BTL-1300
USER’S MANUAL

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 2 of 9
CONTENTS
1USER‘S MANUAL...............................................................................................................................................3
1.1 CONFIGURATION OF THE BTL-1300 Couch ...............................................................................................3
1.2 OUTWARD APPEARANCE of the BTL-1300 ................................................................................................5
1.3 CONTROL UNITS..........................................................................................................................................5
1.4 CONNECTION TO THE MAINS.....................................................................................................................6
1.5 SAFE USE INSTRUCTIONS .........................................................................................................................6
1.6 WARNING......................................................................................................................................................6
1.7 CLEANING AND MAINTENANCE .................................................................................................................6
2TECHNICAL SPECIFICATIONS .........................................................................................................................6
2.1 Aplicable standards........................................................................................................................................7
2.2 classification...................................................................................................................................................7
2.3 Identification of the equipment .......................................................................................................................7
2.4 Operating conditions ......................................................................................................................................7
2.5 Transport and storage conditions..................................................................................................................7
2.6 Power supply .................................................................................................................................................7
2.7 Voltage insulation...........................................................................................................................................8
3DERIVED ALTERNATIVES ................................................................................................................................8

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 3 of 9
1 USER‘S MANUAL
1.1 CONFIGURATION OF THE BTL-1300 COUCH
The couches are manufactured in fifth basic configurations: one section for the exercise therapy according to Bobath
and Vojta, two sections with one motor, three sections with one or two motors, five-sections with one or two motors
and three section traction couch.
The mid-section of the three and five-section couch can be adjusted electrically or mechanically.
•Bobath couch is designed for the exercise therapy according to Bobath and Vojta. It offers enough space for
both the therapist and patient.
•2-section couch. It enables easy manipulation of the patient and facilitates the therapist’s work. The extended
model of two-section couch with adjustable backrest (0°/+20°) is suitable for traction treatment.
•3-section couch has a mechanically or electrically adjustable mid-section. The flex positioning is optimal for
low back treatment . The extended model with negative adjustment is suitable for Trendelenburg position and
hand traction.

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 4 of 9
•5-section couch is an extended configuration of the three-section couch. The adjustable arm rests ensure the
patient’s relaxation in abdominal position.
•3-section couch specially designed for lumbar and cervical traction. It can also be used for other
examination and therapy applications. The movable part of the couch makes the therapy friction-free, giving
the patients maximum muscular relaxation, eliminating their unpleasant feelings, and facilitating the therapy
itself. Couch is a 3-section with electrically adjustable height and pneumatically adjustable head section. For
technical parameters of the BTL-16 Traction unit, please refer to BTL-16 Traction unit user manual.

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 5 of 9
1.2 OUTWARD APPEARANCE OF THE BTL-1300
Therapy table BTL-1300 consists of three interconnected functional units and control units. The first one are electric
motors with hand or foot adjustment switches, the second one is metal frame that enables transmission of valve
motion onto the upper table and the third is the table area itself which consists of particle board and upholstery.
1.3 CONTROL UNITS
1. hand switch (4) - with the help of indicated arrows adjust the height of the table as well as of the middle part
above the frame
2. foot switch - pressing the pedals on one side closer to the pad to adjust the height of the table
3. pressing the pedal (5) lifts the table off the wheels
4. once the safety wheels (1) are released set the arm rests into desired position and then secure the knobs
5. to adjust the head rest upwards: press the lever (2) towards the head rest and release it when desired angle is
reached. To adjust the head rest downwards: press the level towards the head rest and push the head rest in
downward position. Release the level when the desired angle is reached.
6. adjusting the foot part is identical to that of the head rest. Use the lever (3).
Note: Number and types of controls may vary and are dependent on the type of table ordered.

