Owner's Manual
Swash T22
Luxury Bidet Toilet Seat
Models T22EW / T22RW

2
SAFETY INFORMATION
3Important Safeguards
PRODUCT INFORMATION
7Product Features
8Product Dimensions
9Product Parts
PRODUCT INSTALLATION
10 Installation Parts
11 Before Installation
12 Swash Installation
15 External Bidet Filter Installation
PRODUCT OPERATION
16 Control Panel
18 Using the Swash: Getting Started
19 Special Mode Operations
20 Special Mode Operation:
Memory Functions
21 Expert Mode Operations Level 1
23 Expert Mode Operations Level 2
MAINTENANCE
25 Seat Cleaning, Removal,
and Nozzle Cleaning
26 Mesh Filter and Carbon
Deodorizer Cartridge
27 Product Storage
TECHNICAL INFORMATION
28 Troubleshooting
31 Product Specifications
32 Warranty
33 Contact Information
TRANSLATIONS
34 Spanish
66 French
This manual contains important safety
information. Before operating the bidet,
please read this manual thoroughly,
and retain it for future reference.
T22 OWNER’S MANUAL
Contents

3
SAFETY INFORMATION
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
BE CAREFUL TO KEEP THIS SAFETY INFORMATION. PLEASE READ THIS INFORMATION
TO PREVENT PROPERTY LOSS AND ENSURE SAFETY.
Do not use a damaged power plug or plug into
a loose electric outlet.
Do not move the product by pulling the power
cord.
Do not handle the product or power plug with
wet hands.
Do not forcefully bend the power cord or place
heavy objects on it to prevent it from being
damaged or deformed.
Do not connect and pull out the power plug or
cord repeatedly.
Unplug the product before cleaning, repairing,
inspecting, or replacing parts.
Remove any dust or water from the power plug
prior to plugging in.
Do not plug the product into an electrical
outlet or power strip that is being used by too
many other products. Use an electrical outlet
adequate for the wattage of the product rated
for a minimum of 15 amps.
If the power cord is damaged, do not attempt
to repair, modify, or replace the cord yourself.
Contact the Brondell Service Center toll free
at 888-542-3355 or email us through our
website.
If the product produces a strange noise,
a burning smell, or emits smoke, unplug it
immediately from the electrical outlet and
contact Brondell. Failure to do so may result in
electric shock or fire.
Do not insert any wires or sharp objects into
any product gaps. This may result in electric
shock, fire, or product damage.
Do not place an electronic or gas heater
near the product or dispose of any burning
materials such as a lit cigarette in the toilet.
This may result in fire or product deformation.
Do not place any containers filled with water
or other liquids, food, metallic objects, or any
flammable material on top of the product. If
foreign material enters the product, this may
result in electric shock or fire.
DANGER
Failure to observe the following warnings may result in electric shock, fire,
personal injury, property damage, or product damage.

4
SAFETY INFORMATION
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
BE CAREFUL TO KEEP THIS SAFETY INFORMATION. PLEASE READ THIS INFORMATION
TO PREVENT PROPERTY LOSS AND ENSURE SAFETY.
Do not plug in, operate, or store the unit in
locations where flammable or combustible
materials are used or kept.
Do not use industrial water, or gray water for
the supply, as this may cause skin damage or
disease.
Turn o the main water supply valve when
cleaning.
For children and seniors who may have
diculties with adjusting temperatures or those
with sensitive skin or impaired heat sensitivity,
set the temperature of the wash spray and seat
to “low” or “o” to prevent burning.
Close supervision is necessary when this
product is used by children, seniors, or
persons requiring general assistance.
Do not press the buttons using excessive
force.
Do not stand on top of or place any heavy
objects onto the seat cover.
Use this product for its intended use only,
as described in this manual. Do not use any
attachments that are not recommended by
Brondell.
Do not use the product in locations exposed
to excessive moisture and do not splash water
onto the product.
While cleaning the bathroom, pull the power
plug out of the electrical outlet and exercise
caution to ensure that water or cleaning
supplies do not splash onto the bidet. Failure
to do so may result in electric shock or fire.
If foreign material enters the product, pull the
power plug out of the electrical outlet, turn
o the main water valve, and call the Brondell
Service Center.
Do not disassemble, repair, or modify the
product yourself.
Do not use the product while wet from bathing
or showering.
Do not place or store the product where it can
fall or be pulled into a tub or sink.
Do not place in or drop the product into water
or any other liquid.
Do not reach for the product if it has fallen into
water. Unplug the product immediately and
call the Brondell Service Center.
Do not use the product if it is not working
properly. Please unplug the product
immediately, close the main water supply
valve, and call the Brondell Service Center at
888-542-3355. Failure to do so may result in
electric shock, fire, or flooding.
DANGER
Failure to observe the following warnings may result in electric shock, fire,
personal injury, property damage, or product damage.
WARNING
Failure to observe the following warnings may result in electric shock, fire,
personal injury, property damage, or product damage.

