Bticino 374005 User manual

374005
04/21-01 PC
LE12752AA
BTicino SpA – Viale Borri, 231 – 21100 Varese – Italy – www.bticino.com
Dimensional data
Installation
The RJ45 cable must be at least 200 mm long
* Recommended height, unless different regulations are specified.
50 cm
80 °
53 °
50 cm
160 – 165 cm
90 – 130 cm
*
245 mm
92 mm
64 mm
10 mm
82 mm
232
mm
62 mm
3
2
1

2
3
1
2
2 mm60 mm
1
2

3
Uninstall
Adjust the tamper screw so that it presses the tamper switch of
the device and activates the anti-theft function in case of removal
sending an alarm to the guard station.
*
6
1
2
*
3
4
1
2
4 5
3

4
Front and rear view
Read carefully before use and keep for future reference
Touching the units with wet hands is forbidden
Using liquid cleaners or aerosols is forbidden
Blocking the ventilation openings is forbidden
Modifying the devices is forbidden
Removing protective parts from the devices is forbidden
Installing the units near liquids and powders is forbidden
Installing the units near heat sources is forbidden
Installing the units near harmful gases, metal dusts or similar is forbidden
Fastening the units on unsuitable surfaces is forbidden
Danger of electrical shock
Risk of devices falling because the surface on which they are installed collapses or inappropriate installation
Switch the power supply OFF before any work on the system
Caution: Installation, conguration, starting-up and maintenance must be performed exclusively by
qualied personnel.
Check that the wall installation has been carried out correctly
Lay out the wires respecting the standards in force
Connect the power supply wires as indicated
Use only the items indicated in the technical specications for any system expansions
Warnings and consumer rights
Hereby, BTicino S.p.A., declares that the radio equipment type Small entrance panel 4.3" 374005 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.bticino.it/red
Remote operation may cause damage to people or property.
Configuration
The device must be congured by software. For software download, installation device documentation and for any
other information, refer to the website.
www.homesystems-legrandgroup.com
Technical data
Voltage 24 Vdc
Maximum consumption 0.65 A
C NC NO contact output 125 Vac/0.5A, 30Vdc/2A
Max. cable section for clamps 0.8 mm²
Operating temperature (- 40) – (+ 70) °C
IP degree of protection 54
IK degree of protection 07
Camera resolution 1080 p
Camera viewing eld angle H= 80°; V= 53°
Face recognition distance during daytime 30-80 cm
Face recognition distance at night 30-50 cm
Badge reader frequency 13.56 MHz
Badge reader transmission power < 42 dBuA/m @ 10m
1. LED for the shooting eld lighting
2. Microphone
3. Light sensor
4. Camera
5. Display 4.3" (touch screen)
6. Badge reader for door lock opening
7. Loudspeaker
8. Locking screw
9. USB Connector (not used)
10. Reset to the factory settings push button
11. Not used
12. Connection clamp
13. Not used
14. RJ45 Connector (*)
15. Tamper switch
16. Mounting bracket
(*)
This device does not support standard POE power supplies,
but only POE power supplies identied with item no. 375002.
Connect the cat5/5e/6 FTP or cat5/5e/6 UTP cable with ferrite
supplied to the connector.
8
1
2
1
3
4
5
6
7
ISP
12
14
12
11
10
9
15
13
16
LOCK+ electric door lock connection and control
(12V - 4A impulsive on 3 Ohm maximum)
LOCK-
SENSE door lock status signal input (dry contact)
GND – +12V access control devices power supply
OPEN third party access control signal input for door lock opening (+12Vdc pulse)
GND system common ground terminal for third party connection
Door OPEN – GND local door lock release pushbutton connection
FIRE Linkage – GND local door lock release pushbutton connection for realarm system
NO
interlocked contactC
NC
DC24V additional power supply clamps (not polarized)
Connection clamp
GND
Fire Linkage
Door Open
ISP
