brondell DS725 Series User manual

OWNER’S MANUAL
Swash DS725 Advanced Bidet Toilet Seat
DS725-EW
DS725-RW

Attach Proof of Purchase to This Page
Adjunte prueba de compra a esta Página
Joindre une preuve d’achat à cette Page

1
CONTENTS
This manual contains important safety information. Before operating the
bidet, please read this manual thoroughly, and retain it for future reference.
PRODUCT INSTALLATION
GENERAL INFO
PRODUCT OPERATION
02 SAFETY INFORMATION
06
06
07
08
PRODUCT INFORMATION
Product Features
Product Dimensions
Product Parts
09
09
10
10
13
14
PRODUCT INSTALLATION
Installation Parts
Before Installation
Swash Installation
Remote Control Installation
External Bidet Filter Installation
15
15
17
18
20
OPERATING THE SWASH
DS725 Remote Control
DS725 Auxiliary Controls
Using the Swash DS725
Special Mode Operations
TECHNICAL INFO
TRANSLATIONS
21 PRODUCT SPECIFICATIONS
22
22
22
23
23
MAINTENANCE
Seat Cleaning & Removal
Nozzle Cleaning
Cleaning the Mesh Filter
Product Storage & Use
24 TROUBLESHOOTING
27 WARRANTY
28 CONTACT
01 ENGLISH
29 SPANISH
57 FRENCH

2
Failure to observe the following warnings may result in electric shock, fire, personal injury, property
damage or product damage:
• Do not use a damaged power plug or plug into a loose electric outlet.
• Do not move the product by pulling the power cord.
• Do not handle the product or power plug with wet hands.
• Do not forcefully bend the power cord or place heavy objects on it to prevent it from being damaged
or deformed.
• Do not connect and pull out the power plug or cord repeatedly.
• Unplug the product before cleaning, repairing, inspecting, or replacing parts.
• Remove any dust or water from the power plug prior to plugging in.
• Do not plug the product into an electrical outlet or power strip that is being used by too many other
products. Use an electrical outlet adequate for the wattage of the product rated for a minimum
of 15 amps.
• If the power cord is damaged, do not attempt to repair, modify, or replace the cord yourself.
Contact the Brondell Service Center toll free at 888-542-3355 or email us through our website.
• If the product produces a strange noise, a burning smell, or emits smoke, unplug it immediately
from the electrical outlet and contact Brondell. Failure to do so may result in electric shock or fire.
• Do not insert any wires or sharp objects into any product gaps. This may result in electric shock, fire,
or product damage.
Be careful to keep this safety information. Please read this information
to prevent property loss and ensure safety.
SAFETY INFORMATION
IMPORTANT SAFEGUARDS
DANGER:
If not observed, serious injury or even death may occur as a result.
DANGER
WARNING:
If not observed, serious physical injury or property damage may occur as a result.
CAUTION:
If not observed, minor physical injury or property damage may occur as a result.
READ ALL INSTRUCTIONS BEFORE USING
SAVE THESE INSTRUCTIONS

