Brother Laser Printer
PARTS REFERENCE LIST
MODEL: HL-1030/1240/1250/1270N
Read this list thoroughly before maintenance work.
Keep this list in a convenient place for quick and easy reference at all times.
September, 1999
PL-PRN001

NOTE FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)
Note : No orders without Parts Code or Tool No. can be accepted.
<Example>
REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK
Revision No.: marked on the main printed circuit board.
B48K056 - 201A
Revision No.: marked on the power supply printed circuit board.
Rev. A
2. Design-changed parts :
If the parts are changed, any one of the following symbols is indicated in the REMARKS column.
#A : compatible between old and new
#B : replaceable from old to new
#D : incompatible
# : newly established
3. The original of this list was made based on the information available in September, 1999.
4. Parts are subject to change in design without prior notice.
(1) (4)
(3)
(2)
Design change indication
Specification No .
Pattern alteration No.
Circuit board No.
Design change indication
(The first version has no sign.)

CONTENTS
1. FRAME / DRIVE UNIT .......................................................................... 1
2. LASER UNIT ......................................................................................... 1
3. PAPER FEEDER .................................................................................. 3
4. FIXING UNIT......................................................................................... 5
5. PAPER CASSETTE ......................................................................... 7AB
6. COVERS............................................................................................... 9
7. MAIN PCB........................................................................................... 11
8. ENGINE PCB...................................................................................... 13
9. LOW-VOLTAGE POWER SUPPLY PCB............................................ 13
10. HIGH-VOLTAGE POWER SUPPLY PCB........................................... 15
11. AC CORDS ......................................................................................... 15
12. ACCESSORIES .................................................................................. 17
13. PACKING MATERIALS ...................................................................... 19
14. NETWORK BOARD ............................................................................ 19
15. ADJUSTING TOOL ............................................................................. 21

1. FRAME / DRIVE UNIT
PR2002157
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1UL9311001 1MAIN MOTOR ASSY
2 087320616 4 TAPTITE, CUP S M3X6
3LJ4069001 1SOLENOID ASSY
4 000300415 1 SCREW, BIND M3X4
5LJ4432001 1TAPE 32X12
6UL8984001 1LINK
7LJ4745001 1FAN MOTOR UNIT
8UL9099001 1TONER EMPTY PCB UNIT (LIGHT EMISSION) B512038
9UK4405001 1PANEL PCB ASSY B512048
10 087320616 3 TAPTITE, CUP S M3X6
11 LJ7403001 4RUBBER FOOT
12 UL9104001 1TONER EMPTY PCB UNIT (LIGHT RECEPTION) B512037
13 087320616 2 TAPTITE, CUP S M3X6
14 LJ8031001 1LT RELAY PCB ASSY, HL-1250/1270N B512060
15 087320616 1 TAPTITE, CUP S M3X6
16 LE1169001 1USB GROUND PLATE, HL-1270
17 UL8970001 1SOLENOID RELEASE SPRING 30/99
18 LJ5591001 1PLANET GEAR ASSY (SP)
18 LJ5838001 1PLANET GEAR ASSY B (SP)
19 UL8985001 1GEAR 59
20 LJ5705001 1GEAR 21 PRESSURE PLATE
21 087320616 1 TAPTITE, CUP S M3X6
22 UL8972001 1P/R CLUTCH LEVER
23 UL8971001 1F/R CLUTCH LEVER
24 UL8982001 1DEVELOP JOINT
25 UL8983001 1JOINT SPRING
26 UL8959001 1FRICTION SPRING DELETE
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-010
T/I NO. PR99165 / PR2000014 / PR2000073 / PR2000132 / PR2000152 / PR2001023 / PR2001049
PR2001061/ PR2001100 / PR2002013 / PR2002098 / PR2002139 / PR2002157
2. LASER UNIT
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1LJ4157001 1LASER UNIT (SP) (B512033)
2 087321615 3 TAPTITE, CUP S M3X16
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-020
- 1 -

MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-010
1. FRAME / DRIVE UNIT
2. LASER UNIT
- 2 -
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-020
22
2
1
PR2002098
T/I NO.PR99165 / PR2000014 / PR2000073 / PR2000152 / PR2001023 / PE2001049 / PR2001061
/ PR2001100 / PR2002013 / PR2002098
18
20
4
1
14
69
11
5
11
11
11
12
13
2
10
7
16
8
15
10
2
19
21 26 3
17
23 22
25
24

3. PAPER FEEDER
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1UL9060001 1PAPER FEED ROLLER ASSY
2UL9066001 1PAPER PICK-UP ROLLER ASSY
3UL9071001 1TR ELECTRODE HELICAL SPRING A
3LJ4499001 1TR ELECTRODE HELICAL SPRING B
4LJ4843001 1OUTER CHUTE 1 (SP)
5UL9070001 1GEAR 21
6UL9059001 1JOINT 5
7UL9062001 1BEARING 5
8UL9069001 1CONDUCTOR BEARING 5
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-040
T/I NO. PR2000051 / PR2000108 / PR2000130
CAUTION:
1) The new version of the TR electrode helical spring, TR ELECTRODE HELICAL SPRING B
(LJ4499001) should be used for ALL HL-1030/1270N printers and the HL-1240/1250 printers
whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old version of the TR electrode helical spring, TR ELECTRODE HELICAL SPRING A
(UL9071001) should be used for HL-1240/1250 whose serial No. is before the number above
and the numbers in the range of J9J212235 - J9J217459 & J9J219423 - J9J219997.
3) The old and new versions of the TR electrode helical spring are incompatible with each
other.
- 3 -

3. PAPER FEEDER
- 4 -
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-045/047
PR2000130
T/I NO. PR2000051 / PR2000108 / PR2000130
2
3
1
4
5
6
8
7

4. FIXING UNIT PR2002144
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ7759001 1 FIXING UNIT, 115V (SP) CHNG
1 LJ7760001 1 FIXING UNIT, 230V (SP) CHNG
1 LJ4718001 1 FIXING UNIT, 230V LEG (SP)
1-1 UL8902001 1 THERMISTOR ASSY
1-2 087311215 1 TAPTITE, CUP B M3X12
1-3 LJ4169001 1 HEAT ROLLER 25 (SP)
1-3 LJ4719001 1 HEAT ROLLER 25 LEG (SP)
1-4 UL8908001 2 HR BEARING 25
1-5 LJ4160001 1 HALOGEN LAMP, 115V (SP)
1-5 LJ4163001 1 HALOGEN LAMP, 230V (SP)
1-6 UL8929001 8 EJECT PINCH ROLLER
1-7 LJ4431001 8 PINCH SPRING
1-8 LJ4407001 2 CLEANER ROLLER ASSY
1-9 LJ4409001 2 CLEANER SPRING
1-10 087312015 2 TAPTITE, CUP B M3X20
1-11 Z07200001 1 TAPTITE, PAN B M3X10
1-12 LJ4845001 4 PICK OFF FINGER (SP)
1-13 LJ4853001 1 PRESSURE ROLLER 20 (SP)
1-13 LJ4852001 1 PRESSURE ROLLER 20 LE (SP)
1-14 UL8920001 1 PAPER EJECT ACTUATOR
1-15 UL8921001 1 EJECT ACTUATOR SPRING
1-16 UL8914001 2 IDLE GEAR 13
1-17 LJ5871001 1 IDLE GEAR HOLDER
1-18 UL8923001 1 FU DRIVE GEAR 20/38 ADD
1-19 LJ7256001 1 EJECT ROLLER SHAFT L ADD
1-20 LJ7257001 1 EJECT ROLLER ASSY R ADD
1-20-1 LJ7258001 1 EJECT ROLLER SHAFT R ADD
1-21 LJ7259001 1 EJECT ROLLER BUSHING L ADD
1-22 LJ7260001 1 EJECT ROLLER BUSHING R ADD
1-23 LJ7261001 1 FU FRAME LOWER 2 ADD
1-24 LJ7262001 1 EJECT ROLLER JAM REMOVE TOOL ADD
2 087320815 1 TAPTITE, CUP S M3X8
3 LJ4740001 2 SHOULDER SCREW
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-050/051
T/I NO. PR99179, PR99186, PR2000029, PR2000057, PR2000157,PR2001118 / PR2002091 /
PR2002144
- 5 -

