Brunner cellular User manual

cellular
Assembly instructions
Design: Archirivolto

Thank you for buying a quality Brunner product from the cellu-
lar series. The versatile furniture in our cellular range is perfect
if you are looking to furnish small quiet areas and workspaces in
large halls and waiting areas. Available with or without panels,
these versatile chairs and benches can be used in a myriad of
ways.
Thanks to the 60° angled construction of the work and lounging
units, they can be set out in groups, lines or circles, making best
use of available space. Side tables that can be exibly positioned
make for the ideal addition to the range.
If upholstered easy chairs, work tables or standing tables are
ordered with panels, the panels have to be tted on site. These
assembly instructions provide an explanation of all of the key
components and will help you assemble your cellular furniture
with ease.

CELLULAR ASSEMBLY INSTRUCTIONS
Contents
4
6
7
8
12
13
14
15
16
17
18
19
26
26
26
27
30
30
Overview of variants
Scope of delivery of upholstered easy chair with panels CE1100
Scope of delivery of upholstered sofa withpanelsCE2300
Assembly instructions for upholstered easy chair and sofa with panels
Scope of delivery of desk with panels CE1070
Scope of delivery of desk with panels CE1080
Scope of delivery of desk with panels CE4010
Scope of delivery of desk with panels CE4030
Scope of delivery of desk with panels CE3100
Scope of delivery of desk with panels CE3200
Base and panel pre-assembly
Assembly instructions for desk with panels
Further information
General information about assembly
Recommended assembly tool
Care instructions
Notes
Imprint

OVERVIEW OF VARIANTS
CE0100
CE0300
CE1100
CE2300

OVERVIEW OF VARIANTS
Overview of variants 4 . 5
CE1070
CE4010
CE3100
CE1080
CE4030
CE3200

SCOPE OF DELIVERY OF UPHOLSTERED EASY CHAIR
WITHPANELSCE1100
Included in scope of delivery:
12 x 5x30 Spax screws
1 x left-hand panel
1 x easy chair
1 x M5x35 screws
4 x brackets
1 x right-hand panel
4 x M5x16 screws

Scope of delivery of upholstered easy chair and sofa with panels 6 . 7
SCOPE OF DELIVERY OF UPHOLSTERED SOFA
WITHPANELSCE2300
Included in scope of delivery:
21 x 5x30 Spax screws
1 x left-hand panel
1 x sofa
2 x M5x35 screws
7 x brackets
1 x right-hand panel1 x interim panel
7 x M5x16 screws

ASSEMBLY INSTRUCTIONS FOR UPHOLSTERED EASY CHAIR
AND SOFA WITHPANELS
ASSEMBLY STEP 1
Hook the right-hand panel into the pre-assembled xture on the back right of the upholstered easy chair, taking care not to
press down.
ASSEMBLY STEP 2
Then, hook the left-hand panel into the corresponding xture on the back left of the upholstered easy chair, again taking
care not to press down.

Assembly instructions for upholstered easy chair and sofa with panels 8 . 9
ASSEMBLY INSTRUCTIONS FOR UPHOLSTERED EASY CHAIR
AND SOFA WITHPANELS
ASSEMBLY STEP 3
Gently push the top edges of the two panels apart and position the M5x35 screw in the corresponding thread in the left-
hand panel. Tighten the screw until it is approx. 10 mm away from the panel.
ASSEMBLY STEP 4
Now lift the right-hand panel up slightly and hook the screw from the left-hand panel into the recess in the right-hand panel
to attach them to one another.

ASSEMBLY INSTRUCTIONS FOR UPHOLSTERED EASY CHAIR
AND SOFA WITHPANELS
ASSEMBLY STEP 5
Now push the two panels down so they are anchored in the xtures on the upholstered easy chair.
ASSEMBLY STEP 6
Carefully tip the upholstered easy chair back together with the panels and place the furniture on a soft and clean surface,
such as a blanket. Position the four brackets at the recommended points between the lower edge of the upholstery and the
panel. Fix in position on the panel using an M5x16 screw.

