Brother HL-4000CN Assembly instructions

OFF ON
OFF ON
OFF ON
OFF ON
1Turn off the printer power switch.
7Follow the instructions on
the screen.
The Setup is now complete.
Step 5 Connect the Printer to Your Network
and Install the Adobe PostScript3 PPD File and
AdobePS Driver
2Connect the network interface cable to the printer,
and then connect it to a free port on your hub.
For Mac®OS 8.6 to 9.2 Users Only
Step 5 Connect the Printer to Your Network
and Install the Adobe PostScript3 PPD File
For Mac®OS X 10.1 Users Only
3Turn on the printer power switch.
8Open the Chooser from the Apple menu.
6Click the Install Software icon
on the Menu screen.
5Double-click the Start Here! icon.
Follow the instructions on the
screen.
4Insert the CD-ROM into
your CD-ROM drive.
4Insert the CD-ROM into your CD-ROM drive.
Double-click the HL-4000CN icon.
6Double-click the
PPD_Installer.pkg icon.
Follow the instructions on
the screen.
5Open the Mac OS X folder.
1Turn off the printer power switch. 2Connect the network interface cable to the printer,
and then connect it to a free port on your hub. 3Turn on the printer power switch.
7Open the Macintosh HD
icon. 8Open the Applications folder.
Open the Utilities folder. 9Open the Print Center icon.
10 Click the Add Printer button. 11 Select AppleTalk.12 Select BRN_xxxxxx_P1_AT*2,
and then click the Add button. 13 Select Quit Print Center from the Print
Center menu.
The setup is now complete.
*1 xxxxxx are the last six digits of the Ethernet address. For more information, see Chapter 7 of the Network User’s Guide.
*2 xxxxxx are the last six digits of the Ethernet address. For more information, see Chapter 7 of the Network User’s Guide.
9Click the AdobePS icon, and then select
BRN_xxxxxx_P1_AT. *1
Close the Chooser.
Steps 1 to 4 Follow these steps in the Quick Setup Guide first.
©2002 Brother Industries, Ltd. ALL RIGHTS RESERVED
Apple Macintosh, iMac, LaserWriter, and AppleTalk are trademarks of Apple Computer, Inc. Adobe PostScript and PostScript3 are trademarks of Adobe Systems Incorporated.
All other brand and product names mentioned in this guide are registered trademarks of their respective companies.
LM0110001 Printed in Japan
Before you continue, please make sure that the administrator has configured the network printer settings
correctly by referring to the Network Quick Setup Guide.
Follow the instructions in this guide for your operating system.
Driver Installation Guide
Macintosh® For Network Users
Color Laser Printer HL-4000CN
Hub
Hub
Display
LED indicators Buttons
Control Panel
Lights when the printer is ready to print.
Blinks when the printer is receiving data.
Lights when the printer has a problem.
Blinks when the printer has a problem that the user cannot rectify. Contact your dealer or Brother authorized service representative.
Lights when the printer has paper jams. Open the front cover with the indicated button to clear the jamed paper.
Print screen mode
Go back to the menu screen mode.
N/A
N/A
Force the remaining print data to be output.
Cancel printing.
Ready (Green)
Alarm (Red)
LEDs
Buttons
Menu
Form Feed / Set
Job Cancel / Back
Menu screen mode
Close the menu screen mode and switch to the print screen mode.
Scroll through menus and menu items.
Moves the displayed menu one level down.
Moves the displayed menu one level up.
Select menus and menu items.
Moves the displayed menu one level down.
Sets the displayed parameter.
Moves the displayed menu one level up.
Language Setting (Default is English):
When you want to change the language of the control panel message, refer to “Setting Your Language on
the Control Panel” in the Network Quick Setup Guide (the reverse side of the Quick Setup Guide).
For more information, see “CONTROL PANEL” in chapter 5 of the User’s Guide on the supplied CD-ROM.
Macintosh®
Macintosh®

OFF ON
6
Open the Macintosh
HD icon.
1Connect the USB interface cable to your
Macintosh®, and then connect it to the
printer.
1
Click the HL-4000CN icon on the Desktop.
The setup is now complete.
2
Select Set Default Printer from the Printing menu.
Step 6 Connect the Printer to Your Macintosh®
and Install the Adobe PostScript3 PPD File and AdobePS Driver
Step 5 Set the Adobe Protcol
Step 7 Setting Your Printer as the Default Printer
7
Open the AdobePS
Components folder.
For Mac®OS 8.6 to 9.2 Users Only
Step 5 Connect the Printer to Your Macintosh®
and Install the Adobe PostScript3 PPD File
For Mac®OS X 10.1 Users Only
8
Open the Desktop Printer Utility
icon.
9
Select Printer (USB), and
then click the OK button.
12
Click the Create... button.
11 Click the Change... button in USB Printer Selection.
Select HL-4000CN, and then click the OK button.
10 Click the Change... button in PostScriptTM Printer
Description (PPD) file.
Select Brother HL-4000CN, and then click the Select
button.
13 Enter your printer name (HL-4000CN),
and then click the Save button. 14
Select Quit from the File menu.
5Follow the instructions on the
screen.
2Insert the CD-ROM into
your CD-ROM drive. 3Double-click the Start Here! icon. Follow the instructions on the
screen.
3Insert the CD-ROM into your
CD-ROM drive.
Double-click the HL-4000CN
icon.
5Double-click the PPD_Installer.pkg icon.
Follow the instructions on the screen.
4Open the Mac OS X folder.
1Make sure the printer
power switch is on. 2Connect the USB interface cable to your Macintosh®, and then connect it to the printer.
6Open the Macintosh HD icon.
7Open the Applications folder.
Open the Utilities folder. 8Open the Print Center icon.
9Click the Add Printer button. 10 Select USB.
12 Select HL-4000CN from the
Printer Model pop-up menu. 13 Click the Add button.
11 Select HL-4000CN.
14 Select Quit Print Center from the Print
Center menu.
The setup is now complete.
4Click the Install Software icon
on the Menu screen.
Steps 1 to 4 Follow these steps in the Quick Setup Guide first.
Follow the instructions in this guide for your operating system.
Driver Installation Guide
Macintosh®For USB Users
Turn the printer off.
Turn the printer back on.
3 seconds later, an asterisk ( *)
appears.
System1:
Menu
USB6:
Menu
Adobe Pro t oco l
USB6:
Adobe Pro t oco l
TBCP *
Adobe Pro t oco l
RAW
Reboo t sys t em
to take ef fect
Adobe Pro t oco l
AW *
Press .
1
Press 5 times.
2
Press .
5
Press .
3
Press .
4Press .
6
OFF ON
OFF ON
Note: To change the language of the control panel messages, see “Setting Your Language on the Control
Panel”in the Network Quick Setup Guide (the reverse side of the Quick Setup Guide).
7R
Macintosh®
Macintosh®
NETWORK READYNETWORK READY
Ready t o Pr i n t