5
SAFETY INFORMATION
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
BE CAREFUL TO KEEP THIS SAFETY INFORMATION. PLEASE READ THIS INFORMATION
TO PREVENT PROPERTY LOSS AND ENSURE SAFETY.
Do not connect the main water supply to the
hot water pipe or supply (only connect to the
cold water supply).
After the installation, make sure to check all
water supply connections for leaks. Rubber
washers should be in place for the water
connection hoses & T-valve.
Do not open/close the seat or seat cover with
excessive force.
Exercise caution that urine does not come into
contact with the product - failure to do so may
result in bad odors or malfunction.
If the product will not be used for a long period
of time, unplug the power cord, close the main
water supply valve, and drain any water in the
water tank.
Do not pull out the bidet hose using excessive
force.
Do not use thinner, benzene, acidic chemicals,
chloride, or hydrochloric acid detergent on or
near the product. This may result in corrosion
to the metal parts or discoloration or scratches
to the bidet body.
This appliance is not intended for use by
persons (including children and seniors)
with reduced physical, sensory, or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning the use
of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Never operate this product if it has a damaged
cord or plug, if it is not working properly, if it
has been dropped or damaged, or dropped
into water. Contact the Brondell Service
Center for examination and repair.
Keep the cord away from heated surfaces and
heating vents.
Never block the air openings of the product
or place it on a soft surface, such as a bed
or couch, where the air openings may be
blocked. Keep the air openings free of lint,
hair, etc.
Never drop or insert any object into any
opening or hose.
Do not use the product outdoors or operate
where aerosol (spray) products are being
used, or a room where the product could be
exposed to oxygen.
Connect the product to a properly grounded
outlet only. Refer to the Grounding Instructions
in the next pages of the manual.
WARNING
Failure to observe the following warnings may result in electric shock, fire,
personal injury, property damage, or product damage.
CAUTION
Failure to observe the following warnings may result in electric shock, fire,
personal injury, property damage, or product damage.

6
DANGER
Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with green insulation
(either with or without a yellow stripe) is the grounding wire.
Check with a qualified electrician if the grounding instructions are not completely
understood, or if there is doubt if the product is properly grounded.
ATTENTION
For those with certain medical or mobility issues in the bathroom, we recommend
our Swash 1400 or Swash 1000 bidet seats, as their mounting systems are engineered
for the most secure transitions from wheelchairs or walkers.
GROUNDING AND GFCI OUTLET
INSTRUCTIONS
This product should only be used with
a grounded GFCI (Ground Fault Circuit
Interrupter) outlet and a grounded three-
prong electrical cord as shown to the right.
In the event of an electrical short circuit, using
a grounded GFCI outlet reduces the risk of
electric shock.
This product is equipped with a grounded
cord and is for use on a nominal 120V circuit
only (minimum 15 amps) and must be plugged
into an outlet that is properly grounded with
a GFCI breaker as shown. Replace or repair a
damaged cord immediately. 12
3
1. Grounding Pin
2. Test Button
3. Reset Button
SAFETY INFORMATION
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
BE CAREFUL TO KEEP THIS SAFETY INFORMATION. PLEASE READ THIS INFORMATION
TO PREVENT PROPERTY LOSS AND ENSURE SAFETY.