3
• Do not place an electronic or gas heater near the product or dispose of any burning materials
such as a lit cigarette in the toilet. This may result in fire or product deformation. Do not place any
containers filled with water or other liquids, food, metallic objects, or any flammable material on
top of the product. If foreign material enters the product, this may result in electric shock or fire.
• Do not use the product in locations exposed to excessive moisture and do not splash water
onto the product.
• While cleaning the bathroom, pull the power plug out of the electrical outlet and exercise caution to
ensure that water or cleaning supplies do not splash onto the bidet. Failure to do so may result in
electric shock or fire.
• If foreign material enters the product, pull the power plug out of the electrical outlet, turn o the
main water valve, and call the Brondell Service Center.
• Do not disassemble, repair, or modify the product yourself.
• Do not use the product while wet from bathing or showering.
• Do not place or store the product where it can fall or be pulled into a tub or sink.
• Do not place in or drop the product into water or any other liquid.
• Do not reach for the product if it has fallen into water. Unplug the product immediately and call the
Brondell Service Center.
• Do not use the product if it is not working properly. Please unplug the product immediately, close
the main water supply valve, and call the Brondell Service Center at 888-542-3355. Failure to do so
may result in electric shock, fire, or flooding.
SAFETY INFORMATION (cont.)
IMPORTANT SAFEGUARDS
DANGER
SAVE THESE INSTRUCTIONS
Failure to observe the following warnings may result in electric shock, fire, personal injury, property
damage or product damage.
• Do not plug in, operate, or store the unit in locations where flammable or combustible materials are
used or kept.
• Do not use industrial water, or gray water for the supply, as this may cause skin damage or disease.
• Turn o the main water supply valve when cleaning.
• For children and seniors who may have diculties with adjusting temperatures or those with sen-
sitive skin or impaired heat sensitivity, set the temperature of the wash spray and seat to “low” or
“o” to prevent burning.
• Close supervision is necessary when this product is used by children, seniors, or persons requiring
general assistance.
• Do not press the buttons using excessive force.
• Do not stand on top of or place any heavy objects onto the seat cover.
• Use this product for its intended use only, as described in this manual. Do not use any attachments
that are not recommended by Brondell.
WARNING

4
SAFETY INFORMATION (cont.)
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
Failure to observe the following warnings may result in electric shock, fire, personal injury, property
damage, or product damage.
• Do not connect the main water supply to the hot water pipe or supply (only connect to the cold
water supply).
• After the installation, make sure to check all water supply connections for leaks. Rubber washers
should be in place for the water connection hoses & T-Valve.
• Do not open/close the seat or seat cover with excessive force.
• Exercise caution that urine does not come into contact with the product - failure to do so may result
in bad odors or malfunction.
• If the product will not be used for a long period of time, unplug the power cord, close the main
water supply valve, and drain any water in the water tank.
• Do not pull out the bidet hose using excessive force.
• Do not use thinner, benzene, acidic chemicals, chloride, or hydrochloric acid detergent on or near
the product. This may result in corrosion to the metal parts or discoloration or scratches to the
bidet body.
• This appliance is not intended for use by persons (including children and seniors) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning the use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
CAUTION
WARNING
• Never operate this product if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or dropped into water. Contact the Brondell Service Center for
examination and repair.
• Keep the cord away from heated surfaces and heating vents.
• Never block the air openings of the product or place it on a soft surface, such as a bed or couch,
where the air openings may be blocked. Keep the air openings free of lint, hair, etc.
• Never drop or insert any object into any opening or hose.
• Do not use the product outdoors or operate where aerosol (spray) products are being used or a
room where it could be exposed to oxygen.
• Connect this product to a properly grounded outlet only. Refer to the Grounding Instructions in the
next Pages of the manual.

5
This product should only be used with a grounded GFCI
(Ground Fault Circuit Interrupter) outlet and a grounded
three-prong electrical cord as shown to the right. In the
event of an electrical short circuit, using a grounded GFCI
outlet reduces the risk of electric shock.
This product is equipped with a grounded cord and is for
use on a nominal 120V circuit only (minimum 15 amps) and
must be plugged into an outlet that is properly grounded
with a GFCI breaker as shown. Replace or repair a damaged
cord immediately.
Extension Cord Use
If it is necessary to use an extension cord, only use those rated for a minimum of 15 amps with a three-
wire extension cord with a three-blade grounding plug. Only plug into a three-slot grounded GFCI
receptacle that will accept the plug of the product. Replace or repair any damaged cords immediately.
GROUNDING AND GFI OUTLET INSTRUCTIONS
Test
Reset
Ground GFCI Outlet
Grounding Pin
Improper use of the grounding plug can result in a risk of electric shock.
• If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with green insulation
(either with or without a yellow stripe) is the grounding wire.
• Check with a qualified electrician if the grounding instructions are not completely
understood, or if there is doubt if the product is properly grounded.
For those with certain medical or mobility issues in the bathroom, we recommend our Swash 1400 or
Swash 1000 bidet seats, as their mounting systems are engineered for the most secure transitions
from wheelchairs or walkers.
SAFETY INFORMATION (cont.)
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
ATTENTION

