sure bottom of housing will be flush with finished
ceiling.
For proper location using ½-inch ceiling material: Bend
out housing tabs to fit against bottom of structure.
Secure housing through mounting ears with
appropriate fasteners.
If mounting housing to I-joist, use wood blocking as
shown.
NEW CONSTRUCTION
For Retrofit Installation - Skip to Page 6.
HOUSING
TABS

INSTALLATION AND USE & CARE INSTRUCTIONS INSTALLATION
6
9. Finish ceiling, remove mask,
then install grille.
Remove mask from housing. Plug in light. Squeeze
grille springs and insert into slots in housing.
7. Install blower.
Re-install blower. Secure blower with 2 screws from parts
bag and plug blower into black receptacle. Plug in humidity-
sensing control.
3. Remove old fan.
Enlarge ceiling opening (if necessary) to 9¾-inches
(parallel to joist) by 10½-inches (perpendicular to joist).
Leave ductwork and wiring in place.
1
2
4. Fold mounting ears flat against
housing.
RETROFIT
CAUTION
•Make sure that the wiring inside of
the housing does not interfere with
re-installation of the blower.
8. Install housing mask.
Place mask into housing
opening to
prevent drywall
spray and
construction dust
from damaging
blower.
Push grille up against ceiling.
Leave this mask in place to prevent
construction dust, drywall spray, or paint
from damaging inside of product.
REMOVE MASK BEFORE
INSTALLING GRILLE.
Laissez ce masque en place pour empêcher
la poussière de construction, le plâtre ou la
peinture, etc. d’endommager
l’intérieur du produit.
ENLEVEZ CE MASQUE AVANT
D’INSTALLER LA GRILLE.
Deje esta cubierta en su lugar para evitar
que polvos de construcción, rocíos de yeso
o pintura dañen el interior del producto.
QUITE LA CUBIERTA ANTES
DE INSTALAR LA REJILLA.
99352432A

INSTALLATION AND USE & CARE INSTRUCTIONS
INSTALLATION
7
5. Connect wiring.
Bend tab to expose desired access hole. Connect
power cable to housing with appropriate UL approved
connector. Connect wires per diagram on page 8. Re-
install wiring panel and secure with screw from parts
bag.
7. Connect 4-in. round duct.
Pull existing ducting through housing discharge
opening.
Attach and tape ducting to duct connector.
Push connector/ducting back through opening.
Engage tabs and secure with screw from parts
bag.
1
2
3
Install blower. Finish ceiling, then
install grille.
See Steps 7, 8 & 9 on Page 6.
(Step 8 is only necessary in RETROFIT
installations if ceiling requires repair.)
6. Mount housing to ceiling
structure.
Mount housing to ceiling structure with standard
drywall or wood screws in 3 locations shown. The
humidity control panel assembly must be removed to
access one of the locations.
4
TABS
CAUTION
•DO NOT TOUCH THE HUMIDITY-
SENSING CIRCUIT BOARD.
Electrostatic discharge may damage
the circuit board.

INSTALLATION AND USE & CARE INSTRUCTIONS SERVICE PARTS
8
MODELS AE80SL, AE110SL
SERVICE PARTS
1
2
3
5
7
6
8
4
WIRING DIAGRAMS
WIRING OPTION #1
•When first switch (1) is ON, fan will operate auto-
matically, based on room humidity conditions.
•Turn fan ON immediately for the set timer period
(to control odors), by cycling first switch.
•Use second switch (2) to turn light ON/OFF.
•With optional connection shown, fan will always
be ON when light is ON.
Key No. Part No. Description
1 97019514 Housing
297019561
97020122
Duct Connector - 4-in. (AE80SL)
Duct Connector - 4-in. (AE110SL)
3 97020537 Wire Panel Assembly
4 97020538 Humidity Control Panel Assembly
597019785
97019786
Blower Assembly (AE80SL)
Blower Assembly (AE110SL)
6 99271529 LED Module
7 99140214 Grille Spring (2 req.)
8 97019920 Grille Assembly (includes key no. 6 & 7)
97019743 Parts Bag (not shown)
BLK HUMIDITY
CONTROL
LIGHT
FAN
GREY
BRN
BLK
RED BLK
BLK
WHT
WHT
WHTWHT
WHT
GRD GRD
LIGHT
(ON/OFF)
FAN
(AUTO/OFF)
120
VAC
LINE
IN
COM
2-FUNCTION CONTROL
(PURCHASE SEPARATELY)
WHT
GRD
SWITCH UNIT
(Optional)
(1)
(2)
WIRING OPTION #2
•When first switch (1) is ON, fan will operate auto-
matically based on room humidity conditions.
•Turn fan ON immediately (to control odors) by using
second switch (2).
•Use third switch (3) to turn light ON/OFF.
3-FUNCTION CONTROL
(PURCHASE SEPARATELY)
LIGHT
(ON/OFF)
COM
FAN
(ON/OFF)
FAN AUTO
(AUTO/OFF)
120
VAC
LINE
IN
SWITCH
WHT
GRD
BLK
BLK
WHT
UNIT
BLK
WHT
GRD
BLK
RED
LIGHT
WHT
WHT
BLK WHT
BRN HUMIDITY
CONTROL
FAN
WHT
(1)
(2)
(3)
GREY
