Broyhill H22SO2080-1 User manual

ASSEMBLY INSTRUCTION
ITEM#: H22SO2080-1
SKU#: 810588248
Need help? We are here for you! 1 (877) 800 – 6021 • Toll Free
[email protected] • Email Address
PEMBROKE CUSHION OTTOMAN

Read all instructions before starting
Clear a flat covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its letter in the package
Helpful hints provided along the way
MAINTENANCE:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
Retain these assembly instructions for future reference.
Wash frame, wicker and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame, wicker or fabric parts.
The cushions may be washed on the surface only by using mild soap and water or a commercial foaming upholstery
cleaner if necessary. If washed, rinse well and hang to dry. Do not machine wash or dry.
We recommend the use of furniture covers when not in use.
Inspect and tighten all of the bolts and fasteners on a regular basis to ensure the proper performance and safety of your
ottoman.
In order to prolong the life and beauty of your ottoman, we recommend that it be stored in a dry and protected area
during off season periods.
Regularly check hardware and tighten if necessary
Use the correct bolts as indicated. Do not tighten any of the bolts until the ottoman is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Standing on or misuse of ottomans may result in damage or injury.
PAGE 1 OF 3
To Ensure Alignment & Easy Assembly, Secure All Bolts & Washers In Place Before Fully Tightening

PARTS LIST
1
1
8
4
HXVS018B-JK
LS-M6-45
SEAT ASSEMBLY
PART
NO. MATERIAL CODE PART Q’TY
1
2
4
3
5
8
HXVS018B-JD
PLASTIC LEG CAP
BOLT M6*45
CUSHION
HXVS018B-MD
STEP 1
PAGE 2 OF 3
500 10 20 30 40 60 70 80 90
mm 100
Tools
DP-d6.5-D13
WASHER d6.5*D13*1.0
PARTS REQUIRED: 1, 2, 3, & 4
Tighten all bolts by using the supplied Hex key.
x4 x8
2 3
x8
4
2
3
4
3
4
1
22
2
2

STEP 2
PARTS REQUIRED: 5
5
Warranty
•One–year limited warranty.
•Proof of purchase (dated register receipt) is required for warranty claims.
•It remains the customer’s responsibility for freight and packing charges to and from the service center.
PAGE 3 OF 3
The store where you made your purchase does not stock parts for this item.
If you need parts, whether they are missing or damaged,
STOP!
Missing A Part? No Need To Go Back To The Store
Call us between 9:00 AM and 4:30 PM Eastern Time Monday through Friday
For further assistance, please visit us at [email protected]
Call Toll Free:
TEL: [phone]