6
PRODUCT INFORMATION
Stainless-Steel Nozzle System - stainless steel resists soiling and bacterial
contamination for enhanced hygiene.
Posterior and Feminine Warm Water Wash – experience the ultimate in clean with
adjustable temperature, position, pressure, massage, and oscillation settings.
Positionable Nozzle – the nozzle has five dierent positions to ensure the most
comfortable and complete wash.
Wireless Remote Control – the intuitive remote control allows the user to easily select
functions and settings.
Adjustable Water Temperature and Pressure – each wash mode (Front and Rear) has
four available water temperature settings, and five water pressure settings.
Massage – when activated, the water pressure automatically increases and decreases
to provide a pulsating, cleaning spray.
Warm Air Dryer – includes adjustable temperature with five levels for a hands-free
experience and toilet paper reduction.
Nozzle Oscillation – the Move function provides a massaging, oscillating cleanse
during the wash cycle ensuring a thorough and comfortable wash.
Auto Function – activates a preset for a rear wash cycle followed by a drying cycle.
Ergonomic Heated Seat – with four temperature settings (High/Med/Low/O).
Illuminating Nightlight – the cool blue hue of the nightlight means no more blinding
lights during midnight trips to the bathroom.
Gentle-Closing Seat and Lid – “slam free” gentle closing seat and lid are user friendly.
Eco Mode – when activated, this function automatically lowers the water temperature
and seat temperature after the Swash was last used.
Deodorizer – the activated charcoal deodorizing filter eliminates odors at the source.
It does not cover or mask odors, but eliminates them by removing air from the toilet
bowl, passing it through the filter and expelling the clean air through the vent in the
back of the Swash.
PRODUCT FEATURES

7
PRODUCT DIMENSIONS
5.5 in
Required Distance Between
Mounting Holes
15.5 in
15.5 in
7.8 in
7.8 in
16.4 in
15.2 in
4.3 in
4.3 in
Elongated Top View
Round Top View

8
PRODUCT PARTS
PRODUCT INFORMATION (cont.)
1. Lid
2. Seat Sensor
3. Warm Seat
4. Warm Air Dryer
5. Nozzle Assembly
6. LED Nightlight
7. Power Plug
8. Water Inlet with Mesh Filter
9. Auxiliary Control Panel
10. Drain Plug
11. Mounting Plate
12. IR Receiver (x2)
7
8
6
1
5
4
2
3
9
10
11
12

9
INSTALLATION PARTS
1. Mounting Bolt (2)
2. Rubber Cone Washer (2)
3. Flat Washer (2)
4. Nuts (2)
5. Mounting Plate
6. Top Mount Brackets
1
5
2
3
6
4
7. T-Valve Connector with
Rubber Washer
8. Bidet Hose
9. Remote Control
10. Remote Control Wall Mount
11. Batteries (2 x AAA)
8
10
11
9
7
PRODUCT INSTALLATION

10
DO NOT PLUG THE PRODUCT IN WHILE THE UNIT IS UPSIDE DOWN
This may cause damage to the internal components.
WATCH OUR INSTALLATION VIDEO
Installation for all Swash products can be found online at brondell.com.
CHECK BOLT SPREAD
This bidet seat can only be installed on toilets with a bolt hole spread of 5.5 inches
(see Product Dimensions on Page 7 for more information).
CHECK FOR TOP MOUNT INSTALLATION
If your fixture only has top-side access to the mounting bolts that hold the seat to the toilet,
use the Top-Mount Brackets included in the hardware pack (see Page 12).
CHECK FOR A CONCEALED TOILET FILL VALVE
Many modern toilets have sleek designs intended to cover and camouflage plumbing
connections, which makes a standard Swash installation dicult or impossible. For this, we
recommend using our Alternate Swash Bidet Seat T-Valve, found on brondell.com.
CHECK WATER SUPPLY LINE
Check the line that connects the toilet tank to the water shut o valve. If it is a rigid pipe, you may
need to purchase a flexible hose to replace it before installing the Swash. The length of the hose
and the size of the connectors will vary.
RESIDUAL MOISTURE IS NORMAL
Every product is tested with pure water during production to ensure the highest quality and
performance. It is normal to find a small amount of residual moisture on the product and in the
reservoir and filter.
TOOLS
A Phillips head or standard screwdriver may be needed to remove the existing toilet seat and a
standard wrench may be needed for tight water supply connections. Teflon tape can be helpful
in creating a water-tight seat between plumbing connections.
PRODUCT INSTALLATION (cont.)
BEFORE INSTALLATION
SWASH INSTALLATION
Please read these instructions carefully before installing the Swash. Failure to do so could result
in flooding, leaking or damage to the product.
NOTE: Steps may vary by type of seat and toilet