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 6 of 9
1.4 CONNECTION TO THE MAINS
1. Connect the higher motor (M2) that secures lifting of the middle part and the lower motor (M1) that operates the
whole table.
2. Connect the control panel to (M1).
3. Connect the mains cable from (M1) to a 230V plug.
4. Using the control panel check the table adjustment.
1.5 SAFE USE INSTRUCTIONS
•When adjusting the head or foot rests downwards, it is necessary to hold these parts before releasing the safety
levers
•When manipulating the table on the wheels, move it only on an even surface! Otherwise it is necessary to lift the
table.
•The table cannot be adjusted to any height when loaded with more than 170 kg. Do not overload the table.
1.6 WARNING
•When lifting up the table, the upper desk also moves horizontally.
•When you wish to have the table at a place with uneven floor, eliminate the unevenness with a height adjustable
screws in the frame of the table.
•Pedals that lift the table onto the wheels are placed on both sides of the table at the foot end.
1.7 CLEANING AND MAINTENANCE
Wash the upholstery with a detergent. Disinfect using for example a 10% Persteril solution. Do not use acetone-based
substances.
Revolving bearings of the metal frame are equipped with plastic and brass cases. We recommend to grease the brass
cases.
2 TECHNICAL SPECIFICATIONS
BTL-1300
2-section
BTL-1300
3-section
BTL-1300
5-section
BTL-1300
Bobath couch
BTL-1300
Trac
Length (cm) 195 195 195 195 210
Standard width (cm) 70 70 70 90 70
Reduced width: 60cm o o o - -
Extended width: 80cm o o o - -
Conical narrowing of the foot section o o o - -
Height adjustment: 42-95cm x x x x x
Mid-section elevation: 0-22cm - x x - -
Horizontally movable foot section: 15 cm - - - - x
Head section adjustment: +45°/-30° x x x - x
Foot section adjustment: 0°/+30° - o* o* - -
Mid-section adjustment together with
Foot section adjustment: 0°/+20° - o* o* - -
Backrest adjustment: 0°/+40° - - - o -
Weight: 90-110kg (according to model) x x x x x
Load capacity: 170kg x x x x x
Mains supply: 230V/50Hz x x x x x
x – standard, o – optional, * available only in configurations with electrical adjustment of the mid-section

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 7 of 9
2.1 APLICABLE STANDARDS
No. Name EN, ISO
1 Medical electrical equipment
Part 1: General requirements for safety
EN 60601-1
2 Amendments to EN 60601-1 A2
3 Medical electrical equipment
Part 1: General requirements for safety
2.Collateral Standard: Electromagnetic compatibility. Requirements and tests.
EN 60601-1-2
4 Medical devices – Risk Analysis EN 1441
5 Biological evaluation of medical devices – Part 1: Evaluation and testing EN ISO 10993-1
6 Medical electrical equipment
Part 2: Special requirements for safety electrical couches for hospital use
EN 60601-2-38
2.2 CLASSIFICATION
Class according to NV 180 (93/42/EEC): I
Type applied part B
Class according EN 60601-1 II
2.3 IDENTIFICATION OF THE EQUIPMENT
1. Type of the product BTL-1300
2. Name of the product therapy couch
3. Region of use medical device
2.4 OPERATING CONDITIONS
1. ambient temperature -10°C to +55°C
2. relative humidity 30% to 75%
3. atmospheric pressure 700 to 1060hPa
4. position vertical – on legs
5. type of operation continuous
2.5 TRANSPORT AND STORAGE CONDITIONS
1. ambient temperature -10°C to +55°C
2. relative humidity 25% to 85%
3. atmospheric pressure 650 to 1100hPa
4. position vertical – on legs
5. time max. 1 year
2.6 POWER SUPPLY
1. Voltage AC 230 V
2. Frequency 50 Hz

BTL-1300 USER MANUAL Medical Technologies s.r.o.
page 8 of 9
2.7 VOLTAGE INSULATION
1. Mains-patient 4 kV
3 DERIVED ALTERNATIVES
1. in 5 sections (head part with arm rests, foot part and middle section), without the possibility to adjust the foot part,
with mechanic middle part adjustment.
2. in 3 sections (head rest without arm rests, foot part and a middle part), without foot part adjustment, with mechanic
middle part adjustment.
3. in 4 sections (head part with arm rests, one piece foot and middle section), without foot and middle part
adjustment.
4. in 2 sections (head part without arm rests, one piece foot and middle section), without foot part adjustment.