7
Stainless steel nozzle
Stainless steel resists soiling and
contamination for enhanced hygiene
Rear and front warm water wash
Adjustable temperature, position, pressure,
and oscillation settings
Strong wash
Concentrated stream with adjustable pressure,
position, temperature, and oscillation settings
Nozzle positioning
Adjustable, 5-position nozzle ensures a
comfortable and complete wash
Ceramic water heating system
Instant ceramic heating system provides an
endless warm water stream for washes
Adjustable water temperature and pressure
Front, rear, and strong wash modes have 4
available water temperature settings and 5
water pressure settings
Warm air dryer
Adjustable, 5-level temperature setting for a
hands-free drying experience and toilet paper
reduction/elimination
Nozzle oscillation
Move function provides a massaging,
oscillating cleanse during the wash cycle,
ensuring a thorough and comfortable wash
Gentle wash
Activates a preset wash cycle at the softest
setting for a gentle clean, followed by a
drying cycle
Deodorizer
Activated charcoal deodorizing filter
eliminates odors at the source
Ergonomic heated seat
Provides 4 temperature settings for comfort
(o/low/medium/high)
Multicolored, illuminating nightlight
Select a preferred nightlight color to help
ensure safer evening bathroom visits
Gentle-close seat and lid
Gentle-close seat and lid eliminates slamming
and pinched fingers
Sittable lid
Sturdy, sittable lid can support up to 264
pounds
Quick-release seat
Quick-release button for easy removal and
cleaning of the seat and toilet
Nozzle cleaning
Activate for automatic or manual nozzle
cleaning
Programmable user memory
Set water pressure, oscillation, water
temperature, nozzle positioning, and seat
temperature for two users
Eco mode
Automatically lowers the seat temperature for
energy saving when activated
Expert mode custom settings
Personalize and change the running time of
wash and dry cycles
PRODUCT INFORMATION
Product Features

8
PRODUCT INFORMATION
Product Dimensions
Required Distance Between Mounting Holes
Elongated Top View
Round Top View
20.7” / 52.6 cm
11.8” / 30 cm
7.9” / 20.1 cm
2.1” / 5.3 cm
15” / 38.1 cm 17.6” / 44.7 cm
5.3–7.7” / 13.50–19.6 cm
7.9” / 20.1 cm
2.1” / 5.3 cm
19.6” / 49.8 cm
11” / 28.0 cm
15” / 38.1 cm 17.6” / 44.7 cm

9
PRODUCT INFORMATION
Product Parts
1. Lid
2. Control panel
3. Nozzle assembly
4. Seat sensor area
5. Quick-release button
6. Deodorizer cover & outlet
7. Deodorizer inlet
8. Mounting plate
9. Water inlet with mesh filter
10. Nightlight
11. Power cord
1
2
3
6
5
4
11
7
8
9
10

10
PRODUCT INSTALLATION
Installation Parts
1. Metal mounting bolt (2)
2. Rubber anchor (2)
3. T-valve connector with rubber washer
4. Deodorizer cover
5. Carbon deodorizer cartridge
6. Bidet hose
7. Adjustable brackets (2)
8. Mounting plate
6
1 2
7
5
3
8
4

11
PRODUCT INSTALLATION
Before Installation
Watch our installation video
Installation for all Swash products can be
found online at brondell.com
Check bolt spread
This bidet seat can only be installed on toilets
with a bolt hole spread of 5.3–7.7”.
(see Product Dimensions on page 8 for more
information).
Check for a concealed toilet fill valve
Many modern toilets have sleek designs
intended to cover and camouflage plumbing
connections, which make a standard Swash
installation dicult or impossible. For this, we
recommend using our Alternate Swash Bidet
Seat T-valve, found on brondell.com.
Check water supply line
Check the line that connects the toilet tank
to the water shut o valve. If it is a rigid pipe,
you may need to purchase a flexible hose
to replace it before installing the Swash.
The length of the hose and the size of the
connectors will vary.
Residual moisture is normal
Every product is tested with pure water during
production to ensure the highest quality
and performance. It is normal to find a small
amount of residual moisture on the product.
Tools
A Phillips head or standard screwdriver may be
needed to remove the existing toilet seat and
a standard wrench may be needed for tight
water supply connections. Teflon tape can be
helpful in creating a water-tight seal between
plumbing connections.
CAUTION
Do not plug the product in while the unit is upside down.
This may cause damage to the internal components.