11
SWASH INSTALLATION (cont.)
3. Connect the female side of the T-Valve to the incoming
water connection on the bottom of your toilet tank,
ensuring the rubber washer is properly seated.
4. Connect the water supply line coming from the wall to the
bottom of the T-Valve.
NOTES:
• The T-Valve connects to the fill valve directly under
your toilet tank – it does not connect at the wall.
• Only connect to the cold toilet water supply line.
• If your water supply line is rigid you may need to
replace it before continuing.
Steps 5b & 5c
Steps 3-4
toilet tank
t-valve
cold water
supply line
NOTES:
• You may wish to place a container under the tank to
catch any excess water.
• Do not continue without completing the above steps.
• Failure to do so could result in flooding, leaking or
damage to the Swash.
1. Existing Toilet Seat Removal
a. Lift hinge covers and use a screwdriver to remove the
mounting bolts.
b. Remove the toilet seat. Keep for future use.
2. Turn O Water Supply Valve and Flush Toilet
a. Turn water valve o to stop the flow of water.
b. Flush toilet and hold down handle to completely
empty tank.
c. Disconnect water supply hose from toilet tank. Do not
disconnect from the water supply valve. Step 2c
5. Install Mounting Plate for Standard Installation
(see Page 12, Step 6 for instructions on using the Top-Mount Brackets)
a. Place adjustable mounting plate over mounting holes on toilet,
rubber side facing down, arrow pointing to the toilet bowl.
b. Insert the mounting bolts through the mounting plate and mounting holes of the toilet.
Be sure that the square mounting bolt head is even with the sides of the mounting plate.
c. Slide rubber cone washer, flat washer, and then nut onto mounting bolts under the toilet
bowl and tighten to keep mounting plate in place.

12
PRODUCT INSTALLATION cont.
SWASH INSTALLATION (cont.)
NOTES:
• For those with mobility issues, we recommend our
Swash 1400 or Swash 1000 bidet seats, as their
mounting systems are engineered for the most secure
transitions from wheelchairs or walkers.
Step 8b
Step 7a
Step 9
6. Install Mounting Plate for top-mounted toilet seats (see
Page 11, Step 5 for instructions on Standard Installation).
This method will use a combination of the included Top-
Mount Brackets and the original toilet seat mounting bolts.
a. Place adjustable mounting plate over mounting holes
on toilet, rubber side facing down, arrow pointing to the
toilet bowl.
b. Place provided Top Mount Brackets, flat side down, into
the slots of the mounting plate, over the bolt holes.
c. Insert the original toilet seat mounting bolts through the
Top-Mount Brackets and into the threaded bolt holes of
the toilet, using a screwdriver to tighten.
7. Connect the Bidet Hose to the Seat
a. Connect the elbow side of the bidet hose to the water
inlet. Hand-tighten to secure. Take care not to twist the
bidet hose, excessively bend it, or strip the plastic screw
threads when screwing the hose onto the bidet seat.
8. Attach the Swash to the Mounting Plate
a. Set the Swash flat on the toilet bowl in front of the
mounting plate, and slide seat onto plate until it is secure.
b. If the seat appears too short or too long for the toilet,
adjust the mounting plate accordingly. To adjust the
mounting plate, loosen the nuts underneath the toilet
and slide seat forward or backwards as needed.
Once the seat is lined up properly, tighten the nuts
to hold in place.
Steps 6b & 6c
9. Connect the open end of the Bidet Hose to the T-Valve.
10. Turn On Water Supply
a. Open the main water supply valve slowly and check for leaks.
b. Wait 5 minutes, check again and if there are no leaks continue.

