Broyhill CRESTFIELD GBO23-903 User manual

ASSEMBLY INSTRUCTIONS
ITEM# : GBO23-903
SKU# : 810580279
CRESTFIELD 3PC GLIDER SET
Need help? We are here for you! 1-888-733-8169 Toll Free
Or email us at [e-mail],[e-mail]
[e-mail]

Read all instructions before starting
Clear a flat covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its letter in the package
Helpful hints provided along the way
Retain these assembly instructions for future reference.
WARNINGS:
Use the correct bolts as indicated. All bolts should be hand tightened until the complete piece is assembled ( This will make the assembly
process much easier ). Once the piece is fully assembled, then go back and tighten all bolts with provided tool.
Regularly check hardware and tighten if necessary.
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair and table are completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children and pets away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Chair is for sitting purposes only. The table is not to be used for standing purposes and will not function as a stool or step-ladder.
Standing on or misuse of chair and table may result in damage or injury.
Chair weight limit is 300 lbs ( 136.4 kg). Not intended for commercial use.
MAINTENANCE
Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on
the frame or fabric parts.
The cushions may be washed on the surface only by using mild soap and water or a commercial foaming upholstery cleaner if necessary.
If washed, rinse well and hang to dry. Do not machine wash or dry.
Well recommend the use of furniture covers when not in use.
Inspect and tighten all of the bolts and fasteners on a regular basis to ensure the proper performance and safety of your chair and table.
In order to prolong the life and beauty of your chair and table, we recommend that it be stored in a dry and protected area during off season
periods.
GENERAL BEST PRACTICE FOR ASSEMBLY:
WARNINGS:
MAINTENANCE:

PARTS LIST
Part No. Part Qty Image Part No. Part Qty Image
1Chair Back 110 Bolt (M6x36mm) 6
2Seat Panel Frame 111 Bolt (M6x41mm) 2
3Seat Panel Cloth 112 Bolt (M6x44mm) 4
4Right Arm 113 Washer 20
5Left Arm 114 Nut 4
6U-shaped Fitting 115 Spring Washer 4
7Chair Base 116 Seat Cushion 1
8Short Bolt (M6x28mm) 417 Back Cushion 1
9Long Bolt (M6x48mm) 4
Tool
PARTS LIST FOR 1 GLIDER:

STEP 2
PART REQUIRED: 6, 7
Keep the bolts loose.
PRODUCT FRAME MAP
1
5
4
3
2
6
7
STEP 1
9
14
15
X4
X8
X4
X4
13
13
15
7
6
13
14
9

STEP 2
PART REQUIRED: 2, 3
Keep the bolts loose.
STEP 3
PART REQUIRED: 1
Keep the bolts loose.
STEP 3
10
X2
X4
X2
X2
13
10
1
3
2
13
10
13
11
13
11
STEP 2
X2
10
13
10

STEP 4
PART REQUIRED: 5
Keep the bolts loose.
PART REQUIRED: 4
Keep the bolts loose.
STEP 4
X1
X3
X3
X1
13
10
X2
12
13
10
13
12
5
13
10
X2
12
13
10
13
12
4
STEP 5

PART REQUIRED: 2, 6 & 7
Keep the bolts loose.
PART REQUIRED: 16 & 17
Fully tighten all the bolts, then put the cushions (16)
and (17) on the chair. Finished!
Caution:
To ensure one's safety during use of this swivel glider, make sure that all of the bolts are completely tightened.
The chair has the ability to swivel and glider; therefore use by young children should be under adult supervised.
Warranty
One year limited warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
It remains the customer's responsibility for freight and packing charges to and from the service center.
STEP 6
X4
STEP 7
8
8
2
6
7
17
16

PARTS LIST
Part No. Part Qty Image Part No. Part Qty Image
1Table Top 1 4Short Bolt (M6x20mm) 2
2Table Support 1 5Long Bolt (M6x31mm) 4
3Table Leg 2 6Washer 6
Tool
PART REQUIRED: 1 & 2PC 3
Keep the bolts loose.
PARTS LIST:
STEP 1
X4
X4
6
5
1
3
6
5
3

STEP 2
PART REQUIRED: 2
Tighten all bolts by using the supplied Tool.
STEP 3
Warranty
One year limited warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
It remains the customer's responsibility for freight and packing charges to and from the service center.
STEP 2
X2
X2
STEP 3
4
6
6
4
2