12
Please read these instructions carefully before
installing the Swash. Failure to do so could
result in flooding, leaking, or damage to the
product.
1. Existing toilet seat removal
a. Lift hinge covers and use a screwdriver
to remove the mounting bolts.
b. Remove the toilet seat; keep for future
use.
2. Turn o water supply valve and flush toilet
a. Turn water valve o to stop the flow of
water.
b. Flush toilet and hold down handle to
completely empty tank.
c. Disconnect water supply hose from toilet
tank; do not disconnect from the water
supply valve.
3. Connect the top of the T-valve to the
incoming water connection on the bottom
of your toilet tank
4. Connect the water supply line coming from
the wall to the bottom of the T-valve
PRODUCT INSTALLATION
Swash Installation
NOTE: Steps may vary by type of seat
and toilet
NOTES:
You may wish to place a container under
the tank to catch excess water.
Do not continue without completing the
above steps.
Failure to do so could result in flooding,
leaking, or damage to the Swash.
Steps 3,4
Step 2c
Continued following page
NOTES:
The T-valve connects to the fill valve
directly under your toilet tank—it does
not connect at the wall.
Check to ensure the rubber washer sits
flat inside of the T-valve.
Only connect to the cold toilet water
supply line.
If your water supply line is rigid you may
need to replace the water supply line
before continuing.

5. Installing mounting plate
a. Wet the rubber anchors with water,
squeeze the sides of the anchors, and
firmly press them all the way down into
the mounting holes on top of the toilet.
b. Place the mounting plate over the rubber
anchors on the toilet.
c. Place the adjustable brackets flat side
down on the mounting plate over the
rubber anchors.
d. Insert the metal mounting bolts through
the adjustable brackets and rubber
anchors; use a Phillips screwdriver to
screw in the mounting bolts and tighten.
6. Insert the deodorizer cartridge into the back
of the bidet body and attach the deodorizer
cover until it snaps into place.
7. Connect the bidet hose to the seat
Connect the bidet hose to the water inlet
and hand-tighten to secure; take care not
to twist the bidet hose, excessively bend
it, or strip the plastic screw threads when
screwing the hose onto the bidet seat.
8. Attach the bidet seat to the mounting plate
a. Set the bidet seat flat on the toilet bowl
in front of the mounting plate. Slide seat
forward onto plate until it clicks into place
and is secure.
b. If the seat does not align with the front
edge of the toilet bowl, remove the seat
by pressing the quick-release button
located on the right side of the seat and
slide it o the mounting plate.
13
TIP: Wetting the rubber anchors will
allow for easier installation. The top of
the anchors should be flat to the surface.
Steps 5b–5d
Step 6
Step 5a
Continued following page
Step 7

c. Loosen the bolts and slide the mounting
plate back or forth to readjust the
placement; reinstall the seat and check
the alignment to the edge of the toilet
bowl (you may need to remove, readjust,
and reinstall multiple times).
d. When the seat is lined up properly, tighten
the bolts and reinstall the bidet seat.
9. Connect the open end of the bidet hose to
the T-valve
10.Turn on the water supply
a. Open the main water supply valve slowly
and check for leaks.
b. Wait 5 minutes, check again and, if there
are no leaks, continue.
11. Plug the power cord into an electrical
outlet; nozzle will extend and retract.
12.Follow instructions on page 18 for using the
bidet seat
14
PRODUCT INSTALLATION
Swash Installation (Cont’d)
NOTES:
Make sure to only use a grounded GFCI
(ground fault circuit interrupter) electrical
outlet, as in the case of a short circuit, a
grounded GFCI outlet may help prevent
electric shock or injury.
If it is necessary to use an extension
cord, only use those rated for a minimum
of 15 amps with a 3-wire extension cord
and a 3-blade grounding plug.
Step 8
Step 9