4. FIXING UNIT
- 6 -
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-045/047
T/I NO. PR2000029 / PR2000057 / PR2001118 / PR2002091
PR2002091
1-10 1-11
1-6
1-7
1-7
2
1-6
1-6
1-7
1-7
1-6
3
1-10
1
1-1
1-9
1-8
1-13
1-16
1-17
1-18
1-2
1-9
1-8
1-12
1-12
1-12 1-12
1-15
1-14
3
1-4
1-3
1-4
1-5

5-1. PAPER CASSETTE, LGL PR2002009
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LE1162001 1PAPER TRAY ASSY, LGL (SP)
1-1 LJ4537001 1PRESSURE PLATE ASSY, LGL
1-2 UL9077001 2PRESSURE PLATE SPRING
1-3 UL9078001 1SIDE GUIDE L
1-4 UL9079001 1SIDE GUIDE R
1-5 U73515001 2TAPTITE, CUP B M2.6X5
1-6 UL9080001 2SIDE GUIDE RACK
1-7 UL9081001 1SIDE GUIDE GEAR
1-8 UL9082001 1FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1REAR PAPER GUIDE
1-11 UL9084001 1SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1SEPARATION PAD SPRING
1-13 UL9091001 1PAPER INDICATOR
1-14 UL9092001 1LOCK LEVER
1-15 LJ4534001 1PRESSURE ROLLER HOLDER, LGL
1-16 LJ4892001 1PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1PAPER TRAY COVER
1-19 UF8709001 1TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1TRAY COVER FILM
1-21 LJ4221001 1SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2SCRATCH SPONGE SPRING
1-23 LJ4865001 1MYLAR LABEL 1240 TRAY
1-24 LJ4332001 1TRAY FEED GUIDE ASSY ADD
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-045
T/I NO. PR2000066 / PR2000127 / PR2002009
5-2. PAPER CASSETTE, A4 PR2002009
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LJ4181001 1PAPER TRAY ASSY, A4 (SP)
1-1 UL9074001 1PRESSURE PLATE ASSY, A4
1-2 UL9077001 2PRESSURE PLATE SPRING
1-3 UL9078001 1SIDE GUIDE L
1-4 UL9079001 1SIDE GUIDE R
1-5 U73515001 2TAPTITE, CUP B M2.6X5
1-6 UL9080001 2SIDE GUIDE RACK
1-7 UL9081001 1SIDE GUIDE GEAR
1-8 UL9082001 1FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1REAR PAPER GUIDE
1-11 UL9084001 1SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1SEPARATION PAD SPRING
1-13 UL9091001 1PAPER INDICATOR
1-14 UL9092001 1LOCK LEVER
1-15 LJ4196001 1PRESSURE ROLLER HOLDER, A4
1-16 LJ4892001 1PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1PAPER TRAY COVER
1-19 UF8709001 1TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1TRAY COVER FILM
1-21 LJ4221001 1SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2SCRATCH SPONGE SPRING
1-24 LJ4332001 1TRAY FEED GUIDE ASSY ADD
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-047
T/I NO. PR2000127 / PR2002009
- 7A -

