Brunton OmniSlope User manual

OmniSlope
7088 Winchester Cir
Boulder, CO 80301
www.brunton.com

Nous vous remercions de l'achat de votre inclinomètre Brunton OmniSlope. Intégrant
plus de 100 ans d'expérience de l'instrument, l'inclinomètre est construit pour les
professionnels les plus exigeants. S'il vous plaît comprendre l'utilisation de ce produit
avant de s'en servir dans le domaine.
Regardez à travers la lentille et le point à votre cible. Look in the insturment with both
eyes. Parce illusion d'optique, le guide peut être consulté sur l'objet. Voir la Figure 1.
Concentrer l'objectif en tournant l'oculaire. Choisissez votre niveau désiré sur la base
de la représentation de la figure 1.
• Éloignez-vous de l'objet à une distance facile à calculer.
• Maintenez l'inclinomètre verticalement près d'un oeil.
• Vue sur le haut de l'objet avec les deux yeux.
• Lire l'angle de la ligne d'index.
• Voir la figure 2 pour un exemple de la façon de mesurer un arbre

Thank you for purchasing your Brunton OmniSlope
compass. Incorporating more than 100 years of excellence
in instruments, this inclinometer is built for demanding
outdoor professionals who cannot cut corners on accuracy
and precision. Please fully understand the use of this product
before relying on it in the field.
Gracias por la compra de su inclinómetro Brunton OmniSlope. La incorporación de
más de 100 años de experiencia del instrumento, este inclinómetro se construye para
los profesionales más exigentes. Por favor, comprenda el uso de este producto antes
de confiar en ella en el campo.
Mira a través de la lente y apuntar a su objetivo. Mire a través del insturment con
ambos ojos. Debido a la ilusión óptica, la guía se puede ver en el objeto. Véase la
figura 1. Enfoque la lente girando el ocular. Elija su escala deseada basada en la
ilustración de la figura 1.
• Párese lejos del objeto a una distancia calculada fácilmente.
• Sostenga el inclinómetro verticalmente cerca de un ojo.
• Mira a la parte superior del objeto con ambos ojos.
• Lea el ángulo en la línea de índice.
  

OWNER’S PURCHASE RECORD
Model
Date of Purchase
Dealer Purchased From
WARRANTY
Please register your OmniSlope by visiting www.brunton.com/
register. Brunton has taken every eort to ensure years of
trouble-free use from your new product. This product is
guaranteed to be free of defect in material and workmanship for
12 months according to local regulatory requirements. This
product is not subject to guarantee from third-parties and is
subject to change. Brunton will repair or replace with a new
equivalent, without charge for parts or labor, per Brunton’s
discretion. Brunton cannot be held responsible for accidents,
damages or injury occasioned by the use of this product. Warranty
will be rendered invalid if product is damaged by tampering,
negligence, or misuse.
To obtain service, please contact BRUNTON for a return
authorization (RA) number. Please be prepared to provide contact
name, address and phone number, and a description of the
problem.
BRUNTON
7088 Winchester Cir. Boulder CO 80301
307.857.4700
[email protected]

OmniSlope
User Manual
2
3
4
5
6
INSTRUCTIONS FOR USE
1OUR STORY
MEASURING HEIGHT
DIRECT READING OF ANGLE
SPECIFICATIONS
WARRANTY
SPECIFICATIONS
- Anodized aluminum housing with rubber bump cover and
leather case.
- Aluminum card with 180° precision scales, forestry chain scales,
and % grade scale
- 10x magnification adjustable lens.
- 1/2° accuracy

BRUNTON
MADE IN USA
%
%
%
DEGREE / % GRADE / 66'
%
%
Degrees Forestry
Chain
Percent Grade
Front Dial Face
INDESTRUCTABLE SINCE 1894
At Brunton, we come to work with a clear vision: remove any
obstacles that stand between our customers and their passion to
stay outdoors. It’s been this way since 1894, when D.W. Brunton
created the now legendary Pocket Transit a compact, precision
compass that continues to give outdoorsman the confidence to
push beyond the beaten path. Today, this spirit of indestructible
innovation lives in the form of professional-grade solutions as
tough and diverse as the rugged Rocky Mountains that we’ve
called our laboratory for over 125 years. Our goal is to build
products as tough as the people who get to use them and to allow
these users to push themselves and our products to extend
their adventure.

CAUTION
Some users who suer from an eye condition called heterophoria (misalignment
of the eye axis) may get incorrect bearing when reading the compass with both
eyes. This can be checked as follows: take a bearing to an object with both eyes
open. Then close the eye not sighting through the compass. If the bearing does
not shift or change dramatically, there is no heterophoria and bearings can be taken
with both eyes open.
INSTRUCTIONS FOR USE
View through the optical lens and aim at your target object. With
both eyes open, the hairline can be seen to ‘stand up’ from the
clinometers housing making it easy to accurately read the correct
angle toward the object due to optical illusion. (see figure 1). You
can focus the lens on your desired scale by turning the eyepiece.
Choose between dierent scales based on the labels in figure 1.
60 30
40
35
Percent Grade
Degrees
Forestry
Chain
FIGURE 1
FIGURE 3

MEASURING HEIGHT
1. Distance yourself from the object to be measured at a
easily calculated space like 10 meters.
2. Hold OmniSlope vertically close to one of your eyes.
Because of the optical illusion, the index line will appear
to stand from the housing over the object.
3. Sight with both eyes to the top of the object. You can
focus the lens on dierent scales by turning the eyepiece
4. Read the angle/height at the index line
5. Remember to add the angle/height below the horizontal
line to the first reading in order to obtain correct height
of the object. For example 15% (see figure 2).
6. In the example shown in figure 2, the correct height of
the object would be 70%+15%=85% x 10 meters = 8.5
meters tall.
7. If you are standing below the object being measured,
please refer to the right example in figure 2.
8. Please note that when using the 66 foot forestry chain
scale, you can read out the correct height directly from
the scale without calculations.
FIGURE 2
DIRECT READING OF ANGLE
The top scale of side window with lubber line can be used by
placing the instruments long side along the inclined plane to be
measured. Read the slope angle direct from the lubber line. Use
this method when sighting measurements are impossible
because of lack of space, although sighting measurements are
always most accurate. (fig 3)