13
SWASH INSTALLATION (cont.)
REMOTE CONTROL INSTALLATION
NOTES:
• Make sure to only use a grounded GFCI (ground fault circuit interrupter) electrical outlet. In
the case of a short circuit, a grounded GFCI outlet may help prevent electric shock or injury.
• If it is necessary to use an extension cord, only use those rated for a minimum of 15 amps
with a three-wire extension cord with a three-blade grounding plug.
Step 1b
Step 2b
1. Battery Installation
a. Remove the Remote Control from the Wall Mount.
b. Turn remote over and remove the battery compartment.
Insert the two included AAA batteries and replace
battery cover.
c. To confirm the batteries are installed correctly, press
and release the DRY button. One of the center vertical
LED lights will illuminate for twenty seconds.
2. Mount Remote (optional)
a. Identify a location in the bathroom for the remote
control that is visible and reachable from the toilet.
b. Use the provided double-stick tape on the back of
the remote wall mount. Make sure the remote mount
is fully secure so that it does not fall and damage the
remote control.
c. Slide the remote control into the mount.
double-stick
tape (on back)
11. Plug the Power Cord into an Electrical Outlet
a. If the Power Indicator is not illuminated press any button on the control panel.
12. Fill the Water Reservoir Tank
a. Press either the “Rear” or “Front” button on the remote control to fill the
Water Reservoir Tank with water.
b. The Swash will beep continuously while the tank is filling and will emit one long
beep to indicate when the tank is full.
c. Wait 3-5 minutes for the water to heat up, and the Swash will be ready for use.
13. Follow instructions on Page 18 for using the Swash.

14
PRODUCT INSTALLATION cont.
EXTERNAL BIDET FILTER INSTALLATION
1. Turn O Water Supply Valve and Flush Toilet.
a. Turn water valve o to stop the flow of water.
b. Flush toilet and hold down handle to completely empty tank.
2. Disconnect the Bidet Hose from the T-Valve.
3. Connect the female end of the Swash Filter to the open T-Valve connection.
4. Connect the Bidet Hose to the male end of the Swash Filter.
5. Turn the toilet water supply valve back on.
Step 2
FLOW
Step 3
FLOW
Step 4
NOTE:
• Customers with hard water, well water, and softened water can extend the life of their bidet
seat by purchasing and installing an external inline water filter to be used with the Swash.
The bidet filter should be changed every six months, and can be purchased online at
brondell.com.

15
OPERATING THE SWASH
DS725 REMOTE CONTROL
Water Temperature
Button
Nozzle Position
Buttons
Water Pressure and
Dry Temperature
Buttons
Water Pressure and
Dry Temperature
Indicators
Seat Temperature
Button
Water Temp. and Seat
Temp. Indicators
Battery Life Indicator
Deodorizer Button
Auto Mode Button
Massage Button
Move Button
Rear Wash Button
Stop Button
Front Wash Button Warm Air Dry
Button
DS725
10
1
2
4
3
7
6
5
8
11
13 14
12
9
15