5-3. PAPER CASSETTE, PB
PR2002009
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LJ4639001 1PAPER TRAY ASSY 3 (SP)
1-1 UL9074001 1PRESSURE PLATE ASSY, A4
1-2 LJ4621001 2PRESSURE PLATE SPRING 340
1-3 UL9078001 1SIDE GUIDE L
1-4 UL9079001 1SIDE GUIDE R
1-5 U73515001 2TAPTITE, CUP B M2.6X5
1-6 UL9080001 2SIDE GUIDE RACK
1-7 UL9081001 1SIDE GUIDE GEAR
1-8 UL9082001 1FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1REAR PAPER GUIDE
1-11 UL9084001 1SEPARATION PAD HOLDER ASSY
1-12 LJ4705001 1SEPARATION PAD SPRING 300
1-13 UL9091001 1PAPER INDICATOR
1-14 UL9092001 1LOCK LEVER
1-15 LJ4196001 1PRESSURE ROLLER HOLDER
1-16 LJ4893001 1PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1PAPER TRAY COVER
1-19 UF8709001 1TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1TRAY COVER FILM
1-21 LJ4221001 1SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2SCRATCH SPONGE SPRING
1-24 LJ4332001 1TRAY FEED GUIDE ASSY ADD
MODEL HL-1240 84U-Z01-049
T/I NO. PR99179 / PR2000127 / PR2002009
5-4. PAPER CASSETTE, LEG PR2002009
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LJ4684001 1PAPER TRAY ASSY, LEG (SP)
1-1 UL9074001 1PRESSURE PLATE ASSY, A4
1-2 UL9077001 2PRESSURE PLATE SPRING
1-3 UL9078001 1SIDE GUIDE L
1-4 UL9079001 1SIDE GUIDE R
1-5 U73515001 2TAPTITE, CUP B M2.6X5
1-6 UL9080001 2SIDE GUIDE RACK
1-7 UL9081001 1SIDE GUIDE GEAR
1-8 UL9082001 1FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1REAR PAPER GUIDE
1-11 UL9084001 1SEPARATION PAD HOLDER ASSY
1-12 LJ4622001 1SEPARATION PAD SPRING 250
1-13 UL9091001 1PAPER INDICATOR
1-14 UL9092001 1LOCK LEVER
1-15 LJ4196001 1PRESSURE ROLLER HOLDER, A4
1-16 LJ4892001 1PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1PAPER TRAY COVER
1-19 UF8709001 1TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1TRAY COVER FILM
1-21 LJ4221001 1SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2SCRATCH SPONGE SPRING
1-24 LJ4332001 1TRAY FEED GUIDE ASSY ADD
MODEL HL-1240/1250/1270N 84U-Z06/Z07/08-043
T/I NO. PR99179 / PR2000127 /PR20002009
- 7B -

6. COVERS PR2002052
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LJ5753001 1MAIN COVER ASSY
1-1 LJ7292001 1HEAT PROTECTION FILM ADD
2UL9122001 4PINCH ROLLER ASSY
3UL9125001 4PINCH ROLLER SPRING
4LJ5763001 1REAR COVER
5UL9127001 1REAR COVER SPRING L
6UL9128001 1REAR COVER SPRING R
7UL9129001 1FRONT COVER ASSY
7LJ4526001 1FRONT COVER ASSY LE
8UL9140001 1TRAY EXTENSION FLAP
9UL9088001 1TOP COVER
10 UL9142001 1SECOND EJECT ROLLER ASSY
11 087321015 2 TAPTITE, CUP S M3X10
12 085320816 6 TAPTITE, BIND S M3X8
13 LJ8166001 1MODEL PLATE 1030
13 UL9143001 1MODEL PLATE 1240
13 UL9315001 1MODEL PLATE 1250
13 LJ4794001 1MODEL PLATE 1270
13 LJ4135001 1MODEL PLATE 1270N
13 LJ4452001 1MODEL PLATE J624
13 LJ4460001 1MODEL PLATE 2312P
13 LJ4496001 1MODEL PLATE 2412P
13 LJ4724001 1MODEL PLATE 8212N
13 LJ4772001 1MODEL PLATE 1500 WIP
13 LJ4846001 1MODEL PLATE 1700 WIP
13 LJ4848001 1MODEL PLATE 1900 WIP
14 UL6740001 1LASER CAUTION LABEL, EUR
14 UL7931001 1LASER LABEL LEGEND
15 LJ8167001 1MYLAR LABEL 1030, CAN
15 LJ8172001 1MYLAR LABEL 1030, EUR
15 UL9146001 1MYLAR LABEL 1240, US
15 UL9249001 1MYLAR LABEL 1240, CAN
15 UL9250001 1MYLAR LABEL 1240, EUR
15 UL9316001 1MYLAR LABEL 1250, US
15 LJ4078001 1MYLAR LABEL 1250, CAN
15 UL9317001 1MYLAR LABEL 1250, EUR
15 LJ4136001 1MYLAR LABEL 1270N, US
15 LJ4232001 1MYLAR LABEL 1270N, CAN
15 LJ4137001 1MYLAR LABEL 1270N, EUR
16 LJ4905001 1FAN GUARD
17 UL9145001 1PROCESS UNIT OP LABEL
18 LJ4855001 1TRAY REAR COVER ASSY
19 LJ5834001 1TRAY REAR COVER LGL ASSY
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-060
T/I NO. PR99165 / PR99179 / PR99204 / PR2000005 / PR2000055 / PR2000066 / PR2000075 /
PR2000108 / PR2000129 / PR2002017/ PR2002052
- 9 -