Assembly instructions for upholstered easy chair and sofa with panels 10 . 11
ASSEMBLY STEP 7
Push the panel to the side of the upholstered easy chair and align the bracket with the chair. Fasten the four brackets to the
base of the upholstered easy chair using three 5x30 Spax screws for each.
Make sure the rst panel is fastened before moving on to the second panel.
ASSEMBLY INSTRUCTIONS FOR UPHOLSTERED EASY CHAIR
AND SOFA WITHPANELS

View from below
SCOPE OF DELIVERY OF DESK WITH PANELS CE1070
Included in scope of delivery:
2 x M6x16 screws
1 x table top
1 x front left foot
1 x cross-brace
16 x M6x18 screws4 x M6x25 screws
1 x left-hand panel
1 x back centre foot
2 x M8x20 screws4 x 4.5x13 Spax screws
1 x right-hand panel
1 x front right foot
1 x connecting hook 2 x M5x16 screws
2 x panel attach-
ments 4 x M6x45 screws

View from below
Assembly instructions for work table and standing table with panels 12 . 13
SCOPE OF DELIVERY OF DESK WITH PANELS CE1080
Included in scope of delivery:
1 x table top
1 x front left foot
1 x cross-brace
1 x left-hand panel
1 x back centre foot
1 x right-hand panel
1 x front right foot
2 x M6x16 screws 16 x M6x18 screws4 x M6x25 screws 2 x M8x20 screws4 x 4.5x13 Spax screws
1 x connecting hook 2 x M5x16 screws
2 x panel attach-
ments 4 x M6x45 screws

View from below
SCOPE OF DELIVERY OF DESK WITH PANELS CE4010
Included in scope of delivery:
1 x left-hand panel
1 x table top
1 x front left foot 1 x back left foot 1 x back right foot
1 x cross-brace
1 x centre panel 1 x right-hand panel
1 x front right foot
2 x M6x16 screws 22 x M6x18 screws6 x M6x25 screws 2 x M8x20 screws4 x 4.5x13 Spax screws
2 x connecting hooks 4 x M5x16 screws
2 x panel attach-
ments 4 x M6x45 screws

View from below
Assembly instructions for work table and standing table with panels 14 . 15
SCOPE OF DELIVERY OF DESK WITH PANELS CE4030
Included in scope of delivery:
1 x left-hand panel
1 x left-hand S panel
3 x table tops
3 x front left feet 3 x back left feet 3 x back right feet
3 x cross-braces
2 x centre panels 1 x centre panel
1 x right-hand S panel 1 x right-hand panel
3 x front right feet
6 x M6x16 screws 66 x M6x18 screws18 x M6x25 screws 6 x M8x20 screws12 x 4.5x13 Spax screws
6 x connecting hooks 12 x M5x16 screws
4 x panel attach-
ments 8 x M6x45 screws

View from below View from below
SCOPE OF DELIVERY OF DESK WITH PANELS CE3100
Included in scope of delivery:
1 x left-hand panel
1 x table top 1 x table top
1 x front left foot1 x front right foot 2 x back left feet 2 x back right feet
1 x cross-brace
2 x centre panels 1 x end panel1 x interim panel
1 x front right foot
3 x M6x16 screws 44 x M6x18 screws12 x M6x25 screws 2 x M8x20 screws4 x 4.5x13 Spax screws
4 x connecting hooks 8 x M5x16 screws
3 x panel attach-
ments 6 x M6x45 screws

View from below
View from below
Assembly instructions for work table and standing table with panels 16 . 17
1 x end panel
SCOPE OF DELIVERY OF DESK WITH PANELS CE3200
Included in scope of delivery:
1 x right-hand panel
1 x table top 1 x table top
1 x front left foot1 x front left foot 2 x back left feet 2 x back right feet
1 x cross-brace
2 x centre panels 1 x end panel1 x interim panel
1 x front right foot
3 x M6x16 screws 44 x M6x18 screws12 x M6x25 screws 2 x M8x20 screws4 x 4.5x13 Spax screws
4 x connecting hooks 8 x M5x16 screws
3 x panel attach-
ments 6 x M6x45 screws

BASE AND PANEL PREASSEMBLY
Ax the panel attachment to the pre-drilled place on the panel. Secure with screws (M6x45).
Ax the connecting hook to the pre-drilled place on the base. Secure with screws (M5x16).

Assembly instructions for desk with panel 18 . 19
ASSEMBLY INSTRUCTIONS FOR DESK WITH PANELS
The following steps also apply to models CE1070, CE1080, CE4010, CE4030, CE3100 and CE3200
ASSEMBLY STEP 1
Insert the legs into the recesses provided on the table and tablet and secure them using the SeKo M6x18 screws provided.

ASSEMBLY INSTRUCTIONS FOR DESK WITH PANELS
ASSEMBLY STEP 2
To connect the table to the tablet, stand the table up and place the tablet on the protruding base. Then tighten all the
screws.