15
1. Turn o water supply valve and flush toilet
a. Turn water valve o to stop the flow of
water.
b. Flush toilet and hold down handle to
completely empty tank.
2. Disconnect the bidet hose from the T-valve
3. Connect the female end of the Swash filter
to the open T-valve connection
4. Connect the bidet hose to the male end of
the Swash filter
5. Turn the toilet water supply valve back on
PRODUCT INSTALLATION
External Bidet Filter Installation (optional, not included)
NOTE: Customers with hard water, well
water, and softened water can extend
the life of their bidet seat by purchasing
and installing an external inline water
filter to be used with the bidet seat. The
bidet filter should be changed every 6
months and can be purchased online at
brondell.com.
Step 2
FLOW
Step 4
FLOW
Step 3

16
PRODUCT OPERATION
Control Panel
1115
14
762 3 85
13
9
12
41
10

17
1. Stop Button
Stops all wash and dry functions currently
operating.
2. Rear Wash / Move Button
Press once to initiate a 2-minute rear wash.
Press again to initiate nozzle oscillation
(repetitive forward and backward nozzle
movement).
3. Front Wash / Move Button
Press once to initiate a 2-minute front wash.
Press again to initiate nozzle oscillation
(repetitive forward and backward nozzle
movement).
4. Strong Wash / Move Button
Press once to initiate a 2-minute strong
wash. Press again to initiate nozzle
oscillation (repetitive forward and backward
nozzle movement).
5. Dry Button
Press once to initiate a 2-minute warm air
dryer cycle.
6. Nozzle Position
Press the left or right arrow to adjust the
nozzle position forward and backward
during a wash cycle. The 5 LED indicator
lights will indicate the dierent positions
selected.
7. Nightlight Button
Press to turn the nightlight ON/OFF and to
change the color of the nightlight.
8. Seat Temperature Button and Indicator
Press to adjust the seat temperature to 1 of 4
settings (green/low: 93.2°F, yellow/medium:
98.6°F, red/high: 104°F, and OFF). Settings
will be saved for the next use.
9. Nozzle Cleaning Button
Press to initiate nozzle cleaning when not
sitting on the seat, or when the seat sensor
is deactivated. For more nozzle maintenance
instructions, see page 25.
10. Deodorizer Button
Deodorizer is defaulted to automatically
turn on when seated (indicator light is ON).
Press button to turn the auto deodorizer o
(indicator light is OFF). See page 19 for more
instructions.
11. Water Temperature Button and Indicator
Press to adjust the water temperature to
1 of 4 settings (green/low: 93.2°F, yellow/
medium: 98.6°F, red/high: 104°F, and OFF).
Settings will be saved for the next use.
12.Gentle Wash Button
Press to initiate a gentle wash cycle followed
by a dry cycle. See page 18 for more
instructions.
13. Water Pressure and Dry Temperature
Press the button + or – to adjust the water
pressure during a wash cycle. Press
the same button + or – to adjust the dry
temperature during a dry cycle. The 5 LED
indicator lights will indicate the dierent
positions selected. Settings will be saved for
the next use.
14. Memory User 1 and User 2 Buttons
Press User 1 or User 2 to initiate preferred
settings for a wash. User can set nozzle
position, water pressure, oscillation,
water temperature, and seat temperature
settings to memory. See page 20 for more
instructions.
15.Five LED Indicator Lights
Indicator lights for Level 1 to Level 5 from
right to left indicate nozzle position, water
pressure, and dryer temperature level
settings when those buttons are pressed.

18
PRODUCT OPERATION
Using the Swash: Getting Started
Prepare for Wash
Sit on the seat to ensure skin-to-seat contact
on the seat sensor.
Warm Water Wash
When ready to wash, press the Rear Wash,
Front Wash, or Strong Wash button on the
control panel once to initiate a wash. The
nozzle will perform a self-cleaning rinse,
extend into the toilet bowl, spray for 2 minutes,
turn o automatically, retract, and self-clean
once again.
1. To activate the move function during a
wash, press the Rear Wash, Front Wash,
or Strong Wash button a second time. This
will initiate the nozzle to oscillate forward
and backward, providing a wider wash
spray range. Press again to stop the move
function.
2. While washing, users can adjust the water
temperature, pressure, and nozzle position
settings. See page 17 for details.
3. To stop the wash before the 2-minute cycle
ends, press the Stop button to discontinue
water flow.
Warm Air Dryer Function
Press the Dry button to activate the warm air
dryer. The dryer will run for 2 minutes and turn
o automatically.
1. While the air dryer is operating, users
can adjust the dryer temperature to a
comfortable level using the Dry Temp +
and – button on the control panel. The dry
temperature will be reflected on the 5 LED
indicator lights.
2. To stop the dryer before the 2-minute cycle
ends, press the Stop button.
Gentle Wash
Auto settings within the gentle wash mode are
40% softer than standard wash modes. Gentle
wash will begin a wash that includes:
• full nozzle extension
• water pressure set to level 2
• front wash and oscillation for 1.5 minutes
• warm air dry cycle for 2-minutes set
on level 2
NOTE: The seat has a built-in skin
conductivity sensor. The wash functions
will not work unless the sensor detects
someone is seated. To override the seat
sensor, see instructions on page 22.
NOTE: During a gentle wash cycle, water
pressure and dryer settings may still be
adjusted.