16
DS725 REMOTE CONTROL (cont.)
1. Rear Wash Button
Press once to initiate a two-minute rear wash.
2. Front Wash Button
Press once to initiate a two-minute
front (feminine) wash.
3. Warm Air Dry Button
Press once to initiate a two-minute warm air
dry cycle.
4. Stop Button
Press to stop all wash or dry functions
currently operating.
5. Nozzle Position Buttons
Press the arrow up and arrow down buttons
to adjust the nozzle position forward and
backward during a wash cycle.
6. Water Pressure and Dry
Temperature Indicators
These lights indicate the Water Pressure
setting during a wash cycle, and the dryer
temperature during a Dry cycle.
7. Water Pressure and Dry
Temperature Buttons
Press the “+” and “–” buttons to increase and
decrease the outgoing water pressure to one
of five settings. Pressing these buttons while
the Warm Air Dryer is operating will adjust the
drying temperature. Settings will be saved for
the next use.
8. Water Temperature Button
Press and release this button to adjust
the outgoing water temperature to one
of four settings (LO: 93.2° F, MED: 98.6° F,
HI: 104° F, and OFF). Settings will be saved
for the next use.
OPERATING THE SWASH cont.
9. Seat Temperature Button
Press and release the “Seat Temp” button
to adjust the seat temperature to one of
four settings (LO: 95° F, MED: 100.4° F,
HI: 104° F, and OFF). Settings will be saved
for the next use.
10. Water Temperature and Seat
Temperature Indicators
These lights indicate the water
temperature setting while a wash cycle is
active, and the seat temperature setting
during all other times.
11. Massage Button
Pressing this button while a wash is
running enables the water to repeatedly
increase and decrease in pressure in a
pulsating pattern. Press again to stop.
12. Auto Mode Button
Press this button once to initiate a one
minute rear wash cycle followed by a
one minute dry cycle. See Page 19 for
more information.
13. Move Button
Press to initiate nozzle oscillation
(repetitive forward and backward nozzle
movement) during either the Front or Rear
Wash. Press again to stop the oscillation.
14. Deodorizer Button
Press this button to activate a one-minute
Deodorizer cycle.
15. Battery Life Indicator
This indicator will light up when the
batteries are low. See Page 13 on how to
replace the batteries.

17
DS725 AUXILIARY CONTROLS
123
456
AUXILIARY CONTROL PANEL
1. Power Indicator Light
This light is illuminated when there is electricity running to the bidet seat.
2. Night Light Indicator
This indicator is illuminated when the Night Light is on. The indicator
extinguishes when the Night Light is turned o.
3. Eco Mode Indicator
This indicator is illuminated when Eco Mode is selected.
4. Night Light Button
Pressing this button turns the Night Light on and o.
5. Eco Mode Button
Pressing this button turns Eco Mode on and o. See Page 19 for more details
on Eco Mode.
6. Rear Wash Button
Pressing this button initiates the Rear Wash cycle. Press this button again to
stop the Rear Wash cycle.

18
OPERATING THE SWASH cont.
USING THE SWASH DS725
Prepare for Wash
Sit on the seat to ensure skin-to-seat contact on the Seat Sensor. Once contact is made the seat
will automatically:
1. Give an audible beep letting you know the Seat Sensor has been engaged.
2. If the bidet was set to Eco Mode, the seat and water temperature will rise to the set
temperature settings.
Warm Water Wash
When ready to wash, press the Rear Wash or Front Wash button on the control panel one time to
initiate a wash. The nozzle will self-clean, extend into the toilet bowl, spray for two minutes, turn
o automatically, retract, and self-clean once again.
1. While washing, users can adjust the water temperature, pressure, and nozzle position settings,
as well as initiate the Massage and Pulse features by following the notes on Page 16.
2. If you would like to stop the wash before the two minute cycle ends, press the Stop button to
discontinue water flow.
3. After extended use the water may decrease in temperature if a LOW, MEDIUM, or HIGH water
temperature setting is selected. To regain warmer water, stop all wash functions for three
minutes to allow the bidet to reheat the water.
Warm Air Dryer Function
Press the Dry button to activate the warm air dryer. The dryer will run for two minutes and
turn o automatically.
1. While the air dryer is operating, users can adjust the dryer temperature to a comfortable level
using the Dry “+” and “–” buttons. The dry temperature will be reflected on the five indicator
LED lights (see Page 15).
2. If you would like to stop the dryer before the two minutes has elapsed, press Stop.
Deodorizer
Press the Deodorizer button to activate the deodorizer for a one minute cycle. Push the Stop
button to turn the deodorizer o. Note that the deodorizer will not function during any wash or
dry cycle.
NOTES:
• The wash functions will not work unless the sensor in the seat detects someone sitting
down (with the built-in skin conductivity sensor). To override the Seat Sensor, please see
the instructions on Page 20.
