Brodit ProClip 854570 User manual

14 April, 2020, www.brodit.com, © 2020 Brodit AB
Product 854570
854570 ProClip Kuga - NOT for Sony stereo.
Center mount, Note: May block buttons for some 2014 models with built-in navigation.
The ProClip is a mounting bracket for the vehicle’s dashboard. Onto the ProClip you can install e.g. a holder for
your mobile phone or PDA or a handsfree set etc. Safe and convenient -always within easy reach. The ProClip is
car specific and easy to install. The installation is quick, no special tools or dismantle of the dashboard is required
and it will not damage the interior of the vehicle. Made in black ABS plastic. Comes with detailed instructions.
EAN: 7320288545707
Item no 854570 fits:
Ford C-Max 11-18 (For Europe)
Ford Grand C-Max 11-18 (For Europe)
Ford Kuga 13-16 (For Europe)

1. 2.
INSTALLATION INSTRUCTIONS
4.3.
Please read all of the instructions and look at the pictures before attaching the ProClip.
1. Use the enclosed alcohol pad to clean the area where the ProClip is to be installed. Press the thin end of the
enclosed gap opener into the gap between the control panel and the dashboard. Peel off the adhesive tape
covers on the ProClip. Press the curved edge on the upper part of the ProClip into the gap next to the gap
opener.
2. Flip the ProClip downward so the curved upper edge hooks behind the control panel. Pull out the gap opener.
3. Press the gap opener into the gap between the frame surrounding the air vent and the center console. Pull the
ProClip downward. Hook the angled edge on the lower part of the ProClip into the gap next to the gap opener.
Press upward on the lower part of the ProClip so the angled edge goes all the way into the gap. Pull out the gap
opener.
4. The ProClip is in place.