19
Deodorizer
1. The deodorizer is defaulted to automatically
turn on when seated. When the auto
deodorizer is on, the deodorize indicator
light is ON. After leaving the seat, it will
automatically turn OFF after 1 minute.
2. To manually turn OFF the auto deodorizer,
press the Deodorize button and the
indicator light will turn OFF. The deodorizer
will remain o until it is turned back on
again by pressing the Deodorize button.
Nightlight
1. To change the nightlight color, press the
Nightlight button repeatedly to cycle
through and select your preferred color.
2. To turn OFF the nightlight, press and hold
the Nightlight button for 3 seconds. It will
beep twice to indicate it is o.
3. To turn ON the nightlight, press the
Nightlight button for 1 second. It will beep
once to indicate it is on.
Power ON/OFF
1. To power OFF and shut down the bidet
seat, press and hold the Deodorize button
for 3 seconds. The unit will make a tone and
power OFF, shutting down the nightlight,
seat heater, and water heater.
2. To power ON, press and hold the Deodorize
button. The unit will make a tone and power
ON.
Factory Default Reset
1. Factory reset can only be performed when
the seat is not occupied.
2. To reset the bidet seat back to its factory
default program settings, press the Stop
button 4 times within 2 seconds to clear all
current programming.
3. A tone will be heard to confirm that the
bidet seat has been reset.
PRODUCT OPERATION
Special Mode Operations
NOTE: Factory default reset only resets
programming.

20
PRODUCT OPERATION
Special Mode Operation: Memory Functions
User Memory Settings
The Swash User 1 and User 2 memory
functions allow you to program your preferred
wash settings for rear, front, or strong wash
cycles for two users. These settings include
nozzle positioning, water pressure, water
temperature, seat temperature, and move
function. Follow the steps below to program
and use the memory function.
Programming User 1 Memory Function
1. Sit on the seat and select your wash cycle
(rear, front, strong). Adjust the nozzle
position, water pressure, water temperature,
seat temperature, and/or activate move
function, to your preference.
2. Press the Stop button.
3. Press User 1 for 2 seconds. A beep will
occur, and the yellow Deodorize LED
light on the remote will blink to confirm
programming is complete.
4. Repeat instructions for the next wash cycle
you want to program.
Programming User 2 Memory Function
1. Sit on the seat and select your wash cycle
(rear, front, strong). Adjust the nozzle
position, water pressure, water temperature,
seat temperature, and/or activate move
function, to your preference.
2. Press the Stop button.
3. Press User 2 for 2 seconds. A beep will
occur, and the yellow Deodorize LED button
on the remote will blink to confirm the
programming is complete.
4. Repeat instructions for the next wash cycle
you want to program.
Using User 1 and User 2 Memory Function
1. Sit on the seat and select User 1 or User 2.
The deodorize LED light will flash alerting
you that user memory is activated.
2. Press Rear, Front, or Strong Wash
button depending on which cycle was
programmed.
3. The preset nozzle positioning, water
pressure, water temperature, seat
temperature, and move function (if selected)
will be activated.
4. To stop user preset wash before the cycle
ends, press Stop.
5. To exit user preset, press the same user
button again and the deodorize LED light
will turn o. This will revert to the previous
settings.
NOTE: After leaving the seat without
manually exiting, the seat will
automatically revert to the previous
settings.