6. COVERS
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-060
- 10 -
7
17
15
1
12
12
12
16
9
11
11
8
6
2
5
10
13
18
4
3
3
2
12
14
T/I NO. PR2000066 / PR2000075 / PR2000108 / PR2000129

7. MAIN PCB PR2002121
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1LJ8239001 1MAIN PCB ASSY, HL-1030 US (SP) B512040-450F NAME CHNG
1LJ8309001 1MAIN PCB ASSY, HL-1030 EU (SP) B512040-477F
1LJ8066001 1MAIN PCB ASSY, HL-1240 US (SP) B512040-410H NAME CHNG
1LJ8303001 1MAIN PCB ASSY, HL-1240 EU (SP) B512040-447H
1LJ8067001 1MAIN PCB ASSY, HL-1240 HEB (SP) B512040-411B
1LJ8251001 1MAIN PCB ASSY, HL-1240 PB (SP) B512040-445H
1LJ8160001 1MAIN PCB ASSY, 2312P LEG (SP) B512040-413F
1LJ8318001 1MAIN PCB ASSY, HL-1250-2 US (SP) B512115-160C NAME CHNG
1LJ8305001 1MAIN PCB ASSY, HL-1250-2 EU (SP) B512115-177C
1LJ8306001 1MAIN PCB ASSY, HL-1250-2 DEN (SP) B512115-178C
1LJ8326001 1MAIN PCB ASSY, HL-1250-2 LEG (SP) B512115-163D
1LJ8328001 1MAIN PCB ASSY, HL-1270N-2 US (SP) B512115-180B NAME CHNG
1LJ8307001 1MAIN PCB ASSY, HL-1270N-2 EU (SP) B512115-197B
1LJ8308001 1MAIN PCB ASSY, HL-1270N-2 DEN (SP) B512115-198B
1LJ8329001 1MAIN PCB ASSY, HL-1270N-2 LEG (SP) B512115-163A
1-1 LJ8295001 1MASK ROM, HL-1030/1240
1-1 LJ8047001 1MASK ROM, HL-1240 HEB
1-1 LJ8797001 1MASK ROM, HL-1250
1-1 LJ8310001 1MASK ROM, HL-1270N
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-101/103
T/I NO. PR99165 / PR99179 / PR99194 / PR99198 / PR99203 / PR99207/ PR2000015 / PR2000074 /
PR2000109 / PR2000124 / PR2000134 / PR2001060 / PR2001067 / PR2001127 /PR2002121
- 11 -

7.MAIN PCB
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-101/103
- 12 -
HL-1030 1
1-1
HL-1250
1
1-1
1-1
HL-1270/1270N
1
HL-1240 1
1-1
T/I NO. PR99165 / PR2000124

8. ENGINE PCB PR2002097
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1LJ4178001 1ENGINE PCB ASSY A, 1240 (SP) B512059-101D VER.CHNG.
1LJ8157001 1ENGINE PCB ASSY B, 1030/1240 (SP) B512075-121D
1LJ4222001 1ENGINE PCB ASSY A, 1250 (SP) B512059-102D VER.CHNG.
1LJ8158001 1ENGINE PCB ASSY B, 1250/1270 (SP) B512059-122C VER.CHNG.
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-151
T/I NO. PR99165 / PR99197 / PR99202 / PR99213 / PR2000016 / PR2000121
9. LOW-VOLTAGE POWER SUPPLY PCB
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1LG4015001 1PS PCB ASSY ZLE-B,115V
1LG4016001 1PS PCB ASSY ZLE-B,230V
2UK4426001 1INLET UNIT, 115V
2UK4430001 1INLET UNIT, 230V
3 085320816 1 TAPTITE, BIND S M3X8
4 087320616 1 TAPTITE, CUP S M3X6
5LJ4756001 1AC INLET FILM
6LJ8330001 1PROTECTION TUBE
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-200/201
T/I NO. PR99188 / PR99189 / PR2000113 / PR2001064 / PR2002097
CAUTION:
1) The new versions of the engine PCB, ENGINE PCB ASSY B, 1240/1030 (LJ8157001) &
ENGINE PCB ASSY B, 1250/1270 (LJ8158001) should be used for ALL HL-1030/1270N
printers and the HL-1240/1250 printers whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old versions of the engine PCB, ENGINE PCB ASSY A, 1240 (LJ4178001) & ENGINE
PCB ASSY A, 1250 (LJ4222001) should be used for HL-1240/1250 whose serial No. is before
the number above and the numbers in the range of J9J212235 - J9J217459 & J9J219423 -
J9J219997.
3) The old and new versions of the engine PCB are incompatible with each other.
- 13 -

MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-151
8. ENGINE PCB
9. LOW-VOLTAGE POWER SUPPLY PCB
- 14 -
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-200/201
1
T/I NO. PR99188 / PR2000113
1
3
4
6
5
2

10. HIGH-VOLTAGE POWER SUPPLY PCB PR2002011
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1LJ4176001 1HIGH-VOLTAGE PS ASSY A (SP)
1LJ8156001 1HIGH-VOLTAGE PS ASSY B (SP)
2 085411215 4 SCREW BIND B TITE M4X12
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-220
T/I NO. PR99153, PR99165
11. AC CORDS
REF.NO.
CODE Q'TY DESCRIPTION REMARK
1A LJ8875001 1AC CORD, UL/CSA CODE CHNG
1B LJ8879001 1AC CORD ASSY, SAA CODE CHNG
1C LJ8877001 1AC CORD ASSY, SEV CODE CHNG
1D UK4099001 1AC CORD, CHLI
1E UH1054001 1AC CORD, BS
1F U34322001 1AC CORD #6, ISRAEL
1G U34320001 1AC CORD #4, BS
1H UK4094001 1AC CORD, DEMKO
1I LJ8876001 1AC CORD ASSY, VDE CODE CHNG
1J UK3610001 1AC CORD ASSY, CHN96
1K LJ8288001 1AC CORD ASSY, IND
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-230
T/I NO. PR99179, PR2000055,PR2002011
CAUTION:
1) The new version of the high-voltage power supply PCB, HIGH-VOLTAGE PS ASSY B
(LJ8156001) should be used for ALL HL-1030/1270N printers and the HL-1240/1250 printers
whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old version of the high-voltage power supply PCB, HIGH-VOLTAGE PS ASSY A
(LJ4176001) should be used for HL-1240/1250 whose serial No. is before the number above
and the numbers in the range of J9J212235 - J9J217459 & J9J219423 - J9J219997.
3) The old and new versions of the high-voltage power supply PCB are incompatible each
other.
- 15 -

MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-220
10. HIGH VOLTAGE POWER SUPPLY PCB
11. AC CORD
- 16 -
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-23 0
1A
1B
1C
1D
1E
1F
1G
1H
1I
1J
1K
2
1
2
T/I NO. PR99179 / PR2000055
